Nikon One-Touch Zoom 90s One-Touch Zoom 90s AF Quartz... User manual

E
Instruction Manual (Pages 2-39)
Bedienungsanleitung (Seiten 40-77)
Manuel d’ulilisation (Pages 78-115)
Manual de instrucciones (Páginas 116-153)
G
F
S

2Getting Started
For your safety Caring for the Camera and Battery
To prevent damage to your Nikon product or injury to
yourself or to others, read the following safety precautions
in their entirety before using this equipment. Keep these
safety instructions where all those who use the product
will read them.
The consequences that could result from failure to
observe the precautions listed in this section are
indicated by the following symbols:
WARNINGS
Do not look at the sun through the viewfinder
Viewing the sun or other strong light source through the
viewfinder could cause permanent visual impairment.
Turn off immediately in the event of malfunction
Should you notice smoke or an unusual smell coming
from the equipment, remove the battery immediately,
taking care to avoid burns. Continued operation could
result in injury. After removing the battery, take the
equipment to a Nikon-authorized service center for
inspection.
Do not use in the presence of flammable gas
Do not use electronic equipment in the presence of
flammable gas, as this could result in explosion or fire.
Do not place strap around neck
Placing the camera strap around your neck could result
in strangulation. Special care should be taken to avoid
placing the strap around the neck of an infant or child.
Do not disassemble
Touching the product’s internal parts could result in
injury. In the event of a malfunction, the product should
be repaired only by a qualified technician. Should the
product break open as the result of a fall or other
accident, remove the battery and then take the product
to a Nikon-authorized service center for inspection.
This icon marks warnings, information that should be
read before using your Nikon product to prevent
possible injury.

Getting Started 3
E
Observe proper precautions when handling
batteries
Batteries may leak or explode if improperly handled.
Observe the following precautions when handling
batteries for use in this product:
•Be sure the product is off before replacing the
battery.
•Use only a 3 V CR2 lithium battery.
•When inserting the battery, do not attempt to insert
it upside down or backwards.
•Do not short or disassemble the battery.
• Do not expose the battery to flame or to excessive
heat.
•Do not immerse in or expose to water.
•Do not transport or store with metal objects such as
necklaces or hairpins.
•Immediately after use, or when the product is used
on battery power for an extended period, the battery
may become hot. Before removing the battery, turn
the camera off and allow the battery to cool.
•Discontinue use immediately should you notice any
changes in the battery, such as discoloration or
deformation.
Keep out of reach of children
Particular care should be taken to prevent infants
from putting the battery or other small parts into their
mouths.
Observe caution when operating the flash
Using the flash close to your subject’s eyes could
cause temporary visual impairment. Particular care
should be observed if photographing infants, when the
flash should be no less than one meter (39”) from the
subject.

4Getting Started
Caring for the Camera and Battery
Keep dry
This product is not waterproof, and may malfunction if
immersed in water or exposed to high levels of humidity.
Rusting of the internal mechanism can cause irreparable
damage.
Keep free of salt, sand, and dust
After using your camera at the beach or seaside, wipe
off any sand or salt with a lightly dampened cloth and
then dry your camera thoroughly.
Do not touch the lens with your fingers
Use a blower brush to remove dirt and dust from the
lens. To remove fingerprints or smudges from the
lens’ surface, use a soft, clean cotton cloth or lens
tissue moistened with ethanol (alcohol) or lens
cleaner.
Handle the lens cover and all moving parts with care
Do not apply force to the lens or to the battery or lens
covers. These parts are especially susceptible to
damage.
Do not drop
The product may malfunction if subjected to strong
shocks or vibration.
Keep away from strong magnetic fields
Do not use or store this device in the vicinity of
equipment that generates strong electromagnetic
radiation or magnetic fields. Strong static charges or
the magnetic fields produced by equipment such as
radio transmitters could affect the product’s internal
circuitry.
Avoid sudden changes in temperature
Sudden changes in temperature, such as occur when
entering or leaving a heated building on a cold day,
can cause condensation inside the device. To prevent
condensation, place the device in a carrying case or a
plastic bag before exposing it to sudden changes in
temperature.

