Niles AT8 User manual

AT8
IN-WALL LOUDSPEAKER
• Tweeter can be rotated and pivoted
•Baffle-mounted bass and treble tone controls for
acoustical adjustments
8" 2-Way AT Advanced Technology
In-wall Loudspeaker
SPECIFICATIONS SHEET

IN-WALL LOUDSPEAKER
WOOFER TECHNOLOGY
■8" Interlaced glass and carbon-fiber cone is extremely rigid to reduce breakup and lower distortion
even under high power
■Butyl rubber cone surround damps resonance and provides
exceptional durability
■High BL magnet structure with vented pole piece insures powerful
bass response
■Dispersion stabilizer distributes midrange tones for clear off-axis sound
TWEETER TECHNOLOGY
■Proprietary tweeter-adjustment mechanism ratchets in 1mm increments and then pivots for precise
aiming of high frequencies
■1" Tri-laminate Teteron dome with fluid-cooling and ultra-wide dispersion for clear and detailed
high-frequencies
AUDIOPHILE FEATURES
■Premium crossover components provide seamless driver integration and smooth sound
■Anti-resonant wave-bracing ABS baffle eliminates unwanted resonance to keep bass tones rich
and dynamic
TONE CONTROLS
■Baffle mounted bass and treble controls allow easy access to adjust the sound in any room
INSTALLATION
■Patented snap-in speaker baffle mounting mechanism facilitates quick installations and upgrades
■100% rustproof MicroPerf™ aluminum grille conceals loudspeaker elements yet allows full
frequency sound through. Grille can be painted to match décor
■Infrared sensor knockout provides a hidden remote control solution
SPECIFICATIONS
■Impedance: 6 ohms
■Recommended amplifier power: 10W to 150W
■Frequency response: 40Hz-21kHz +/-3dB
■Sensitivity: 90dB for 2.83V pink noise
■Frame dimensions: 10-3/16" x 14-1/4"
■Hole cutout dimension: 9-1/8" x 13-1/8"
■Depth behind wall: 3-5/8" deep (assumes 1/2" drywall)
Warranty: Five-year limited
Shipping weight: 14 lbs.
AT8
Stock Number
FG00891
8" In-Wall Loudspeaker
NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: [phone] – www.nilesaudio.com NAAT8PDF
©2004 Niles Audio Corporation. All Rights Reserved. Niles and the Niles logo are registered trademarks of Niles Audio Corporation.

IN-WALL LOUDSPEAKER
Technology
PIVOTING RATCHETING TWEETER
Enable installers to precisely adjust the angle of the tweeter for optimum coverage
ADVANCED MATERIAL SCIENCE
Elevates performance of sub component parts like woofer cones, tweeter diaphragms and crossover components
SOPHISTICATED MOTOR AND MAGNETIC DESIGN
Including High BL magnets and vented pole pieces for deep bass response
ACOUSTIC FINE TUNING
Bass and treble controls optimize system sound for every acoustical environment
ANTI-RESONANT WAVE-BRACING TECHNOLOGY
Prevents transmission of woofer vibrations to the baffle and into the drywall for clear and dynamic bass response
Details
HOME THEATER SPECIFIC MODELS
Deliver voice-matched cinema performance and are compatible with all AT Advanced Technology models
SNAP-IN SPEAKER-BAFFLES
Greatly reduces installation time and cost
MODULAR MOUNTING SYSTEM
Uses innovative mounting technique to simplify installation and ensure uniform contact with wall
BLACK BAFFLES
Deliver a seamless appearance after the speakers are installed and the grilles are in place
MICROPERF™ RUSTPROOF ALUMINUM GRILLES
Are acoustically transparent yet won’t rust or discolor
DEBRIS SCREENS
Block unwanted debris such as fiberglass insulation, sheetrock chips, or other foreign matter from coming in contact with the woofer cone
OPTIONAL FIRE-RATED METAL ENCLOSURES
Optimize performance and ensure code compliance
OPTIONAL NEW CONSTRUCTION BRACKETS
Secure loudspeaker’s location and simplify installation
NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: [phone] – www.nilesaudio.com NAAT8PDF
©2004 Niles Audio Corporation. All Rights Reserved. Niles and the Niles logo are registered trademarks of Niles Audio Corporation.
