Lantronix SecureLinx SLK Series User manual

SecureLinx SLK Remote KVM
User Guide
•SecureLinx SLK1
•SecureLinx SLK8
•SecureLinx SLK16
Part Number: 900–336
Revision B March 2005

Copyright and Trademark
© 2005, Lantronix. All rights reserved. No part of the contents of this book may
be transmitted or reproduced in any form or by any means without the written
permission of Lantronix. Printed in the United States of America.
SecureLinx and Remote KVM are trademarks of Lantronix. Ethernet is a trademark of
XEROX Corporation. UNIX is a registered trademark of The Open Group. Windows 95,
Windows 98, Windows NT, Windows ME, Windows 2000, and Windows XP are
trademarks of Microsoft Corp. Netscape is a trademark of Netscape Communications
Corporation.
Contacts
Lantronix Corporate Headquarters
15353 Barranca Parkway
Irvine, CA 92618, USA
Phone: [phone]
Fax: [phone]
Technical Support
Phone: [phone] or 949–453–7198
Fax: [phone]
Online: www.lantronix.com/support
Sales Offices
For a current list of our domestic and international sales offices, go to the Lantronix Web
site at www.lantronix.com/about/contact/index.html.

Disclaimer
Operation of this equipment in a residential area is likely to cause interference, in
which case the user, at his or her own expense, will be required to take whatever
measures may be required to correct the interference.
Changes or modifications to this device not explicitly approved by Lantronix will void
the user's authority to operate this device.
Note: This equipment has been tested and found to comply with the limits for Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with this
User Guide, may cause interference to radio communications.
Theinformationinthisguidemaychangewithoutnotice.Themanufacturerassumes
no responsibility for any errors that may appear in this guide.
Revisions
Rev. Date Comments
A2/04
B 3/05 Updated firmware; added new Java viewer applet;
added secondary administrator account, integrated
remote power control support of SLP series.

SecureLinx SLK Remote KVM User Guide i
Contents
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-i
List of Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-v
List of Tables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-vii
1: Quick Start
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Making the Physical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Powering On and Initial Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Validating Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Where to Go from Here . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
2: Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
SecureLinx SLK Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
SLK1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
SLK8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
SLK16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Features at a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Feature Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
SLK Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Connecting to the Same Network and Switch as the Server . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Connecting to Different Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Multiple Server Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
3: Installing the SLK
Unpacking Your Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Items Supplied by the User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
SLK1 Front and Back Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
SLK8 Front and Back Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
SLK16 Front and Back Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Installing the SLK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Rack-Mounting the SLK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Preparing the Target Servers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Connecting Devices to the SLK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
Connecting to the Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Connecting Serial Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Connecting to a Power Source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Validating Target Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
Where to Go from Here . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
4: Using the Web Control Interface to Configure the SLK
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Starting a Session . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Understanding the Web Control Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4

ii SecureLinx SLK Remote KVM
Performing Operation Activities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Controlling Hosts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Viewing Hosts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
Using Power Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Performing User Activity Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
Viewing the Event Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-16
Flash File System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-17
Debug (SLC16 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
Performing Configuration Activities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
Specifying the SLK Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
Configuring PPP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-21
Setting Up User Accounts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-23
Changing Your Own Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-28
Configuring a Security Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
Monitoring Your Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
Configuring Serial Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-37
Configuring Local User/VNC Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-39
Setting the Date and Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-41
Configuring Syslog Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-41
Configuring SNMP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-43
Performing Information Activities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
Viewing the Full Menu Tree. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-45
Viewing the Browse Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-46
Viewing Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-47
Viewing Version Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-48
Viewing Capture Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-49
Viewing Copyright Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-50
5: Using the OSD Interface to Configure the SLK
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Logging into the OSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Navigating through the OSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Channel Switch Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Setup Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Network Configuration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
PPP Options (SLC16 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Monitoring Settings Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
First Monitoring Settings Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Second Monitoring Settings Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
Third Monitor Settings Screen (SLK16 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Network Management Settings Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
SNMP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Syslog Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Security Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
Initial Security Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
Second Security Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
User Administration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
User Name Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
Serial Port Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
Local User Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
Virtual Network Computing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20
Channel Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20
Power Outlet Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20
Debug – (Factory Only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20

