Nimbus Water Systems CS-3 User manual

1
41840-A McAlby Court, Murrieta, CA 92562
[phone], www.nimbuswater.com
REV: 0507
Nimbus CS-3
Reverse Osmosis System
05/09
41840 McAlby Court, Suite A
Murrieta, CA 92562
800-451-9343, FAX [phone]
www.nimbuswater.com

2
41840-A McAlby Court, Murrieta, CA 92562
[phone], www.nimbuswater.com
Congratulaons on your purchase of the Nimbus CS-3 reverse osmosis system. When properly maintained, this system will
provide you with years of trouble-free service. The next secons contain important informaon on the proper care and
maintenance of your system, please take a few minutes to read through this informaon.
The cartridges in this system must be replaced on a regular basis to maintain efficiency and to safeguard water quality.
These cartridges work together to remove potenal contaminants from your tap water and must be replaced every 6-12
months. Any significant change in performance of the system should be invesgated promptly to avoid secondary damage
or deterioraon to other parts of the system.
Introducon to the CS-3
Descripon Replacement
Interval
RO Membrane Desalinator 12 months
Pre-filters 6-12 months
Post-Filter 12 months
In-line Carbon Filter 12 months
Tested at 60 psig (4 bar), 500ppm TDS municipal water, 77°F
(25°C)
Feed Water Requirements
System Specificaons
Replacement Cartridges
Membrane System w/Tank
Producon 36 GPD
(136.3 LPD)
11.3 GPD
(42.8LPD)
TDS Rejecon 95% 95%
Pressure 40-80 psi (275 kPa - 552 kPa)
Temperature 40°F - 100°F (4°C - 38°C)
TDS <2000 mg/L
Chlorine <1.0 mg/L
NTU <1
SDI <5
pH 4-8
Feed water must be potable, municipal water. Must be free
of potenal membrane foulants such as Iron, Hydrogen
Sulfide and Manganese.

3
41840-A McAlby Court, Murrieta, CA 92562
[phone], www.nimbuswater.com
The Limited Warranty extends to the original purchaser of the system. This warranty covers all parts and factory labor needed to repair any Man-
ufacturer-supplied item that proves to be defecve in material, workmanship or factory preparaon. The above-menoned warranty applies for
the first full calender year from date of purchase. These defecve items are subject to the following exclusions: membranes, filters, O-rings, and all
other parts or components that require regular replacement as a result of ordinary usage.
Disclaimers This Warranty applies only if the system is installed and used in compliance with the instrucons enclosed with the system.
This Warranty does not cover the costs of repairs or adjustments to the unit that may be needed because of the use of improper parts, equipment
or materials. This Warranty does not cover repairs required due to unauthorized alteraons of the unit, or failure of a unit caused by such altera-
ons or by unauthorized repairs.
The Warranty does not cover malfuncons of the unit due to tampering, misuse, alteraon, lack of regular maintenance, misapplicaon, fouling due
to hydrogen sulfide or iron, scaling from excessive hardness, turbidity greater than 1.0 NTU, Silt Density Index (SDI) greater than 5.0 SDI, or excessive
membrane hydrolysis due to chlorine levels in excess of 0.5 ppm. In addion, damage to the unit due to fire, accident, negligence, act of God, or
events beyond the control of the Manufacturer are not covered by this warranty.
Incidental and Consequenal Damages The Manufacturer does not assume responsibility for payment of incidental and consequenal damages as
a result of the failure of this unit to comply with express or implied warranes, such as lost me, inconvenience, damage to personal property, loss
of revenue, commercial losses, postage, travel, telephone expenditures, or other losses of this nature. Some states do not allow the exclusion or
limitaon of incidental or consequenal damages, so this exclusion may not apply to you.
Owner’s Warranty Responsibilies Under the provisions of the Warranty, the owner is expected to schedule maintenance, as described in this
Manual. Neglect, improper maintenance, abuse, or unapproved modificaons may invalidate the Warranty. Should your unit develop a defect or
otherwise fail to perform in accordance with this warranty, you should contact the dealer from whom the product was originally purchased.
Implied Warranes The implied at-law warranes of merchantability and fitness for a parcular purpose shall terminate on the date one year aer the
date of purchase. Note: some states do not allow limitaons on how long an implied warranty lasts, so the above limitaons may not apply to you.
Other Rights This Warranty gives you specific legal rights and you may also have other rights which vary from state to state.
Model:
Date Code:
Install Date:
Sold by:
Installed By:
Service Center
Phone Number:
Please fill out the form below and retain for future reference.
Nimbus CS-3
Warranty

