Nilfisk-Advance Advolution 2710 User manual

7/06 revised 6/08 FORM NO. 56043107
Advolution™ 2710
UHR 70-1700
Service Manual
Advance Models: 56422000, 56422002
Nilfisk Model: 56422001

2- FORM NO. 56043107 - Advolution™ 2710 / UHR 70-1700
TABLE OF CONTENTS
INTRODUCTION .................................................................................................................4
IMPORTANT SAFETY INSTRUCTIONS .............................................................................5
TECHNICAL SPECIFICATIONS..........................................................................................6
MAINTENANCE SCHEDULE ..............................................................................................8
KNOW YOUR MACHINE..............................................................................................10-11
FUNCTIONAL DESCRIPTION OF CONTROL BUTTONS:...............................................12
BURNISHING SYSTEM ....................................................................................................13
FUNCTIONAL OVERVIEW ........................................................................................13
PAD LIFT ACTUATOR REMOVAL AND INSTALLATION ...........................................14
PAD DRIVE DECK REMOVAL ...................................................................................14
PAD DRIVE MOTOR CARBON BRUSH INSPECTION .............................................14
PAD DRIVE MOTOR REMOVAL................................................................................15
DUST SHROUD REMOVAL .......................................................................................15
DUST SHROUD EDGING REPLACEMENT ..............................................................16
PAD DRIVE DECK LEVEL ADJUSTMENT.................................................................17
PAD DRIVE DECK LEVEL ADJUSTMENT.................................................................18
INSTALLATION OF THE BURNISHING PAD.............................................................19
INSTALLATION OF THE DUST COLLECTION BAG .................................................20
TROUBLESHOOTING GUIDE ELECTRICAL............................................................21
WHEEL DRIVE SYSTEM ..................................................................................................25
GENERAL FUNCTIONAL OVERVIEW ......................................................................25
DRIVE MOTOR SYSTEM CONTROLLER FUNCTION OVERVIEW .........................25
DRIVE MODE SELECTION OPERATION OVERVIEW .............................................25
WHEEL DRIVE TROUBLESHOOTING GUIDE .........................................................28
WHEEL DRIVE ASSEMBLY REMOVAL.....................................................................30
WHEEL DRIVE MOTOR REMOVAL ..........................................................................31
DRIVE WHEEL REMOVAL.........................................................................................32
ELECTROMAGNETIC BRAKE ASSEMBLY REMOVAL ............................................33
STEERING CHAIN REMOVAL AND TENSIONING ...................................................34
POTENTIOMETER REMOVAL AND TESTING..........................................................35
POTENTIOMETER INSTALLATION AND ADJUSTMENT:.........................................35
ALTERNATE METHOD FOR THROTTLE ADJUSTMENT.........................................35
DRIVE PEDAL NEUTRAL ADJUSTMENT & PEDAL REPLACEMENT .....................37
TROUBLESHOOTING GUIDE ELECTRICAL............................................................38

