R&S NGE-K101 User manual

R&S®NGE100B
Power Supply
User Manual
User Manual
Version 02
5601134302
(Æ1=[2)
www.allice.de
Allice Messtechnik GmbH

This manual describes the following R&S®NGE100B models and options:
●R&S®NGE102B 2-Channel PSU (5601.3800.02)
●R&S®NGE103B 3-Channel PSU (5601.3800.03)
●R&S®NGE-K101 Ethernet Remote Control (5601.2204.03)
●R&S®NGE-K102 Wireless LAN Remote Control (5601.2210.03)
●R&S®NGE-K103 Digital Trigger I/O (5601.2227.03)
The contents of this manual correspond to firmware version 1.50 or higher.
The software contained in this product uses several valuable open source software packages. For information, see the "Open
Source Acknowledgment" document, which is available for download from the R&S NGE100B product page at www.rohde-
schwarz.com/product/nge100b > "Downloads" > "Firmware".
Rohde & Schwarz would like to thank the open source community for their valuable contribution to embedded computing.
© 2018 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Fax: [phone]
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
5601.1343.02 | Version 02 | R&S®NGE100B
The following abbreviations are used throughout this manual: R&S®NGE100B is abbreviated as R&S NGE100B. R&S® is abbrevi-
ated as R&S.
www.allice.de
Allice Messtechnik GmbH

1171.1307.42 - 05
1
Safety Instructions
Instrucciones de seguridad
Sicherheitshinweise
Consignes de sécurité
Risk of injury and instrument damage
The instrument must be used in an appropriate manner to prevent
electric shock, fire,
personal injury or instrument damage.
●
Do not open the instrument casing.
●
Read and observe the "Basic Safety Instructions" delivered as
printed brochure with the instrument.
●
Read and observe the safety instructions in the following sections.
Note that the data sheet may specify additional operating conditions.
●
Keep the "Basic Safety Instructions" and the product documentation
in a safe place and pass them on to the subsequent users.
Riesgo de lesiones y daños en el instrumento
El instrumento se debe usar de manera adecuada para p
revenir
descargas eléctricas, incendios, lesiones o daños materiales.
●
No abrir la carcasa del instrumento.
●
Lea y cumpla las "Instrucciones de seguridad elementales"
suministradas con el instrumento como folleto impreso.
●
Lea y cumpla las instrucciones de seguridad incluidas en las
siguientes secciones. Se debe tener en cuenta que las
especificaciones técnicas pueden contener condiciones adicionales
para su uso.
●
Guarde bien las instrucciones de seguridad elementales, así como
la documentación del producto, y entréguelas a usuarios
posteriores.
www.allice.de
Allice Messtechnik GmbH

1171.1307.42 - 05
2
Gefahr von Verletzungen und Schäden am Gerät
Betreiben Sie das Gerät immer ordnungsgemäß, um elektrischen
Schlag, Brand, Verletzungen von Personen oder Geräteschäden zu
verhindern.
●
Öffnen Sie das Gerätegehäuse nicht.
●
Lesen und beachten Sie die "Grundlegenden Sicherheitshinweise",
die als gedruckte Broschüre dem Gerät beiliegen.
●
Lesen und beachten Sie die Sicherheitshinweise in den folgenden
Abschnitten; möglicherweise enthält das Datenblatt weitere
Hinweise zu speziellen Betriebsbedingungen.
●
Bewahren Sie die "Grundlegenden Sicherheitshinweise" und die
Produktdokumentation gut auf und geben Sie diese an weitere
Benutzer des Produkts weiter.
Risque de blessures et d'endommagement de l'appareil
L'ap
pareil doit être utilisé conformément aux prescriptions afin d'éviter
les électrocutions, incendies, dommages corporels et matériels.
●
N'ouvrez pas le boîtier de l'appareil.
●
Lisez et respectez les "consignes de sécurité fondamentales"
fournies avec l’appareil sous forme de brochure imprimée.
●
Lisez et respectez les instructions de sécurité dans les sections
suivantes. Il ne faut pas oublier que la fiche technique peut indiquer
des conditions d’exploitation supplémentaires.
●
Gardez les consignes de sécurité fondamentales et la
documentation produit dans un lieu sûr et transmettez ces
documents aux autres utilisateurs.
www.allice.de
Allice Messtechnik GmbH

