Nilfisk-Advance VHS110N1 CR User manual

C424-US-F-E
EDITION 04/2016
VHS110N1 CR
Instructions for use
INSTRUCTIONS MANUAL
MANUEL D’INSTRUCTIONS
MANUAL DE INSTRUCCIONES
EN-US English-American
F French
E Spanish

VHS110N1 CR
04/2016 1C424
US
Table of contents
Instructions for use.........................................................................................................2
Operator’s safety............................................................................................................................. 2
General information for using the vacuum cleaner.......................................................................... 2
Proper uses..................................................................................................................................... 2
Improper Use................................................................................................................................... 2
General recommendations.............................................................................................................. 3
Vacuum cleaner description...........................................................................................4
Vacuum Cleaner Parts and Labels.................................................................................................. 4
Optional kits..................................................................................................................................... 4
Accessories..................................................................................................................................... 4
Packing and unpacking ................................................................................................................... 4
Unpacking, moving, use and storage.............................................................................................. 4
Setting to work - connection to the power supply............................................................................ 5
Extensions....................................................................................................................................... 5
Wet and dry applications................................................................................................................. 5
Vacuuming of liquids ....................................................................................................................... 5
Maintenance and repairs................................................................................................................. 6
Technical data ................................................................................................................................. 7
Dimensions...................................................................................................................................... 7
Safety devices................................................................................................................................. 8
Controls, indicators and connections .............................................................................................. 8
Inspections prior to starting ............................................................................................................. 8
Starting/stopping the vacuum cleaner............................................................................................. 8
Vacuum cleaner operation............................................................................................................... 8
Main lter cleaning .......................................................................................................................... 9
Emergency stopping........................................................................................................................ 9
Emptying the container.................................................................................................................... 9
At the end of a cleaning session ..................................................................................................... 9
Dust bag.......................................................................................................................................... 9
Safe Dust Bag ................................................................................................................................. 9
How to change the bag ................................................................................................................... 9
Maintenance, cleaning and decontamination................................................................................ 10
Autoclavable parts......................................................................................................................... 10
Primary and absolute lter disassembly and replacement.............................................................11
Primary star lter replacement .......................................................................................................11
Upstream absolute lter replacement.............................................................................................11
Motor cooling fan inspection and cleaning .....................................................................................11
Inspection.......................................................................................................................................11
Wiring diagrams .............................................................................................................................11
Recommended spare parts ..........................................................................................12
Troubleshooting ............................................................................................................13
WARRANTY.................................................................................................................................. 14
DISCLAIMER ................................................................................................................................ 14
Translation of original instructions

C424 204/2016
VHS110N1 CR
US
Instructions for use
Proper uses
This vacuum cleaner is specially designed for Cleanrooms
This vacuum cleaner is available in dry or wet collection
models.
For collecting corrosive materials the AISI 316L version
should be used.
■Always leave enough room around the vacuum cleaner
to reach the controls easily.
The vacuum cleaner has been designed to be used by one
operator only.
This vacuum cleaner consists of an automated vacuum
unit, with a lter upstream and a container for collecting the
vacuumed material.
Improper Use
WARNING!
■Outdoors always.
■When not placed on horizontal level grounds.
■When the lter unit is not installed.
■When the vacuum inlet and/or hose are turned to
parts of the human body.
■When the protective covers and safety systems
are not installed by the manufacturer.
■When the cooling vents are partially or totally
clogged.
■When the vacuum cleaner is covered with plastic
or fabric sheets.
■When the air outlet is partially or totally closed.
■When used in narrow areas where there is no
fresh air.
■Vacuuming the following materials:
1. Burning materials (embers, hot ashes, lit
cigarettes, etc.).
2. Open ames.
3. Combustible gas.
4. Flammable liquids, aggressive fuels (gasoline,
solvents, acids, alkaline solutions, etc.).
5. Explosive dust/substances and/or ones liable
to ignite in a spontaneous way (such as
magnesium or aluminum dusts, etc.).
IMPORTANT: Fraudulent use is not permitted.
Read the operating instructions and comply with the important safety recommendations identied
by the word WARNING!
Operator’s safety
WARNING!
Before starting the vacuum cleaner, it is
absolutely essential to read these operating
instructions and to keep them on hand for
consultation.
The vacuum cleaner can only be used by people who
are familiar with the way it works and who have been
explicitly authorised and trained for the purpose.
Before using the vacuum cleaner, the operators must
be informed, instructed and trained on how to work
it and for which substances its usage is permitted
including the safe method for removing and disposing
of the vacuumed material.
WARNING!
The use of vacuum cleaner by people (including
children) with limited physical and mental capacities
or lacking in experience and knowledge is strictly
forbidden, unless they are supervised by a person
who is experienced in the use and safe handling of the
machine.
Children must be supervised to make sure they will
not play with the vacuum cleaner.
General information for using the vacuum
cleaner
Use of the vacuum cleaner is governed by the laws in force in
the country where it is used.
Besides the operating instructions and the laws in force in
the country where the vacuum cleaner is used, the technical
regulations for ensuring safe and correct operation must
also be observed (Legislation concerning environmental and
labor safety, i.e. European Union Directive 89/391/EC and
successive Directives).
Do not carry out any operation that could jeopardize the safety
of people, property and the environment.
Comply with the safety indications and prescriptions in this
instruction manual.