FORM NO. 56043107 - Advolution™2710 / UHR 70-1700 - 3
TABLE OF CONTENTS (CONTINUED)
ELECTRICAL SYSTEM.....................................................................................................40
BATTERIES................................................................................................................40
CHARGING THE BATTERIES ...................................................................................41
CHECKING THE BATTERY WATER LEVEL..............................................................41
BATTERY MAINTENANCE ........................................................................................41
CHARGING THE BATTERIES (CONTINUED)...........................................................42
BATTERY TESTING...................................................................................................42
BATTERY SPECIFICATIONS.....................................................................................42
BATTERY CHARGER SPECIFICATIONS..................................................................42
ACTUATOR DRIVE NUT ADJUSTMENT...................................................................43
CURTIS CONTROLLER DIAGNOSTICS:..................................................................44
FUNCTION OF THE SPEED CONTROLLER STATUS LIGHT AND DISPLAY..........44
PROGRAMMER DIAGNOSTICS: ..............................................................................44
DIAGNOSTIC HISTORY ............................................................................................44
SPEED CONTROL PROGRAMMING OPTIONS.......................................................45
INSTALLATION CHECKOUT FOR THE CURTIS SPEED CONTROLLER................47
PROGRAMMING VEHICLE SPEED CHANGES .......................................................47
FUNCTIONAL OVERVIEW OF MAIN CONTROL BOARD ........................................48
MAIN CONTROLLER ERROR CODES .....................................................................48
ADVOLUTION PROGRAMMING MODES .................................................................49
FAULT RECALL MODE / REVISION DISPLAY: ..............................................................................49
SERVICE TEST MODE: .................................................................................................................. 49
STATUS DISPLAY: .......................................................................................................................... 50
OUTPUT CONTROLS: .................................................................................................................... 50
HORN SWITCH: .............................................................................................................................. 50
PAD SWITCH:.................................................................................................................................. 50
LOW VOLTAGE CUTOUT THRESHOLD SELECTION MODE:......................................................51
FAULT DETECTION ENABLE/DISABLE MODE:............................................................................51
PAD PRESSURE ADJUSTMENT MODE: ....................................................................................... 51
FORWARD MOTION ALARM VOLUME LEVEL ADJUSTMENT MODE:........................................52
REVERSE MOTION ALARM (BACK-UP ALARM) VOLUME LEVEL ADJUSTMENT MODE:......... 52
BURNISHING SPEED LIMIT ENABLE/DISABLE MODE:...............................................................52
TROUBLESHOOTING GUIDE ..........................................................................................53
COMPONENT LOCATION .............................................................................................................. 55
WIRING DIAGRAM / SCHEMATIC.............................................................................................56-57
Note: All references to right, left, front, or rear in this manual are as seen from the operator’s standpoint.

4- FORM NO. 56043107 - Advolution™ 2710 / UHR 70-1700
INTRODUCTION
This manual will help you get the most from your Nilfisk-Advance Advolution™ 2710 / UHR 70-1700. Read it thoroughly before operating the
machine.
Note: Bold numbers in parentheses indicate an item illustrated on pages 10 – 11.
This product is intended for commercial use only.
PARTS AND SERVICE
Repairs, when required, should be performed by Nilfisk-Advance service personnel using Nilfisk-Advance original replacement parts and
accessories.
Call Nilfisk-Advance for repair parts or service. Please specify the Model and Serial Number when discussing your machine.
NAME PLATE
The Model and Serial Number of your machine are shown on the Nameplate on the machine. This information is needed when ordering repair
parts for the machine. Use the space below to note the Model and Serial Number of your machine for future reference.
MODEL ________________________________________________
SERIAL NUMBER ________________________________________
TRANSPORTING THE MACHINE
CAUTION!
Before transporting the machine on an open truck or trailer, make sure that . . .
• The machine is tied down securely.
• All access doors and covers are secured (tape and strap as needed).
TOWING
Reference page 8 for towing instructions.
OTHER MANUALS AVAILABLE FOR YOUR MACHINE
The manuals listed below can be found via Nilfisk-Advance’s two electronic supported databases. They are:
• Nilfisk-Advance Dealer Customer Zone
• Ezparts service / parts CD-Rom
•Parts List - Form Number 56042468
•Instructions for Use - Form Number 56041634 (English, Spanish)
56041635 (Danish, Norwegian, Swedish, Finnish)
56041636 (German, French, Dutch, Russian)
56041637 (Spanish, Portuguese, Italian, Greek)
56041638 (Estonian, Latvian, Lithuanian, Slovenian)
56041639 (Slovakian, Czech, Polish, Hungarian)
56041655 (Turkish)