Contents
R&S®NGE100B
3User Manual 5601.1343.02 ─ 02
Contents
1 Preface.................................................................................................... 7
1.1 Documentation Overview............................................................................................. 7
1.2 Conventions Used in the Documentation...................................................................8
1.2.1 Typographical Conventions.............................................................................................8
1.2.2 Other Conventions.......................................................................................................... 8
2 Welcome to R&S NGE100B...................................................................9
3 Important Notes....................................................................................10
3.1 Symbols....................................................................................................................... 10
3.2 Ambient Conditions.................................................................................................... 10
3.3 Measurement Categories............................................................................................11
3.4 Mains Voltage...............................................................................................................11
3.5 Limits............................................................................................................................12
4 Quick Start............................................................................................13
4.1 Putting into Operation................................................................................................ 13
4.1.1 Safety............................................................................................................................ 14
4.1.2 Intended Operation....................................................................................................... 15
4.1.3 Unpacking and Checking the Instrument...................................................................... 17
4.1.4 Setting Up the Instrument............................................................................................. 17
4.1.4.1 Bench Operation........................................................................................................... 18
4.1.4.2 Rack Mounting.............................................................................................................. 18
4.2 Instrument Tour...........................................................................................................19
4.2.1 Overview of Controls.....................................................................................................19
4.2.1.1 Front Panel....................................................................................................................19
4.2.1.2 Rear Panel.................................................................................................................... 20
4.2.2 Switching On the Instrument......................................................................................... 22
4.3 Trying Out the Instrument.......................................................................................... 23
4.3.1 Selecting the Channels................................................................................................. 23
4.3.2 Setting the Output Voltage and Current Limit................................................................23
4.3.3 Activating the Channels Output.....................................................................................23
4.3.4 Storing/Recalling of Instrument Settings....................................................................... 23
www.allice.de
Allice Messtechnik GmbH

Contents
R&S®NGE100B
4User Manual 5601.1343.02 ─ 02
4.4 Maintenance................................................................................................................ 24
5 Instrument Functions.......................................................................... 25
5.1 User Interface.............................................................................................................. 25
5.1.1 Screen Layout............................................................................................................... 25
5.1.2 Function Keys............................................................................................................... 28
5.1.3 Virtual Keyboard............................................................................................................29
5.1.4 Navigation Controls.......................................................................................................30
5.1.4.1 Rotary Knob.................................................................................................................. 31
5.1.4.2 Arrow Keys....................................................................................................................31
5.1.4.3 Live-Mode..................................................................................................................... 31
5.1.5 Menu............................................................................................................................. 32
5.2 Power Derating............................................................................................................34
5.3 Output Modes.............................................................................................................. 34
5.4 Basic Functions.......................................................................................................... 35
5.4.1 Setting the Channels Voltage and Current....................................................................35
5.4.2 Tracking Function..........................................................................................................36
5.4.3 Activating Fuse..............................................................................................................37
5.4.4 Activating the Channels Output.....................................................................................38
5.4.5 Store and Recall............................................................................................................38
5.5 Advanced Functions...................................................................................................40
5.5.1 Protection...................................................................................................................... 40
5.5.2 Fuse.............................................................................................................................. 42
5.5.3 EasyArb.........................................................................................................................43
5.5.4 EasyRamp.....................................................................................................................44
5.5.5 Digital Trigger I/O.......................................................................................................... 45
5.6 Connecting to a Network............................................................................................48
5.6.1 LAN Connection............................................................................................................ 48
5.6.1.1 Wired Connection..........................................................................................................48
5.6.1.2 Wireless Connection..................................................................................................... 50
5.6.2 USB Connection............................................................................................................51
5.7 General Instrument Settings...................................................................................... 52
5.7.1 Instrument Information.................................................................................................. 52
5.7.2 General Instrument Settings......................................................................................... 53
www.allice.de
Allice Messtechnik GmbH