Getting Started 5
E
Batteries
•When you turn the device on, check the battery-level
displayed in the LCD panel to determine whether the
battery needs to be replaced. The battery needs to
be replaced the low battery power indicator appears
in the LCD panel.
•Ready a spare battery when taking pictures on
important occasions. Depending on your location,
you may find it difficult to purchase replacement
batteries on short notice.
• On cold days, the capacity of batteries tends to
decrease. Use a fresh battery at low temperatures.
Keep a spare battery in a warm place and exchange
the two as necessary. Once warmed, a cold battery
may recover some of its charge.
•Should the battery terminals become dirty, wipe them
off with a clean, dry cloth before use.
Storage
•To prevent mold or mildew, store the camera in a dry,
well-ventilated area. If you will not be using the
product for a long period of time, remove the battery
to prevent leakage and store the camera in a plastic
bag containing a desiccant. Do not, however, store
the camera case in a plastic bag, as this may cause
the material to deteriorate. Note that desiccant
gradually loses its capacity to absorb moisture and
should be replaced at regular intervals.
•Do not store the camera with naphtha or camphor
moth balls, close to equipment that produces strong
magnetic fields, or in areas subject to extremes of
temperature, for example near a space heater or in a
closed vehicle on a hot day.
•To prevent mold or mildew, take the camera out of
storage at least once a month. Turn the camera on
and release the shutter a few times before putting
the camera away again.
•Store the battery in a cool, dry place.

6Getting Started
Thank you for purchasing the Nikon One Touch Zoom
90s/One Touch Zoom 90s QUARTZ DATE (QD) camera.
Be sure to read this manual thoroughly before use, and
keep it handy until you feel confident using the camera.
Some of the illustrations show the model with the date
function (One Touch Zoom 90s QD).
Your Nikon camera features:
•35mm compact camera with built-in 2.4X zoom lens
from 38 to 90mm focal length range. ( p. 17)
• Close-up photography in Macro mode for subjects as near
as at approx. 0.3 to 0.7m (1.0 to 2.3 ft.). ( p. 31)
Symbols used in this manual
: Indicates items to be checked, such as requirements
and restrictions.
:Indicates notes and cautions you are requested
to follow.
:Indicates supplementary descriptions.
:Indicates pages for reference.
Accessories
The following strap is supplied with this camera.
Attaching the strap
Attach the strap as shown
in the illustration.
Optional accessory
•Camera case CS-L26
Strap

Getting Started 7
E
Table of Contents
For your safety _________________________________________ 2
Caring for the Camera and Battery __________________________ 4
Camera parts ________________________________________ 8-10
Body ______________________________________________ 8
LCD panel _________________________________________ 10
Indications in the viewfinder ___________________________ 10
1Preparations
Installing a battery ______________________________________ 11
Turning the camera on ___________________________________ 12
Checking the battery power _______________________________ 12
Loading the film _______________________________________ 13
2Basic Operations
Holding the camera properly ______________________________ 15
Operating the Shutter Release button _______________________ 16
Zooming _____________________________________________ 17
Shooting _____________________________________________ 18
Rewinding the film _____________________________________ 19
Removing the film ______________________________________ 19
3Advanced Operations
When the main subject is not in the center of the picture ________ 20
Difficult-to-focus subjects ________________________________ 21
Flash photography ______________________________________ 22
Procedure for Flash Photography __________________________ 23
To automatically fire the flash _____________________________ 24
To cancel flash operation _________________________________ 25
To fire the flash intentionally ______________________________ 26
To photograph a person in a night view ______________________ 27
To reduce “Red-eye” effect _______________________________ 28
Shooting a distant view or landscape through a window _________ 30
Using the self-timer _____________________________________ 30
Close-up photography ___________________________________ 31
Printing the date/time on pictures
(One Touch Zoom 90s QD only) ________________________ 32
4Additional Information
Correcting the date and time
(One Touch Zoom 90s QD only) ________________________ 33
Replacing the battery for date
(One Touch Zoom 90s QD only) ________________________ 34
Troubleshooting _______________________________________ 36
Specifications _________________________________________ 38

8Getting Started
Strap slot ( p. 6)
Camera parts (Body)
Autofocus window
Auto Exposure
metering window
Flash
(pp. 22-27)
LCD panel ( p. 10)
Mid-roll Rewind button
(p. 19)
Red-eye Reduction lamp/
Self-Timer lamp
Lens
Autofocus window
Zoom buttons
(p. 17)
button
Red-eye Reduction
(pp. 28, 29)
Self-Timer ( p. 30)
Viewfinder
window
(p. 10)
Power button
(p. 12)
Macro button
(orange lamp)
(p. 31)
button
Flash mode ( pp. 22-27)
Infinity Focus mode ( p. 30)
Shutter Release button
(p. 16)
Camera back lock
release lever
(p. 13)