FORM NO. 56043107 - Advolution™2710 / UHR 70-1700 - 5
IMPORTANT SAFETY INSTRUCTIONS
This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than
normal residential housekeeping purposes.
Read all instructions before using.
WARNING!
To reduce risk of fire, electric shock, or injury:
•Use only as described in this manual. Use only manufacturer’s recommended attachments.
•This machine shall be used only by properly trained and authorized persons.
•This machine is for dry use only and shall not be used or stored outdoors in wet conditions.
•Do not allow to be used as a toy. Close attention is necessary when used by or near children.
•Keep sparks, flame and smoking materials away from batteries. Explosive gases are vented during normal operation.
•Charging the batteries produces highly explosive hydrogen gas. Charge batteries with seat cover open in well-ventilated areas,
away from open flame. Do not smoke while charging the batteries.
•Remove all jewelry when working near electrical components.
•Turn the key switch off (O) and disconnect the batteries before servicing electrical components.
•Never work under a machine without safety blocks or stands to support the machine.
•Do not dispense flammable cleaning agents, operate the machine on or near these agents, or operate in areas where flammable
liquids exist.
•Do not clean this machine with a pressure washer.
•This machine is not approved for use on public paths or roads.
•Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may
reduce air flow.
• Do not use on surfaces having a gradient exceeding that marked on the machine.
•When operating this machine, ensure that third parties, particularly children, are not endangered.
•Before performing any service function, carefully read all instructions pertaining to that function.
•Do not leave the machine unattended without first turning the key switch off (O) and removing the key. The parking brake is
automatically activated at this time.
• Turn the key switch off (O) and remove the key, before changing the brushes, and before opening any access panels.
•Take precautions to prevent hair, jewelry, or loose clothing from becoming caught in moving parts.
•Do not use without dust bag and / or filters in place.
•Do not stand on the pad housing.
•This machine is not suitable for picking up health endangering dust.
• The batteries must be removed from the machine before the machine is scrapped. The disposal of the batteries should be
safely done in accordance with your local environmental regulations.
• All doors and covers are to be positioned as indicated in the instruction manual before using the machine.
• Refer to the battery charger OEM product manual for additional specific battery charger warnings.
SAVE THESE INSTRUCTIONS

6- FORM NO. 56043107 - Advolution™ 2710 / UHR 70-1700
TECHNICAL SPECIFICATIONS
General Specifications English (Metric)
Burnishing Pad Diameter 27 inches (68.58 cm)
Machine Length 65.5 inches (166.37 cm)
Machine Width 32 inches (81.28 cm)
Machine Height 54 inches (137.16 cm)
Machine Weight 484 lbs. (219.53 kg) net w/o batteries
1,379 lbs. (626 kg) gross w/six 395 AH batteries
Front Wheel Weight (w/six 395 AH batteries) 308 lbs. (139.7 kg)
Rear Right Wheel Weight (w/six 395 AH batteries) 445 lbs. (201.8 kg)
Rear Left Wheel Weight (w/six 395 AH batteries) 451 lbs. (204.5 kg)
Front Wheel Pressure (w/six 395 AH batteries) 128 PSI
Rear Right Wheel Pressure (w/six 395 AH batteries) 72 PSI
Rear Left Wheel Pressure (w/six 395 AH batteries) 105 PSI
Average Coverage Rate 41,580 sq. ft (3,862m2) per hour
Average Run Time 3 hours per battery charge
Batteries Recommended Six 6 volt, 395 A/H @ 20 hour rate,
120 lbs. (54.4 kg) each
Battery Compartment Size
25 inches (63.50 cm) long
22.5 inches (57.15 cm) wide
17.50 inches (44.45 cm) high
Battery Charger Recommendation 25 or 36 Amp output, 36 volt charger
Burnisher Pad Motor 36 volt, 3.25 hp, 85 Amp
Wheel Drive Motor 36 volt, 1 hp, 27 Amp
Pad Lift Motor 36 volt, 1/6 hp, 6.7 Amp
Drive System Speed Control Electronic, fully variable Fwd/Rev
Max Transport Speed 396 FT/min
Max Burnish Speed 308 FT/min
Turning Radius 72 inches (182.88 cm)
Wheels 9.75 inch (24.76 cm) drive wheel
12 inch (30.48 cm) rear wheels
Ramp Climbing Ability 12.3% grade
Sound Pressure Level (IEC 60704-1) 69 dB(A)/20μPa (at operator’s ear)