Contents
R&S®NGE100B
5User Manual 5601.1343.02 ─ 02
5.7.3 Managing Options......................................................................................................... 54
5.7.4 Reset Instrument...........................................................................................................55
5.7.5 System Test...................................................................................................................55
5.7.6 Updating the Firmware..................................................................................................56
5.7.7 Help...............................................................................................................................57
6 Remote Control.................................................................................... 59
6.1 Interfaces and Protocols............................................................................................ 59
6.1.1 USB...............................................................................................................................59
6.1.1.1 USB VCP...................................................................................................................... 59
6.1.1.2 USB TMC...................................................................................................................... 60
6.1.2 LAN............................................................................................................................... 61
6.1.3 WLAN............................................................................................................................61
6.1.4 LXI.................................................................................................................................62
6.1.5 SCPI..............................................................................................................................63
6.1.6 VISA.............................................................................................................................. 64
6.2 Setting Up Remote Control Connection....................................................................64
6.3 SCPI Command Structure and Syntax...................................................................... 65
6.3.1 Structure of a Command............................................................................................... 65
6.3.1.1 Common Commands.................................................................................................... 65
6.3.1.2 Device-Specific Commands.......................................................................................... 66
6.3.1.3 Overview of Syntax Elements....................................................................................... 69
6.3.2 Parameters....................................................................................................................70
6.3.2.1 Numeric Values............................................................................................................. 70
6.3.2.2 Special Numeric Values................................................................................................ 70
6.3.2.3 Boolean Parameters..................................................................................................... 71
6.3.2.4 Text................................................................................................................................71
6.3.2.5 Strings........................................................................................................................... 71
6.3.2.6 Block Data.....................................................................................................................72
6.3.3 Structure of a Program Message.................................................................................. 72
6.3.4 Responses to Queries...................................................................................................72
6.4 Command Sequence and Command Synchronization............................................73
6.5 Remote Control - Commands.................................................................................... 73
6.5.1 Common Commands.................................................................................................... 74
www.allice.de
Allice Messtechnik GmbH

Contents
R&S®NGE100B
6User Manual 5601.1343.02 ─ 02
6.5.2 System Commands.......................................................................................................76
6.5.3 Firmware Update...........................................................................................................79
6.5.4 HCOPY......................................................................................................................... 79
6.5.5 Channel Selecting......................................................................................................... 79
6.5.6 Output Setting............................................................................................................... 80
6.5.7 Fuse Setting.................................................................................................................. 83
6.5.8 OVP Setting.................................................................................................................. 85
6.5.9 OPP Setting.................................................................................................................. 86
6.5.10 Measurement Commands.............................................................................................88
6.5.11 Voltage and Current Configuration Commands............................................................ 89
6.5.12 EasyRamp Commands................................................................................................. 90
6.5.13 Arbitrary Commands..................................................................................................... 91
6.5.14 DIO Commands............................................................................................................ 93
7 Applications..........................................................................................98
7.1 Parallel and Serial Mode.............................................................................................98
7.1.1 Serial Mode................................................................................................................... 98
7.1.2 Parallel Mode................................................................................................................ 99
Index....................................................................................................101
www.allice.de
Allice Messtechnik GmbH

Preface
R&S®NGE100B
7User Manual 5601.1343.02 ─ 02
1 Preface
1.1 Documentation Overview
This section provides an overview of the R&S NGE100B user documentation. You find
it on the product page at:
http://www.rohde-schwarz.com/product/nge100b > "Downloads"
Getting started manual
Introduces the R&S NGE100B and describes how to set up and start working with the
product. A printed version is included in the delivery.
User manual
The user manual contains the description of all instrument modes and functions. It also
provides an introduction to remote control, a complete description of the remote control
commands with programming examples, and information on maintenance, instrument
interfaces and error messages.
Service manual
The service manual is available for registered users on the global Rohde & Schwarz
information system (GLORIS, https://gloris.rohde-schwarz.com).
Basic safety instructions
Contains safety instructions, operating conditions and further important information.
The printed document is included in the delivery.
Brochure
The brochure provides an overview of the R&S NGE100B and shows its specific char-
acteristics. The technical specifications of the R&S NGE100B are included in the bro-
chure. It also lists the options and their order numbers as well as optional accessories.
Calibration certificate
The calibration certificates of your device are available online. Visit the R&S NGE100B
product page and select the item to download the calibration certificate. You will be for-
warded to a Gloris page.
https://gloris.rohde-schwarz.com/calcert.
Enter the device ID of your R&S NGE100B and download the certificate. You can find
the device ID either in the "Setup" menu or on the label on the rear panel.
Documentation Overview
www.allice.de
Allice Messtechnik GmbH

