Nokta MAKRO Midi Hoard User manual

WORLD'S FIRST WATERPROOF KIDS METAL DETECTOR!
Quick Guide
For the young
treasure hunters
of the future…
Authorized
R&D CENTER

ASSEMBLY
The device comes disassembled in 2 pieces. To assemble the
device, first remove the small spongy cable protector piece
on the middle shaft and dispose it. Next, engage the shafts
together so that the screw hole is centered in the slot. Pay
attention not to damage the cable during this process. Then,
place the obround piece in the slot with the arch mark facing
upwards. Lastly, tighten the bolt to secure.
To adjust the shaft length to your height, open the lever latch.
Pull the lower shaft down and after adjusting the length, press
the level latch to secure. Do not extend it beyond the ''max''
mark.
To adjust the coil angle parallel to the ground, loosen the nut.
Once adjusted, tighten back to secure.
WARNING! The search coil is NOT detachable, do not attempt
to remove!

BATTERY INSTALLATION
To install or replace batteries, remove the screw located on the battery compartment cover
with a screwdriver. Then, rotate the cover 1/4 turn as shown in the image and pull out.
Install the batteries paying attention to (+) and (-) signs as indicated on the sticker. Then,
attach the battery compartment cover by reversing the above process and secure by
tightening the screw.

QUICK GUIDE
13
2
4
9
8
10
11
7
5
6
1) On/Off and Discrimination Button
On/Off and Discrimination Button
To discriminate out one or two of the target types mentioned above, press once or twice.
The detector now will only detect targets shown on screen.
2) Pinpoint Button: Press and hold down to find the exact location of the target.
Signal sound becomes stronger and changes in tone while getting closer to the target
center. In addition, the LED turns green when the search coil is over the center of the
target.
3) Sensitivity/Volume Button
4) LED Indicator
While detecting - Green: Low and high value coins, screw caps and some pull-tabs. Yellow:
Rings, pull-tabs, lower value coins and aluminum foil. Red: Ferrous (iron) objects, nails and
horseshoes.
While Pinpointing - Lights up green when the search coil is over the center of the target.

QUICK GUIDE
5) Sensitivity
Consists of 3 levels:
Press the Sensitivity/Volume button one by one to increase and decrease.
6) Depth Indicator
TARGETS TYPES AND TONES
7) Ferrous (iron) objects, nails and horseshoes.
Midi Hoard will emit a low tone for these targets.
8) Rings, pull-tabs, lower value coins and aluminum foil.
Midi Hoard will emit a medium tone for these targets.
9) Low and high value coins, screw caps and some pull-tabs.
Midi Hoard will emit a high tone for these targets.
10) Battery Indicator
Once the battery indicator displays empty status, the device will continue to work for a
short period of time and then shut off after a warning tone.
11) Volume
Consists of 2 levels:
Press and hold down the Sensitivity/Volume button to adjust.
Overload Warning Sound
Large and/or near-surface targets will overload the detector and the detector will emit a
continuous warning sound. In such a case, lift the search coil up until the sound stops.
Auto Shut-off & Alarm
After about half an hour of inactivity, the Midi Hoard will start emitting an audible alarm.
After 3 minutes of alarm, the device will shut off automatically to save battery life.
Low Medium High
Shallow Medium Depth Deep
Low High
Empty Low Medium Full

CORRECT WAY OF SWEEPING
It is important to keep the search
coil parallel to the ground in order
to get accurate results.
The search coil must be parallel to
the ground at all times.
Wrong search coil angle Wrong search coil angle Correct search coil angle
Incorrect way of sweeping Correct way of sweeping
WARNINGS
1. Do not store the device and search coil under extremely low or high temperatures for
extended periods. (Storage Temperature: - 20°C to 60°C / - 4°F to 140°F)
2. The device has been designed with IP68 rating as a waterproof unit up to 1 meters /
3ft.
Pay attention to the items below after using the device especially under salty water:
a. Wash the device with tap water and be sure no salt water is left.
b. Do not use any chemicals for cleaning and/or for any other purposes.
c. Wipe the device dry with a soft, non-scratch cloth.
QUICK GUIDE

Ideal Age : 8-12+ yrs.
Operating Principle : VLF
Operating Frequency : 15kHz
Audio Tones : 3
Pinpoint : Yes
Sensitivity Setting : 3 Levels
Discrimination : 2 Levels
LED Indicator : Pinpoint & Discrimination (Red, Yellow, Green)
Depth Indicator : 3 Levels
Battery Indicator : Yes
Auto Shut-off & Alarm : Yes
Volume Control : 2 Levels
Search Coil : 18cm. (7'')
Display : Custom LCD
Weight : 880gr. (1.9lbs.)
Length : 82-109cm. (32.5''- 43'')
Battery : 2xAA (not included)
Warranty : 2 years
Nokta Makro Detectors reserves the right to change the design, specifications or
accessories without notice and without any obligation or liability whatsoever.
WARRANTY
This product has a 2 year limited warranty from the time of purchase. Please refer to
www.noktadetectors.com for further warranty information.
Happy metal detecting with the Midi Hoard!
For Consumers within the
European Union: Do not
dispose of this equipment
in general household waste.
The crossed wheeled bin
symbol on this equipment
indicates this unit should
not be disposed of in general household waste,
but recycled in compliance with local government
regulations and environmental requirements.
FCC STATEMENT This device complies with Part
15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not
cause harmful interference, and (2) this device
must accept any interference received, including
interference that may cause undesired operation.
TECHNICAL SPECS
