USER’S MANUAL
Model No. NTL19124-INT.2
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference. iconeurope.com
MEMBER CARE
UNITED KINGDOM
Website: iFITsupport.eu
E-mail: [email protected]
Write:
iFIT Health & Fitness Limited
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: [e-mail]
Write:
iFIT Inc.
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA

2
IMPORTANT PRECAUTIONS..................................................................3
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
PART IDENTIFICATION CHART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
HOW TO PLUG IN THE POWER CORD ........................................................17
HOW TO USE THE TREADMILL ..............................................................18
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
MAINTENANCE AND TROUBLESHOOTING.....................................................31
EXERCISE GUIDELINES ....................................................................34
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
RECYCLING INFORMATION ......................................................... Back Cover
TABLE OF CONTENTS
NORDICTRACK and IFIT are registered trademarks of iFIT Inc. The Bluetooth®word mark and logos are regis-
tered trademarks of Bluetooth SIG, Inc. and are used under license. Google Maps is a trademark of Google LLC.
Wi-Fi is a registered trademark of Wi-Fi Alliance. WPA and WPA2 are trademarks of Wi-Fi Alliance.

3
1. It is the responsibility of the owner to ensure
that all users of the treadmill are adequately
informed of all warnings and precautions.
2. Keep children under age 16 and pets away
from the treadmill at all times.
3. Consult your health care provider before
beginning any exercise program. This is
especially important for persons over age 35
or persons with pre-existing health problems.
4. Consult your health care provider before
beginning or continuing any exercise pro-
gram during pregnancy. Use the treadmill
only as authorized by your health care
provider.
5. The treadmill is not intended for use by
persons with reduced physical, sensory, or
mental capabilities or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning the
use of the treadmill by someone responsible
for their safety.
6. Use the treadmill only as described in this
manual.
7. The treadmill is intended for home use only.
Do not use the treadmill in any commercial,
rental, or institutional setting.
8. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
9. Place the treadmill on a level surface, with
at least 8 ft. (2.4 m) of clearance behind it
and 2 ft. (0.6 m) on each side. Do not place
the treadmill on any surface that blocks air
openings. To protect the floor or carpet from
damage, place a mat under the treadmill.
10. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
11. The treadmill should be used only by
persons weighing 300 lbs. (135 kg) or less.
12. Never allow more than one person on the
treadmill at a time.
13. Wear appropriate exercise clothes while
using the treadmill. Do not wear loose
clothes that could become caught in the
treadmill. Athletic support clothes are recom-
mended for both men and women. Always
wear athletic shoes. Never use the treadmill
with bare feet, wearing only stockings, or in
sandals.
14. When connecting the power cord (see
page 17), plug the power cord into an earthed
circuit. No other appliance should be on the
same circuit. When replacing the fuse in the
power cord adapter, insert an ASTA-approved
BS1362, 13-amp fuse into the fuse carrier.
15. If an extension cord is needed, use only a
3-conductor, 14-gauge (2 mm2) cord that is
no longer than 5 ft. (1.5 m).
16. Keep the power cord away from heated
surfaces.
17. Never move the walking belt while the power
is turned off. Do not operate the treadmill
if the power cord or plug is damaged, or if
the treadmill is not working properly. (See
MAINTENANCE AND TROUBLESHOOTING
on page 31 if the treadmill is not working
properly.)
18. Read, understand, and test the emergency
stop procedure before using the treadmill
(see HOW TO TURN ON THE CONSOLE on
page 19). Always wear the clip while using
the treadmill.
19. Be careful when mounting and dismounting
the treadmill. Always stand on the foot rails
when starting or stopping the walking belt.
Always hold the handrails while using the
treadmill.
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read
all important precautions and instructions in this manual and all warnings on your treadmill before
using your treadmill. iFIT assumes no responsibility for personal injury or property damage sus-
tained by or through the use of this product.
IMPORTANT PRECAUTIONS

4
20. When a person is walking on the treadmill,
the noise level of the treadmill will increase.
21. Keep fingers, hair, and clothing away from
the moving walking belt.
22. The treadmill is capable of high speeds.
Adjust the speed in small increments to
avoid sudden jumps in speed.
23. Never leave the treadmill unattended while
it is running. Always remove the key, press
the power switch into the off position (see
the drawing on page 6 for the location of the
power switch), and unplug the power cord
when the treadmill is not in use.
24. Do not attempt to move the treadmill until
it is properly assembled. (See ASSEMBLY
on page 8 and HOW TO FOLD AND MOVE
THE TREADMILL on page 30.) You must be
able to safely lift 45 lbs. (20 kg) to move the
treadmill.
25. When folding or moving the treadmill, make
sure that the storage latch is holding the
frame securely in the storage position. Do
not operate the treadmill while it is folded.
26. Do not change the incline of the treadmill by
placing objects under the treadmill.
27. Never insert any object into any opening on
the treadmill.
28. Inspect and properly tighten all parts each
time the treadmill is used. Replace any worn
parts immediately. Use only manufacturer-
supplied parts.
29. DANGER: Always unplug the power
cord immediately after use, before clean-
ing the treadmill, and before performing the
maintenance and adjustment procedures
described in this manual. Never remove the
motor hood unless instructed to do so by an
authorized service representative. Servicing
other than the procedures in this manual
should be performed by an authorized ser-
vice representative only.
30. Over exercising may result in serious injury
or death. If you feel faint, if you become short
of breath, or if you experience pain while
exercising, stop immediately and cool down.
SAVE THESE INSTRUCTIONS

