Niles SW10 User manual

SPECIFICATIONS SHEET
10", 125 Watt, Powered Subwoofer
SW10
POWERED SUBWOOFER
• High and low level inputs with music sense and voltage trigger circuitry
• Front mounted controls provide frequency and level adjustments
• Removable cloth grille
*SHOWN WITHOUT GRILLE

NILES AUDIO CORPORATION 12331 SW 130 Street, Miami, FL 33186 1-800-BUY-HIFI – www.nilesaudio.com
FEATURES
1 Advanced amplifier design provides significant dynamic power
2 10" injection-molded TCC™ (Talc, Carbon and Ceramic-filled) polypropylene woofer with butyl
rubber surround
3 RCA LFE input bypasses all filtered inputs
4 Left and Right line-level inputs include fixed 80Hz high-pass filter
5 Cascade audio outputs facilitate easy connection of additional system components and speakers
6 On/off system trigger input accepts 3V-30V AC/DC
7 Cascade trigger output allows easy expansion to other triggered system equipment
8 3 turn on modes: Music Sense, Voltage Trigger and Always On
9 Gold plated connection terminals ensure long term performance
10 Subwoofer phase control switch ensures optimal system integration
11 Adjustable low pass filter 60Hz – 125Hz
12 Adjustable woofer level control
SPECIFICATIONS
■ Amplifier power: 125 W peak
■ Frequency response: 30Hz – 160Hz +/-3dB
■ Overall dimensions: 14-1/4" W x 15-1/4" H x 17-1/4" D
■ AC Power: 120V AC or 220-240V AC switchable
Warranty: Two-year limited
Shipping weight: 47 lbs.
SW10
Stock Number
FG01236
Front and Rear Panel Details
Features and Specifications
©2006 Niles Audio Corporation. All Rights Reserved. Niles and the Niles logo are registered trademarks of Niles Audio Corporation.
POWERED SUBWOOFER
10
4
3
9
11
278
4
5
12
1
