NinjaBatt PPS300-5 User manual

280Wh PORTABLE
POWER STATION
USER GUIDE
www.ninjabatt.com
[e-mail]

Thank you for
purchasing your new
power station from
NinjaBa. A great deal of
effort and care has been
invested into this unit so
that you could enjoy a
high-end back-up
battery pack.
Your new power station is a vital
addition to any emergency kit. It is
also perfect as a power back-up
when camping, fishing, hunting and
many other outdoor activities.
Please read through the
following quick start guide
before using the unit.
Package
includes:
Our awesome power station
AC charger with charging cable
Car lighter adapter
›
›
›

Product
Specifications
Baery Power Lithium-ion - 280Wh (26Ah/10.8V)
AC Input Charging AC100-240V to DC19V/3.78A
Car Input Charging DC 12.8V~24V/5.5A Max
Solar Panel Input DC 12.8V~24V/5.5A Max
LED Lights 2W Max, 3 Levels with SOS function
Operating temperature 0 - 40°C
DC 12V Output 1X Cigarette Lighter / 9V~12.6V/8A Max Regulated
3X DC Rated Output / 9V~12.6V/3A Max Regulated
AC Output Pure Sine Wave Output
AC Continuous Output: 300W Max
AC Voltage: 110V AC ± 10%
Output Frequency: 60Hz ± 5%
USB Outputs Type-C: PD3.0 60W Max (5V/3A, 9V/3A, 12V/3A,
15V/3A, 20V/3A) Auto
Type-A: Single output QC3.0 18W (5V3A,9V2A Auto),
Simultaneous output 5V 2.4A, Total 4.8A
Safety Protections Short-Circuit
Over-Current
Over-Voltage
Low-Voltage
Over-Load
Over-Temperature
Baery Charge Cycles 1000 +
Pass-Through Charging Supported
Dimensions 230*219*148mm / 9.06X7.87X7.2in
Weight 3kg/6.6lb
Certifications ETL, UN38.3, MSDS
CAUTION
Before using our power station,
please read the following instructions
carefully:
To always be prepared - please charge the power
station every other month if not used for a long
period of time
Heat is the enemy - Keep your powerstation away from
heat sources like direct fire or different heaters.
Keep away from moisture or water.
Do not disassemble, microwave, puncture, incinerate or
insert foreign objects into the power station.
Do not crush, blend, shred, drop or place heavy objectos
on top of the device.
Please avoid exposing this product to fire sources. The
product contains Li-ion batteries which are highly
sensitive to high temperatures.
Do not use the product if damaged or punctured.
1
2
3
4
5
6

1. LCD On/Off
controller
& power
button
7. Smart
Fan
3. DC1 controller 4. USB & Type-C Controllers
Handle
5. DC2 controller
Car lighter Port
6. Input
Charging Port
LCD display 8. LED
controller
LED Lights
2. AC Output
port controller
Product DiagramProduct Diagram
On/Off button - Press to turn off display (for night mode) or
long press (5 seconds) to turn off the unit
AC port controller - Press to enable/disable double AC ports
Press to enable/disable 3 12V/3A DC ports
Press to enable/disable USB and type-C ports
4
Input for charging from solar panels, AC, generator, or car
cigarette lighter port.
Smart fan – Your fan will automatically kick in as soon as the
unit detects high temperatures
Press to enable/disable 12V/8A DC port car cigarette lighter
5
Change LED brightness – High, medium, low
8
6
7

Recharging the unit
Recharge through AC socket - simply plug in the power station
to an AC outlet using the included wall plug cable.
Recharge through your car or truck lighter socket - using the
included 12V Car Charger - cable included.
Recharge using a solar panel - We recommend using a solar panel
of 60 to 100 Watts and 24 volts - MC4 cables included.
3 recharging options
When recharging the Power station – time value
numbers indicate time left to a full charge.
When using the unit to power devices – time value
display remaining usage time.
Remaining usage time is dynamic and dependent
on output wattage. Output wattage changes
according to battery level of the item that is being
charged.
LCD Diagram
Please note
›
›
Battery Capacity
Percentage
Time value for
reference AC Output Power (W)
Over temperature
Fan
Port Indicators
AC Wall Charger
5.5-6.5 hours
fully charged
7-8 hours
fully charged
(By 80W Panel)
Solar Charger
Car Charger
5.5-6.5 hours
fully charged
Before using or storing, please charge your
power station until it is fully charged.

Using your 300Wa
power station
Press the power button or any other port button to turn on the
unit. When not using certain ports, it is best to turn them off
to conserve power.
Read the LCD screen to know which port is turned on.
Plug in your gear.
Your unit supports a full pass-through charging so you can charge
your power station and run your gear at the same time.
Note
Always take note of the LCD battery display. If you plug in a
device that has a high-power consumption, the charge level
of your power station may drop quickly. In addition,
especially when using the AC outputs, your power station
will be converting battery power into AC power. Although
your power station has a highly efficient pure sine wave
inverter, there is still some energy lost in the conversion and
you will not get the full rated capacity of your battery.
Charging via solar-panels
We recommend: 60-100 Was solar
panels of up to 24 Volts.
5.5*2.1mm Connector
Your new power station is solar ready. It
includes a built in MPPT controller that
prevents overcharging, and it is designed
for an easy and efficient compliance with
your solar panel.

1
2
3
4
5
How long will my device run when plugged into the
power stations?
Usage time = 280Wh divided by your device’s Wh
consumption.
Which electronic appliances can I use with the power
stations?
All electronic devices of up to 300 Watts.
Which solar panels can I use to charge the power
station?
We suggest using solar panels of 60 to 100 Watts and
up to 24 Volts. Remember – Charging speed is also
dependent on sunlight intensity.
Which solar panel charger controller is being used
with this unit?
We use MPPT – Maximum power point tracking to
maximize power extractions from solar panels.
Can this device be used as a jump starter?
No.
FAQ’S FAQ’S
6
7
8
9
10
Is this device water/weather resistant?
No. Do not expose the unit to water.
Are the baeries used replaceable or upgradeable?
No. Batteries are built in. Note – opening of the unit
will void your warranty.
Is there a way to disable a port group?
Yes. Clicking a port’s group button will disable/enable
it. When enabled, an icon appears on the LCD screen.
How long will a single charge last without using the
unit?
2-3 Months.
Does this device support pass-through charging?
Yes. You can simultaneously charge other devices
while recharging the power station.
