Attix Wet/Dry Series
The Attix 8, 12 and 19: The industry standard for wet/dry vacuums

WAP HEPA filter systems meet the following standards:
ANSI Z9.2-1979 EPS 560-OPTS-86-003
OSHA 1910.1001 MIL 51058 F
EPA 560-OPTS-86-002 DOE Nuclear Standard NE F 3-43
HEPA standards also applicable to WAP Attix 12
WARNUNG. Dieses Ger�tenth�ltgesundheitsgef�hrlicheSt�ube.
Entleerung und Wartung, einschlie§lich der Entfernung des
Staubbeutels, dŸrfennur von sachkundigen Personen vorgenommen
werden, die geeignete pers�nlicheSchŸtzausrŸstungtragen.
Nicht einschalten, bevor das komplette Filtersysteminstalliert ist und
die Funktion der Volumenstromkontrolle ŸberprŸftwurde.
MM
ATTIX 8 - designed to improve mobility
With the new WAP ATTIX 8, Nilfisk-ALTO widens the wet/dry vacuum range.
The vacuum is the perfect solution for craftsmen and other professionals in
woodworking, drywall, and automotive industries. Bring the ATTIX 8 with
you to remove all traces of dust and dirt. You will experience a power sur-
plus greater than one would expect from such a small machine.
Silent Operation
The low noise level of 59 dB(A) is a luxury feature for a
comfortable working environment
Cable hook & Accessory Holder
Have everything in one place. It also allows for proper storage
after use.
New Container Design
The slim design allows for an easy transport. The container has
no rips and no secret corners inside, so emptying is not a problem.
ATTIX 8 SERIES
WET/DRY ON THE MOVE
WAP ATTIX 8
HEPA Options
Mobile & Compact - With Light Weight
Filter Cleaning System
A unique, compact and flexible vacuum cleaner. The only
vacuum in the market that alerts users when the filter
needs cleaning.*

Push&Clean button*
For cleaning the filter just
cover the fitting or the
tube and press the button.
PET-fleece* filter cartridge
Washable and long lasting
filter cartridge with high
filtration rate for a clean air.
If your work is with “normal” dirt, you may not
need a filter cleaning system... But if you are
working with fine dust, you are surely familiar
with the dreaded task of cleaning clogged filter
cartridges to restore normal suction perfor-
mance.
With Push&Clean, all you have to do to clean
the filter is to cover the fitting or the hose and
press the button. Powerful air pulses will clean
the filter gently, and you are back to work in
no time.
The Push&Clean system:
• Keepssuctionperformanceconstantlyhigh
• Extendsthelifeofthefilterandreduces
your costs
• Savesyouworkingtime
• Improvesthereliabilityofthemachine
Push&Clean filter cleaning technology
The Push&Clean technology allows a fast and
simple cleaning of the filter cartridge. When you
block the fitting for the air inlet or the hose and
push the filter cleaning button, the surrounding
air enters into the container, passing through
the filter cartridge in the opposite direction.
The dirt is blasted off the filter and the suction
performance is high again. A comfortable and
powerful but gentle way of cleaning the filter.


Filter Cleaning System
Audio filter alarm
A high-pitched alarm will notify the user that the filter needs cleaning.
Ergonomic and sturdy grip
The machine can be moved round in an easy and comfortable way
even with a full container.
Round switch and auxiliary power outlet
The switch can be easily used, even with gloves. It always indicates
whether the machine is on or off. The automatic auxiliary power
outlet* allows you to use electric tools.
SoftStart*
A gentle start-up motor keeps starting current low and prevents voltage.
Power Regulator*
To adjust suction performance and to prevent the power tool from
sticking to the work surface.
Superior Suction Performance
The power you need for better cleaning with less effort in less time.
Hose selection feature*
Adjustment for various diameter of suction hose for optimum cleaning.
*Standard on Attix AS/E


