NISBETS ESSENTIALS DB303 User manual

Back Bar Cooler
Instruction manual
Model • Model • Modèle • Modell • Modello • Modelo:
DB303
EN Back bar Cooler
Instruction manual
2
NL Barkoeler
Gebruikshandleiding
8
FR Armoire réfrigérante
Mode d’emploi
14
DE Backbar-Kühler
Betriebsanleitung
20
IT Vetrina refrigerata bar
Manuale di istruzioni
26
ES Expositor refrigerado
bajo barra
Manual de instrucciones
32
DB303_ML_A5_v2_20221109.indb 1DB303_ML_A5_v2_20221109.indb 1 2022/11/9 16:172022/11/9 16:17

2
EN
Safety Instructions
• Position on a flat, stable
surface.
• A service agent/qualified
technician should carry out
installation and any repairs
if required. Do not remove
any components on this
product.
• Consult Local and National
Standards to comply with
the following:
- Health and Safety at Work
Legislation
- BS EN Codes of Practice
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• DO NOT immerse in water,
or use steam/jet washers to
clean the unit.
• DO NOT cover the
appliance when it is
operating.
• Bottles that contain a high
percentage of alcohol
must be sealed and placed
vertically in the appliance.
• Always carry, store and
handle the appliance in a
vertical position.
• Never tilt the appliance
more than 45° from the
vertical.
• Not suitable for outdoor
use.
• Keep all packaging away
from children. Dispose of
the packaging in accordance
to the regulations of local
authorities.
• If the power cord is
damaged, it must be
replaced by a Nisbets
Essentials agent or a
recommended qualified
technician in order to avoid
a hazard.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved.
DB303_ML_A5_v2_20221109.indb 2DB303_ML_A5_v2_20221109.indb 2 2022/11/9 16:172022/11/9 16:17

3
EN
• Children shall not play with
the appliance.
• Nisbets Essentials
recommend that this
appliance should be
periodically tested (at least
annually) by a Competent
Person. Testing should
include, but not be limited
to: Visual Inspection,
Polarity Test, Earth
Continuity, Insulation
Continuity and Functional
Testing.
• Nisbets Essentials
recommend that this
product is connected to a
circuit protected by an
appropriate RCD (Residual
Current Device).
Warning: Risk of fire
flammable materials
• Do not store explosive
substances such as aerosol
cans with a flammable
propellant in this appliance.
Warning: Keep all ventilation
openings clear of obstruction.
Unit should not be boxed in
without adequate ventilation.
• Warning: Do not use
mechanical devices or other
means to accelerate the
defrosting process, other
than those recommended
by the manufacturer.
• Warning: Do not damage
the refrigerant circuit.
• Warning: Do not use
electrical appliances
inside the food storage
compartments of the
appliance, unless they are
the type recommended by
the manufacturer.
Introduction
Please take a few moments to carefully read through
this manual. Correct maintenance and operation
of this machine will provide the best possible
performance from your Nisbets Essentials product.
This cooler is designed for drink chilling and
storage and is not recommended for the storing of
foodstuffs.
Pack Contents
The following is included:
• Single Door Back Bar Cooler - 92Ltr
• Instruction manual
Nisbets Essentials prides itself on quality and service,
ensuring that at the time of unpacking the contents
are supplied fully functional and free of damage.
Should you find any damage as a result of transit,
please contact your Nisbets Essentials dealer
immediately.
DB303_ML_A5_v2_20221109.indb 3DB303_ML_A5_v2_20221109.indb 3 2022/11/9 16:172022/11/9 16:17