Preface
R&S®NGE100B
8User Manual 5601.1343.02 ─ 02
Release notes and open source acknowledgment (OSA)
The release notes list new features, improvements and known issues of the current
firmware version, and describe the firmware installation.
The open source acknowledgment document provides verbatim license texts of the
used open source software.
See http://www.rohde-schwarz.com/product/nge100b > "Downloads" > "Firmware".
Application notes, application cards, white papers, etc.
These documents contain information about possible applications and background
information on various topics, see www.rohde-schwarz.com/appnotes.
1.2 Conventions Used in the Documentation
The following conventions are used throughout the R&S NGE100B manual.
1.2.1 Typographical Conventions
Convention Description
"Graphical user interface elements" Names of graphical user interface elements on the
screen, such as dialog boxes, menus, options, but-
tons, and softkeys are enclosed by quotation marks.
Keys Name of key is bolded.
Filenames, commands, program code File names, commands, coding samples and screen
output are distinguished by their fonts.
Input User input is displayed in italics.
Links Links are displayed as underlined.
"References" References to other parts of the documentation are
enclosed by quotation marks.
1.2.2 Other Conventions
Remote commands may include abbreviations to simplify input. In the description of
such commands, all parts that have to be entered are written in capital letters.
Additional text in lowercase characters is for information only.
Conventions Used in the Documentation
www.allice.de
Allice Messtechnik GmbH

Welcome to R&S NGE100B
R&S®NGE100B
9User Manual 5601.1343.02 ─ 02
2 Welcome to R&S NGE100B
The two or three-channels power supply series are based on a classical transformer
concept with high efficiency electronic pre-regulators and secondary linear regulators.
This concept allows the instrument to achieve the high output power within a minimum
space, high efficiency and lowest residual ripple.
The R&S NGE100B power supply series feature galvanically isolated, floating overload
and short-circuit proof outputs with adjustable power ratings. The outputs can be con-
nected in series or in parallel, thus making high currents and voltages available.
Multi-purpose protection functions are available for each channel which you can set
separately, such as overcurrent protection (FUSE), overvoltage protection (OVP), over-
power protection (OPP) and overtemperature protection (OTP). If such a limit is
reached, the affected output channel is automatically turned off and an indicator mes-
sage (FUSE, OVP, OPP or OTP) is displayed. The overcurrent protection can be linked
to other channel (FuseLink function). In this case, all linked channels are turned off
when the set channel reaches its limit.
The EasyArb function allows channel 1 (Ch 1) to have a freely definable voltage and
current sequences with a timeframe as short as 10 ms. It allows you to vary the voltage
or current limit during a test sequence, for example to simulate different charging con-
ditions of a battery. With EasyRamp function, the R&S NGE100B provides the operat-
ing condition to simulate the continuous rise of the supply voltage within a defined
timeframe of 10 ms to 10 s.
Four data lines of the digital I/O interface are mutually independent and can be used as
trigger input or trigger output separately. Various trigger conditions (e.g. fuse tripped,
voltage, current, indicator messages) can be used to turn off, on or invert the output
state when the trigger condition is met.
All R&S NGE100B power supply series are equipped with a color LCD display (320 x
240 pixels resolution). The R&S NGE100B comes with a USB interface and optional
LAN (LXI) and wireless LAN (WLAN) interface.
For models with WLAN, network connection can also be established wirelessly.
This user manual contains a description of the functionalities that the instrument pro-
vides. The latest version is available for download at the product homepage (http://
www.rohde-schwarz.com/product/nge100b).
www.allice.de
Allice Messtechnik GmbH

Important Notes
R&S®NGE100B
10User Manual 5601.1343.02 ─ 02
3 Important Notes
3.1 Symbols
Caution, general danger zone
Ground
PE terminal
ON (supply voltage)
OFF (supply voltage)
Ground terminal
3.2 Ambient Conditions
The allowed operating temperature ranges from +0 °C to +40 °C (pollution category 2).
The maximum relative humidity (without condensation) is at 80 %.
During storage and transport, the temperature must be between -20 °C and +70 °C. In
case of condensation during transportation or storage, the instrument will require
approximately two hours to dry and reach the appropriate temperature prior to opera-
tion. The instrument is designed for use in a clean and dry indoor environment. Do not
operate with high dust and humidity levels, if danger of explosion exists or with aggres-
sive chemical agents.
Any operating position may be used; however adequate air circulation must be main-
tained. For continuous operation, a horizontal or inclined position (integrated stand) is
preferable.
Specifications with tolerance data apply after a warm up period of at least 30 minutes
at a temperature of 23 °C (tolerance -3 °C/+ 7 °C). Specifications without tolerance
data are average values.
The heat produced inside the instrument is guided to the exterior via temperature-con-
trolled fan. Each channel has multiple temperature sensors which check the heat gen-
eration in the instrument and control the fan speed.
It is necessary to ensure that there is sufficient space around the instrument sides for
heat exchange. If the temperature inside the instrument increases to more than
Ambient Conditions
www.allice.de
Allice Messtechnik GmbH

