WALL MOUNT LOUDSPEAKER
WOOFER TECHNOLOGY
nPatent pending, Cone Forward™ design positions the woofer cone at the front of the baffle for
natural sounding bass and clear, open midrange
nDual 5-1/4" injection-molded TCC™ (talc, carbon, and ceramic-filled) polypropylene woofers offer
extreme rigidity to reduce breakup and lower distortion
TWEETER TECHNOLOGY
n1" Teteron dome tweeter is fluid cooled and delivers ultra-wide dispersion to reproduce clear and
detailed high frequencies
nBass-reflex design enhances low frequency response and dynamic impact
AUDIOPHILE FEATURES
nSymmetrical driver configuration offers effective dispersion control for precise imaging and
accommodates vertical or horizontal installations
nRigid extruded aluminum enclosure delivers accurate bass response with low distortion
nContemporary finish matches popular flat panel displays
INSTALLATION
nIntegrated wall mount bracket makes installation quick and easy
nSilver model includes both black and silver grilles to complement popular décor
SPECIFICATIONS
nImpedance: 4 ohm
nRecommended amplifier power: 10W to 150W
nFrequency response: 70Hz – 21kHz +/-3dB
nSensitivity: 88dB for 2.83V pink noise input, measured at 1 meter on axis
nDimensions: 6.2" Wide x 19.6" High x 5.6" Deep (including wall bracket)
Warranty: Five-year limited
PHD30
Stock Number
FG01146 - Silver
FG01286 - Black
Technology
Details
PHD High Definition Wall Mount Loudspeakers
NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: 800.289.4434 – www.nilesaudio.com NAPHD30PDF
©2005 Niles Audio Corporation. All Rights Reserved. Niles and the Niles logo are registered trademarks of Niles Audio Corporation.
NARROW FRONTAL AREA ENCLOSURES
Reduces cabinet diffraction and reflection effects to preserve accurate imaging and natural tonal balance
PORTED BASS SYSTEM DESIGN
Delivers accurate and powerful bass output for music and movie soundtracks
TCC™ WOOFER CONES
Are comprised from a proprietary blend of injection-molded polypropylene, talc, carbon and ceramic materials that have
an ideal stiffness-to-mass ratio for precise detail and powerful bass tones
HYPERBOLIC DOME MIDRANGE DRIVERS
Feature tri-laminate Teteron material and fluid cooling to produce high sound pressure levels with exceptional clarity and
natural midrange tones that blend seamlessly with PHD high frequencies
TETERON TWEETERS
Employ a tri-laminate soft dome and fluid cooling system to deliver smooth and precise treble tones in a uniform pattern
over a wide area for crystal clear highs everywhere in the room
NILES HD HIGH DEFINITION VOICE MATCHING
Ensures compatibility with other Niles HD High Definition in-wall and ceiling mount models to accommodate a wide variety
of system designs
Details