VHS110N1 CR
04/2016 3C424
US
Versions
HEPA
This vacuum cleaner is always equipped with an upstream
(HEPA) lter. The procedures for servicing and emptying the
vacuum cleaner including removing the dust container, must
only be performed by authorized personnel wearing protective
clothing. Do not use without the complete lter system in
place.
[ NOTE ]
■In the case of dust harmful to health, contact the local
health and safety authorities, and observe national
regulations in force both during use and disposal.
■Radioactive substances are not included in the
denition of the type of dust harmful to health
described above.
General recommendations
WARNING!
If an emergency situation occurs:
■Filter breakage
■Fire outbreak
■Short-circuit
■Motor blockage
■Electric shock
■Other emergency situations.
Turn the vacuum cleaner off, unplug it and request
assistance from qualied personnel.
[ NOTE ]
Check the place of work and substances tolerated for the
vacuum cleaner suitable for liquids.
WARNING!
The vacuum cleaners must not be used or stored
outdoors, or in damp places.
Only versions with mechanical oater kit can be used
for liquids, if not, they can only be used to vacuum dry
materials.
DANGER !
Version for liquids.
If foam or liquid leaks out of the vacuum cleaner, turn
it off immediately, unplug it and contact qualied
personnel for assistance.

C424 404/2016
VHS110N1 CR
US
Vacuum cleaner description
Optional kits
Please contact the manufacturer’s sales network for
information on options.
Instructions for installing the options are included in the
conversion kit.
WARNING!
Use only genuine optional kits supplied and
authorized by the manufacturer.
Optional kits must be installed by Nilsk qualied
personnel.
Accessories
Various accessories are available; refer to the manufacturer’s
accessory catalog.
WARNING!
Use only genuine accessories supplied and authorized
by the manufacturer.
Packing and unpacking
Dispose of the packing materials in compliance with the laws
in force.
Figure 2
MODEL A
mm
B
mm
C
mm kg (*)
VHS110N1 CR 700 790 1440 53
* Weight with packaging
Unpacking, moving, use and storage
Operate on at, horizontal surfaces.
The load-bearing capacity of the surface the vacuum cleaner
is placed on must be suitable for bearing its weight.
Vacuum Cleaner Parts and Labels
Figure 1
1. Data plate which includes:
• Manufacturer’s name and address
• Technical specications
• Serial number
• Year of manufacture
• Weight (kg)
2. Panel power plate
Indicates that the panel must only be powered by the
voltage indicated on the data plate.
3. Inlet
4. Air Outlet
5. Manual motor starter
6. Motorhead
7. Band latches
8. Container release handle
9. Float for stopping liquids (optional)
10. Container for liquids
11. Inlet container for liquids
12. Lid
This vacuum cleaner creates a strong air ow which is drawn
in through the inlet (4) and blows out from the motor head
cover (5).
Before turning the vacuum cleaner on, t the vacuum hose
into the inlet and then t the required tool on the end of the
hose. After the hose and tools have been tted, make sure
that the motor turns correctly.
The vacuum cleaner is equipped with a main lter which
enables it to be used for the majority of applications.
Besides the main lter which retains the more common
types of dust, the vacuum cleaner is tted with an upstream
absolute (HEPA) lter with a higher ltering capacity for ne
dust and substances harmful to health.
Vacuuming of liquids (Optional)
The machine vacuums liquids and deposits them into the
container.
When the machine vacuums liquid materials must be
equipped with an optional oat for stopping liquids (9).
The oater stopping liquids requires a dedicated bin (10) with
apposite inlet (11).
Before turning on the vacuum cleaner close the top inlet with
the apposite lid (12) and t the vacuum hose into the inlet then
t the required tool on to the other end of the hose (refer to
the manufacturer’s accessory catalog or Service Center).
The oat (9) stops the vacuuming operation (the vacuuming
units remain activated) when the liquid container (10) is full; it
is then necessary to turn off the vacuum cleaner and to empty
the liquid container (10).
The vacuum cleaner does not shut off automatically.

