AT8000
IN-WALL LOUDSPEAKER
• Tweeter and midrange can be pivoted
•Baffle-mounted bass, midrange and treble tone controls for
acoustical adjustments
8" 3-Way AT Advanced Technology
In-wall Loudspeaker
SPECIFICATIONS SHEET

IN-WALL LOUDSPEAKER
WOOFER TECHNOLOGY
■8" interlaced glass and carbon-fiber cone is extremely rigid to reduce breakup and lower distortion
even under high power
■Butyl rubber cone surround damps resonance and provides exceptional durability
■Sophisticated motor assembly including high BL magnet, extended pole piece, high temperature
aluminum voice coil former and machined top plate for deep bass response and clean bass tones
■Inverted dust cap for added rigidity and wide mid-bass dispersion
MIDRANGE TECHNOLOGY
■1-1/2" fluid-cooled tri-laminate Teteron hyperbolic dome midrange driver reproduces critical
midrange sounds with exceptional accuracy
■NDFE 35 neodymium, high BL magnet motor structures enable compact driver construction
TWEETER TECHNOLOGY
■1" Tri-laminate Teteron hyperbolic dome tweeter reproduces high frequencies and their harmonics
with crystal clear accuracy
■Tweeter is housed in a zero diffraction swiveling enclosure that allows installer to control dispersion
patterns for optimal response
AUDIOPHILE FEATURES
■Linkwitz-Riley filters with premium crossover components provides seamless driver integration
■Low diffraction, X-Matrix™ reinforced polycarbonate Baffle eliminates unwanted resonance
TONE CONTROLS
■4 increment (-2dB, Flat, +2dB, +4dB) bass, midrange and treble controls adjust from the front
baffle for fine tuning after installation
INSTALLATION
■100% rustproof MicroPerf™ aluminum grille conceals loudspeaker elements yet allows full
frequency sound through. Grille can be painted to match décor
■Moisture and UV resistant materials including all stainless steel and brass hardware stand up to
harsh environments
■Infrared sensor knockout provides a hidden remote control solution
■6mm low diffraction X-Matrix reinforced polycarbonate baffler resonance for improved
dynamic range
SPECIFICATIONS
■Impedance: 8 ohms (4 ohms minimum)
■Recommended amplifier power: 20W to 200W
■Frequency response: 30Hz-21kHz +/-3dB
■Sensitivity: 89dB for 2.83 pink noise, measured at 1 meter on axis
■Frame dimensions: 11" x 18-3/8"
■Hole cutout dimension: 9-3/4" x 17-1/4"
■Depth behind ceiling: 3-3/4" deep (based on 1/2" dry wall)
Warranty: Five-year limited
Shipping weight: 9 lbs.
AT8000
Stock Number
FG00741
8" In-Wall Loudspeaker
NILES AUDIO CORPORATION 12331 S.W. 130 Street, Miami, FL 33186 Tel: [phone] – www.nilesaudio.com NAAT8000PDF
©2004 Niles Audio Corporation. All Rights Reserved. Niles and the Niles logo are registered trademarks of Niles Audio Corporation.

IN-WALL LOUDSPEAKER
Details
HOME THEATER SPECIFIC MODELS
Deliver voice-matched cinema performance and are compatible with all AT High Definition models
MODULAR MOUNTING SYSTEM
Uses innovative mounting technique to simplify installation and ensure uniform contact with wall
BLACK BAFFLES
Deliver a seamless appearance after the speakers are installed and the grilles are in place
MICROPERF™ RUSTPROOF ALUMINUM GRILLES
Are acoustically transparent yet won’t rust or discolor
DEBRIS SCREENS
Block unwanted debris such as fiberglass insulation, sheetrock chips, or other foreign matter from coming in contact with the woofer cone
REQUIRES USE OF BRACKET KIT
Use AT8000 bracket kit - FG00746
REQUIRES USE OF FRAME AND GRILLE KIT
Use AT8000 frame and grille kit - FG00745
Technology
PIVOTING RATCHETING TWEETER AND MIDRANGE DRIVER
Enable installers to precisely adjust the angle of the tweeter and midrange driver up to 20° for optimum coverage
ADVANCED MATERIAL SCIENCE
Elevates performance of sub component parts like woofer cones, tweeter diaphragms and crossover components
SOPHISTICATED MOTOR AND MAGNETIC DESIGN
Including HIgh BL magnet, extended pole pieces, high temp aluminum voice coil former and machined top plates for deep bass response
IMPEDANCE MANAGEMENT
Selectable 4 ohm or 8 ohm impedance lets installers optimize the system design
ACOUSTIC FINE TUNING
Bass, midrange and treble controls optimize system sound for every acoustical environment
ANTI-RESONANT WAVE-BRACING TECHNOLOGY
Prevents transmission of woofer vibrations to the baffle and into the drywall for clear and dynamic bass response
