RLH 24V 300 Watt
Solar Power Supply
Solar power system with 150AH backup
battery in NEMA-4X Cabinet
Overview
The RLH 300W solar power supply is a fully integrated solution
provide remote powering for industrial equipment. RLH solar
power supplies are engineered with durable and highly efficient
solar electric panels to ensure reliable operation in any
geographical region.
The charge controller continuously maintains the correct 24V
charge level on the 150Ah battery pack, and ensures a seamless
power transition to battery power when needed. The charge
controller allows maximum array current to flow into the batteries,
and the temperature sensor adjusts the charging current based
on ambient conditions. A digital LCD display shows battery
voltage, solar amps, equipment amps, and battery level.
The gel batteries are sealed and maintenance free, and are field
replaceable. The system includes a NEMA-4X outdoor rated,
aluminum cabinet to house the batteries, charge controller and
related equipment. The cabinet may wall or pole mounted (pole
mount kit optional), and includes mounting hardware.
The cabinet comes pre-wired and includes a fuse to protect the
system. The panels and charge controller are covered by our
Exclusive Unconditional Lifetime Warranty.
2012A-0627
Standard Features
Complete solar power system with panels, charge controller
and sealed batteries in a steel pedestal
Cabinet is outdoor rated and includes padlock ring and
recessed hex latches
Includes fuse holder and screw down connection terminals
Solar panels include flexible mounting hardware for easy
mounting onto poles or structures
Sealed 24V 150Ah battery array, field replaceable
Batteries are warranted for 10 years
Built-in battery test function
Convenient LCD display shows battery voltage, solar amps,
equipment amps, and battery level
Solar panels and charge controller are covered by our
Exclusive Unconditional Lifetime Warranty
300W 24V Solar Power Supply w/150Ah Battery Pack
The leader in
rugged fiber optic
technology.
Unconditional
Lifetime Warranty
USER GUIDE
RLH Industries, Inc.

Panel Information
Battery/Charge Controller Cabinet
+–+–
+–+–
3 4
1 2
Batteries
20A Fuse
Charge Controller
Connection Diagram
Page 2!!!RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax [phone] • www.fiberopticlink.com
RLH Industries, Inc.
300W Solar Panel
Assembly Rear View
52”
64”
Tilt Leg
Lower
Bracket
Upper
Bracket
Solar Panel
South
Mounting
Pole
35 ~ 60˚
Mounting Diagram
Side View
Power
Cable
Cable
Tie

Installation
Plan the installation of the battery/charge controller cabinet and solar panel array prior to installation. For best
results, mount the cabinet as close to the panels as practicable. Mount the cabinet and Install and connect the
batteries prior to connecting the solar panels. Refer to the battery/charge controller cabinet wiring diagram.
Mount the solar panel assembly in an appropriate South facing (in the Northern hemisphere) location.
•The location should be free of shadow between the hours of 9:00am and 3:00pm
•For the maximum power generation, the solar panels must be situated with the proper amount of tilt for the
latitude of installation.
•Refer to the latitudinal chart to determine the proper amount of tilt for your location. Note that all figures refer
to angle from horizontal.
For pole mounting, mount the panel assembly to a 4” diameter pole using the U-bolts provided. Alternatively,
mount the panel to a wall using appropriate hardware depending on the type of structure. Adjust the telescoping
tilt legs for optimum sun angle, and tighten all bolts securely after making adjustments. Since the top of the panel
is close to the wall/pole mounting, it is best to route the panel wiring at the top.
The panel wiring is connected directly to the solar battery charge controller inside the battery cabinet. A section of
wiring and liquid tight conduit is provided for ease of installation. Refer to the charge controller operation manual
for additional information on the displays and indicators of the charge controller.
30˚
45˚
60˚
75˚
90˚
Mercator Projection
Recommended Solar
Panel Tilt Angle
(From horizontal)
Solar panels face South
!RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax [phone] • www.fiberopticlink.com!Page 3
RLH Industries, Inc.