VHS110N1 CR
04/2016 5C424
US
Setting to work - connection to the power
supply
WARNING!
■Make sure there is no evident sign of damage to
the vacuum cleaner before starting work.
■Before plugging the vacuum cleaner into the
electrical mains, make sure that the voltage rating
indicated on the data plate corresponds to that of
the electrical mains.
■Plug the vacuum cleaner into a plug with a
correctly installed ground contact/connection.
■Make sure that the vacuum cleaner is turned off.
■The plugs and connectors of the connection
cords must be protected against splashed water.
■Make sure that connections to the electrical
mains and plug are correct.
■Use the vacuum cleaners only when the cords
that connect to the electrical mains are in perfect
condition (damaged cords could lead to electric
shocks!).
■Regularly check that the electric cord does not
show signs of damage, excessive wear, cracks or
aging.
WARNING!
When the vacuum cleaner is operating, do not:
■Crush, pull, damage or tread on the cord that
connects to the electrical mains.
■Only disconnect the cord from the electrical
mains by removing the plug (do not pull the
cord).
■Only replace the electric power cord with one of
the same type as the original: SJT. The same rule
applies if an extension is used.
■The cord must be replaced by the manufacturer’s
Service Center staff or by equivalent qualied
personnel.
Extensions
If an extension cord is used, make sure it is t for the power
draw and protection degree of the vacuum cleaner.
Minimum section of extension cords: 16 AWG
Maximum length = 20 m
Cord = SJT
WARNING!
Sockets, plugs, connectors and installation of the
extension cord must maintain the IP protection degree
of the vacuum cleaner, as indicated on the data plate.
WARNING!
Never spray water on the vacuum cleaner: this could
be dangerous for persons exposed and could short
circuit the power supply.
WARNING!
The vacuum cleaner’s power plug must be protected
by a differential circuit-breaker with surge current
limitation that shuts off the power supply when the
current discharged to the ground exceeds 30 mA for
30 msec. or an equivalent protection circuit.
Wet and dry applications
[ NOTE ]
The supplied lters and the bag (if applicable) must be
installed correctly.
WARNING!
Comply with the safety regulations governing the
materials for which the vacuum cleaner is used.
WARNING!
If the version for liquids is used:
■If foam forms, turn off the vacuum cleaner
immediately and empty the container.
N.B.: Switch off the vacuum cleaner immediately if
foam or liquid leaks out.
■Regularly clean the liquid level limiting device
and check to make sure that there are no signs of
damage.
N.B.: dirty liquid vacuumed up by the vacuum cleaner
must be considered conductive.
WARNING!
When vacuuming a mix of water and air, take care to
avoid overloading the motor of the vacuum unit.
Vacuuming of liquids
WARNING!
Comply with the safety regulations governing the
materials for which the vacuum cleaner is used.
WARNING!
■Before vacuuming, check that the oat is present.
■If foam forms, turn off the vacuum cleaner
immediately and empty the container.
■Warning: switch off the vacuum cleaner
immediately if foam or liquid leaks out.
■Warning: the dirty liquid collected by the vacuum
cleaner must be considered conductive.
WARNING!
Do not use the vacuum cleaner without the oat!
If it’s used without the oat, the vacuum cleaner may
be seriously damaged.

C424 604/2016
VHS110N1 CR
US
Maintenance and repairs
WARNING!
Disconnect the vacuum cleaner from its power
source before cleaning, servicing, replacing parts or
converting it to another version/variant, the plug must
be disconnected from the socket.
■Carry out only the maintenance operations
described in this manual.
■Use only original spare parts.
■Do not modify the vacuum cleaner in any way.
Failure to comply with these instructions could
jeopardize your safety.
WARNING!
Contact the manufacturer’s technical service or sales
network for maintenance operations not described in
this manual.

VHS110N1 CR
04/2016 7C424
US
Technical data
Parameter Units VHS110N1 CR
Frequency Hz 60
Voltage, 1-phase V 120
Current draw A 7.5
Power rating @ 60 Hz HP (kW) 1.34 (1)
Noise Level, @ 3’ 3” (1 meter) ISO 3744 dB(A) 76
Protection IP 54
Motor insulation class Class A
Container capacity gal. (L) 9.77 (37)
Inlet diameter in. (mm) 2 (50)
Vibration, ah (*) m/s2≤2,5
Max vacuum (controlled) in. (mm) H2O 82.4 (2093)
Maximum air ow rate, blower CFM (L/min) 99 (2800)
Main lter surface area ft2 (m2) (10.76) 1
Upstream lter surface H14 - HEPA MPPS method (EN 1822) ft2 (m2) (11.84) 1.1
Power cord length ft (m) (30) 9
(*) Total value of vibration output to the operator arm and hand
Dimensions
Figure 3
Model VHS110N1 CR
A (mm) 570
B (mm) 560
C (mm) 1240
Weight (kg) 38.5
■Storage conditions:
Temperature : +14°F ÷ +104°F (-10°C ÷ +40°C)
Humidity: ≤ 85%
■Operating conditions:
Maximum altitude: 2,624 ft. (800 m)
[Up to 6,561 ft. (2,000 m) with reduced performances]
Temperature : +14°F ÷ +104°F (-10°C ÷ +40°C)
Humidity: ≤ 85%