ATTIX 12 SERIES
XTREME SILENCE
Xtreme Efficiency
Superior suction power, silent operation and new
innovative features.
The Most Silent Worker Around
Even when it does the tough jobs, you won't notice. The
ATTIX 12 was developed with many improvements and
a new design. Additionally, it gives you the most silent
operation of the WAP line. Then add superior suction perfor-
mance, automatic filter cleaning, and anti-static features, and
you have the perfect wet/dry vacuum for the body shop, rental
store, and manufacturing industries.
Silent Operation
The low noise level of 59 dB(A) is a luxury feature for a
comfortable working environment
Cable hook & Accessory Holder
Have everything in one place. It also allows for proper storage
after use.
Extra large wheels and castors
Good mobility even on different or uneven surfaces.
Application-Specific Models Available
Automatic Filter Cleaning System

Ergonomic and sturdy grip
The machine can be moved round in an easy and comfortable way
even with a full container.
Round switch and auxiliary power outlet
The switch can be easily used, even with gloves. It always indicates
whether the machine is on or off. The automatic auxiliary power
outlet* allows you to use electric tools.
SoftStart*
A gentle start-up motor keeps starting current low and prevents voltage.
Power Regulator*
To adjust suction performance and to prevent the power tool from
sticking to the work surface.
AntiStatic Feature
To prevent shocks and dirt caused by static charges.
Hose selection feature*
Adjustment for various diameter of suction hose for optimum cleaning.
WAP now offers the impressive filter clean-
ing system called XtremeClean. The name is
characteristic for the cleaning level of this
system: Extremely efficient and completely
automatic, saving you time and money.
The best filter cleaning system that the
market has ever seen.
All you have to do is start the vacuum. The
filter is immediately cleaned automatically,
and every 30 seconds while you work. So
there is no need to interrupt your work to
clean the filter. You concentrate on your
task, and XtremeClean will take care of the
filter.
Powerful air pulses clean
the filter gently and:
• Keepthesuctionperformance
constantly high
• Extendthelifeofthefilterandreduce
your costs
• Saveyouworkingtimewithout
interruptions
• Improvethereliabilityofthemachine
•Word-Patended
XtremeClean filter cleaning technology
Advanced technology delivers automatic filter
cleaning while you work with full vacuum
performance. The XtremeClean technology is based
on a valve controlled solution, using reversed air
flow to clean the one half of the filter cartridge
- while you still work with the other half of the filter
cartridge. The valve allows the surrounding air to
enter into the container, passing through the filter
in the opposite direction. The dirt is blasted off the
filter and the suction performance is restored.
Automatic Filter Cleaning System
*Standard on different variants


Nilfisk-ALTO OFFERS MORE
DEDICATED SOLUTIONS...
In order to accommodate specific customer needs, Nilfisk-ALTO has developed a full range of
accessories and accessory sets. You will find more accessories and more sets in the main
Nilfisk-ALTO catalog.
Accessories for ATTIX 8 & 12
Filter Cartridge
Filter cartridge made of washable PET-fleece
with high filtration rate and long service life.
Cloth filter insert "special"
Additional filtration stage with high-level fil-
tration efficiency. Best suitable for very fine
dust mixed with moisture. For those that
work without filter bags. Made of needled
felt. Plastic coated.
Filter bags
2-ply filter bag in sturdy quality and with high
filtration rate. PU 5 pcs. The original Nilfisk-
ALTO quality.
Accessory net
Helps carrying different goods like
accessories or small tools. Content is visible.
Kitincludesscrews.
Handle, folding
Offers an extreme comfortable handling
whenthemachineistransported.Kitincludes
screws.
Exhaust air collector
To collect the exhaust air and lead it out
of the room. Ideal for 100% clean rooms.
Can also be used to blow some dirt out of
hard-to-reachplaces.Kitincludesscrews.
ATTIX 8 302 000 449
ATTIX 12 302 000 527
ATTIX 8 & 12 302 000 490
ATTIX 12 XtremeClean 302 000 751
ATTIX 8 & 12 302 000 606
ATTIX 12 302 000 525
ATTIX 8 302 000 607
ATTIX 12 302 000 524
ATTIX 8 & ATTIX 12 302 000 522 ATTIX 8 302 000 523