5
This drawing shows the locations of the warning
decals. If a decal is missing or illegible, see
the front cover of this manual and request a
free replacement decal. Apply the decal in the
location shown. Note: The decals may not be
shown at actual size.
WARNING DECAL PLACEMENT

6
Thank you for selecting the new NORDICTRACK®
COMMERCIAL 2450 treadmill. The COMMERCIAL
2450 treadmill provides an impressive selection of fea-
tures designed to make your workouts at home more
effective and enjoyable.
For your benefit, read this manual carefully before
you use the treadmill. If you have questions after
reading this manual, please see the front cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
BEFORE YOU BEGIN
Handrail
Console
Key/Clip
Accessory Tray
Power Switch
Walking Belt
Motor Hood
Wheel
Foot Rail
Idler Roller Screws
Platform Cushions
Power Cord
Fan
Length: 6 ft. 7 in. (199 cm)
Width: 3 ft. 0 in. (90 cm)
Weight: 245 lbs. (111 kg)

7
PART IDENTIFICATION CHART
Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key
number is the quantity used for assembly. Note: If a part is not in the hardware kit, check to see whether it is
preattached. Extra parts may be included.
3/8" Star
Washer (8)–12
5/16" Star
Washer (5)–2
3/8" x 2 3/4" Screw (40)–4
3/8" x 1 1/4"
Screw (1)–8
Ground
Screw (3)–1
#8 x 3/4"
Screw (7)–1
M4 x 20mm
Screw (4)–2
M6 x 25mm
Screw (6)–4

8
ASSEMBLY
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you nish all assembly steps.
• After shipping, there may be an oily substance
on the exterior of the treadmill. This is normal. If
there is an oily substance on the treadmill, wipe
it off with a soft cloth and a mild, non-abrasive
cleaner.
• To identify small parts, see page 7.
• Left parts are marked “L” or “Left” and right parts
are marked “R” or “Right.”
• Assembly requires the following tools:
the included hex keys
one Phillips screwdriver
one adjustable wrench
To avoid damaging parts, do not use power tools.
1
1. To register your product and activate your
warranty in the UK, go to iFITsupport.eu. If you
do not have internet access, complete the war-
ranty registration card in the warranty booklet
and send it by registered post to the address on
the back cover of the warranty booklet.
To register your product and activate your
warranty in Australia, email or post the
following information to the email address or
postal address on the front cover of this manual.
• your receipt (make sure to keep a copy)
• your name, address, and telephone number
• the model number, serial number, and name
of your product (see the front cover of this
manual)

9
3. Make sure that the power cord is unplugged.
Identify the Right Upright (94), and lay it near the
Upright Base (101) as shown.
Next, connect the Belly Pan Wire (80) to the
Upright Wire (92) in the Right Upright (94). For
your treadmill to function properly, make sure
to connect the wires as described in step 2.
Next, insert the Wires (80, 92) into the indicated
square hole (A), and press the Grommet (81)
into the square hole.
Then, remove and discard the indicated screw
(B), and attach the ground wire (C) to the Right
Upright (94) with a Ground Screw (3).
3
2. IMPORTANT: You will connect wires in one or
more of the following steps. For your tread-
mill to function properly, connect the wires as
described below. Note: The actual wires may
look different from the wires shown.
First, firmly push the wires (V) into each connec-
tor (W, X) to make sure that the wires are fully
seated.
Next, turn the wires so that the latch (Y) on one
connector (W) is on the same side as the catch
(Z) on the other connector (X). (Note: If there are
red dots on the connectors, turn the connectors
so that the red dots are on the same side.) Then,
slide the connectors together; the connectors
should slide together easily and snap into
place with an audible click.
Then, pull on the connectors (W, X) to make
sure that they are connected; do not pull on the
wires (V).
V
W
X
Y
Z
V
2
3
C
80
81
94
92
B
A
101

10
5. Do not pinch the Wires (91, 92) during this
step. Have a second person hold the handrail
assembly (E) near the Left and Right Uprights
(93, 94) as shown.
See the inset drawing. Remove the two ties (D)
securing the Handrail Wire (91) and the Upright
Wire (92).
Next, have the second person hold the handrail
assembly (E) on the Left and Right Uprights
(93, 94). Attach the handrail assembly with four
3/8" x 2 3/4" Screws (40) and four 3/8" Star
Washers (8); start all four Screws, and then
tighten them.
4. Do not to pinch the Belly Pan Wire (80)
during this step. Have a second person hold
the Right Upright (94) against the Upright Base
(101).
Insert two 3/8" x 1 1/4" Screws (1) with two 3/8"
Star Washers (8) into the top of the bracket on
the Right Upright (94), and partially tighten the
Screws into the Upright Base (101); do not fully
tighten the Screws yet.
Finish attaching the Right Upright (94) with
two additional 3/8" x 1 1/4" Screws (1) and two
3/8" Star Washers (8); do not fully tighten the
Screws yet.
Attach the Left Upright (not shown) in the
same way. Note: There is not a wire on the left
side.
4
5
E
40
8
94
8
93
40
91
92
D
D
101
94
1
1
1
8
80
8
8
1
8