C424 804/2016
VHS110N1 CR
US
Starting/stopping the vacuum cleaner
Figure 7
WARNING!
Lock the caster brakes (1) before starting the vacuum
cleaner.
Standard version
■Turn the manual motor starter (2) to the “I” position
to start the vacuum cleaner. Turn the manual motor
starter (2) to the “O” position to turn the vacuum cleaner
off.
Liquid vacuum stopping
■ When the tank is full, the oat (9 Fig.1) stops the
vacuuming operation; the vacuum units remain activated.
■Switch off the vacuum units by pushing the switches (5
Fig.5).
Vacuum cleaner operation
Figure 8
Vacuum gauge (2): green zone (3), red zone (1)
Check the ow rate:
■when the vacuum cleaner is operating, the pointer of
the vacuum gauge must remain in the green zone (3)
to ensure that the speed of the intake air does not drop
below the safety value of 3937 ft/min (20 m/s);
■if the pointer is in the red zone (1) it means that the
speed of the air in the vacuum hose is less than
3937 ft/min (20 m/s) and that the vacuum cleaner is
not operating optimally. The lter must be shaken or
replaced.
■during normal operation conditions, close the vacuum
hose, the pointer of the vacuum gauge must switch from
the green zone (3) to the red zone (1).
WARNING!
When the vacuum cleaner is operating, always check
that the vacuum gauge pointer remains in the green
zone (3).
Consult the “Troubleshooting” chapter if faults occur.
Safety devices
Figure 4
1. Cover
2. Cooling air HEPA lter
3. Motor
Controls, indicators and connections
Figure 5
1. Container release handle
2. Swivel caster with brake
3. PullClean lter cleaning system
4. Vacuum gauge
5. Manual motor starter
6. Band latches
7. Power supply cord
8. Push bar handle
Inspections prior to starting
Figure 6
1. Inlet
Prior to starting, check that:
■ The lter is installed;
■All latches are tightly locked;
■ The vacuum hose and tools have been correctly tted
into the inlet (1).
■The polyliner is installed (if applicable)
■ The oater inside the liquid container is present and
correctly installed (if applicable)
WARNING!
Do not use the device if the lter is faulty.

VHS110N1 CR
04/2016 9C424
US
Main lter cleaning
Figure 8-9
Depending on the vacuumed dust quantity and when the
pointer of the vacuum gauge switches from the green zone
(3, Fig. 8) to the red zone (2, Fig. 8), clean the main lters by
closing the inlet and opening the PullClean ap 3 or 4 times
for 1 or 2 seconds each time (1Fig.9).
Emergency stopping
Turn the manual motor starter to the “0” position.
Emptying the container
WARNING!
Before proceeding with these operations, turn off the
vacuum cleaner and remove the plug from the power
plug.
Before emptying the container it is advisable to clean the lter
(see “Main lter cleaning” paragraph).
At the end of a cleaning session
■Turn off the vacuum cleaner and remove the plug from
the socket.
■Coil the power supply cord and store it on the hanger at
the center of the handle (Fig. 8). Empty the container.
■ Remove the oat holding plate (if present).
■Clean the vacuum cleaner as described in the
“Maintenance, cleaning and decontamination” paragraph.
■Wash the container with clean water if aggressive
substances have been vacuumed.
■Store the vacuum cleaner in a dry place, out of reach of
unauthorized people.
[ NOTE ]
At the end of a cleaning session let the vacuum cleaner
run for at least 60 seconds before turning it off.
Avoid too frequent starts/stops.
Dust bag
The vacuum cleaner can be supplied with the dust bag (*)
(Fig. 10).
If the bag is not installed or is installed incorrectly, this could
create health risks for persons exposed.
Safe Dust Bag
The vacuum can be supplied with a dust bag (*) (Fig. 11).
If these bags are installed incorrectly, this could create health
risks for persons exposed.
(*) For the codes, see the Recommended Spare Parts table
How to change the bag
WARNING!
■These operations can only be carried out by
trained and qualied personnel who must wear
adequate clothing, in compliance with the laws in
force.
■Take care not to raise dust during these
operations. Wear an N100(P3) protective mask.
■In case of dangerous and/or toxic dust, you must
use the supplied safety bag for these certied
vacuum cleaners.
■The bag must only be disposed of by qualied
personnel and in compliance with the laws in
force.
WARNING!
Installing the wrong paper bag for the class of dust
to be vacuumed or incorrect installation, can create a
health risk for the persons exposed.
How to replace the Dust Bag
Figure 10
■Close the inlet by using the relevant lid. (1).
■Release the dust container.
■Remove the Dust Bag and close it.
■Insert a new bag, making sure the bag inlet is sealed.
■Replace the dust container in the vacuum cleaner.
WARNING!
Only use suitable bags for the vacuum cleaner class
you are using.
How to replace the Safe Bag
Figure 11
■Remove and put the vacuum hose in a safe and dust-
free place.
■Close the inlet by using the relevant lid (1).
■Release the dust container.
■Close the connection part between the two plastic inlets
with a plastic clamp (2)
■Remove the relevant connection (3) of the bag from the
inlet.
■Fix together the two plastic inlets (4).
■Close the plastic bag using the relevant band (5)
■Insert a new safe bag, making sure the bag inlet is
sealed.
■Wrap the plastic bag around the dust container external
wall.
■Replace the dust container in the vacuum cleaner.
WARNING!
Only use suitable bags for the vacuum cleaner class
you are using.