Getting Started 9
E
Green LED
(p. 10)
Film cartridge confirmation
window ( p. 34)
Tripod socket
SET button*
(p. 33)
SELECT button*
(p. 33)
MODE button*
(pp. 32, 33)
*One Touch Zoom 90s QD only
Date panel*
(pp. 32, 33)
Battery chamber lid
(p. 11)
Viewfinder
eyepiece

10 Getting Started
Indications in the viewfinder
1Parallax compensation marks (p. 31)
For photography in Macro mode at a distance of
approx. 0.3m (1.0 ft.), and when shooting a subject at
a distance of less than 0.7m (2.3 ft.) with the Zoom in
the Telephoto setting.
2Autofocus spot marks (p. 18)
Center the main subject to be in focus within this spot.
3Green LED
Lights when focus is achieved or when the flash is
ready to fire. It blinks while the flash is being charged.
If the subject is closer than approx. 0.7m (2.3 ft.), the green
LED does not light even when you press the Shutter Release
button halfway, and the shutter cannot be released. Note that
you may take a picture even if the camera-to-subject
distance is extremely short and out of the control range of
the camera. However, the focus may not be sharp.
LCD panel
Red-eye Reduction indicator
(pp. 28, 29)
Flash Mode indicator
(pp. 22-27)
Infinity Focus Mode indicator
(p. 30)
Low battery power
indicator
(p. 12)
Frame counter ( p. 14)
Self-Timer indicator
(pp. 28, 30)
32
1
The illustrations are fully labeled for your reference.

Getting Started 11
E
Installing a battery
Battery type
Use one CR2 type 3 V lithium battery in this camera.
1.
Open the battery chamber lid using a
coin or equivalent.
2.
Install a new battery.
Observe the correct polarities and insert the battery in the
direction shown in the illustration above.
3.
Close the battery chamber lid.
Firmly press the battery chamber lid until it clicks shut.
Preparations

12 Preparations
Turning the camera on
Press the Power button.
Once you press the Power button, the camera is turned on,
and the lens protrudes. When you press the Power button
again, the camera is turned off and the lens retracts.
Auto Power-Off function
The camera is automatically turned off if it is not operated for
more than 3 minutes. When the camera is turned off, the lens
cover closes, and all shooting modes are reset (except for
Red-eye Reduction mode).
Checking the battery power
Make sure that the Low Battery Power
indicator ( ) is not appeared on the LCD
panel.
If “ ” is not appeared, battery power is sufficient.
If “ ” is blinking, or no indicators on the LCD panel appear, the
battery is exhausted. Replace it with a new one.
Always check the battery condition before shooting.
It is recommended to carry spare batteries with you.
The batteries may be difficult to obtain in some areas.

13Preparations
E
Use DX-coded 35mm film with this camera.
For DX-coded film, film speed is automatically set. Film
speeds valid for automatic setting are ISO 100, 200, 400 and
800. (With other films, the film speed is automatically set to
ISO 100.)
When loading/unloading film, be sure not to open the camera
back cover in direct sunlight.
Recommended film
It is recommended to use ISO 400 film, which provides good
results in flash photography, and reasonable protection
against camera shake.
1.
Open the camera back.
Slide the camera back lock release lever in the direction of the
arrow (1) to open the camera back (2).
2.
Insert a film cartridge.
Loading the film
Tips on DX-coded 35mm film
DX code
Film cartridge
DX mark
DX-coded 35mm
film
Number of frames
Film speed

14 Preparations
3.
Pull the film leader out to the red index
mark.
Hold the film cartridge and ensure film is properly
positioned with no slack.
4.
Close the camera back, and check that
the film has been correctly loaded.
Once the camera back is closed, the film automatically
advances to the first frame. Until film loading is complete,
“” blinks on the LCD panel.
When the film has been properly set, “ ” is displayed on the
LCD panel.
If the letter “ ” blinks on the LCD panel, film is not properly
loaded. Open the camera back again and reload film.
Loading the film (continued)