FORM NO. 56043107 - Advolution™2710 / UHR 70-1700 - 7
TECHNICAL SPECIFICATIONS

8- FORM NO. 56043107 - Advolution™ 2710 / UHR 70-1700
MAINTENANCE SCHEDULE
MAINTENANCE ITEM Daily Weekly Monthly Yearly
Charge Batteries X
Check/Clean/Replace Burnishing Pad X
Check/Replace Dust Collection Bag X
Check Battery Water Level(s) X
Check/Replace Pad Shroud Skirt X
Chain Tension - Steering X
Lubrication - Grease Fittings X
Check Carbon Brush Wear On Pad/Drive/Vacuum Motors X
Note: See the individual machine system sections for maintenance information.
* Have Nilfisk-Advance check the vacuum motor carbon motor brushes once a year or after 300 operating hours. The pad and drive motor carbon
brushes check every 500 hours or once a year.
WARNING!
Turn the key switch off and disconnect the batteries before servicing the machine.
* Check vacuum motor carbon brushes (Qty 2) once a year or after 300 operating hours.
* Check pad and wheel drive motor(s) carbon brushes (Qty 4 per motor) once a year or after 500 operating hours.
* The original (new) length of each carbon brush is 1-3/32” (27.76mm) on all 36 volt machine models brush and wheel drive motors.
* All motors: Replace carbon brushes when shorter than 3/8” (9.5mm) to obtain the same motor efficiency as new brushes.
IMPORTANT!
Motor damage resulting from failure to service the carbon brushes is not covered under warranty. See the Limited Warranty
Statement.
BATTERIES AND CHARGERS
Attention: See the ELECTRICAL SYSTEM section for battery installation, battery maintenance and charger system requirements.
LUBRICATING THE MACHINE
Locations requiring periodic oiling are:
Qty 1 - Steering Wheel Shaft Universal Joint (oil hole or port)
TOWING THE MACHINE
CAUTION!
The Drive / Steer Wheel Assembly (14) has a built in
electromagnetic brake that is engaged whenever the
Master Key Switch (AA) is OFF or the FWD / REV Drive
Pedal (8) is in the neutral position. This brake can be
manually over ridden if necessary by inserting a medium
to large screwdriver behind the Yoke (A) as shown. This
should only be done in the event you need to push or pull
the unit.

FORM NO. 56043107 - Advolution™2710 / UHR 70-1700 - 9
Advance Advolution 2710 & Nilfisk UHR 70-1700
Rider Burnisher
PM Checklist Defect Codes
Customer A needs adjustment
Bbinding
Address C dirty or contaminated
Ddamaged, bent or torn
City St Zip L leaks
Mmissing
Model Serial Hours W worn out
Ref OPERATIONAL INSPECTION ITEMS OK Defect Codes
(circle)
Does
Not
Work
1 Steering A B
2 Drive System Pedal Operation (check for Fwd/Rev drive & any neutral creep) A B D
3 Seat Safety Switch D W
4 Electrical Parking Brake (Brake releases when the key is turned on & the drive pedal is
engaged. Note machine should not move when machine is at rest.) A B W
5 Drive System Performance noisy sluggish
6 Burnishing System Deck & Motor Operation (pad deck raise/lower & pad motor auto
functions) A B C D
7 Burnishing System performance (even shine) A W
8 Emergency Battery Disconnect Control Knob B D
9 Tilt Steering Mechanism A B
10 Optional Accessories (Headlight, Safety Beacon, Active Dust Control System, Etc.) <----->
11 Battery Charger (auto turn ON & OFF)
12 Main Control Board Special Program Options (Reference SVR Manual 56043107) and
check all applicable program settings. Examples stored error fault codes, diagnostic
SVR test mode, pad pressure settings etc.
A
Ref VISUAL INSPECTION ITEMS Comments OK Defect Codes
(circle)
Does
Not
Work
13 Pad Motor Carbon Brushes (check for wear) C D W
14 Wheel Drive Motor Carbon Brushes (check for wear) C D W
15 Pad Deck Actuator Motor and Pad Drive Deck Levelness Perform a pad pattern
test A B D
16 Pad Retainer, Pad Driver and Burnishing Pad (check for wear) D M
17 Dust Shroud Assembly Edging and Dust collection Bag D M W
18 Battery Condition (load test, clean & water) D L W
19 Check and Lubricate the Steering Wheel Universal Joint A B D W
20 Steer Chain Tension adjust A B C W
21 Drive and Steer wheels (thread wear) A D W
NOTE: For additional service information see service manual form number 56043107 and
operators manual (English & Spanish) form number 56041634.
WORK COMPLETED BY: ACKNOWLEDGED BY:
Service Technician Signature Date Customer Signature Date