C424 10 04/2016
VHS110N1 CR
US
Maintenance, cleaning and
decontamination
WARNING!
To guarantee the safety level of the vacuum cleaner,
only original spare parts supplied by the manufacturer
should be used.
WARNING!
The precautions described below must be taken
during all maintenance operations, including cleaning
and replacing the primary and absolute lters.
WARNING!
The maintenance, cleaning and decontamination
operations must only be performed with the
vacuum cleaner turned off with switch and the plug
disconnected from the power socket.
It is absolutely forbidden to perform maintenance with
the plug connected to the socket.
Danger of electric shock!
■If the user is performing the maintenance operations,
the vacuum cleaner must be disassembled, cleaned
and overhauled as far as reasonably possible without
hazards for the maintenance personnel or other people.
The suitable precautions include decontamination before
disassembling the vacuum cleaner, adequate ltered
ventilation of the exhaust air from the room in which it
is disassembled, cleaning the maintenance area and
suitable personal protection.
■ A check must be carried out by qualied personnel at
least once a year. For example: check the air lters to
nd out whether the air-tightness of the vacuum cleaner
has been impaired in any way and make sure the electric
control panel operates correctly.
WARNING!
The procedures for servicing and emptying the
vacuum cleaner, including removing the dust
container, must only be performed by authorized
personnel wearing protective clothing.
Autoclavable parts
This vacuum cleaner is composed of autoclavable and NON
autoclavable parts.
- All stainless steel parts and silicone rubber gaskets can
be cleaned / decontaminated by means of an autoclave at
121C/250F this will secure an absolute decontamination of
the parts.
The autoclavable parts are:
• Trolley (without wheels)
• Dust container (with wheels and release handle)
• Filter chamber
• Screws, nuts etc.
• Silicone rubber gaskets
• Inlet (without seal to be replaced)
• All accessories: Hoses, nozzles and white silicone hose.
All NON autoclavalbe parts shall be cleaned by means an
appropriate detergents / sanitizers, to ensure an absolute
clean surface and to prevent any bacterial growth or the like.
The NON autoclavable parts are:
• Motor unit
• Machine wheels xed to the trolley
• Filter chamber with PullClean system
• Knobs for the lter chamber release
• Plastic parts
• Filter
• Bag
In order to secure a complete cleaning of the NON
autoclavable parts the appliance needs to be dismantled
before the cleaning operation.

VHS110N1 CR
04/2016 11 C424
US
Primary and absolute lter disassembly
and replacement
WARNING!
When the vacuum cleaner is used to vacuum
hazardous substances, the lters become
contaminated, therefore:
■work with care and avoid spilling the vacuumed
dust and/or material;
■place the disassembled and/or replaced lter in a
sealed plastic bag;
■close the bag hermetically;
■dispose of the lter in accordance with the laws
in force.
WARNING!
Filter replacement is a serious matter. The lter must
be replaced with one of identical characteristics,
ltering surface and category.
Otherwise the vacuum cleaner will not operate
correctly.
Primary star lter replacement
Figure 12
1. Band latch
2. Lid
WARNING!
Take care not to raise dust when this operation is
carried out.
Wear an N100(P3) mask and other protective clothing
including protective gloves (PPE/DPI) suited to the
hazardous nature of the dust collected, refer to the
laws in force.
Before proceeding with these operations, turn off the
vacuum cleaner and remove the plug from the power
socket.
■Use the band latches (1) to remove the lid (2) together
with the primary star lter.
■ Remove the old star lter from the cage.
■ Fit the new star lter.
■ Install the lid and the primary star lter in the reverse
order of removal.
■ Dispose of the old star lter according to the laws in
force.
If necessary contact the manufacturer’s Service Center.
Upstream absolute lter replacement
Version for dust harmful for the health
WARNING!
Take care not to raise dust when this operation
is carried out. Wear an N100 (P3) mask and other
protective clothing including protective gloves (PPE
/ DPI) suited to the hazardous nature of the dust
collected; refer to the laws in force.
WARNING!
Do not use the HEPA lter again after having removed
it from the vacuum cleaner.
Figure 13
1. Band Latch
2. Lid
3. Absolute lter /HEPA)
4. Stop nut (absolute lter)
■Stop the vacuum cleaner.
■ Remove the absolute lter (3) unscrewed the nut (4)
■ Cover the absolute lter (3) with a plastic bag, close
the plastic bag hermetically and dispose of the lter in
accordance with the laws in force.
■ Insert a new absolute lter (3) with the same ltering
characteristics as the removed one.
■ Lock the absolute lter with the nut (4).
■Close the cover hermetically by means of the band latch
(1).
Motor cooling fan inspection and cleaning
WARNING!
These operations can only be carried out by trained
and qualied personnel.
Periodically replace the motor cooling lters to prevent the
motor from overheating, especially if the vacuum cleaner is
used in a dusty place (2, Fig. 5).
Inspection
Filter chamber seal check
Figure 14
If the gasket (1, Fig. 14) between the container and the lter
chamber (3) fails to guarantee tightness:
■Loosen the four screws (2) that lock the ltering chamber
(3) against the vacuum cleaner structure.
■Allow the ltering chamber (3) to lower down and tighten the
screws (2) once it has reached the tightness position.
If an optimal seal cannot be obtained and the gasket (1) is
torn or cracked, etc. it must be replaced.
Wiring diagrams
Fig. 15
Item Type Description Qty.
P1 4083901741 Switch 3 pole 20A 1
J1 Z8 39219 Antijamming lter 10A 1