SecureLinx SLK Remote KVM User Guide iii
6: Using a VNC Viewer to Access the SLK
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Using a VNC Viewer to Access Target Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
7: Troubleshooting
General Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Keyboard Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Mouse Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Video Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
8: Uploading Flash Files and Certificates
Uploading Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Checking the Current SLK Firmware Version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Downloading Firmware from the Lantronix Web Site. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Uploading Firmware to Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Using Security and Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Using SSL with a Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Using SSL without a Browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Locating Internet Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Uploading Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
9: Defining Custom Send Keys
Custom Key Creation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Custom Key Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Examples. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Potential Send Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
A: Specifications
Hardware Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-1
Software Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-5
Agency Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-6
B: Binary to Hexadecimals
C: Glossary
Warranty
Index

iv SecureLinx SLK Remote KVM

SecureLinx SLK Remote KVM User Guide v
List of Figures
Figure 1-1. SLK1 Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Figure 1-2. SLK8 Back Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
Figure 1-3. SLK16 Back Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-4
Figure 2-1. Connecting to the Same Network and Switch as the Server . . . . . . . . . . . .2-4
Figure 2-2. Connecting to Different Switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Figure 2-3. Multiple Server Configuration without Firewall. . . . . . . . . . . . . . . . . . . . . . . . . .2-5
Figure 2-4. Multiple Server Configuration with Firewall . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6
Figure 3-1. SLK1 Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
Figure 3-2. SLK1 Back Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
Figure 3-3. SLK8 Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5
Figure 3-4. SLK8 Back Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
Figure 3-5. SLK16 Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7
Figure 3-6. SLK16 Back Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8
Figure 3-7. Recommended Mouse Settings for Target Servers. . . . . . . . . . . . . . . . . . . . .3-12
Figure 3-8. SLK1 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-14
Figure 3-9. SLK8 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15
Figure 3-10. SLK16 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15
Figure 3-11. Connecting a Notebook PC to the SLK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-18
Figure 3-12. SLK Home Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-19
Figure 3-13. Example of Viewing Video from a Remote Server. . . . . . . . . . . . . . . . . . . . . .3-20
Figure 3-14. Example of No Incoming Video Message . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-20
Figure 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Login Window4-2
Figure 4-2. SLK Home Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3
Figure 4-3. Web Control Interface Page Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Figure 4-4. Example of Controlling a Host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9
Figure 4-5. Viewing Hosts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-12
Figure 4-6. Power Control with an Optional SLP Remote Power Manager . . . . . . . . . . . .4-13
Figure 4-7. User Activity Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-15
Figure 4-8. Event Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-16
Figure 4-9. Flash File System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-17
Figure 4-10. Debug Menu Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-18
Figure 4-11. Network Configuration Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-20
Figure 4-12. PPP Configuration Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-22
Figure 4-13. User Accounts Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-23
Figure 4-14. Entering a Master Account Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-24
Figure 4-15. Page for Changing a User ID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-25
Figure 4-16. Page for Changing a User Password. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-26
Figure 4-17. Page for Changing User Channel Privileges . . . . . . . . . . . . . . . . . . . . . . . . . .4-27
Figure 4-18. Page for Changing Your Own Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-28
Figure 4-19. Security Policy Configuration Page (Security Profiles and Policy). . . . . . . . . .4-29
Figure 4-20. Security Policy Configuration Page (bottom) . . . . . . . . . . . . . . . . . . . . . . . . . .4-30
Figure 4-21. Monitoring Configuration Page (Alert Action). . . . . . . . . . . . . . . . . . . . . . . . . .4-35
Figure 4-22. Monitoring Configuration Page (Error Conditions to Monitor)). . . . . . . . . . . . .4-36
Figure 4-23. Serial Port Configuration Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-37
Figure 4-24. Local User/VNC Configuration Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-39
Figure 4-25. Date and Time Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-41
Figure 4-26. Syslog Configuration Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-42