10 - FORM NO. 56043107 - Advolution™ 2710 / UHR 70-1700
KNOW YOUR MACHINE
As you read this manual, you will occasionally run across a bold number or letter in parentheses - example: (2). These numbers refer to an item
shown on these pages unless otherwise noted. Refer back to these pages whenever necessary to pinpoint the location of an item mentioned in
the text.
1 Pad Drive Deck
2 Dust Control Shroud
3 Burnishing Pad
4 Pad Retainer
5 Dust Collection Bag
6 Machine Tie Down
7 Battery Connector Assembly
8 FWD/REV Drive Pedal
9 Tilt Steering Wheel Adjuster
10 Emergency Power Disconnect
11 Steering Wheel
12 Operator’s Seat W/Safety
Switch
13 Battery Compartment Cover
14 Drive / Steer Wheel
15 Circuit Breakers
40 Amp (Wheel Drive)
5 Amp (Control Circuit)
16 Deck Latch
17 I/O Panel (Indicator /
Operation Panel)
18 Spare Dust Bag Storage
19 Beacon (Optional)
20 Headlight (Optional)
21 Active Dust Control (Optional)
22 Onboard Charger (Optional)
23 Serial Plate (qty of 2)

FORM NO. 56043107 - Advolution™2710 / UHR 70-1700 - 11
KNOW YOUR MACHINE
AA Master Key Switch
BB Battery Condition Indicator
CC Hour Meter / Error Display
DD Pad Drive Indicator Light
EE Pad Drive Raise / Lower Switch
FF Horn Indicator Light
GG Horn Switch

12 - FORM NO. 56043107 - Advolution™ 2710 / UHR 70-1700
FUNCTIONAL DESCRIPTION OF CONTROL BUTTONS:
Key Switch (AA) – Main Power Switch, when turned on controls battery input to machine’s main control board and wheel drive speed control.
Battery Condition Indicator (BB) – The Battery Condition Indicator will give an indication of the state of charge of the batteries. Three lights
make up the Indicator Display (Red-Yellow-Green). See the electrical system in this manual for discharge percentage details of each indicator
light.
Hour Meter/Error Display (CC) The 5-character display on the I/O Panel is primarily used as a display for the hour meter function. When the Key
Switch (A) is activated pad pressure setting 1,2, or 3 will appear briefly in the right corner of the display. Followed by five 8’s to show functionality
of the L.E.D. Display, then switching to hours on the unit. This display is also used to display the following information depending upon which
mode the control is in:
• Error Codes*
• Pad Pressure Settings (1,2, and 3)
• Display of control system default parameters*
*Service Note: Have a qualified Service Technician reference the Service Manual for explanations about Error Codes and Control Fault + Parameter Changes. A
description of Error Codes can be found in the electrical section of this manual
Pad Drive Indicator Light (DD) –
• Indicator will be blank (off) when deck is in the raised position.
• Indicator will be light Green when lowering the deck as the pad drive raise-lower switch is activated.
• Indicator will be dark Green when the Drive Pedal is engaged in Forward or Reverse activating the pad motor.
• Indicator will be Red when raising the deck as the pad drive/raise-lower switch is activated.
• At full raised position the Red light will go out.
Pad Drive Raise-Lower Switch (EE) – Pressing this switch will activate (turn on) the Lower/Raise burnishing deck lift actuator functions – see
indicator lights description for further information.
Horn Indicator Light (FF) – Indicator Light will turn Green when Horn Switch is depressed. And also displays fault flash codes. NOTE: See
electrical system Curtis Control diagnostics in this manual.
Horn Indicator Switch (GG) – Pressing this switch will activate (turn on) the horn, causing a horn like sound to emanate from the machine.

