Bartscher 109881 User manual

109881
Original
-
Gebrauchs
anleitung
V1/0116

- 13 -
ENGLISH
Table of contents
1.General instructions ................................................................................................ 14
2. Safety instructions, standards, legal and regulatory provisions........................ 15
3. Intended use............................................................................................................ 15
4. Transport, packaging and storage......................................................................... 16
4.1 Delivery check...................................................................................................... 16
4.2 Packaging............................................................................................................. 16
4.3 Storage................................................................................................................. 16
5. Technical data......................................................................................................... 17
6. Operation of the device .......................................................................................... 17
7. Installation............................................................................................................... 18
7.1 Information for the installer................................................................................... 18
7.2 Installation of the water filter system..................................................................... 19
8. Possible malfunctions............................................................................................ 23
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
GB/UK

- 14 -
Read this instruction manual before using and
keep them available at all times!
1.General instructions
•This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
•Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
•In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
•The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning. Please keep these instructions and give them to future owners of the device.
•All persons using the device must follow the recommendations and instructions in this
instruction manual.
•Manufacturer is not liable for any damages or faults caused by:
-violation of advice concerning operation and cleaning;
-use other than designed;
-alterations made by user;
-use of inadequate spare parts.
•Do not use any accessory or spare parts that have not been recommended by the
manufacturer. These can be dangerous for the user or lead to damages of the device
or personal injury, and further, the warranty expires.
•To prevent hazards and to ensure optimum efficiency, no modifications or alterations to
the device that are not explicitly approved by the manufacturer may be undertaken.
•Temperature at the site of installation cannot be lower than 10 °C.
•Protect the device against freezing temperature.
•The device’s installation site must be protected against flooding with water
(e.g. through the existing floor drain). The manufacturer is not responsible for any
damages resulting from flooding the system with water.
•In case of any inquiries or ordering of spare parts please quote the code number and
serial number of the device. This ensures quick and effective processing of inquiries
and orders.

- 15 -
2. Safety instructions, standards, legal and regulatory
provisions
•Water fed into the water filter system must be of drinking water quality.
•The water filter system is designed for cold water in the range from 5 °C to 30 °C.
•Components of the water filter system that come into contact with the filtered water
must be made of the appropriate water-resistant materials.
•Make sure that there is a drainage at the site of installation of the water filter system.
•For certain groups of people (e.g. people with a weakened immune system,
children) it is recommended, in general, to boil the water from the water supply
network. This rule also applies to the filtered water.
•In case of longer interruptions in the operation of the system, it is recommended to
rinse the water filter system with the water volumes specified below:
2 – 3 days
4 litres
4 – 10 days 15 litres
14 days Replace the filter
•Do not disassemble the water filter system during its use.
•Do not open the water filter system, because this will void the warranty.
3. Intended use
Safety of the device’s operation is guaranteed only when using it according to its
intended purpose, in compliance with the data included in the operating instructions.
The water filter system for coffee machines is designed for reducing the carbonate
hardness which causes formation of carbon deposits inside the connected end-user
equipment.
The system is intended for use in the gastronomy in order to obtain the drinking water of
high quality for coffeemakers, coffee machines and combi steamers.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the
device is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use
are impossible.
The operator is liable for all damages resulting from inappropriate use.

- 16 -
4. Transport, packaging and storage
4.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
4.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
Drain water from the system before shipment to avoid damaging the
packaging caused by water leakage.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in
your country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
4.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
-Do not store outdoors.
-Keep it dry and dust-free.
-Do not expose it to aggressive media.
-Do not expose it to direct sunlight.
-Avoid mechanical shocks and vibration.

- 17 -
-In case of longer storage (> 3 months) make sure you check the state of the
packaging and the parts regularly. If required refresh or renew.
CAUTION!
Before the first use of the product in the recommended ambient temperature,
after being stored or transported in the temperature below 0°C, leave the
device for at least 24 hours in an open original packaging.
5. Technical data
Name: Water filter system for coffee machines
Code-No.:
109881
Material: Plastic
Capacity: For 10°CH (carbonate hardness): 1600 litres
Max system pressure: 1.5- 6 bar
Water temperature: 5 °C – 30 °C
Connection thread: 1/2“
Dimensions: W 200 x D 140 x H 320 mm
Weight: 2.2 kg
Subject to technical modifications!
6. Operation of the device
The water filter system was designed to reduce the carbonate hardness (CH) in the
drinking water which produces scale deposits that may damage the device or
deteriorate the quality of beverages.
Water purification process consists of the following stages:
reduction of the carbonate hardness (CH)
mechanical filtration
mineralisation
The water filter system does not require a bypass mixing valve.

