Dreamer DHA-WPA160W User manual

COUNTER TOP WATER PURIFIER
USER’S MANUAL
Model: DHA-WPA160W

A. Pure water outlet
B. Composite filter cartridge
C. Water purifier housing
D. Suction cup
E. Water outlet connecting nut
F. Water hose
G. Connecting nut
H. Adapter
I. Silicone washer
J. Stainless steel mesh
K. Switch
L. Main body
M. Adapter key
N. Multi-function adapter
1. Part name
1

2. Please confirm whether the package is complete
1. The water purifier housing……...1 pc
2. Main body…….........................................1 pc
3. Accessories kit.......................…………..1 pc
(adapters 4 pcs, silicone ring 4 pcs, adapter key 1 pc, multi-functional adapter 1pc)
4. User manual....................................…..1 pc
2

3. Safety Precautions
Please use the standard tap water.
Avoid damage to the body.
Let the water run at the filtered setting for 15 seconds before use
each day.
In order to drain the retained water.
Let the water run at the filtered setting for 60 seconds before use
if you have not used the water purifier for more than two days.
In order to keep the pure water at the water outlet.
Please use the “Purified water” as soon as possible.
As there is no residual chlorine in the water, bacteria is easy to reproduce.
Please put the purified water in a covered clean countainer and
store it in a refrigerator.
Please do not touch the “purified water” outlet!
Avoid bacteria growth.
If there is a lot of turbidity in the tap water (such as cleaning the
water tank or not using tap water for a long time, etc.).
Please drain the tap water for some time before using the water
purifier.
Avoid shortening the life of filter cartridge.
This product is a household water purifier and should not be used
for purposes other than cooking or drinking.
Do not connect the special faucets with other machines such as
gas-type water heaters, etc.
Avoid damage to other machines.
Please do not install it near flame or high temperature place.
To avoid deformation or rupture, resulting in failure and leakage.
Replace the filter cartridge when the water outlet volume is reduced.
Please replace the filter cartridge regularly.
Please slowly adjust the knobs for the raw water and pure water.
Avoid damage to the water purufier itself.
When used in high pressure can cause damage and leakage.
The working water pressure fror this product is 0.1~0.4MPa.
Do not freeze this product!
Freezing this product will cause damage.
When purifying the tap water, do not use hot tap water above 38oC.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
3

If you accidentally let the hot water pass through the water purifier,
there is sometimes temporary odor from the purified water.
Do not block the water outlet or connect to other equipment.
To avoid damage to the housing of the water purifier.
Never use steel balls, abrasive cleaning agents or corrosive liquids
such as patrol or acetone to clean the water purifier.
These substances may cause cracking, discoloration, or distortion.
Please do not disassemble the water purifier housing and filter
cartridge.
When an abnormality is found, refer to 8. Troubleshooting.
4. Precautions for using
Part of faucet cannot be installed
The water filter can be installed in most the thread faucet with four
adapters very easily.
Uninstalled faucets: water sprinkler faucet, the faucet with square
outlet or oval outlet, induction faucet, the diameter is out of
15-24mm faucer and the depth of throat id less than 15mm.
The replacement periods of the filter cartridge are different based
on the water volume, water quality, and water pressure ect.
Please keep the water filter temperature less than 38oC in “pure
water” mode, if install the water filter in the cold/hot faucet.
Please keep the water filter out of the sunlight.
The sunlight will cause the water filter out of shape and change the
color.
The water purifier can not transfer hard water to soft water.
Can not remove dissolved salt (sea water), meral ions.
13.
14.
15.
1.
2.
3.
4.
5.
4