FORM NO. 56043107 - Advolution™2710 / UHR 70-1700 - 13
BURNISHING SYSTEM
FUNCTIONAL OVERVIEW
The machines: Advolution 2710 / UHR 70-1700 (Model numbers 56422000, 56422001 & 56411002) use the disk type burnishing system. The pad
driver assembly is directly attached to a single 3.25hp – 36v DC permanent magnet motor.
The burnishing deck is raised and lowered by a horizontally mounted electric lift actuator motor. The operation of the machine’s burnishing
functions are activated when the operator presses the main I/O Panel’s pad drive raise/lower switch (EE). NOTE: See the Electrical System-
Advolution programming modes section of this manual for more detailed operation and instructions to change the burnishing pad pressure setting.
The machines main burnishing system input and output operating functions are regulated (managed) by the I/O Panel and the Control Box. For
the Pad motor to function the operator must turn on (energize) the (K1) pad motor solenoid by pressing the Pad drive Raise/Lower switch (EE) on
the I/O Panel and press the drive pedal moving it off it’s neutral position. These two operator functions deliver the required (A1) Speed control and
Control Box circuit inputs and outputs for the burnishing operation. NOTE: See troubleshooting (page 22) section for more details.
BLK
RED
RED/GRN YEL/BLK BLK
GRN/WHT BRN/BLK
GRA
VIO/BRN
RED
GRN
RED/WHT
ORN
RED/WHT
VIO/BRN
RED RED
WHT/RED
GRNVIO
VIO
VIO
VIO
WHT/ORN
WHT/ORN
WHT/BRN
WHT/BRN
GRN/BLK
GRN/BLK
ORN/BLK
ORN/BLK
GRA/BLK
VIO/BLK
GRA/WHT
BRN/WHT
ORN/BLU
BLK/WHT
BLU/WHT
RED BLK
BLK/YEL
RED
BLK
BLK
RED/WHT
BLKWHT
VIO
RED BLK
BLK
BLK/GRA
BLU
PINK
ORN/WHT
BLU/BLK
BRN
YEL/WHT
YEL/WHT
GRNYEL
WHT/ORN
J2-4 (ACC (-))
J3-1 (B+)
J3-9 (SEAT SW)
J3-2 (KEY SW)
J3-10 (F/R)
(MODE) J2-2
(STATUS) J3-4
I/O PANEL
(B-) J2-10
(B-) J3-8
(SENSE) J3-3
(ACT 1) J2-12
(ACT 2) J2-6
(HORN +) J2-7
(HORN -) J2-1
J2-11 (PAD CONT +)
J2-5 (PAD CONT -)
J3-7 (INTERLOCK B-)
J3-5 (INTERLOCK)
CONTROL BOX
ON-BOARD
BATTERY CHARGER
(OPTIONAL)
56015612 REV. F
(B-) J2-9
J4-6 (PAD SW)
J4-1 (SDA)
J4-2 (SCL)
J4-3 (+5 V)
J4-5 (B-)
J4-4 (HORN SW)
(PAD SW) J1-6
(B-) J1-5
(+5 V) J1-3
(SCL) J1-2
(SDA) J1-1
(HORN SW) J1-4
(REV) J3-6
M
M2
MOTOR, PAD
M
M2
MOTOR, PAD
-+
K1K1
1 2
PLUG AC MALEPLUG AC MALE
S5
SW SPST
S5
SW SPST
1 2
CB2
CIRCUIT BREAKER, 40 AMP
CB2
CIRCUIT BREAKER, 40 AMP
1 2
H1
HORN/BACK-UP ALARM
H1
HORN/BACK-UP ALARM
+ -
M
M4
MOTOR, DUST CONTROL VAC
(OPTIONAL)
M
M4
MOTOR, DUST CONTROL VAC
(OPTIONAL)
1 2
R1
POT. 5K OHM
R1
POT. 5K OHM
1
2
3
---
BT1
BATTERY, 36 VDC
---
BT1
BATTERY, 36 VDC
J7J7
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18
S9
SW SPST
S9
SW SPST
1 2
S2
SWITCH, SEAT
S2
SWITCH, SEAT
21
S3
SWITCH, DECK INTERLOCK
S3
SWITCH, DECK INTERLOCK
1 2
LP6
LAMP, FLASHING
(OPTIONAL)
LP6
LAMP, FLASHING
(OPTIONAL)
1 2
Y1
BRAKE
Y1
BRAKE
12
LP5
LAMP, HEAD
(OPTIONAL)
LP5
LAMP, HEAD
(OPTIONAL)
1 2
K1
COIL, RELAY
K1
COIL, RELAY
M
M1
MOTOR, TRACTION
M
M1
MOTOR, TRACTION
- +
F1
FUSE, 150 A.
F1
FUSE, 150 A.
12
A1 CURTIS 1228 SPEED CONTROLLER A1 CURTIS 1228 SPEED CONTROLLER
B+
B-
M1 (a) M2 (a) M1 (b) M2 (b)
S1
SWITCH, KEY
S1
SWITCH, KEY
1 2
M
M3
ACTUATOR
M
M3
ACTUATOR
- +
S10
EMERGENCY STOP
S10
EMERGENCY STOP
CB1
CIRCUIT BREAKER, 5 AMP
CB1
CIRCUIT BREAKER, 5 AMP
1 2
K1
A
1
K1