Important Notes
R&S®NGE100B
11User Manual 5601.1343.02 ─ 02
~72 °C, a channel-specific overheat protection intervenes. Affected outputs will auto-
matically be switched off.
Air circulation
Do not obstruct the ventilation holes!
3.3 Measurement Categories
This instrument is designed for supplying power on circuits that are only indirectly con-
nected to the low voltage mains or not connected at all. The instrument is not intended
for measurements within the measurement categories II, III or IV; the maximum poten-
tial against earth generated by the user must not exceed 150 VDC in this application.
The following information refers solely to user safety. Other aspects, such as the maxi-
mum voltage, are described in the technical data and must also be observed.
The measurement categories refer to transients that are superimposed on the mains
voltage. Transients are short, very fast (steep) current and voltage variations which
may occur periodically and non-periodically. The level of potential transients increases
as the distance to the source of the low voltage installation decreases.
●Measurement CAT IV: Measurements at the source of the low voltage installations
(e.g. meters)
●Measurement CAT III: Measurements in building installations (e.g. power distribu-
tion installations, power switches, firmly installed sockets, firmly installed engines
etc.)
●Measurement CAT II: Measurements on circuits electronically directly connected to
the mains (e.g. household appliances, power tools, etc.)
●0 (instruments without measured measurement category): Other circuits that are
not connected directly to the mains
3.4 Mains Voltage
The instrument applies 50 Hz/60 Hz mains voltages ranging from 115 VAC or 230 VAC
(tolerance ± 10 %). Mains voltage switching is not intended. The input line fuse is
accessible externally. Power socket and fuse holder form a single unit.
You need to first disconnect the power cord from the connector before you can safely
replace the fuse (as long as the fuse holder is undamaged). Next, the fuse holder must
be pried out using a screwdriver. The starting point is a slot next to the contacts. The
fuse can then be forced out of its mounting and must be replaced with an identical fuse
(see information about the fuse type on the rear panel). The fuse holder will be inserted
against the spring pressure until it locks into place. The use of mended fuses or short
Mains Voltage
www.allice.de
Allice Messtechnik GmbH

Important Notes
R&S®NGE100B
12User Manual 5601.1343.02 ─ 02
circuiting the fuse holder is prohibited. Resulting damages are not covered by the war-
ranty.
Safe operation
If the instrument is to remain unattended for a longer time period, it must be switched
off at the mains switch for safety reasons.
3.5 Limits
The R&S NGE100B is equipped with a protective overload feature. The protective
overload feature prevents damage to the instrument and is intended to protect against
a possible electrical shock. The maximum values for the instrument must not be excee-
ded. The protection limits are listed on the front panel of the R&S NGE100B to ensure
the safe operation of the instrument.
These protection limits must be adhered to:
Specification Limits
Maximum output voltage 32 VDC
Maximum output current 3 A (max 33.6 W per channel)
Maximum voltage against earth 250 V peak
Maximum reverse voltage 33 VDC
Maximum inverse voltage 0.4 VDC
Maximum permitted current in case of inverse volt-
age
3 A
Power supply 115 VAC or 230 VAC (tolerance ± 10%)
Frequency 50 Hz/60 Hz
Maximum power output 100 W (R&S NGE103B), 66 W (R&S NGE102B)
Limits
www.allice.de
Allice Messtechnik GmbH