- 18 -
Special resin in the water filter system ensures preparation of the water and eliminates
compounds producing scale deposits, while the filtered water is enriched with minerals.
The drinking water with 5 - 7°CH is ideal for preparation of coffee and tea, while
ensuring great taste and aroma of beverages.
7. Installation
7.1 Information for the installer
•Unpack the device and remove the packaging material. Never remove the type plate
and warning signs.
•Before the installation of the water filter system, the device working with the system
should be descaled.
•Do not install the device near the sources of heat and open flame. Do not expose
the device to the direct sunlight.
•Protect the water filter system against mechanical damages.
•Install the shut-off valve upstream of the water filter system. Install the drain valve on
the drain hose, downstream of the water filter system.
•If the water pressure in the water supply installation exceeds 6 bar, install the
pressure regulator upstream of the water filter system.
•Components of the water filter system, which come into contact with the filtered
water must be made of the appropriate water-resistant material.
•All components must be installed according to the local guidelines regarding
installations for drinking water.
•Installation and maintenance of the water filter system may be performed only by the
qualified and authorised personnel.
Water inlet
Water outlet

- 19 -
7.2 Installation of the water filter system
CAUTION!
Before installation check the technical data and during the installation observe
the safety and installation instructions included in these operating instructions.
Installation drawing
1. The shut-off valve must be installed between the water supply installation
and the water filter system. The drain valve must be mounted downstream of
the water filter system on the drain hose to enable reduction of the pressure.
2. If the water pressure exceeds 6 bar, install the pressure regulator upstream of
the water filter system.
3. The water filter system is equipped with the mounting bracket for wall
mounting. It can be mounted horizontally or vertically.
Install the mounting bracket in the desired place.
The mounting bracket is a fixed component of the device and the water filter
system is always replaced along with the mounting bracket.
4. Install the water filter system in compliance with the local standards for drinking
water installation.
5. Perform the test in order to determine the carbonate hardness of water from the
local water supply network.
6. Based on the results of the carbonate hardness test, the relevant volume of water
may be determined (table page 22).
7. In order to precisely determine the quantity of water, it is recommended to install
a water meter (e.g. Water Meter Bartscher 109861) upstream of the filter.
Water supply
installation
Shut-off valve
Drain valve Filtered water
Mounting bracket

- 20 -
Installation of the water filter system
1. Close the shut-off valve on the water supply line and disconnect the terminal unit from
the power supply.
2. Install the water filter system using the wall mounting bracket in the desired place.
During the installation observe the mounting dimensions and hose bending radius.
CAUTION! Only hoses with flat gaskets may be used at the connection joints, because
hoses with cone seat unions would damage the filter head connections, which will void
the warranty.
3. Close the shut-off valve on the water supply hose (IN), in order to cut off the water
supply. Connect the hose for flushing the water filter system to the water outlet (OUT).
a. The water from the hose connected to the water outlet (OUT) should be
drained to the appropriate container (e.g. bucket).
b. Open the shut-off valve on the water supply line and flush the water filter system
until the water starts flowing evenly without air bubbles.
c. Close the water supply with the shut-off valve.
4. Connect the hose which will connect the water outlet (OUT) with the terminal unit.
5. Open the water supply and connect the terminal unit to the power supply.
6. Check the system for leakages.
Replacement of the water filter system
1. The water filter system needs to be replaced after reaching a specified volume
(depending on the carbonate hardness) during the period defined by the manufacturer,
but not later than within 6 months after its launch (whatever comes first).
During the replacement of the water filter system, write down the date of the next
expected replacement (a date in the date field on the filter).
CAUTION! During the replacement of the filter inspect all the parts of the device!
Replace damaged parts and clean the contaminated ones. Do not use abrasive
agents, cleaning solutions or coarse cleaning materials.
2. Before the first use of the product in the recommended ambient temperature, after
being stored or transported in the temperature below 0°C, leave the device for at
least 24 hours in an open original packaging.
3. Close the water inlet and disconnect the power supply from the terminal unit.
4. Before the filter’s replacement, open the drain valve in order to reduce the pressure in
the system.