4
41840-A McAlby Court, Murrieta, CA 92562
[phone], www.nimbuswater.com
This system has been designed for installaon by a licensed professional such as a contractor or plumber. Proper compleon of this installa-
on will require basic familiarity with standard sink plumbing and proper use of common hand and power tools. Improperly installed systems
could result in water damage due to leaks or flooding. Do not use with water that is microbiologically unsafe.
Typical Installaon Diagram
A. Product water storage tank
B. Tank shut-offvalve
C. Tank tubing
D. Air-gap faucet
E. Drain connecon assembly
F. Drain tubing
G. Quick-connect fing
H. Product water tubing
I. Membrane desalinator
J. Carbon post-filter
K. Carbon pre-filter
L. Sediment pre-filter
M. Carbon inline post-filter
N. Inlet fing
O. Feed water tubing
P. Feed water shut-off
Q. Automac shut-offvalve
(not shown)
A
BC
D
EF
G
I
JK
M
N
O
HP
L

5
41840-A McAlby Court, Murrieta, CA 92562
[phone], www.nimbuswater.com
CS-3 Push Handle Faucet
For easier installaon, aach all tubing prior to mounng the
faucet.
1. Insert polished faucet base onto base of faucet.
2. Push the 1/4” drain tubing onto the 1/4” barb fing. This tube
must be of sufficient length to reach the white swivel with yellow
collet on the membrane desalinator.
3. Push the 3/8” tubing onto the larger 3/8” barbed fing, being
sure you have enough tubing to reach the drain saddle.
4. Slip the 1/4" and 3/8" tubing though opening in polished faucet
base. Slide white plasc spacer open-end-up onto the threaded
faucet stem (2).
5. Thread the 3/8" washer (3) and mounng lock nut (4) onto the
threaded stem. (Fig 6)
6. Thread faucet quick-connect adapter (5) on to threads of faucet
stem. NOTE: This connecon should be hand-ghtened only. Push
one end of product tubing into connecon.
7. Insert tubing and faucet assembly down through the sink hole.
8. Posion the faucet to the desired handle orientaon. Slip the
sloed washer (1) between the white plasc spacer and the sink.
Securely hand ghten the mounng nut.
9. Connect the 3/8” tubing to the drain saddle assembly using the
drain connector nut supplied. This tubing should follow as direct a
path as possible; long runs, looping or deep sags will restrict nor-
mal brine flow to the drain. Save the unused poron of the tubing
for the installaon of the storage tank.
10. Apply a small amount of silicone-based lubricant to the O-rings
located at the base of the spout. Firmly insert spout assembly into
the top hole of faucet body (approximately 1/4"). You may swivel
the faucet leor right.
Airgap to system drain
(1/4" tubing)
Faucet to drain
saddle (3/8" tubing)
Product water
(1/4" tubing)
Metal base plate
Rubber seal
1
2
3
4
5
Connect to product
water tubing

