Niveo Professional NGSME16T2H User manual

Version 1.0
Niveo Professional NGSME16T2H
16-Port 10/100/1000Base-T PoE+ + 2 Gigabit SFP
Advanced Web Management PoE Switch

NGSME16T2H User Manual | 2
FCC Warning
This Equipment has been tested and found to comply with the limits for a Class-A digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy. It may cause harmful interference to radio communications if the
equipment is not installed and used in accordance with the instructions. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
 Consult the dealer or an experienced radio/TV technician for help.
CE Mark Warning
This is a Class-A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.

Table of Contents
NGSME16T2H User Manual | 3
Table of Contents
Before Starting ............................................................................................................................... 8
Intended Readers ......................................................................................................................... 9
Icons for Note, Caution, and Warning ......................................................................................... 9
Product Package Contents .........................................................................................................10
Chapter 1: Product Overview ..................................................................................................... 11
Product Brief Description ...........................................................................................................12
Product Specification .................................................................................................................14
Hardware Description .................................................................................................................17
Hardware Installation ..................................................................................................................18
Chapter 2: Preparing for Management ......................................................................................19
Preparation for Serial Console ...................................................................................................20
Preparation for Web Interface ....................................................................................................22
Preparation for Telnet/SSH Interface .........................................................................................24
Chapter 3: Featuring Configuration – Web UI ...........................................................................26
System Configuration .................................................................................................................27
System Information ...................................................................................................................27
Configuration .............................................................................................................................28
IPv6 Configuration ....................................................................................................................30
NTP Configuration .....................................................................................................................32
System Log Configuration ........................................................................................................33
Power Reduction .........................................................................................................................35
LED Power Reduction Configuration .......................................................................................35
Port Configuration ......................................................................................................................38
Security Configuration: ..............................................................................................................40
Security / Switch ........................................................................................................................40
Security / Switch / Users Configuration .................................................................................40
Security / Switch / Privilege Levels Configuration ................................................................42
Security / Switch / Auth Method..............................................................................................44
Security /Switch / SSH Configuration.....................................................................................45
Security / Switch / HTTPS Configuration ...............................................................................46
Security / Switch / Access Management Configuration ........................................................47
Security / Switch / SNMP .........................................................................................................49
RMON Statistics Configuration...............................................................................................60
Security /Network ......................................................................................................................67
Port Security Limit Control Configuration .............................................................................67

Table of Contents
NGSME16T2H User Manual | 4
Security / Network / Network Access Server Configuration .................................................71
Security / Network / Access Control List Configuration .......................................................82
Switch / Network / DHCP Configuration .................................................................................99
IP Source Guard Configuration ............................................................................................ 102
ARP Inspection ...................................................................................................................... 104
Security / AAA Authentication Server Configuration ............................................................ 107
Aggregation Configuration ....................................................................................................... 110
Static Aggregation ................................................................................................................... 110
LACP - Dynamic Aggregation ................................................................................................. 112
Loop Protection ......................................................................................................................... 114
Spanning Tree ........................................................................................................................... 116
Spanning Tree / Bridge Setting............................................................................................... 117
Spanning Tree / MSTI Mapping ............................................................................................... 119
Spanning Tree / MSTI Priorities .............................................................................................. 120
Spanning Tree / CIST Ports ..................................................................................................... 121
Spanning Tree MSTI Ports ...................................................................................................... 124
MVR (Multicast VLAN Registration) ......................................................................................... 125
IPMC (IP Multicast) .................................................................................................................... 127
IGMP Snooping Configuration ................................................................................................ 127
Basic Configuration ............................................................................................................... 127
IGMP Snooping VLAN Configuration ................................................................................... 130
IGMP Snooping / Port Group Filtering ................................................................................. 132
MLD Snooping Configuration ................................................................................................. 133
Basic Configuration ............................................................................................................... 133
MLD Snooping VLAN Configuration..................................................................................... 135
IPMC / MLD Snooping / Port Group Filtering ....................................................................... 137
LLDP Parameters ...................................................................................................................... 138
LLDP Configuration ................................................................................................................. 138
LLDP Media Configuration ...................................................................................................... 141
PoE Configuration ..................................................................................................................... 149
MAC Address Table Configuration ........................................................................................... 152
VLAN (Virtual LAN).................................................................................................................... 155
VLAN Membership Configuration .......................................................................................... 155
VLAN Port Configuration ........................................................................................................ 158
Private VLANs ........................................................................................................................... 160
Private VLAN Membership Configuration .............................................................................. 160
Port Isolation Configuration ................................................................................................... 162