5. Installation method
Ensure select all the right adapter before installing the water filter.
The diameter of the faucet is 15-24mm.
Check the faucet type, and select the proper adapter.
The water filter with the adapters suit for most of the kitchen faucet,
but may be not suit for some unnormal and nonstandard faucet.
The faucet water pressure must be between 0.1-0.4MPa, If the
pressure is less than 0.1MPa, the water flow will be less, if higher than
0.4MPa, it will damage the water filter.
a. Internal thread faucet installation
For taps with an aerator (thread inside) with a diameter of 21.55 mm or 23.5 mm.
b. External thread faucet installation
For taps with an aerator (thread inside) with a diameter of 20.5 mm or 23.5 mm.
1. Remove connecting nut from the mail body.
2. Remove the tap aerator and choose matching adapter.
3. Install the connecting nut onto the tap, place & tighten adapter
over the tip of the faucet.
4. Screw the connecting nut firmly onto the main body.
1. Remove connecting nut from the mail body.
2. Remove the tap aerator and choose matching adapter.
3. Install the connecting nut onto the tap, place & tighten adapter
over the tip of the faucet.
4. Screw the connecting nut firmly onto the main body.
1.
2.
3.
5

c. Unthreaded faucet installation method
For taps with an aerator (unthreaded) with a diameter of 15-22mm.
1. Remove the mounting nut from the main unit.
2. Put the silicone ring gasket into the adapter, put on the connecting
nut and screw it into the multi-function adapter.
3. Insert the multifunction adapter into the tap and tighten the
retaining ring with a screwdriver.
4. Screw the attachment nut firmly onto the water purifier housing.
Installation for the main body and the hose
The hose connect with the housing
6

6. Battery Replacement Method and Functions Description
1. Take off the battery cover.
2. Remove the battery.
3. Install the battery according to the correct cathode anode ends.
4. Close the battery cover.
5. Display filter lifespan reset button.
6. Display time setting button.
1. 2. 3.
4. 5. 6.
1. When the batteries work, LCD self-tests for about 1 second
(showing all LCD characters).
2. After self-checking, the LCD indicates “6000” as initial filter lifespan.
3. If the purified water flow is more than 0.5L/min, the LCD is
awakened and calculates the flow.
4. When the battery power is 3.5-3.8V, the screen appears low battery
icon until the battery is replaced.
Function Description
7

7. Filter replacement method and maintenance
1. Push out the fixed bracket.
2. Turn the outlet counterclockwise.
3. Romove the outlet cover.
4. Turn the filter counterclockwise.
5. Remove the used filter cartridge.
6. Replace with the new filter cartridge
7. Install the new filter cartridge.
8. Install the outlet cover.
9. Turn the outlet clockwise.
10. Push in the fixed buckle.
For long-term use, be sure to replace the filter cartridge within the
replacement cycle.
Due to the different local water quality, sometimes the purified
water volume is not reduced, but the activated carbon is saturatedd,
please try to replace the filter cartridge according to the recommended
cycle.
If you encounter the following situation, please replace the filter cartridge.
1. The purified water volume is significantly reduced.
2. The residual chlorine (bleaching powder) smell and other odor
have been produced!
8

8. Trouble Shooting
Problem
- Main body head
leaking
Possible reasons Solutions
- Whether installed properly
to the faucet or not ?
- Whether the faucet is aged
or not ?
- Whether the seal is aged or
not ?
- Whether house nut of the
main body tight enough ?
- Whether the seal ring
damage or not?
- Reconnect in the right way.
- Replace the seal.
- Re-install.
- Repair the faucet.
- Replace the seal.
- Water hose leaking
- Housing leaking
- Odor
- Raw water flow low
and uneven
- Pure water flow low
- Re-connect in the right way. - Whether the hose connected
properly or not ?
- Whether the filter hose
connected properly or not?
- Whether housing have
residual water or not?
- Whether the filter mesh is
dirty or not ?
- Whether the raw water outlet
is clean or not?
- Whether the filter cartridge
is installed properly?
- Whether the filter cartrdge
is expired or not?
- Whether in inlet hose folded
or not ?
- Whether filter cartridge is
blocked or not?
- Wash with a clean soft brush
sterilized by hot water.
- Install in the right way
- Replace the filter cartridge.
- Put the inlet hose in the
proper way.
- Replace the filter cartridge
(if the water pressure is low, the
pure water flow will be low too).
- Reconnect in the right way.
- Wipe up the water.
9

Specifications
Product Name : Counter top water purifier
Type: Directly faucet installed
Water flow: 2L/min
Capacity: 6000L
Water Source: Municipal tap water
Working pressure: 0.1-0.4MPa
Suitable water temperature: 5-38oC
Accessories 4 x adapters
1 x multi-functional adapter
1 x adapter key
Please keep this user manual carefully
10