Nilfisk-ALTO OFFERS MORE
DEDICATED SOLUTIONS...
In order to accommodate specific customer needs, Nilfisk-ALTO has developed a full range of
accessories and accessory sets. You will find more accessories and more sets in the main
Nilfisk-ALTO catalog.
Accessory net
For transportation of even more
accessories, an accessory net is
available and can be mounted
on the vac.
Handle (Folding)
A comfortable way to transport
your vac.
Exhaust air collector
If you want to get rid of the
vacuumed air - just use the
exhaust air collector. Can also
be used to blow some dirt out
of hard-to-reach places.
 
Selection of some accessory sets
Industrial set No. 63216
•6-piece,2-inchdiameterconnection
13-foot suction hose 15358
•Anodisedaluminiumextensiontube 15335
•Industrialfloornozzle,aluminium 15343
•Replacementrubberlips 15346
•Crevicenozzle,specialplastic 7102
•Coarsedirtnozzle,aluminium 41100
Industrial/floor set No. 63214
•4-piece,1.5-inchdiameterconnection
13-foot suction hose, oil-resistant 61779
•Curvedhandtube,stainlesssteel 46691
•2Suctiontubes,stainlesssteel 15546
•Large-capacityfloornozzle
with rubber lips 15349
Pipe cleaning set No. 63215
•4-piece,1.5-inchdiameterconnection
13-foot suction hose 15365
•8-footanodisedaluminium
extension tube 15340
•Tubecleaningnozzles
2.75 - 4.75-inch diameter 7964
4.75 - 7.75-inch diameter 8054
Chip set No. 61681
•2-piece,2-inchdiameterconnection
13-foot aluminium suction hose 15182
•Diagonaltubenozzle,rubber 7868
Oven cleaning set No. 14341
•3-piece,38mmdiameterconnection
4 m suction hose 6070
•2.5manodizedaluminium
extension tube 15340
•Ovennozzle“XL” 63380
Animal Care Set No. 6095
•4-piece,1-inchconnection
11-foot suction hose 14289
•Spikedcurrycomb 6094
•Currycomb 6092
•Ovennozzle“XL” 6093


The new Attix 19-gallon wet/dry vacuum features the
XtremeClean filter-cleaning system*, the best filter-
cleaning system the market has ever seen.
With the XtremeClean system, there’s no need to stop
working as the filter is continually being cleaned
automatically. There are no buttons to press, no
canisters to open -- no manual effort at all.
Powerful air pulses gently clean the filter and:
 •Reducedowntime
 •Keepsuctionperformanceatitspeak
 •Improvethereliabilityofthemachine
 •Extendthelifeofthelter
 •Saveyoumoney
*Available on select models only
XtremeClean technology lets you keep working longer,
even when working with fine dust.
ÅXtremeClean filter-cleaning system
ÇSemi-automatic filter-cleaning systems
ÉManual filter-cleaning systems
ERGONOMIC DESIGN
Comfortable handle, tilt or
lift-out container, handy
tool tray and suction
tube holder.
SILENT POWER
Works at a low 57d(B)A
STURDY
Steelframeand
stainless-steel
canister
ATTIX 19 SERIES
REVOLUTIONARY
The revolution in wet/dry vacuums
Automatic Filter Cleaning System