Table of Contents
NGSME16T2H User Manual | 5
VCL ............................................................................................................................................. 163
VCL / MAC-Based VLAN Configuration ................................................................................. 163
VCL / Protocol-based VLAN .................................................................................................... 165
VCL / IP Subnet-based VLAN .................................................................................................. 169
Voice VLAN Configuration ........................................................................................................ 171
Voice VLAN / Configuration .................................................................................................... 171
Voice VLAN / OUI Configuration ............................................................................................. 173
QoS ............................................................................................................................................ 174
QoS / Ingress Port Classification ........................................................................................... 174
QoS / Ingress Port Policer Config .......................................................................................... 176
QoS / Port Scheduler ............................................................................................................... 177
QoS / Egress Port Shapers ..................................................................................................... 178
QoS / Port Tag Remarking ...................................................................................................... 179
QoS / Port DSCP Configuration .............................................................................................. 180
QoS / DSCP based QoS Ingress Classification ..................................................................... 182
QoS / DSCP Translation .......................................................................................................... 183
QoS / DSCP Classification ...................................................................................................... 185
QoS / Control List Configuration ............................................................................................ 186
QoS / Storm Control Configuration ........................................................................................ 189
Mirroring Configuration ............................................................................................................ 190
UPnP Configuration .................................................................................................................. 192
sFlow Configuration.................................................................................................................. 193
Chapter 4: Feature Configuration - CLI ................................................................................... 196
System Configuration ............................................................................................................... 198
Power Reduction ....................................................................................................................... 205
Port Configuration .................................................................................................................... 207
Security Configuration .............................................................................................................. 210
Aggregation Configuration ....................................................................................................... 230
Loop Protection ......................................................................................................................... 232
Spanning Tree ........................................................................................................................... 233
MVR ............................................................................................................................................ 237
IPMC ........................................................................................................................................... 239
LLDP Configuration .................................................................................................................. 242
Power over Ethernet Configuration ......................................................................................... 244
MAC Address Table Configuration ........................................................................................... 246
VLAN Configuration .................................................................................................................. 248
Private VLAN Configuration ..................................................................................................... 249

Table of Contents
NGSME16T2H User Manual | 6
VCL Configuration..................................................................................................................... 250
Voice VLAN Configuration ........................................................................................................ 252
QoS Configuration .................................................................................................................... 254
Mirroring Configuration ............................................................................................................ 258
UPnP Configuration .................................................................................................................. 259
sFlow Configuration.................................................................................................................. 260
Diagnostic Commands ............................................................................................................. 262
Maintenance Commands .......................................................................................................... 264
Chapter 5: Web Configuration - Monitor, Diagnostic, Maintenance ...................................... 266
Monitor ....................................................................................................................................... 267
Monitor / System ..................................................................................................................... 267
Monitor / System / Information ............................................................................................. 267
CPU Load ............................................................................................................................... 269
System Log Information ........................................................................................................ 270
System / Detailed Log ........................................................................................................... 272
Monitor / Port State ................................................................................................................. 273
Port State ............................................................................................................................... 273
Traffic Overview ..................................................................................................................... 274
QoS Statistics ........................................................................................................................ 275
QCL Status ............................................................................................................................. 276
Detailed Port Statistics .......................................................................................................... 278
Monitor / Security .................................................................................................................... 281
Security / Access Management Statistics ............................................................................ 281
Security / Network ................................................................................................................. 282
Security / AAA ........................................................................................................................ 302
Switch / SNMP / RMON .......................................................................................................... 310
LACP System Status ............................................................................................................... 318
System Status ........................................................................................................................ 318
LACP Port Status ................................................................................................................... 319
LACP statistics ...................................................................................................................... 320
Loop Protection ....................................................................................................................... 321
STP Bridge Status ................................................................................................................... 321
Bridge Status ......................................................................................................................... 322
STP Port Status ..................................................................................................................... 323
STP Port Statistics ................................................................................................................. 324
MVR Status .............................................................................................................................. 325
Statistics ................................................................................................................................ 325