4
EN
Installation
Location: Not for use in vans or trailers, food
trucks or similar vehicles.
Note: If the unit has not been stored or moved
in an upright position, let it stand upright for
approximately 12 hours before operation. If in
doubt allow to stand.
1. Remove the appliance from the packaging and
the protective film from all surfaces.
2. Avoid positioning the cooler in direct sunlight or
damp areas.
3. To optimize performance and longevity, ensure
a minimum clearance of 2.5cm is maintained
between the unit and walls and other objects,
with a minimum 20cm clearance on the top.
NEVER LOCATE NEXT TO A HEAT SOURCE.
4. If necessary, adjust the screw legs of the cooler
to make it level.
Note: Before using the appliance for the first
time, clean the shelves and interior with soapy
water.
Reverse the Door
Before action, ensure to disconnect the appliance
from the power supply.
The door is opened from left side originally.
1. Remove the hinge cover and the upper hinge
from the right top (Fig. 1A). Then remove the
door.
2. Remove the screw covers from the left top and
install on the right top (Fig. 1B).
1
A
B
3. Remove the screw cover from the left top of the
door and install on the right top (Fig. 2).
2
4. Remove the lower hinge from the right bottom
and install on the left bottom (Fig. 3).
3
5. Install the door onto the lower hinge. Then install
the upper hinge on the left top. Note: Before
tightening the screws, ensure the top of the
door is level with the top of the cabinet and the
rubber gasket makes a good seal. Finally install
the hinge cover.
6. Now the door is opened from right.
Operation
Thermostat
Located at the rear of the
cabinet, the thermostat is
graded from MIN (9°C) to
MED (5°C) to MAX (1°C).
Note: For best results and optimum efficiency, we
recommend setting the controller to MED.
Note: Setting the thermostat to ‘O’ turns off the
compressor.
Turn on
1. Close the door of the appliance.
2. Connect the appliance to a mains power supply.
3. Turn the light switch On (I) or Off (O) as desired.
DB303_ML_A5_v2_20221109.indb 4DB303_ML_A5_v2_20221109.indb 4 2022/11/9 16:172022/11/9 16:17

5
EN
Tips for use:
• Avoid opening the door too often. Opening the
door for long periods can cause a significant
increase of the temperature in the appliance.
• If the gasket or door seal is damaged or
deformed, energy consumption will increase. To
restore efficiency, replace in time.
• If the appliance is left empty for long periods,
switch it off. Then defrost and clean it thoroughly.
Let it dry well and leave the door open to prevent
mould developing within the appliance.
• Clean regularly surfaces that can come in contact
with food and accessible drainage system.
• Condensation will form in refrigeration with
frequent opening of the doors and on hot humid
days, please ensure condensation is allowed to
drain properly or is wiped dry.
Cleaning, Care &
Maintenance
• Switch off and disconnect from the power supply
before cleaning.
• Clean the interior of the appliance as often as
possible.
• Do not use abrasive cleaning agents. These can
leave harmful residues.
• Clean the door seal with water only.
• Always wipe dry after cleaning.
• If left unused for any length of time, store the
appliance with the door ajar.
Auto Defrost
Periodically the appliance will run an automatic
defrost cycle to prevent any ice build-up.
Note: In case of Ice built-up (3-5mm thick), set the
thermostat to “O” and leave the door open. Then
manually defrost the appliance. Never use sharp
objects for scraping.
Troubleshooting
A qualified technician must carry out repairs if required.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and switched on
Plug or lead is damaged Replace plug or lead
Fuse in the plug has blown Replace the fuse
Mains power supply fault Check mains power supply
Appliance is noisy or
works intermittently
Appliance is not level Adjust the feet to level the appliance
The appliance is touching a
neighbouring object
Check installation position and change if necessary
Cooler cabinet is not
cold enough
Temperature set incorrectly Check temperature and reset if necessary
External environment may
require colder temperature
Check temperature and reset if necessary
The door is opened too often Only open when necessary
Door seal is worn Replace the seal
The light does not
work
Bulb has blown Consult a qualified technician
Door will not close
properly
Cooler is not level Adjust the feet
Door has been reversed and
not properly fitted
See “Reverse the door”
Shelves are out of position Check all shelves are properly inserted
Door seal is dirty Wipe clean with a damp cloth
DB303_ML_A5_v2_20221109.indb 5DB303_ML_A5_v2_20221109.indb 5 2022/11/9 16:172022/11/9 16:17