Mobility and Transport
With a comfortable, integrated handle, it’s easy to take
the Attix 19 wherever the work is.
Versatile and Flexible
Tilt the container to empty, or simply lift it out of the frame to dispense
of its contents elsewhere.
HIGH PERFORMANCE
Two-stage turbines and bypass motors
VERSATILITY
Tilting, removable container;
optional features including
XtremeClean and automatic on/off
TheAttix19Seriesis
ideal for:
Rental
BodyShops
Industrial
Oil & Lube
Automotive
Construction
Food Processing
Manufacturing
Hospitality
Agriculture
Pharmaceutical
No situation or job is too
tough for the Attix 19
Flood Sucker

Attix Series Specifications
l- Standard Accessory/Feature m- Optional Accessory/Feature
ATTIX 12 AS/PE XC
302000588
1.6
8.25
140
105
57
12
20 x 19 x 26
53
l
l
l
XTREME Clean
l
l
l
l
l
Electric/Pneumatic
l
1.25 x 16 (Coaxial)
Chrome
Chrome
l
m
m
m
m
l
l
l
1
m
Part Number
Power HP
Power Peak HP
Air Flow CFM
Vacuum Waterlift in.
Working Noise d(BA)
Container volume gallons
L x W x H in.
Weight/Shipping lbs.
Standard Features:
Accessory Holder
AntiStatic Suction Hose
Cable Hook
Filter Cleaning System
Rubber Cable
Receptical
SoftStart
Power Regulator
Tool Deposit
Auto On/Off
Audio Filter Alarm
Auto Cleaning
Standard Accessories:
Hose (dia x length) in. x ft.
Curved Wand
Extension Tube
Tube Holder
Floor Nozzle - Combi
Metal Floor Nozzle
Crevice Nozzle
Brush Nozzle
Universal Nozzle
Tool Adapter
Filter Cartridge - Fleece
Filter Bags
HEPA Filter
ATTIX 8
302000405
1.6
7.25
120
90
59
8
15 x 15 x 22
35
l
l
l
l
1.5 x 10
Chrome
Chrome
l
l
m
l
l
l
m
l
1
m
ATTIX 8 AS/E
302000414
1.6
7.25
120
90
59
8
15 x 15 x 22
35
l
l
l
Push&Clean
l
l
l
l
l
Electric
l
1.25 x 16
Chrome
Chrome
l
l
m
l
l
l
l
l
1
m
ATTIX 8 HEPA
900120
1.6
7.25
120
90
59
8
15 x 15 x 22
35
l
l
l
l
1.5 x 10
Chrome
Chrome
l
l
m
l
l
l
m
m
1
l
ATTIX 12
302000573
1.6
8.25
140
105
57
12
20 x 19 x 26
53
l
l
l
l
1.5 x 10
Chrome
Chrome
l
l
m
l
l
l
m
l
1
m
ATTIX 12 RDF
302000582
1.6
8.25
140
105
57
12
20 x 19 x 26
53
l
l
l
l
l
l
1.5 x 10
Chrome
Chrome
l
m
l
m
m
l
l
l
1
m
ATTIX 12 HEPA
900121
1.6
8.25
140
105
57
12
20 x 19 x 26
53
l
l
l
l
1.5 x 10
Chrome
Chrome
l
l
m
l
l
l
m
m
1
l
ATTIX 12 RDFD XC
302000585
1.6
8.25
140
105
57
12
20 x 19 x 26
53
l
l
XTREME Clean
l
l
l
l
l
Electric
l
1.5 x 10
Chrome
Chrome
l
m
l
m
m
l
l
l
1
m
Attix 8 & 12 Series