Table of Contents
NGSME16T2H User Manual | 7
MVR Group Table ................................................................................................................... 326
Monitor / IPMC / IGMP Snooping ............................................................................................ 327
IGMP Snooping ...................................................................................................................... 327
MLD Snooping Status ........................................................................................................... 332
Monitor / LLDP ......................................................................................................................... 337
LLDP / Neighbor..................................................................................................................... 337
LLDP MED Neighbors ............................................................................................................ 339
LLDP PoE ............................................................................................................................... 343
LLDP EEE ............................................................................................................................... 345
LLDP Statistics ...................................................................................................................... 347
Dynamic MAC Table ................................................................................................................ 349
VLAN Membership Status ....................................................................................................... 351
VCL MAC-Based VLAN Status ................................................................................................ 355
sFlow ........................................................................................................................................ 356
Diagnostic .................................................................................................................................. 357
Ping .......................................................................................................................................... 357
Ping6 ........................................................................................................................................ 358
VeriPHY Cable Diagnostic ....................................................................................................... 359
Maintenance .............................................................................................................................. 360
Restart Device ......................................................................................................................... 360
Factory Defaults ...................................................................................................................... 360
Software Upload ...................................................................................................................... 361
Firmware Update ................................................................................................................... 361
Image Select .......................................................................................................................... 362
Configuration ........................................................................................................................... 363
Appendix A: Product Safety ....................................................................................................... 365
Appendix B: IP Configuration for Your PC ................................................................................ 366

NGSME16T2H User Manual | 8
Before Starting
In Before Starting:
This section contains introductory information, which includes:
 Intended Readers
 Icons for Note, Caution, and Warning
 Product Package Contents

Before Starting
NGSME16T2H User Manual | 9
Intended Readers
This manual provides information regarding to all the aspects and functions needed
to install, configure, use, and maintain the product you’ve purchased.
This manual is intended for technicians who are familiar with in-depth concepts of
networking management and terminologies.
Icons for Note, Caution, and Warning
To install, configure, use, and maintain this product properly, please pay attention
when you see these icons in this manual:
A Note icon indicates important information which will guide you to use this
product properly.
A Caution icon indicates either a potential for hardware damage or data loss,
including information that will guide you to avoid these situations.
A Warning icon indicates potentials for property damage and personal injury.

Before Starting
NGSME16T2H User Manual | 10
Product Package Contents
Before starting install this product, please check and verify the contents of the
product package, which should include the following items:
One Network Switch
One Power Cord
One User Manual CD
One pair Rack-mount kit + 8 Screws
Note: If any item listed in this table above is missing or damaged, please contact
your distributor or retailer as soon as possible.

NGSME16T2H User Manual | 11
Chapter 1:
Product Overview
In Product Overview:
This section will give you an overview of this product, including its feature functions
and hardware/software specifications.
 Product Brief Description
 Product Specification
 Hardware Description
 Hardware Installation

Chapter 1: Product Overview
Product Overview
NGSME16T2H User Manual | 12
Product Brief Description
This Niveo Web Smart
PoE Switch is 16-port
10/100/1000Base-T + 2
Gigabit SFP Advanced
Web Management PoE Switch that is designed to strengthen its network
connections. The 16 10/100/1000Base-T ports support IEEE 802.3at PoE+
technology, up to 30W per port and maximum 100m transmission distance. The
switch equipped with AC to DC power module to support 200W power budget for
PoE. The added 2 SFP slots support 100M and Gigabit Fiber transceiver for long
distance transmission. The Switch embedded advanced web smart software engine
to support Web Management, SNMP, 802.1Q VLAN, QoS, RSTP, LACP, LLDP,
802.1X and Access Management…etc. The 4K VLAN, 8 physical queues, 13 groups
link aggregation groups are superb functionality for all applications. With these
features, the switch is ideal for the SMB network environment to strengthen its
network connection.
IEEE 802.3at Power over Ethernet (PoE+) ports
The switch features 16 IEEE 802.3at Power over Ethernet (PoE+) ports supplying
up to 30 watts per port. This product can convert standard 100~240V/AC power into
low-voltage DC that runs over existing LAN cable to power up IEEE 802.3at
compliant network accessories. It also features PoE awareness to verify whether the
network device receive power is IEEE 802.3at compliant, or only the data will be
sent through LAN cable. By adding the switch to the existing networking, installing
networking products such as Access Points and IP cameras can be easily managed
and set up. Wireless device deployments are easily located with available power
outlets and network administrators don’t need to use heavy AC power adapters
anymore.
2 Gigabit SFP Open Slots
The switch supports 2 additional SFP open slots to uplink to servers, storage, or
other switching devices for long loop reach applications. The 2 SFP slots can
support different types, speed and distance SFP transceivers. It also supports
legacy 100M SFP transceiver. If the 100M fiber infrastructure is constructed and
100M bandwidth is enough, the 100M SFP transceiver can be an optional choice for
the legacy 100M network environment.