14 - FORM NO. 56043107 - Advolution™ 2710 / UHR 70-1700
BURNISHING SYSTEM
PAD LIFT ACTUATOR REMOVAL AND INSTALLATION
WARNING!
Disconnect the battery pack by separating the battery connectors (7) whenever servicing the machine.
1 Disconnect the battery pack by separating the battery connectors (7) located underneath the drivers seat.
2 Disconnect the actuator wiring harness at the actuator lift motor.
3 See Figure 1. Remove the (2) Hex Screws (A) that fasten the actuator Mount Bracket (B).
4 Remove the Retainer Ring (C). NOTE: Remove the retainer closest to the front of the machine. Then slide the mount pin (D) to the rear to
allow removal of the Actuator (E) from the machine.
5 To re-install follow the above instructions in reverse order. NOTE: See the Actuator Lift Nut Adjustment section in this manual for correct
lift nut adjustment setting as new actuators do not come pre-set.
PAD DRIVE DECK REMOVAL
WARNING!
Disconnect the battery pack by separating the battery connectors (7) whenever servicing the machine.
1 Disconnect the battery pack by separating the battery connectors (7) located underneath the drivers seat.
2 See Figure 1. Remove the (2) Deck Springs (F) from the right side of the lower deck housing. NOTE: Use a pliers to assist in disconnecting
the springs. Having the deck in the up position will also make it easier (less tension).
3 Attach the Advance actuator adapter cord (P.N. 56407502) to the deck Actuator (E) and lower deck. This step is done to gain service access
to the motor wiring and lift linkage mount hardware.
4 Disconnect the deck’s Safety Switch (G) at its harness connector.
5 Remove the (2) pad motor wires. NOTE: Mark the Red (-) & Black (+)wire locations.
Service Tip: Measure the height of the Front to Back Deck Level Adjustment Screw (H) before disassembling (should be approximately 1-
1/8”(28.44mm)).
6 Loosen Lock Nut (I) and thread it down. At the same time remove the Adjustment Screw (H) from the Pivot Shaft (J).
7 Tap the Shaft (J) toward the rear tire to complete its removal.
Service Tip: The shaft is spaced with (2) Nylon Washers (K), note their location for reassembly.
8 Slide the deck assembly out from under the machine.
PAD DRIVE MOTOR CARBON BRUSH INSPECTION
1 Follow instructions for Pad Drive Deck Removal.
2 See Figure 1. Remove the Motor Air Filter (L). NOTE: Inspect the condition of the filter band and clean or replace as needed.
3 Remove the motor Brush Cover (M) secured by (4) Phillips head screws (N).
4 Inspect carbon brushes and springs. NOTE: New carbon brushes measure 1-3/32 (28mm). If the brushes are less than 3/8” (10mm) long
they should be replaced.
5 Important Maintenance Tip: Always blow out motor before reassembling
6 Motor wiring tip: The Red cable goes to NEGATIVE Stand off on the motor and the Black cable goes to the POSITIVE Stand off on the
motor.

FORM NO. 56043107 - Advolution™2710 / UHR 70-1700 - 15
FIGURE 1

16 - FORM NO. 56043107 - Advolution™ 2710 / UHR 70-1700
BURNISHING SYSTEM
PAD DRIVE MOTOR REMOVAL
1 Follow instructions for Pad Drive Deck Removal.
2 See Figure 2. Remove the Dust Bag (A).
3 Tip the deck assembly over and remove the Pad Retainer (B), pad (if installed) and the Motor Shaft Screw (C) that fastens the Pad Driver
Assembly (D) to the motor shaft.
4 Remove the Pad Driver Assembly (D) from the motor shaft. NOTE: Do not lose the motor shaft key.
5 Remove the (4) Screws (E) and the Dust Shroud (F).
6 Remove the (4) Screws (G) that fasten the motor to the deck plate. Lift the remaining Deck Assembly (H) off the Motor (I) to complete its
removal. NOTE: Mark motor terminal location for reassembly.
7 Follow the above steps in reverse order to reinstall the Pad Drive Motor.
FIGURE 2
DUST SHROUD REMOVAL
1 See Figure 2. Remove the Dust Bag (A).
2 Remove the Pad Retainer (B), pad (if installed) and the Motor Shaft
Screw (C) that fastens the Pad Driver Assembly (D) to the motor
shaft.
3 Remove the Pad Driver Assembly (D) from the motor shaft. NOTE:
Do not lose the motor shaft key.
4 Remove the (4) Screws (E) and the Dust Shroud (F).