6
41840-A McAlby Court, Murrieta, CA 92562
[phone], www.nimbuswater.com
CS-3 Feed and Drain Connecons
Fig. 3
Fig. 4
Fig. 2
Feed Connecon
1. Locate and turn offthe angle stop valve on the cold water line feeding the sink where
the system is to be installed. This valve will usually be located under the sink on the
pipe coming out of the wall.
2. When the angle stop valve is closed, relieve pressure in the line by opening the cold
water tap on the sink.
3. To install the feed adapter at the faucet connector, disconnect the cold water feed line
where it connects to the faucet inlet connector. This will usually require an open end
wrench, pliers, or long reach faucet wrench.
4. Take the 1/4" feed connector from the parts kit and install it into the brass feed con-
nector adapter. Use a crescent wrench or open-end wrench to ghten the connector
into the adapter. See Fig. 2.
5. Using the flat and cone washers as necessary, install the feed adapter into the faucet
inlet connector. Then reconnect the cold water feed line to the open end of the feed
adapter. Tighten all connecons securely.
6. Using the 1/4" tubing, install the compression nut, plasc ferrule, and plasc tube
insert. Secure the tubing into the feed connector. Tighten the tubing retaining nut
securely.
7. Obtain the small feed valve warning tag from the parts bag and aach it by its wire
es to the feed valve.
Drain Connecon
Note: The drain saddle assembly must be installed before the 'P' trap. Do not install the
drain saddle assembly between the 'P' trap and the wall.
1. Posion drain saddle assembly (Fig. 3) on drain pipe under sink between the P trap
and the sink connecon.
2. Orient the drain saddle so that the connector opening points in the general direcon
of the planned locaon for the R.O. dispensing faucet.
3. Screw the connector nut onto the drain saddle threaded connector loosely (Fig. 4).
Using the connector opening in the side of the drain saddle as a guide, drill a 3/8" hole
through the wall of the drain pipe.
4. Remove drain saddle assembly. Place the adhesive foam pad over the 3/8" hole in
the drain pipe. Replace the assembly onto the drain pipe, aligning the hole in the drain
with the hole in the drain assembly.
5. Tighten the saddle bolts evenly on both sides unl the saddle grips the pipe snugly -
do not overghten. (Fig.4)

7
41840-A McAlby Court, Murrieta, CA 92562
[phone], www.nimbuswater.com
CS-3 Tubing Connecons
1. Measure and cut a length of tubing 1/4" tubing long enough to reach from the faucet to the faucet connector on the
system. Connect one end to the faucet nipple using a jaco nut and plasc insert. Connect the other end to the faucet con-
necon on the post-filter suing a jaco nut and plasc insert.
2. Measure and cut the length of 1/4" tubing long enough to reach from the feed water supply to the inlet. Connect the
end to the feed inlet on the prefilter using a jaco nut and plasc insert. See Fig. 5.
3. Connect one end of a 3/8" length of tubing to the tank valve. Insert the other end firmly into the quick-connect cross on
the shut-offvalve.
4. Connect the 1/4" tubing from the faucet to the white swivel with yellow collet on the membrane desalinator.
5. Connect the free end of the 3/8" drain tubing to the drain connecon.
Fig. 5
INSERT
FERRULE
COMPRESSION NUT
TUBING

8
41840-A McAlby Court, Murrieta, CA 92562
[phone], www.nimbuswater.com
System Acvaon and Inspecon
1. Check all tubing connecons to ensure they are firmly seated and secure.
2. Open the dispensing faucet at the sink. Close the tank shut-offvalve.
3. Open the feed water valve to the system. Observe all tubing and connecons for several minutes to detect any leaks.
In approximately 5 minutes, (assuming normal feed water pressure) the dispensing faucet should begin dripping.
4. Place a pan or other temporary water basin near the drain 'P' trap. Loosen the connector nut holding the 3/8" tube
in the drain saddle connector. Pull the tube out of the connector and use the pan to catch any water that may spill. Brine
water should be flowing from the tube. Reconnect the tube to the drain saddle and hand-ghten the connector nut.
5. Allow the faucet the run for up to 15 minutes, then close the faucet.
6. Check for leaks at all connecons.
7. Open the tank shut-offvalve.
Inial Flushing Procedure
1. Before the system can be used for drinking water producon it must be adequately flushed. Each reservoir tank is
dosed with a small amount of powdered sanizer before shipment, typically a chlorinang agent, in order to ensure tank
internal cleanliness. Also, the carbon filter cartridge will release a small amount of carbon fines during the first tankful of
flow. This flushing procedure will allow any sanizer or carbon fines to pass from the system.
2. Inial tank filling will take approximately one hour (based on average feed pressure). When the tank is full, the water
pressure will have risen to the point where the automac shut-offvalve inside the system will stop the feed flow through
the system. Actuaon of the automac shut-offvalve can be determined by either checking for a lack of brine flow to the
drain saddle, or by listening very closely near the dispensing faucet for absence of water flow sound though the air gap.
When the tank has filled for the first me, it should be leundisturbed for at least 8 hours to ensure proper sanizaon.
3. Aer 8 hours has elapsed, open the dispensing faucet fully and allow the product water to run out to drain at maximum
flow. The inial discharge will be dark with the bulk of the carbon parcle wash out. There may also be the scent of chlo-
rinated water from the sanizing agent. When the flow has diminished to a fast drip or small stream, close the dispensing
faucet.
4. Fill and flush the tank at least three mes prior to use. If necessary, repeat unl the chlorinaon scent has disappeared.
It is important that the flush be done at maximum flow (e.g. the tank must be full) to assist in rapid wash out. Aer this
flushing procedure the system is ready for normal use.
Acvaon and Flushing