Chapter 1: Product Overview
Product Overview
NGSME16T2H User Manual | 13
Advanced Web Smart Features
The switch features advanced web smart management features and SNMP for
remote management. Through a Web-based interface, an administrator can set up
VLANs to segregate traffic, QoS to prioritize mission-critical data, RSTP/Loop
Protection to avoid network loop, link aggregation to create fat traffic pipelines,
bandwidth control to limit traffic load and the 802.1X and Access Management to
secure your network. Furthermore, it provides Cable Diagnostic, Ping, Firmware
upgrading, Configuration Backup and Restore are very helpful for remote diagnostic
and maintenance.

Chapter 1: Product Overview
Product Overview
NGSME16T2H User Manual | 14
Product Specification
Standard
Ethernet : IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.ab
1000Base-T, IEEE 802.3z 1000Base-SX/LX,
IEEE 802.3x Full-duplex and Flow Control
IEEE 802.3az EEE (Energy Efficient Ethernet)
IEEE 802.3at PoE+ (Power over Ethernet)
IEEE 802.1Q VLAN
IEEE 802.3ad Link Aggregation Control Protocol
IEEE 802.1ab Link Layer Discovery Protocol
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1p Class of Service, Priority Protocols
IEEE 802.1X Port-based Network Access Control
Interface
Number of Port: 18, All Ethernet Port are on the Rear
10/100/1000Base RJ-45 Port: 16, Auto-negotiation, Auto MDI/MDIX
100/1000Base-X SFP: 2
Performance
Switch Fabric: 36Gbps
MAC Address Table Size: 8K
Forwarding Rate: 26.7Mpps
Packet Buffer: 4Mb
PoE Features
802.3af/at Compliant
Max. Power Output Per Port: 30W
PoE Power Budge: 200W
PoE Management:
Per Port: Enable/Disable, Priority Setting, Maximum Power, PoE Mode Setting
Per System: Maximum Power
PD Classification, PoE Status
L2 Features
Management Interface: Web Browser, SNMP v1/v2c/v3
IP Configuration: IP Setting, DHCP Client, NTP

Chapter 1: Product Overview
Product Overview
NGSME16T2H User Manual | 15
EEE: EEE Configuration for power reduction
Port Configuration: Auto-Negotiation, Port Speed/Duplex control, Flow Control,
Jumbo Frame Enable/Disable, Power Control
Switch Security: System Password, Access Management, HTTPS
IEEE 802.1x(NAS): Port-based access control
Link Aggregation: Static & LACP, up to 9 Groups
Spanning Tree: Rapid Spanning Tree Protocol and legacy STP
Loop Protection: Loop protection to avoid network loop
IGMP Snooping: IGMP Snooping V1/V2, IGMP Query
LLDP: IEEE 802.1ab Link Layer Discovery Protocol
MAC Address Table: Ageing Time, Static/Secure MAC Table
VLAN: IEEE 802.1Q VLAN, up to 4K groups
Private VLAN: Private VLAN and Port Isolation
QoS: 8 Priority Queue, Strict & WRR scheduler
Syslog: System log server mode
Diagnostic: Cable Diagnostic, Ping, Mirroing
Maintenance: Firmware Upgrade, Configuration Backup and Restore, Reload
Default, Warm Reboot
LEDs Indicators
Per Port PoE: On(Amber) - PD is connected
Per Port Link/Act: On/Slow Blinking(Green) – Ethernet Port is connected;
Quick Blinking(Green) – Data Transmitting/Receiving
System: On - Power On (Amber)
Power Input
100~240VAC
Power Consumption
PoE: max. 200W
System: 15W
Dimension(H*W*D)
44*330*220mm
Weight
2.2 kg
Operating Temperature
0~40℃

