SPECIFICATIONS SHEET
HDLCR
HOME THEATER LOUDSPEAKER
• For use in multi-channel music or home theater systems
• Optimizes performance for applications as either center-channel or left/right
loudspeaker
HD High Definition Left, Center,
or Right In-Wall Loudspeaker

HOME THEATER LOUDSPEAKERS
FEATURES AND SPECIFICATIONS
nDual 5-1/4" injection-molded TCC™ (talc, carbon, and ceramic-filled) polypropylene woofers offer
extreme rigidity to reduce breakup and lower distortion
nLong-throw voice coil/magnet structure increases cone excursion to enhance low frequency
response and dynamic impact
n1" Teteron dome tweeter is fluid cooled and delivers ultra-wide dispersion to reproduce clear and
detailed high frequencies
nProprietary tweeter-adjustment mechanism ratchets in 1mm increments and then pivots for precise
aiming of high frequencies
nBass and treble controls enable precise tone matching in any room
nIncludes paintable, textured, pearl white ABS frame and Microperf® aluminum grille for a clean and
unobtrusive installation
nImpedance: 4 ohms
nRecommended amplifier power: 10W to 150W
nFrequency response: 65Hz – 21kHz +/-3dB
nSensitivity: 89dB with 2.83V pink noise input, measured at 1 meter on axis
nFrame dimensions: 8-1/4" x 14-1/2"
nHole cutout dimensions: 7-1/8' x 13-1/4'
nDepth behind wall: 3-1/2" (assumes 1/2' drywall)
Warranty: Five-year limited
Shipping weight: 7 lbs.
HD High Definition Home Theater Loudspeakers
HD-LCR
Stock Number
FG01151
Technology
Details