Quick Start
R&S®NGE100B
13User Manual 5601.1343.02 ─ 02
4 Quick Start
The following chapters under Quick Start are identical to the printed R&S NGE100B
Quick Start manual.
●Putting into Operation............................................................................................. 13
●Instrument Tour....................................................................................................... 19
●Trying Out the Instrument....................................................................................... 23
●Maintenance............................................................................................................24
4.1 Putting into Operation
This chapter describes the steps to set up the R&S NGE100B for the first time.
Risk of injury and instrument damage
The instrument must be used in an appropriate manner to prevent electric shock, fire,
personal injury, or damage.
●Do not open the instrument casing
●Read and observe the "Basic Safety Instructions" delivered as a printed brochure
with the instrument. Note that the basic safety instructions also contain information
on operating conditions that prevent damage to the instrument
In addition, read and observe the safety instructions in the following sections. Notice
that the data sheet may specify additional operating conditions.
Risk of radio interference
This instrument is compliant with Class A of CISPR 32. In a residential environment,
this instrument may cause radio interference.
Putting into Operation
www.allice.de
Allice Messtechnik GmbH

Quick Start
R&S®NGE100B
14User Manual 5601.1343.02 ─ 02
Risk of instrument damage during operation
An unsuitable operating site or test setup can cause damage to the instrument and the
connected devices. Ensure the following operating conditions before you switch on the
instrument:
●The instrument is dry and shows no sign of condensation
●The instrument is positioned as described in Chapter 4.1.4.1, "Bench Operation",
on page 18
●The ambient temperature does not exceed the range specified in the data sheet
●Signal levels at the input connectors are all within the specified ranges
●Signal outputs are correctly connected and not overloaded
EMI impact on measurement results
Electromagnetic interference (EMI) may affect the measurement results.
To suppress the generated EMI:
●Use suitable shielded cables of high quality, for example, LAN cables
●Note the EMC classification in the data sheet
●Safety......................................................................................................................14
●Intended Operation................................................................................................. 15
●Unpacking and Checking the Instrument................................................................ 17
●Setting Up the Instrument....................................................................................... 17
4.1.1 Safety
This instrument was built in compliance with DIN EN 61010-1 (VDE 0411 part 1),
safety regulations for electrical instruments, control units and Iaboratory equipment. It
has been tested and shipped from the plant in safe condition. It is also in compliance
with the regulations of the European standard EN 61010-1 and the international stan-
dard IEC 61010-1.
To maintain this condition and ensure safe operation, you must observe all instructions
and warnings given in this user manual. Casing, chassis and all measuring ports are
connected to a protective earth conductor. The instrument is designed in compliance
with the regulations of protection class I.
For safety reasons, the instrument may only be operated with authorized safety sock-
ets. The power cord must be plugged in before signal circuits may be connected.
Never use the product if the power cable is damaged. Check regularly that the power
cables are in perfect condition. Choose suitable protective measures and installation
types to ensure that the power cord cannot be damaged and that no harm is caused by
tripping hazards or from electric shock, for instance.
Putting into Operation
www.allice.de
Allice Messtechnik GmbH

Quick Start
R&S®NGE100B
15User Manual 5601.1343.02 ─ 02
Risk of electric shock
It is prohibited to disconnect the earthed protective connection inside or outside of the
instrument!
If it is assumed that a safe operation is no longer possible, the instrument must be shut
down and secured against any unintended operation.
Safe operation can no longer be assumed as follows:
●Instrument shows visible damage
●Instrument includes loose parts
●Instrument no longer functions properly
– After an extended period of storage under unfavorable conditions (e.g. out-
doors or in damp rooms)
–After rough handling during transport (e.g. packaging that does not meet the
minimum requirements by post office, railway or forwarding agency)
Exceeding the Low Voltage Protection
Use insulated wires and not bare wires for the terminal connection.
For the series connection of all output voltages, it is possible to exceed the low voltage
protection of 42 V. Please note that in this case any contact with live components is
life-threatening. It is assumed that only qualified and trained personnel service the
power supplies and the connected loads.
Prior to switching on the product, it must be ensured that the nominal voltage setting
on the product matches the nominal voltage of the AC supply network. If it is necessary
to set a different voltage, the power fuse of the product must be changed accordingly.
4.1.2 Intended Operation
The instrument is intended only for use by personnel familiar with the potential risks of
measuring electrical quantities.
For safety reasons, the instrument may only be connected to properly installed safety
socket outlets. Separating the ground is prohibited.
The power plug must be inserted before signal circuits may be connected.
Putting into Operation
www.allice.de
Allice Messtechnik GmbH