Chapter 1: Product Overview
Product Overview
NGSME16T2H User Manual | 16
Humidity
5~90% (non-condensing)
Certification
CE, FCC Class A
Safety: UL (UL60950-1), CE(IEC60950-1)

Chapter 1: Product Overview
Product Overview
NGSME16T2H User Manual | 17
Hardware Description
This section mainly describes the hardware of Full L2 Management Network Switch
and gives a physical and functional overview on the certain switch.
Front Panel
The front panel of the L2 management switch consists of 16 10/100/1000 Base-TX
RJ-45 ports and 2 gigabit uplink SFP ports. The LED Indicators are also located on
the front panel.
LED Indicators
The LED Indicators present real-time information of systematic operation status. The
following table provides description of LED status and their meaning.
LED
Color / Status
Description
No. of LEDs
Power
Amber On
Power on
Power
10/100/1000M
Green On
Link Up
16
Green Blinking
Data Activating
PoE
Amber On
PD is connected
16
SFP
Green On
linked to Power Device
17~18
Green Blinking
Data Activating
17~18
Rear Panel
The rear panel of the Web Smart PoE Switch contains 2 ventilation fans, a power
switch, and a IEC 60320 plug for power supply.

Chapter 1: Product Overview
Product Overview
NGSME16T2H User Manual | 18
Hardware Installation
To install the Web Smart PoE Switch, please place it on a large flat surface with a
power socket close by. This surface should be clean, smooth, and level. Also, please
make sure that there is enough space around the PoE Switch for RJ45 cable, power
cord and ventilation.
If you’re installing this Web Smart PoE Switch on a 19-inch rack, please make sure
to use the rack-mount kit (L brackets) and screws come with the product package.
All screws must be fastened so the rack-mount kit and your product are tightly
conjoined before installing it on your 19-inch rack.
Ethernet cable Request
The wiring cable types are as below.
10 Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
100 Base-TX: 2-pair UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
1000 Base-T: 4-pair UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (Max. 100m)
PoE: To delivery power without problem, the Cat 5e and Cat 6 cable is suggested.
The high quality Ethernet cable reduces the lost while power transmission.
SFP Installation
While install the SFP transceiver, make sure the SFP type of the 2 ends is the same
and the transmission distance, wavelength, fiber cable can meet your request. It is
suggested to purchase the SFP transceiver with the switch provider to avoid any
incompatible issue.
The way to connect the SFP transceiver is to Plug in SFP fiber transceiver fist. The
SFP transceiver has 2 plug for fiber cable, one is TX (transmit), the other is RX
(receive). Cross-connect the transmit channel at each end to the receive channel at
the opposite end.
For more information regarding to the product safety and maintenance guide, please
refer to Appendix A: Product Safety.

NGSME16T2H User Manual | 19
Chapter 2:
Preparing for Management
In Preparing for Management:
This section will guide your how to manage this product via serial console,
management web page, and Telnet/SSH interface.
The switch provides both in-band and out-band configuration methods.
Out-band Management: You can configure the switch via RS232 console cable if
you don’t attach your admin PC to your network, or if you lose network connection to
your switch. It wouldn’t be affected by network performance. This is so-called
out-band management.
In-Band Management: You can remotely manage the switch via the Web browser,
such as Microsoft Internet Explorer, or Mozilla, to configure and interrogate the
switch from anywhere on the network.
 Preparation for Serial Console
 Preparation for Web Interface
 Preparation for Telnet/SSH Interface

Chapter 2: Preparing for Management
Preparing for Management
NGSME16T2H User Manual | 20
Preparation for Serial Console
In the package, there is one RS-232 console cable. Please attach one end of the
console cable to your PC COM port, the other end to the console port of the switch.
1. Go to Start -> Program -> Accessories -> Communication -> Hyper Terminal
2. Give a name to the new console connection.
3. Choose the COM name
4. Select correct serial settings. The serial settings of the switch are as below:
Baud Rate: 115200 / Parity: None / Data Bit: 8 / Stop Bit: 1
5. After connected, you can see Switch login request.
6. Login the switch. The default username is “admin”, password, “admin”.
Figure 3-1 Hyper Terminal Console Screen
Note: The Win 7 or later OS version doesn't provide Console Terminal tool, please
download the tool, Hyper Terminal from Microsoft web site or other terminal tools,
such as PuTTY for console connection. Type Hyper Terminal or Putty in Google web
site, thus you can find link to download it.