MODEL Standard RDFL AS/PE 2 HEPA AE
PART NUMBER 302001540 900125 302001542 900124 302001541
Power HP 1.6 1.6 1.6 1.6 1.6
Power Peak HP 8.25 8.25 8.25 8.25 8.5
Air Flow CFM 140 140 140 140 140
Water Lift in. 105 105 105 105 105
Noise Level d(BA) 57 57 57 57 57
Container Volume gallons 19 19 19 19 19
L x W x H in. 24 x 23 x 38 24 x 23 x 38 24 x 23 x 38 24 x 23 x 38 24 x 23 x 38
ShippingWeightlbs. 78 78 92 85 97
Accessory Holder Yes Yes Yes Yes Yes
Anti-StaticSuctionHose No No Yes No No
Cable Hook Yes Yes Yes Yes Yes
Filter-CleaningSystem No No XtremeClean No No
RubberCable Yes Yes Yes Yes Yes
Receptacle No Yes Yes No Yes
SoftStart Yes Yes Yes Yes Yes
PowerRegulator No Yes Yes No No
Tool Deposit Yes Yes Yes Yes Yes
Auto On/Off No No Electric/Pneumatic No No
Auto Cleaning No No Yes No No
Hose (diameter x length) (in x ft) 1.5” x 13’ 1.5” x 13’ 2x(1.25” x 16’) 1.5” x 13” 1.5” x 13’
Curved Wand (Part# 46691) lllll
ExtensionTube(Part# 15546) mllll
Metal Floor Nozzle (Part# 5147) m l l l IndustrialSqueegee
(Part# 5149)
Crevice Nozzle (Part# 6084) llmlm
RubberNozzle(Part# 5067) lmmlm
Tool Adapter (Part# 300200535) m m l m m
Filter Cartridge (washable) (Part#
302000461/302000751) lllll
Filter Bag - 5 Pack (Part# 302001484) llll
Anti-StaticHose(Part# 30657) m m l m m
InletandYConnector(Part#
15953/15331) m m l m m
l- Standard Accessory/Feature m- Optional Accessory/Feature
Attix 19

DISTRIBUTED BY:
©2002Nilsk-ALTOCleaningSystems,Inc.AllRightsReserved.Specicationssubjecttochangewithoutnotice.P/N888003711/07
The Attix 8isunique,compact,andexible.Itoffersalownoiselevelof59d(BA),
anergonomicandsturdygrip,andacablehookandaccessoryholder.Ialsofeatures
superior suction performance, all in a slim package, easy to transport and store.
Powerful vacuum motor generates 120 CFM and 90” of water lift•
Quiet motor technology generates low noise rating of 57 d(BA)•
8 gallon tank capacity•
PET-eeceltercartridgeiswashableforlonglife•
Smoothinteriortankdesignmakesdumpingeasyandclean•
Hose,wand,oortool,andattachmentsincluded•
The Attix 12 offers high suction performance and innovative features, like a power
regulatorthatadjustssuctionperformance,anAntiStaticfeaturethatpreventsshocks,
andanadjustablehoseselectionfeature.Italsoofferssilentoperationat57d(BA),a
cable hook, tube and accessory holder, and an ergonomic and sturdy grip.
Powerful vacuum motor generates 140 CFM and 105” of water lift•
Quiet motor technology generates low noise rating of 57 d(BA)•
12 gallon tank capacity•
PET-eeceltercartridgeiswashableforlonglife•
Motor brush “switch off” technology protects the motor when brushes are worn•
Hose,wand,oortool,andattachmentsincluded•
The Attix 19ispowerful,butveryversatile.Itsportsacomfortablehandleandtube
holder and offers power in the form of two-stage turbines, but at a silent level at
57d(BA).Itssteelframeandcanistermakeitruggedanddependable.Thetilting,
removable container makes it extremely user friendly.
Powerful vacuum motor generates 140 CFM and 105” of water lift•
Quiet motor technology generates low noise rating of 57 d(BA)•
19 gallon tank capacity•
Sturdydollmountconstructionallowsforeasytransport•
Durable stainless steel canister•
Tilting canister feature makes it easy to dump contents•
Attix Wet/Dry Series
Nilfisk-ALTO Cleaning Systems
2100Highway265South•Springdale,AR72764
Phone:877.366.2586•Fax:800.405.9092
[email protected]•www.nilsk-alto.us