C424 12 04/2016
VHS110N1 CR
US
Recommended spare parts
The following is a list of spare parts that should be kept ready at hand in order to speed up maintenance operations.
Refer to the manufacturer’s spare parts catalog when ordering spare parts.
Description Model
VHS110N1 CR
Star lter 4081701220
Filter ring gasket ss Z8 17125
Filter chamber gasket 4081100188
Filter clamp 4084001291
Replacement upstream absolute (HEPA) lter Z8 17262
Dust bag (5 bags) 4084001003
Safe bag Z8 40874
Hepa motor cooling lter 4089100823
Ulpa motor cooling lter 4089100826
Motor
230V 4085400024
120V 408540026
Brushes (carbon) motors (2 brushes)
230V 40000885
120V 40000886

VHS110N1 CR
04/2016 13 C424
US
Troubleshooting
Problem Cause Remedy
The vacuum cleaner suddenly stops
Clogged primary lter Shake the lter. Replace it if necessary.
Clogged vacuum hose Check the vacuum hose and clean it.
Circuit breaker activation
Check the setting.
Check the motor electrical input. Contact
an authorized after-sales service center if
necessary.
Activation of the level monitoring system. Emptying of the liquid container.
Dust leaks from the vacuum cleaner
The lter is torn Replace it with another of identical type.
Inadequate lter Replace it with another of a suitable category
and check.
Electrostatic current on the vacuum
cleaner Non existent or inefcient grounding Check all ground connections. Especially check the connection at the inlet.

C424 14 04/2016
VHS110N1 CR
US
WARRANTY
Nilsk warrants that its equipment will be free of defects in workmanship or material for a period of two years from the date of
delivery. If the vacuum fails to meet these warranty standards, Nilsk shall, upon notication within such time period, correct
such non-conformity, at its option, either by repairing any defective part or parts, or by replacing a part or parts, provided that the
equipment is returned to an authorized Nilsk service facility. In all cases freight both ways will be at expense of the customer.
Equipment shall not be returned without advance notice to, and consent of Nilsk.
EXCEPT AS SPECIFICALLY SET FORTH HEREIN, NILFISK MAKES NO WARRANTIES, EITHER EXPRESSED OR
IMPLIED, AS TO ANY MATTER WHATSOEVER, INCLUDING WITHOUT LIMITATION ANY AND ALL WARRANTIES OF
MERCHANTABILITY, FITNESS OF PURPOSE, OR OTHER WARRANTIES, ALL OF WHICH ARE EXPRESSLY DISCLAIMED
AND EXCLUDED. NEITHER PARTY SHALL BE LIABLE TO THE OTHER FOR SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF PRODUCTION, LOSS OF PROFITS OR ANY
OTHER SIMILAR INDIRECT LOSSES WHICH MIGHT OCCUR AS A RESULT OF DEFECTS, PARTIAL OR TOTAL FAILURE
OF THE PRODUCT TO PERFORM AS SPECIFIED.
Correction of non-conformities or defects in the manner and for the period of time provided above, shall constitute fullment
of all liabilities of Nilsk to the customer, whether based on contract, negligence or otherwise with respect to, or arising out of
such equipment. The remedies set forth herein are exclusive, and the liability of Nilsk with respect to this sale or anything done
in connection therewith, whether in contract, in tort, under any warranty, or otherwise, shall not, except as expressly provided
herein, exceed the price of the equipment or part on which such liability is based.
This warranty does not cover repairs due to normal wear and tear, accident, neglect, misuse or abuse, incorrect installation or
use other than as described in the instruction booklet. Breaks in hoses and cables are not covered.
This warranty is rendered void if the motor number plate is removed or defaced or if repairs are made or attempted by persons
not authorized by Nilsk.
Some states do not allow exclusion of implied warranties or limitations on how long an implied warranty lasts so the above
exclusions or limitation of implied warranties may not apply. Some states do not allow exclusion or limitation of incidental or
consequential damages so the above exclusion or limitation of incidental or consequential damages may not apply. Limited
warranties set forth above give specic legal rights. Customer may have other rights which vary from state to state.
Nilsk, Inc. 740 Hemlock Rd., Suite 100, Morgantown, PA 19543, (800)-645-3475