vi SecureLinx SLK Remote KVM
Figure 4-27. SNMP Configuration Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-43
Figure 4-28. OSD Menu Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-45
Figure 4-29. OSD Menu Page. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-46
Figure 4-30. Viewing Connection Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-47
Figure 4-31. Version Information Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-48
Figure 4-32. Capture Settings Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-49
Figure 4-33. Copyright Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-50
Figure 5-1. OSD Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Figure 5-2. Channel Switch Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-4
Figure 5-3. OSD Setup Menu Screen (1 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Figure 5-4. Network Configuration Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Figure 5-5. PPP Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Figure 5-6. Monitoring Settings Screen (1 of 3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Figure 5-7. Monitoring Settings Screen (2 of 3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-9
Figure 5-8. Monitor Settings Screen – SLK16 Only (3 of 3) . . . . . . . . . . . . . . . . . . . . . . . 5-10
Figure 5-9. Network Management Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Figure 5-10. SNMP Configuration Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Figure 5-11. Syslog Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Figure 5-12. User Administration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
Figure 5-13. User Name Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
Figure 5-14. Serial Port Configuration (Screen 1 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
Figure 5-15. Serial Port 1 — Baud Rate Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
Figure 5-16. Serial Port 2 — Baud Rate Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
Figure 5-17. Serial Port Configuration (Screen 2 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
Figure 5-18. Serial Port 3— Baud Rate Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
Figure 5-19. Local User Control Screen (1 of 2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
Figure 5-20. Local User Control Screen (2 of 2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
Figure 6-1. Local Console VNC Configuration Screen . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Figure 6-2. Connection Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Figure 6-3. OSD/VNC Menu with Corner Icon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Figure 8-1. Example of a Version Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Figure 8-2. Controls for Locating and Uploading Firmware. . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Figure 8-3. Controls for Locating and Uploading Firmware. . . . . . . . . . . . . . . . . . . . . . . . . 8-4
Figure B-1. Scientific Calculator with Binary Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-2
Figure B-2. Scientific Calculator with Hex Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .B-2

SecureLinx SLK Remote KVM User Guide vii
List of Tables
Table 2-1. SLK Feature Comparison. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Table 3-1. Components Shipped with the SecureLinx SLK Remote KVMs . . . 3-2
Table 3-2. SLK1 Front Panel Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Table 3-3. SLK1 Back Panel Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Table 3-4. SLK8 Front Panel Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Table 3-5. SLK8 Back Panel Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Table 3-6. SLK16 Front Panel Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Table 3-7. SLK16 Back Panel Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Table 4-1. Web Control Interface Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Table 4-2. SLK Operation Activities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Table 4-3. Menus, Icons, and Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Table 4-4. SLK Configuration Activities. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
Table 4-5. SLK Information Activities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
Table 5-1. Navigating through the OSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Table 6-2. Values for Selecting Channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Table B-1. Binary to Hex ConversionsDecimal Binary Hex. . . . . . . . . . . . . . . . . . B-1

viii SecureLinx SLK Remote KVM

SecureLinx SLK Remote KVM User Guide 1-1
1: Quick Start
This Quick Start chapter describes how to get your SecureLinx™ SLK Remote KVM™
up and running in the shortest possible time. For detailed installation instructions, see
Chapter 5, Installing the SLK. Topics in this chapter include:
Getting Started
1 Verify and inspect the contents of the SLK package using the enclosed packing slip
or Table 3-1 on page 3-2. If any item is missing or damaged, contact your place of
purchase immediately.
2 Rack-mount the SLK, if desired. For more information, see “Rack-Mounting the
SLK” on page 3-10.
3 For optimum operation during remote sessions, prepare the target servers as
described under “Preparing the Target Servers” on page 3-10.
4 To use your SLK with other KVM switches, see “Connecting KVM Switches” on
page 3-16.
Topic Page Number
“Getting Started” 1-1
“Making the Physical Connections” 1-2
“Powering On and Initial Configuration” 1-4
“Validating Servers” 1-5
“Where to Go from Here” 1-6

