nimble GT-3950 User manual
QUAD BLADE
4 CHANNEL 2.4GHz
NANO RC QUADCOPTER
GT-3950
SAFETY NOTES______________________________________________
CAUTION
The product can be a dangerous toy. Please take care to fly the unit away from people and pets, avoiding
heat, power lines and power sources.
The manufacturer and distributor of this
product will not be liable for any damages incurred by using this
product incorrectly.
Never disassemble any part of the PCB or any other internal components.
KEEP AWAY FROM MOISTURE
R/C quadcopters are composed of many precise electrical components. It is critical to keep the unit and
accessories away from moisture and other contaminants. The exposure to liquid or moisture in any form
can cause the unit to malfunction. DO NOT expose to liquid or moisture as this will void your warranty.
KEEP AWAY FROM HEAT
R/C quadcopters are made of various forms of plastic. Plastic is very susceptible to damage or
deformation due to extreme heat and cold climates. Make sure not to store the unit near any source of
heat such as an oven or heater. It is best to store the model indoors, in a climate-controlled room
temperature environment.
PROPER OPERATION
To avoid potential fire hazard from batteries, please do not short, insert in reverse polarity, or puncture
batteries. Battery charging must be done under supervision at all times, and at location out of reach by
children.
SAFETY FOR NI-MH BATTERIES
Make sure the batteries are installed based on the polarity indicated in the case and DO NOT mix new
and old batteries or batteries of different chemistry or specification. Please take out the batteries if you
are not going to use the product for a long time to avoid potential leakage which may damage the unit.
Please dispose of used batteries in the correct way.
SAFETY FOR LI-POLYMER BATTERIES
Li-Polymer batteries poses higher operational risks compared to other batteries, thus it is imperative to
follow its usage instructions. The manufacturer and distributor of this product will not be liable for
damages caused by improper usage.
DO NOT use the charger other than the factory supplied unit to avoid potential fire and explosion.
DO NOT crush, disassemble, burn, or enter in reverse polarity. Avoid metallic materials coming into
contact with the battery as this will cause the battery to short. NEVER puncture batteries and avoid fire
hazards.
Battery charging must be done under supervision at all times, and at a location out of the reach of
children.
Please stop the use or charge of the battery should there be an unusual increase in battery temperature
after use. Continue use of this battery may cause it to expand, deform, result in fire, or even explosion.
Please dispose of used batteries in the correct way.
OBTAIN THE ASSISTANCE OF AN EXPERIENCED PILOT
The products are suitable for people over the age of 8 years old.
In the beginning, the quadcopter may be difficult to learn to operate. Ask for guidance from an
experienced user if help is needed.
ACCESSORIES_______________________________________________
PARTS EXPLANATION________________________________________
Quadcopter Canopy Top View
Remote Control Bottom View
Quadcopter Top View without Canopy
Throttle
REMOTE CONTROL BATTERY INSTALLATION______________________
CHARGING THE BATTERIES____________________________________
Plug the USB charger into the quadcopter. The red charging light will turn on when the charging is
complete.
BATTERY AND CHARGER SPECIFICATIONS________________________
Battery Location
Battery Specification
Usage Duration
Charge Time
Quadcopter
3.7V 100mAh
Flight time approx. 4
mins
Approx. 30 mins
(Charging current
approx. 0.2A
Remote Control
1.5V
Approx. 18 hours
N/A
Use a screwdriver to loosen the screws
on the remote control battery cover.
Open the battery Cover
Insert 2 x AA batteries in the correct
polarity, as indicated on the unit.
Do not mix new and old batteries, or
batteries of different specification.
SYNCING THE REMOTE CONTROL TO THE QUADCOPTER____________
Step 1:
Turn on the power of the quadcopter by
flipping the power switch located on the
underside.
Place the quadcopter on a flat surface
so that the gyroscope can calibrate. The
status indicator will flash during
calibration.
Step 2:
Turn on the power of the remote
control by flipping the power switch.
Push the throttle from the lowest to the
highest, and then back to the lowest.
The syncing is now complete.
Remote Action_____________________________________________
Remote Action
Quadcopter Movement
Direction
Joystick
Left/Right
Direction
Joystick
Up/Down
Throttle
Joystick
Up/Down
Throttle
Joystick
Left/Right
TRIM ADJUSTMENT__________________________________________
Adjustment of the Left/Right Trim:
-If the quadcopter keeps leaning to the left, please adjust the trim (left/right) to the RIGHT until it
stops flying to the left.
-If the quadcopter keeps leaning to the right, please adjust the trim (left/right) to the LEFT until it
stops flying to the right.
Adjustment of the Forwards/Backwards Trim:
-If the quadcopter keeps going forward, please adjust the trim (forward/backward) DOWN until it
stops flying forward.
-If the quadcopter keeps going backward, please adjust the trim (forward/backward) UP until it
stops flying backward.
Distributed by:
TechBrands by Electus Distribution Pty. Ltd.
320 Victoria Rd, Rydalmere
NSW 2116 Australia
Ph: 1300 738 555
Int’l: +61 2 8832 3200
Fax: 1300 738 500
www.techbrands.com