VHS110N1 CR
04/2016 1C424
F
Table des matières
Mode d’emploi .................................................................................................................2
Sécurité de l’opérateur .................................................................................................................... 2
Informations générales sur l’utilisation de l’aspirateur..................................................................... 2
Utilisations prévues ......................................................................................................................... 2
Utilisations inappropriées ................................................................................................................ 2
Recommandations générales.......................................................................................................... 3
Description de l’aspirateur .............................................................................................4
Composants de l’aspirateur et étiquettes........................................................................................ 4
Options de transformation............................................................................................................... 4
Accessoires..................................................................................................................................... 4
Emballage et déballage................................................................................................................... 4
Déballage, manutention, emploi et stockage .................................................................................. 4
Mise en service - raccordement au réseau électrique..................................................................... 5
Rallonges ........................................................................................................................................ 5
Aspiration de substances sèches - aspiration de liquides............................................................... 5
Aspiration de liquides ...................................................................................................................... 5
Entretien et réparation..................................................................................................................... 6
Caractéristiques techniques............................................................................................................ 7
Dimensions...................................................................................................................................... 7
Dispositifs de sécurité ..................................................................................................................... 8
Commandes, indicateurs et connexions ......................................................................................... 8
Contrôles avant la mise en marche................................................................................................. 8
Mise en marche/arrêt de l’aspirateur............................................................................................... 8
Fonctionnement de l’aspirateur....................................................................................................... 8
Nettoyage des ltres primaires........................................................................................................ 9
Arrêt d’urgence................................................................................................................................ 9
Vidange de la cuve à poussières .................................................................................................... 9
À la n du nettoyage........................................................................................................................ 9
Sac à poussière............................................................................................................................... 9
Safe Bag pour collecte de poussière............................................................................................... 9
Mode de remplacement des sacs ................................................................................................... 9
Entretien, nettoyage et décontamination....................................................................................... 10
Pièces autoclavables..................................................................................................................... 10
Démontage et remplacement des ltres primaire et absolu...........................................................11
Remplacement du ltre étoile primaire...........................................................................................11
Remplacement du ltre absolu à l’aspiration..................................................................................11
Contrôle et nettoyage ventilateur de refroidissement moteurs.......................................................11
Inspection.......................................................................................................................................11
Schémas électriques......................................................................................................................11
Pièces détachées conseillées ......................................................................................12
Dépannage .....................................................................................................................13
GARANTIE.................................................................................................................................... 14
CLAUSE DE NON-RESPONSABILITÉ......................................................................................... 14
Traduction des instructions originales

C424 204/2016
VHS110N1 CR
F
Mode d’emploi
Utilisations prévues
L’aspirateur est spécialement conçu pour les salles blanches
Cet aspirateur est disponible en modèles pour aspiration à
sec ou de liquides.
Pour aspirer des substances corrosives, il faut utiliser la
version AISI 316L.
■Prévoir toujours un espace libre autour de l’aspirateur
pour permettre un accès aisé aux commandes.
La machine a été conçue pour être utilisée par un seul
opérateur.
Cet appareil est formé d’une unité d’aspiration motorisée,
précédée d’une unité ltrante et munie d’une cuve pour la
collecte de la matière aspirée.
Utilisations inappropriées
ATTENTION !
■L’utilisation systématique en plein air.
■L’utilisation de l’appareil sur des surfaces non
planes et non horizontales.
■L’utilisation sans l’unité ltrante prévue par le
fabricant.
■L’utilisation avec la bouche et/ou du tuyau
d’aspiration tournés vers le corps humain.
■L’utilisation sans les capots de protection ni les
systèmes de sécurité prévus par le fabricant.
■L’utilisation du convoyeur en bouchant
partiellement ou totalement les prises d’air de
refroidissement des composants intérieurs.
■Utilisation de l’aspirateur couvert par des toiles
en plastique ou en tissu.
■L’utilisation avec la bouche d’échappement d’air
complètement ou partiellement fermée.
■L’utilisation dans des endroits exigus, qui ne
permettent pas l’échange d’air.
■L’aspiration des matériaux suivants :
1. matières ardentes (braises, cendres chaudes,
cigarettes allumées, etc.).
2. ammes libres.
3. gaz combustibles.
4. liquides inammables, combustibles agressifs
(essence, solvants, acides, solutions alcalines,
etc.).
5. Poussières / substances et / ou mélanges
explosifs et à allumage spontané (poussières
de magnésium ou d’aluminium, etc.).
IMPORTANT : Toute forme d’utilisation frauduleuse est
interdite.
Lire les instructions du mode d’emploi et observer les avertissements importants de sécurité
repérés par la mention ATTENTION !
Sécurité de l’opérateur
ATTENTION !
Avant de mettre l’aspirateur en service, lire
absolument les instructions d’utilisation et
les garder à portée de main pour pouvoir les
consulter en cas de besoin.
L’utilisation de l’aspirateur est réservée exclusivement
au personnel expérimenté, formé et expressément
chargé du fonctionnement.
Avant l’utilisation, les opérateurs doivent être
instruits et formés à l’utilisation de l’aspirateur et
des substances pour lesquelles il doit être utilisé, y
compris la méthode sûre d’évacuation et d’élimination
de la matière recueillie.
ATTENTION !
Cet aspirateur ne doit pas être utilisé par des
personnes (y compris des enfants) présentant des
troubles psychiques, sensoriels ou mentaux ou ayant
un degré d’instruction et de connaissance insufsant,
à moins qu’ils soient toujours surveillées par des
personnes compétentes ou qu’ils aient reçu d’elles les
instructions d’utilisation de l’aspirateur.
Les enfants doivent être surveillés an qu’ils ne jouent
pas avec l’aspirateur.
Informations générales sur l’utilisation de
l’aspirateur
L’utilisation de l’aspirateur est soumise aux normes
internationales en vigueur.
En plus des instructions du mode d’emploi et des règlements
en vigueur dans le pays où l’aspirateur est utilisé, pour la
prévention des accidents il est nécessaire d’observer les
règles techniques pour un travail sûr et correct (Législation
relative à la sécurité sur le lieu de travail, Directive
Communautaire 89 / 391 / CE et suivantes).
Eviter tout travail pouvant porter atteinte à la sécurité des
gens, des choses et de l’environnement.
Observer les informations et les prescriptions de sécurité
contenues dans ce manuel d’instructions.