Quick Start
1-2 SecureLinx SLK Remote KVM
Making the Physical Connections
The following procedure describes how to perform SLK connections. Refer to
Figure 1-1 on page 1-3, Figure 1-2 on page 1-3, and Figure 1-3 on page 1-4 for visual
reference.
1 Disconnect the monitor, keyboard and mouse from the servers or KVM-switch that
your SLK is to control.
2 Connect the local video, keyboard, and mouse to allow local console access to the
SLK and the servers or KVM-switch attached to it:
❖Connect the monitor plug to the blue 15-pin HDDB15 female port labeled
Monitor.
❖Connect the keyboard plug to the round PS/2 mini-DIN female port labeled K.
❖Connect the mouse plug to the round PS/2 mini-DIN female port labeled M.
3 Connect the server monitor, keyboard, and mouse cables (removed in step 1) from
the appropriate ports on the server to the appropriate channel ports on the SLK
back panel:
❖Connect the monitor plug to the black 15-pin HDDB15 male port labeled Video.
❖Connect the keyboard plug to the round PS/2 mini-DIN female port labeled K.
❖Connect the mouse plug to the round PS/2 mini-DIN female port labeled M.
The SLK1 has one channel providing individual ports for a monitor, keyboard, and
mouse. The SLK8 and SLK16 have 8 and 16 channels, respectively, with monitor,
keyboard, and mouse ports for each channel. For these models, start your
connections at CH-1, then CH-2, and so on.
Note: SLK1 and SLK8 only support 2-button mice. The SLK16 is compatible with
2-button wheel mice.
4 Connect the SLK KVM to the network using the 10/100Base-T Ethernet port (RJ45)
labeled Network.
5 To remotely control serial devices, configure the serial port(s) to suit your needs. All
SLK models provide two serial ports for power control, Telnet, and logging functions.
The SLK16 has a third serial port that can connect to an external modem for out-of-
band access.
Note: The second serial port on the SLK1 and SLK8 is an 8-pin mini-DIN connector that
requires the supplied 8-pin–to–DB9 adapter.
6 Connect the supplied power cord to the SLK’s AC receptacle and to a power
source.

Quick Start
SecureLinx SLK Remote KVM User Guide 1-3
Figure 1-1. SLK1 Back Panel
Figure 1-2. SLK8 Back Panel
AC Power Receptacle
RJ45 Network Connector
Serial Port 1
Serial Port 2
Channel Port Connectors for Target Server
Local Keyboard, Monitor, Mouse Connectors
AC Power
Serial Port 1 Serial Port 2
RJ45 Network Connector
Receptacle Local
Keyboard,
Monitor, Mouse
8 Channel Port Connectors for Target Servers
(CH-1 — CH-8)
Connectors

Quick Start
1-4 SecureLinx SLK Remote KVM
Figure 1-3. SLK16 Back Panel
Powering On and Initial Configuration
1 Power on the equipment in the following sequence: start with any KVM switches
cascaded in front of your SLK, followed by your SLK, and then by attached servers
and any converters or extenders.
2 At the local keyboard, press the key twice.
3 When the On Screen Display opens, scroll down to Setup Menus and press Enter.
4 Select Network Configuration and press Enter.
5 From the Network Configuration page, assign an IP address to your SLK. Write
down this number, as you will need to use it in step 1 under “Validating Servers.”
6 If you want your SLK to communicate outside the Local Area Network (LAN), set the
default gateway.
7 Select Commit IP config changes and press Enter to commit your changes.
AC Power
Receptacle
Serial Port 1
Serial Port 2
Serial
Port 3
RJ45 Network Connector
Local
Keyboard,
Monitor, Mouse
Connectors
8 Channel Port Connectors for Target Servers
(CH-1 — CH-8)
8 Channel Port Connectors for Target Servers
(CH-9 — CH-16)

Quick Start
SecureLinx SLK Remote KVM User Guide 1-5
Validating Servers
After you configure your SLK, connect a PC to it via a TCP/IP connection:
Verify each server’s remote performance:
1 Start your web browser and enter the SLK’s IP address in the address bar. User
name and password prompts display.
2 Type the default user name root in lower-case characters and type the default
password PASS in upper-case characters; then click OK. The SLK home page
opens.
3 Under Channel (click to view), click the first channel (the channel in the top
row).
4 Verify that you can view the video. If you see NO INCOMING VIDEO, see
“Video Troubleshooting” on page 7-8.
5 Move the mouse and verify that the on-screen pointer moves as you move the
mouse. If it does not, see “Mouse Troubleshooting” on page 7-5.
6 Click the Back button in your browser to return to the SLK home page.
7 Click the channel on the next row and repeat steps 4 through 6. Repeat this step
for all the remaining channels that are being used.

