NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI – www.nilesaudio.com
©2007 Niles Audio Corporation. All Rights Reserved. Niles and the Niles logo are registered trademarks of Niles Audio Corporation. CS0065
P
RODUCT CONSTRUCTION AND ACCESSORIES
9
INCH CEILING MOUNT LOUDSPEAKER
Loudspeaker Model Works With
Model Stock Number New Bracket Hole Cover
CM953 FG01319
CM900 Hole Cover
FG01325
9" Three-way Ceiling
Mounted Loudspeaker
CM953
Stock Number
FG01319
Features
■Integrated woofer/baffle design delivers greater low frequency response by employing a 9" woofer where
competitive models employ 8-inch woofers
■Twist & Lock™ baffle and frame mechanism facilitates quick installation and trouble-free upgrades
■Injection-molded TCC™ (Talc, Carbon, and Ceramic-filled) cone is extremely rigid to reduce breakup,
lower distortion and provide enhanced bass response
■Butyl rubber surround damps resonance and provides exceptional durability
■1" fluid-cooled Teteron®dome tweeter offers ultra-wide dispersion and silky-smooth high-frequency
response
■1 1/2" fluid-cooled Teteron®dome midrange offers smooth detailed midrange
■Proprietary bridge-mounted midrange/tweeter-adjustment mechanism focuses the mid and high
frequency sound in any direction without diffraction
■Includes flush-mount MicroPerf™aluminum grille for a clean and unobtrusive look
■2 position presence, 3 position tweeter and switchable boundary compensation controls provide for
precise matching to room acoustics
Specifications
■Frequency Response: 44Hz to 22kHz +/-3dB
■Impedance: 8 ohm nominal; 6 ohm minimum
■Recommended Amplifier Power: 10 to 200 Watts
■Frame Dimensions: 12 3/4 inches
■Hole cutout dimensions: 11 1/4 inches
■Depth behind ceiling: 6 5/8 inches
Warranty: Five-year limited Pivoting Midrange/
Tweeter Pod
CM900 BKT
FG01358
12-3/4"
Frame Outer
Diameter
11-1/4"
Hole
Cutout
5-7/8" Depth
11-1/4"
Hole
Cutout
6-3/16" Depth