VHS110N1 CR
04/2016 3C424
F
Versions
FILTRE HEPA
Cet aspirateur est toujours équipé d’un ltre (HEPA) à
l’aspiration. Les procédures d’entretien et de vidange, y
compris le retrait de la cuve à poussière, doivent être conées
exclusivement à du personnel agréé, qui doit porter un
habillement protecteur. Ne pas faire fonctionner sans système
de ltration complet.
[ REMARQUE ]
■En cas de poussières nocives pour la santé,
s’adresser aux autorités nationales préposées à
la santé et la sécurité, et respecter les normatives
nationales en vigueur pendant l’emploi et l’élimination.
■Les substances radio-actives ne font par partie par
dénition du type de poussières nocives pour la
santé, décrites plus haut.
Recommandations générales
ATTENTION !
En cas d’émergence :
■Rupture du ltre
■Incendie
■Court-circuit
■Blocage du moteur
■Choc électrique
■Autres situations d’urgence.
Arrêter l’aspirateur, débrancher la che et demander
l’intervention de personnel spécialisé.
[ REMARQUE ]
Vérier les substances admises et la zone de travail en
cas d’aspirateur en version liquides.
ATTENTION !
Les aspirateurs ne doivent pas être utilisés ou stockés
en plein air ou en présence d’humidité.
Seules les versions à option de otteur mécanique
peuvent être utilisées pour aspirer des liquides,
dans le cas contraire elles peuvent être utilisées
uniquement pour aspirer à sec.
DANGER !
Version pour liquides.
En cas de sortie de mousse ou de liquide, éteindre
immédiatement l’aspirateur, débrancher la che et
demander l’intervention de personnel spécialisé.

C424 404/2016
VHS110N1 CR
F
Description de l’aspirateur
Options de transformation
Pour les options de transformation, veuillez contacter le
réseau commercial du fabricant.
Les instructions pour l’installation des parties en option sont
contenues dans le kit de transformation.
ATTENTION !
Utiliser uniquement des options d’origine fournies et
autorisées par le fabricant.
Les kits en option doivent être installés par du
personnel qualié Nilsk.
Accessoires
Plusieurs accessoires sont disponibles ; veuillez consulter le
catalogue des accessoires du fabricant.
ATTENTION !
Utiliser uniquement des accessoires d’origine fournis
et autorisés par le fabricant.
Emballage et déballage
Éliminer les matériaux de l’emballage conformément à la
législation en vigueur.
Figure 2
MODELE A
mm
B
mm
C
mm kg (*)
VHS110N1 CR 700 790 1440 53
* Poids avec emballage
Déballage, manutention, emploi et
stockage
Travailler sur des surfaces plates et horizontales.
La portée du plan d’appui doit être adaptée au poids de
l’aspirateur.
Composants de l’aspirateur et étiquettes
Figure 1
1. Plaque de données, spéciant :
• Raison sociale et adresse du fabricant
• Données techniques
• Numéro de série
• Année de fabrication
• Poids (kg)
2. Plaque du tableau sous tension
Signale la mise sous tension indiquée sur la plaque à
l’intérieur du tableau.
3. Embout
4. Bouches d’échappement d’air
5. Démarreur du moteur manuel
6. Tête
7. Loquets de fermeture
8. Poignée de décrochage cuve
9. Flotteur pour arrêt de liquide (en option)
10. Cuve à liquides
11. Cuve à bouche à liquides
12. Portillon
Cet aspirateur produit un puissant ux d’air qui est aspiré par
la bouche d’aspiration (4) et est émis par le couvercle de la
tête du moteur (5).
Avant de mettre l’aspirateur en marche, brancher le tuyau
d’aspiration dans la bouche et monter l’accessoire adapté au
travail à effectuer sur l’extrémité du tuyau. Après avoir mis le
tuyau et les accessoires en place, vérier la juste rotation du
moteur.
L’aspirateur est équipé d’un ltre primaire qui permet le
fonctionnement de la plupart des applications.
En plus du ltre principal qui retient les types ordinaires de
poussières, l’aspirateur est équipé d’un ltre absolu (HEPA) à
l’aspiration, à haut pouvoir ltrant, pour les poussières nes et
les substances nocives pour la santé.
Aspiration de liquides (en option)
La machine aspire les liquides et les dépose à l’intérieur de la
cuve.
Lorsque la machine aspire les liquides, elle doit être équipée
d’un otteur en option pour arrêter les liquides (9).
Le otteur d’arrêt des liquides exige un bac spécial (10) avec
une bouche prévue à cet effet (11).
Avant de mettre l’aspirateur en marche, fermer la bouche
supérieure avec le couvercle prévu à cet effet (12) et brancher
le tuyau d’aspiration dans la bouche correspondante puis
monter l’accessoire indiqué pour le travail à faire sur l’autre
extrémité du tuyau (consulter le catalogue des accessoires ou
contacter le service après-vente du fabricant).
Le otteur (9) arrête l’aspiration (les unités d’aspiration restent
en fonction) quand la cuve de récupération de liquide (10) est
pleine. Il est nécessaire d’éteindre l’aspirateur et de vidanger
la cuve du liquide (10).
L’aspirateur ne s’arrête pas automatiquement.