15Preparations
E
Holding the camera properly
Hold the camera firmly.
<When holding the camera horizontally>
Prop your elbows against your body and hold the camera with
both hands.
<When holding the camera vertically>
When holding the camera vertically, make sure that the flash
is on top as shown.
Do not block the lens, autofocus window, or flash with your
fingers or hair, or the strap.
Take some trial shots
Before taking important pictures, it is strongly
recommended to take a few trial shots first to familiarize
yourself with the camera and all its features.
Nikon cannot be held responsible for malfunctions
caused by using the One Touch Zoom 90s / One Touch
Zoom 90s QD in ways not specified in this manual.
N
i
k
o
n
Z
o
o
m
L
e
n
s
3
8
-
9
0
m
m
M
a
c
r
o
N
i
k
o
n
Z
o
o
m
L
e
n
s
3
8
-
9
0
m
m
M
a
c
r
o
Basic Operations

16 Basic Operations
Operating the Shutter Release button
1.
Lightly press the button halfway and
confirm the green LED lights up.
When you press the button lightly, the focus and exposure are
achieved, and the green LED lights up.
The focus is locked (Focus lock p. 20) while the Shutter
Release button is depressed lightly.
2.
Fully depress the Shutter Release button
to take the picture.
Pressing the Shutter Release button abruptly in one stroke
may result in camera shake. Be sure to slowly press the
Shutter Release button.
While the green LED is blinking with the Shutter Release
button pressed lightly, the flash is being charged, and the
shutter cannot be released. Lightly press the Shutter Release
button again, if the green LED is not blinking and remains lit
release the shutter.
If the subject is closer than approx. 0.7m (2.3 ft.) in the
telephoto setting, the green LED does not light even when you
press the Shutter Release button halfway, and the shutter
cannot be released. Move away from the subject until the
green LED lights up. Note that the Shutter Release button may
still work even if the camera-to-subject distance is extremely
short, i.e., out of the control range of the camera.

17
Basic Operations
E
Zooming
Press the Zoom button to compose the
picture.
Press the zoom button for telephoto (90mm) photography
or the zoom button for wide-angle (38mm) photography.
Remove your finger from the button when the desired image
size is obtained.
Example of a telephoto photograph
Example of a wide-angle photograph

18 Basic Operations
Shooting
1.
Center the autofocus spot mark on the
main subject.
If the main subject is outside the autofocus
spot:
If the main subject is outside the autofocus spot, use the
focus lock to achieve focus. ( p. 20)
2.
Lightly press the Shutter Release button
halfway.
3.
Slowly press the Shutter Release button
all the way.
If the subject is dark in Auto Flash mode, the flash fires
automatically.
Pressing the Shutter Release button abruptly in one stroke
may result in camera shake.

19
Basic Operations
E
Rewinding the film
Film rewinds automatically.
At the end of the film roll, the film rewinding starts automatically.
While the film is rewinding, the number on the frame counter
decreases one by one. When rewinding is complete, the letter “ ”
blinks for approx. 10 seconds, then stops blinking and remains lit.
If rewinding stops midway through the roll because of a dead
battery, it resumes automatically as soon as the battery is replaced
and the camera is turned on.
Do not open the camera back until the letter “ ” starts blinking.
To rewind the film in mid-roll
Press the mid-roll rewind ( ) button using
the point of a ballpoint pen or equivalent.
Once rewinding starts, there is no need to keep the button
pressed.
Removing the film
1.
Make sure rewind is complete by
checking the letter “ ” indication.
2.
Open the camera back and remove the film.

Advanced Operations20
When the main subject is not in the center of the picture
Focus lock photography
When the subject to be focused is outside the autofocus
spot in the center of the picture, use focus lock, which
enables you to change the picture composition while
locking the focus. Also use focus lock for difficult-to-
focus subjects described on the next page ( p. 21).
1.
Compose the picture.
If the shutter is released in a condition like that in the above
example where the main subject is out of focus.
2.
Center the autofocus spot mark on the
main subject, then lightly press the
Shutter Release button halfway.
Do not change the camera-to-subject distance
While you lightly press the Shutter Release button, the focus
is locked. Do not change the camera-to-subject distance.
3.
While depressing the Shutter Release button
lightly, recompose the picture and depress
the Shutter Release button all the way.