System Components
SOLAR PANEL ARRAY
Aluminum alloy mounting frame
SOLAR PANEL ARRAY
Mounting feet, brackets, and hardware
SOLAR PANEL ARRAY
Tilt legs, universal mounting brackets and hardware
SOLAR PANEL ARRAY
Liquid tight junction box
CABINET
NEMA-4X outdoor rated, welded, galvanized steel construction
CABINET
Wall mount brackets
CABINET
Standard recessed can wrench latches
CABINET
Padlock ring
CABINET
Sealed gel type batteries
CABINET
Prewired charge controller
INCLUDED
ACCESSORIES
½” x 6” long galvanized bolts with nuts and washers for mounting
INCLUDED
ACCESSORIES
U-bolts and hardware for 4” pole mounting of solar panels
INCLUDED
ACCESSORIES
25ft. Outdoor rated #12 AWG wiring
INCLUDED
ACCESSORIES
25ft. Outdoor rated liquid tight conduit
Ordering Information
Part Number
Description
RLH-300-24-150
300W 48V Solar Power Supply with 150AH batteries and charge controller in 36x30x13 NEMA-4X cabinet
8806-1250-08RB
150A 24V Replacement Battery Set (Set of 4)
Page 4!!!RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax [phone] • www.fiberopticlink.com
RLH Industries, Inc.

Specifications
SOLAR ARRAY
TYPE
2 x150W Solar Panel
SOLAR ARRAY
RATED MAXIMUM POWER (Pmax)
300W
SOLAR ARRAY
TOLERANCE
± 3%
SOLAR ARRAY
VOLTAGE @ Pmax (Vmp)
29.3V
SOLAR ARRAY
CURRENT @ Pmax (Imp)
2.76A
SOLAR ARRAY
SHORT CIRCUIT CURRENT (Isc)
2.94A
SOLAR ARRAY
OPEN CIRCUIT VOLTAGE (Voc)
43.2V
SOLAR ARRAY
NOMINAL OPERATING CELL TEMPERATURE
47˚C ± 2˚C
SOLAR ARRAY
CELL TYPE
Mono
SOLAR ARRAY
WIND LOADING
50lbs/sq. ft.
SOLAR ARRAY
PANEL DIMENSIONS
H 64” x W 52” x D 1.6” (810mm x 1318mm x 40mm)
SOLAR ARRAY
STANDARD TEST CONDITIONS
AM -1.5 STC=1000W/m2 TC=25˚C
SOLAR ARRAY
WARNING Electric Hazard:This unit produces DC electricity when exposed to light. Cover the panel surface before removing
terminal junction box or connecting to charge controller pedestal.
WARNING Electric Hazard:This unit produces DC electricity when exposed to light. Cover the panel surface before removing
terminal junction box or connecting to charge controller pedestal.
CABINET
CIRCUIT PROTECTION
Diode across solar array input
CABINET
FUSE
20A fuse
CABINET
CABINET CONSTRUCTION
Thermoplastic
CABINET
CABINET DIMENSIONS
H 36” x W 30” x L 13”
CABINET
CHARGE CONTROLLER
Digital charge controller with battery status indicators
CABINET
OUTPUT VOLTAGE
24VDC
CABINET
WORKING TEMP., HUMIDITY
-20 ~ +70˚ C, 20 ~ 90% RH
CABINET
STORAGE TEMP., HUMIDITY
-20 ~ +85˚ C, 10 ~ 95% RH
BATTERY PACK
VOLTAGE
24VDC (4 X 12VDC)
BATTERY PACK
CAPACITY
150Ah
BATTERY PACK
BATTERY TYPE
Deep Cycle, Sealed Gel, Lead acid
BATTERY PACK
HOUSING (ea.)
Polypropylene UL 94-V0/File E50955