9
41840-A McAlby Court, Murrieta, CA 92562
[phone], www.nimbuswater.com
1. System is located where it will not be subject to physical impacts or rough contact by heavy objects.
2. Feed water pressure to the unit is no less than 40 psi and no greater than 80 PSI.
3. All tubing connecons, especially push-in quick connecons, are fully inserted.
4. Tubing connected between the faucet and the drain saddle fing (the fing aached to the sink drain pipe) runs
"downhill" to the drain. There should be no loops or places where water would not flow out to the drain.
5. Feed water valve is open.
6. Within one to two hours aer inial applicaon of water pressure, check again for leaks especially at the tank, faucet
tubing and connectors. These parts will not see full pressure unl approximately 2 hours aer the system is acvated.
7. Flush three tankfuls of product water to drain. If a chlorine scent persists, repeat flushing procedure.
CS-3 Installaon Checklist

10
41840-A McAlby Court, Murrieta, CA 92562
[phone], www.nimbuswater.com
Desalinator Replacement
1. Close the feed water shut-offvalve and close the tank shut-offvalve.
2. Open the dispensing faucet to relieve system pressure. Close dis-
pensing faucet when flow has stopped.
3. Remove old desalinator from clips on frame. Install new desalinator
on frame.
4. Remove feed tubing from old desalinator and insert it in the (green)
feed connector of the new desalinator. See Figure 6.
5. Repeat tube removal and replacement steps for product and drain
tubes.
6. Turn on feed water shut-offvalve and open dispensing faucet.
7. Close dispensing faucet aer water starts running.
8. Observe system for any leaks, especially at newly replaced cartridge.
9. Open the tank shut-offvalve.
10. The system should be flushed at least once as described above under
Secon 8.
Filter Replacement
1. Close the feed water shut-offvalve and close the tank shut-offvalve.
2. Open the dispensing faucet to relieve system pressure. Close dis-
pensing faucet when flow has stopped.
3. Remove the prefilter housing by turning it clockwise (when viewed
from above). Remove old prefilter from housing and discard. Remove
O-ring from top of housing. Wash O-ring and housing. Replace O-ring in
groove at top of housing. Insert new filter. Replace housing into cap by
turning counter clockwise. (When viewed from above).
4. Repeat Step 5 for posilter.
5. Turn on the feed water valve and open the tank shut-offvalve.
6. Observe system for any leaks, especially at newly replaced cartridge.
7. The system should be flushed at least once as described in System
Acvaon and Flushing.
CS-3 Maintenance
To Drain
(Yellow Collet)
Fig. 6
Feed
(Green Collet)
Product
(Blue Collet)

11
41840-A McAlby Court, Murrieta, CA 92562
[phone], www.nimbuswater.com
Horizontal Posilter Replacement
1. Close the feed water shut-offvalve and close the tank shut-offvalve.
2. Open the dispensing faucet to relieve system pressure. Close dispensing faucet when flow has stopped.
3. Locate the inline filter behind the membrane desalinator. Remove the fings from the filter by using a wrench on the
unscrew the fings from the filter.
4. To install the new filter, first apply three wraps of teflon tape to the threads on the fings, then reverse the above steps.
5. Turn on feed water shut-offvalve and open dispensing faucet.
6. Close dispensing faucet aer water starts running.
7. Observe system for any leaks, especially at newly replaced cartridge.
8. Open the tank shut-offvalve.
9. The system should be flushed at least once as described in the previous secon - Acvaon and
Flushing.
CS-3 Maintenance