Quick Start
1-6 SecureLinx SLK Remote KVM
Where to Go from Here
Following the initial configuration and verification, set up users and security parameters.
There are two ways to configure your SLK:
❖Using its embedded web control interface
❖Using the local console’s On Screen Display (OSD) interface
The web control interface provides a graphical interface that lets you configure your SLK
and control the target servers and other connected devices using a standard web
browser. For more information, see Chapter 4, “Using the Web Control Interface to
Configure the SLK.”
The OSD configuration method provides a text-based interface with minimal prompting
and guidance. For more information, see “Using the OSD Interface to Configure the
SLK.”
After you configure your SLK, you can:
❖Change the master account password. See “Changing the Master Account
Password” on page 4-23.
❖Check for updated firmware. See “Uploading Firmware” on page 8-1.
❖Upload the proper encryption certificate and key into the SLK Flash File if you want
to use encryption. See “Using Security and Encryption” on page 8-3.
Note: For answers to frequently asked questions about the SecureLinx SLK Remote
KVMs, please visit www.lantronix.com/support.

SecureLinx SLK Remote KVM User Guide 2-1
2: Introduction
This chapter provides introductory information about your SecureLinx SLK Remote
KVM. Topics in this chapter include:
Overview
SecureLinx is a family of remote server-management solutions that enable remote
clients to efficiently control their target servers and serial devices over a Local Area Net-
work (LAN) or the Internet using the standard Transmission Control Protocol/Internet
Protocol (TCP/IP). Secure remote access is provided through any web browser by
entering the SLK’s IP address. Once access is granted, remote clients can perform
activities such as resetting the target hardware, accessing the Basic Input Output Sys-
tem (BIOS), gaining keyboard and mouse control, and cycling power — as if they were
accessing the server locally.
Note: VNC can also be used for remote access. However, because VNC does not
support encryption, it does not provide a secure connection unless used with a Virtual
Private Network (VPN) or Secure Shell (SSH).
SecureLinx SLK Remote KVMs also provide automatic monitoring and notification
capabilities that notify you of problematic symptoms in your network environment before
they become critical. This break-through technology makes the SLK an essential com-
ponent of your server crisis-management infrastructure by giving you the power to
quickly recover from mission-critical server failures anywhere in the world.
SecureLinx SLK Remote KVMs also save you money by eliminating redundant periph-
erals (such as keyboards, monitors, and mice) and providing centralized control of mul-
tiple servers. Best of all, SecureLinx SLK Remote KVMs are plug-and-play solutions
that require no additional hardware or software, making initial setup quick and simple.
This non-intrusive approach means the SLK does not consume valuable server
resources while, at the same time, minimizes potential points of failure.
Topic Page Number
“Overview” 2-1
“SecureLinx SLK Models” 2-2
“Features and Benefits” 2-3
“SLK Configurations” 2-4

Introduction
2-2 SecureLinx SLK Remote KVM
With a small investment, SecureLinx SLK Remote KVMs can preserve precious office
space, centralize the management of your servers and serial devices, slash redundant
peripheral costs, and increase uptime and productivity.
SecureLinx SLK Models
SecureLinx SLK Remote KVMs come in three models:
❖SLK1 lets local and remote users control 1 server.
❖SLK8 lets local and remote users control up to 8 servers.
❖SLK16 lets local and remote users control up to 16 servers.
SLK1
The SLK1 provides one local user and multiple remote users with “shared” access to
one server. All users have simultaneous access to the single server. Because this
access is shared, only one user should control the server at a time. The SLK1 has two
serial ports.
SLK8
The SLK8 provides one local user and multiple remote users with access to up to eight
servers. The SLK8 supports independent operation between the local user and remote
users. This allows the local user to perform tasks independently of remote users. For
example, the local user might access the server on channel 1, while remote users
access the server on channel 2 at the same time.
By contrast, all remote users are dependent on each other. If a remote user changes
the view from the server on channel 2 to the server on channel 3, for example, all other
remote users view the channel 3 server.
The SLK8 has two serial ports.
SLK16
The SLK16 provides one local user and multiple remote users with access to up to 16
servers. The SLK16 supports up to 6 independent remote sessions. This allows the
local user and up to six remote users to perform simultaneous tasks independently of
each other. They can all access the same server or servers on different channels.
The SLK16 also allows a remote user to “lock down” his server channel for his use only.
Locking down a channel privatizes the session, preventing the channel from being
accessed by other users. When a channel is locked, only the user who locked it and the
SLK administrator can unlock the channel.
The SLK16 has three serial ports.