- 21 -
5. The filter may be changed by disconnecting the hoses on the water inlet (IN) and outlet
(OUT) or quick-fit connectors.
a) Replacement by disconnecting the hoses on the water inlet (IN) and
outlet (OUT):
Disconnect the hoses on the water inlet (IN) and outlet (OUT).
Replace the filter.
Install a new mounting bracket to replace the old one. During the installation,
observe the mounting dimensions and hose bending radius.
oClose the shut-off valve on the water supply hose (IN), to prevent drainage
of water.
oThe water from the hose connected to the water outlet (OUT) should be
drained to the appropriate container (e.g. bucket).
oOpen the water supply to the filter and flush the system until the water
starts flowing evenly without air bubbles.
oClose the shut-off valve.
Connect the hose to the water outlet (OUT), and connect the other end of the
hose to the terminal unit.
b) Replacement of the filter with quick-fit connectors (see illustrations below):
(1) filter ready for replacement;
(2) prize the blockade open by means of the screwdriver;
(3) remove the blockade;
(4) remove the quick-fit connector from the filter;
(5) repeat the operation on the other quick-fit connector;
(6) inspect the connectors for damages and contaminations, clean or
replace if necessary. Install a new filter.
(7) Mount the blockades in the appropriate places;
(8) Lock the quick-fit connector with the blockades;

- 22 -
(9) Filter after replacement.
Close the shut-off valve on the water supply hose (IN), to prevent drainage
of water.
oThe water from the hose connected to the water outlet (OUT) should be
drained to the appropriate container (e.g. bucket).
oOpen the water supply to the filter and flush the system until the water
starts flowing evenly without air bubbles.
oClose the shut-off valve.
Connect the hose to the water outlet (OUT), and connect the other end
of the hose to the terminal unit.
6. Install a new mounting bracket to replace the old one. During the installation,
observe the mounting dimensions and hose bending radius.
7. After the filter replacement, close the drain valve.
8. Open the shut-off valve on the water inlet and connect the terminal unit to the
power supply.
9. Check the system for leakages.
Table of volumes
Carbonate hardness (°CH)/
quoted in °dH (German
degrees)
Volume
l / min
Carbonate hardness (°CH)/
quoted in °dH (German
degrees)
Volume
l / min
1 16000 21 762
2 8000 22 727
3 5333 23 696
4 4000 24 667
5 3200 25 640
6 2667 26 615
7 2286 27 593
8 2000 28 571
9 1778 29 552
10 1600 30 533
11 1455 31 516
12 1333 32 500
13 1231 33 485
14 1143 34 471
15 1067 35 457
16 1000 36 444
17 941 37 432
18 889 38 421
19 842 39 410
20 800 40 400

- 23 -
Maintenance of the operational performance
Regularly control the water filter system.
Inspect the tightness of the water filter system. In case of any leakages through
connection joints or sealing, seal or replace the elements.
Check the hoses for bends, bended hoses should be replaced.
Replace hoses periodically, at least every 5 years, or earlier if necessary.
Do not use abrasive agents, cleaning solutions or coarse cleaning materials.
Waste disposal
Dispose of the decommissioned device according to the national regulations.
For this purpose, contact a local waste management agency.
8. Possible malfunctions
Problem Cause Solution
No water flow Closed water inlet
Open the shut-off valve on the
water inlet
Pressure too low Too low pressure in the
installation Check the pressure in the water supply network
Clogged hoses or filter Check the water filter system,
water inlet and drain hoses,
replace if necessary
Air in the installation Check the installation, bleed the
air from the system
Leakage Incorrectly installed pipe
unions -Check the entire fittings,
gaskets for leakages, replace
if necessary.
-If the problem persists, replace
the filter.
Excessive pressure in the
water installation -Check the pressure in the water supply network.
-Reduce the pressure
upstream of the filter, replace
the filter

- 24 -
Problem Cause Solution
Loss of resin Filter is installed counter to the
water flow Replace the filter. Install the
filter adjusted to the water flow
(marked with arrows on the top
of the filter).
Excessive pressure in the
water installation -Check the pressure in the system.
-Reduce the pressure
upstream of the filter, replace
the filter.
Too hot water flows through
the water filter system (over
30 °C)
Replace the filter, make sure
the water temperature does not
exceed 30 °C.
Water
downstream of
the filter has the
carbonate
hardness higher
than 8°dH
Filter capacity exceeded Replace the filter
A different hardness than a
carbonate hardness has been
measured
Check the carbonate hardness
Water from the water
installation does not meet
hygienic requirements:
presence of iron, manganese
or other compounds in the
water supply network which
contaminate or damage the
resin
Check the quality of water in the
water supply network, replace
the filter
Loss of resin See the problem „Loss of
resin”
Incorrectly measured filter
capacity, incorrectly measured
water hardness or water
hardness has changed
Measure the carbonate
hardness and calculate the filter
capacity again
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