Quick Start
R&S®NGE100B
16User Manual 5601.1343.02 ─ 02
Use only the power cord included in the delivery package. See "Delivery package"
on page 17.
Before each measurement, measuring cables must be inspected for damage and
replaced if necessary. Damaged or worn components can damage the instrument or
cause injury.
The product may be operated only under the operating conditions and in the positions
specified by the manufacturer, without the product's ventilation being obstructed. If the
manufacturer’s specifications are not observed, this can result in electric shock, fire
and/or serious personal injury, and in some cases, death.
Applicable local or national safety regulations and rules for the prevention of accidents
must be observed in all work performed.
The instrument is designed for use in the following sectors: Industrial, residential, busi-
ness and commercial areas and small businesses.
The instrument is designed for indoor use only. Before each measurement, you need
to verify at a known source if the instrument functions properly.
To disconnect from the mains, the low-heat device socket on the back panel has to be
unplugged.
See Table 4-1 for the general data on the instrument specification. For more informa-
tion, see the instrument product brochure (PN: 5214.8748.12).
Table 4-1: General data on instrument specification
Mains nominal voltage AC 115/230 V (±10 %) 50/60 Hz
Power consumption Maximum input power 180 W
Mains fuses 115 V AC IEC 60127-2/5 T 5 A 250 V
230 V AC IEC 60127-2/5 T 2.5 A 250 V
Temperature Operating temperature range 0 °C to + 40 °C
Storage temperature range - 20 °C to + 70 °C
Humidity Non-condensing 5 % to 80 %
Display 3.5 " (QVGA)
Rack mount capability ½ 19 "R&S HZC95 option
Dimensions W x H x D 222 mm x 88 mm x 280 mm
(8.74 in x 3.46 in x 11.02 in)
Weight R&S NGE102B 4.9 kg (10.80 lb)
R&S NGE103B 5.0 kg (11.02 lb)
Putting into Operation
www.allice.de
Allice Messtechnik GmbH

Quick Start
R&S®NGE100B
17User Manual 5601.1343.02 ─ 02
4.1.3 Unpacking and Checking the Instrument
Check the equipment for completeness using the delivery note and package contents
list for the various items. Check the instrument for any damage and loose parts. If there
is any damage, immediately contact the carrier who delivered the instrument.
Packing material
Retain the original packing material. If the instrument needs to be transported or ship-
ped at a later date, you can use the material to protect the control elements and con-
nectors.
Risk of damage during transportation and shipment
Insufficient protection against mechanical and electrostatic effects during transportation
and shipment can damage the instrument.
●Always ensure that sufficient mechanical and electrostatic protection are provided
●When shipping an instrument, the original packaging should be used. If you do not
have the original packaging, use sufficient padding to prevent the instrument from
moving around inside the box. Pack the instrument in antistatic wrap to protect it
from electrostatic charging
●Secure the instrument to prevent any movement and other mechanical effects dur-
ing transportation
Delivery package
The package contents contain the following items:
●R&S NGE100B power supply preloaded with two 230 V fuses
●Four power cables
●Two 115 V fuses (replace the preloaded fuses with these fuses depending on the
mains voltage, see Chapter 4.2.2, "Switching On the Instrument", on page 22 for
more information)
●One Getting Started manual
●One document folder containing safety instructions, calibration certificate, KC and
CE certificate
4.1.4 Setting Up the Instrument
The R&S NGE100B is designed for benchtop and rackmount.
Putting into Operation
www.allice.de
Allice Messtechnik GmbH

Quick Start
R&S®NGE100B
18User Manual 5601.1343.02 ─ 02
4.1.4.1 Bench Operation
On a benchtop, the R&S NGE100B can either lie flat or stand on its feet. As shown in
Figure 4-1, feet on the bottom can be folded out to set the instrument in an inclined
position.
Figure 4-1: Operating positions
Positioning of instrument
The instrument must be positioned in a manner that allows the user to disconnect the
unit from the mains at any time and without restrictions.
4.1.4.2 Rack Mounting
The instrument can be installed in a 19 " rack-mount using a rack adapter kit.
Ambient temperature
Place the R&S NGE100B in an area where the ambient temperature is within +0 °C to
+40 °C. The R&S NGE100B is fan-cooled and must be installed with sufficient space
on the top to ensure a free flow of air. Required minimum distance: 1 rack unit (RU).
Figure 4-2: Rack mounting
Putting into Operation
www.allice.de
Allice Messtechnik GmbH