FORM NO. 56043107 - Advolution™2710 / UHR 70-1700 - 17
BURNISHING SYSTEM
DUST SHROUD EDGING REPLACEMENT
1 See Figure 3. Remove existing Edging (A) by pulling it away from the Shroud (B).
2 To install start at the rear of the Shroud (B) with one end of the new Edging (A) so that the seam is hidden. Push “U” channel onto Shroud
(B), work edging assembly around Shroud (B).
3 Check that Edging (A) “U” channel is firmly in place all around Shroud (B). NOTE: Pinch the “U” channel every 3 to 4 inches with a vise-
grips to ensure it is securely fastened to the shroud.
FIGURE 3

18 - FORM NO. 56043107 - Advolution™ 2710 / UHR 70-1700
BURNISHING SYSTEM
PAD DRIVE DECK LEVEL ADJUSTMENT
NOTE: Install a new pad before performing this adjustment.
1 Put the pad drive deck in the down position.
2 Briefly run the pad drive motor to get a pattern on the floor.
CAUTION!
Do not run pad motor for an extended period without moving machine.
Left to Right Pad Contact Adjustment – See Figure 4.
1 Loosen the (2) Nuts (A) on the Adjustable Bracket (B).
2 Turn the (2) Lock Nuts (C) on the Carriage Screw (D) either
down to increase or up to decrease Dimension “X”.
Decreasing Dimension “X” will increase the pad pressure at
the 3 O’clock position.
Increasing Dimension “X” will increase the pad pressure at the
9 O’clock position.
FIGURE 4
NOTE: As a general rule the
measurement at the 3 o’clock and the
9 o’clock position should be the same
when measured from the floor to the
edge of the dust shroud.
revised 6/08

FORM NO. 56043107 - Advolution™2710 / UHR 70-1700 - 19
BURNISHING SYSTEM
PAD DRIVE DECK LEVEL ADJUSTMENT
NOTE: Install a new pad before performing this adjustment.
1 Put the pad drive deck in the down position.
2 Briefly run the pad drive motor to get a pattern on the floor.
CAUTION!
Do not run pad motor for an extended period without moving machine.
Front to Back Pad Contact Adjustment – See Figure 5.
1 Loosen Lock Nut (A) and turn the Adjustment Screw (B) clockwise to
increase or counter-clockwise to decrease Dimension “X”.
Increasing Dimension “X” will increase the pad pressure to the front of the
pad assembly at the 12 O’clock position.
Decreasing Dimension “X” will increase the pad pressure to the rear of the
pad assembly at the 6 O’clock position.
FIGURE 5
NOTE: As general rule the pad should
be approximately 3/8” higher at the 12
o’clock position than at the 6 o’clock
position.

20 - FORM NO. 56043107 - Advolution™ 2710 / UHR 70-1700
BURNISHING SYSTEM
INSTALLATION OF THE BURNISHING PAD
WARNING!
Disconnect the machines Battery Pack Connector (7) when ever servicing the machine.
CAUTION!
Turn the key switch off (O) and remove the key, before changing the pad, and before opening any access panels.
1See Figure 6. Grab hold of the right side of the Pad Drive Deck (1) and lift up until it Latches (16) in place as shown.
2Place your hand underneath the Dust Control Shroud (2) and remove the Pad Retainer (4) from the flexible pad holder assembly. NOTE:
Grip the retainer firmly and turn clockwise (to the right) as the retainer uses a Left Hand thread.
3Select a 27 inch (68 cm) Dia. Burnishing Pad (A). See your local Nilfisk-Advance Distributor for a complete selection of pads and
accessories.
4Insert the plastic Pad Retainer (4) into the center of the Pad (A). Then reinstall by turning the retainer counter-clockwise (to the left). NOTE:
Important !!! Turn the retainer in until you hear a clicking ratchet sound, this insures proper tightening of the pad by properly compressing the
pad material and drawing up the retainer so it will not strike the floor.
FIGURE 6