11
6
91
92
94
6. Connect the Handrail Wire (91) to the Upright
Wire (92). For your treadmill to function
properly, make sure to connect the wires as
described in step 2. Then, insert the wires into
the Right Upright (94).
7
7. Identify the Right Handrail Cover (84). Insert the
front edge of the Right Handrail Cover into the
top of the handrail assembly (E) on the right side
of the treadmill as shown. Then, press down on
the top of the Right Handrail Cover until it snaps
into place.
Attach the Left Handrail Cover (83) to the left
side of the handrail assembly (E) in the same
way. E
83
84

12
8F
E
8. Do not pinch the wires (G) during this
step. Have a second person hold the console
assembly (F) near the handrail assembly (E).
Make sure that the console assembly is
properly oriented so that the curved edge (H)
of the Console Pivot Bracket (117) faces the
front (I) of the handrail assembly.
Insert the wires (G) into the round hole in the
handrail assembly (E) as you set the console
assembly (F) on the handrail assembly.
Attach the console assembly (F) with two
M6 x 25mm Screws (6); do not fully tighten the
Screws yet.
I
6
9
9. Rotate the console assembly (F) so that it
faces the opposite direction. Tighten two
M6 x 25mm Screws (6) into the Console Pivot
Bracket (117); start both Screws, and then
firmly tighten them.
Next, identify the Left Pivot Cover (115). Attach
the Left Pivot Cover to the Console Pivot Bracket
(117) with an M4 x 20mm Screw (4); do not
overtighten the Screw.
4
117
115
F
6
117
G
H

13
10
10. Rotate the console assembly (F) back to
its original position. Firmly tighten the two
M6 x 25mm Screws (6) that you attached in
step 8.
Next, identify the Right Pivot Cover (116). Attach
the Right Pivot Cover to the Console Pivot
Bracket (117) with an M4 x 20mm Screw (4); do
not overtighten the Screw.
4
117
116
F
11
118
11. Do not pinch the wires (J, K) during this step.
Connect the indicated wires (J, K). For your
treadmill to function properly, make sure to
connect the wires as described in step 2.
Next, position the wires (J, K) inside of the open-
ing in the handrail assembly (E). Then, insert
the front edge of the Access Panel (118) into the
opening in the handrail assembly, and attach the
Access Panel with a #8 x 3/4" Screw (7): do not
overtighten the Screw.
JK
E7
6

14
12. Raise the Frame (66) to the position shown.
IMPORTANT: Have a second person hold the
Frame until step 14 is completed.
Remove the two 5/16" x 3/4" Screws (9) from the
Latch Crossbar (62). Note: The Latch Crossbar
is not preattached to the treadmill.
Next, orient the Latch Crossbar (62) as shown.
Make sure that the “This side toward belt”
sticker (L) is facing the treadmill. Attach the
Latch Crossbar to the brackets (M) on the Frame
(66) with the two 5/16" x 3/4" Screws (9) that you
just removed and two 5/16" Star Washers (5).
66
62 L
12
M
M
5
9
13. Remove the 5/16" Nut (12), the two 3/8" Thrust
Washers (37), and the 5/16" x 1 3/4" Bolt (10)
from the bracket on the Upright Base (101).
Note: If one of the 5/16" Bushings (130)
comes out, reinsert it.
Next, orient the Storage Latch (65) as shown.
Attach the lower end of the Storage Latch (65)
to the bracket on the Upright Base (101) with
the 5/16" x 1 3/4" Bolt (10), the two 3/8" Thrust
Washers (37), and the 5/16" Nut (12).
Then, raise the Storage Latch (65) to a vertical
position, and remove the tie (N).
65
13 N
5
9
10
37
37
12
130
101
130

15
14. Remove the 5/16" Nut (12) and the 5/16" x
2 1/4" Bolt (11) from the bracket on the Latch
Crossbar (62).
Next, align the upper end of the Storage Latch
(65) with the bracket on the Latch Crossbar (62),
and insert the 5/16" x 2 1/4" Bolt (11) through the
bracket and the Storage Latch. This will push a
spacer (O) out of the Storage Latch; discard
the spacer. Note: If one of the 5/16" Bushings
(130) comes out, reinsert it.
Next, tighten the 5/16" Nut (12) onto the
5/16" x 2 1/4" Bolt (11). Do not overtighten the
Nut; the Storage Latch (65) must be able to
pivot.
Then, lower the Frame (66) (see HOW TO
LOWER THE TREADMILL FOR USE on
page 30).
62
11
12 O
65
14
15. Firmly tighten the four 3/8" x 1 1/4" Screws (1)
in the Right Upright (94).
Repeat this step on the left side of the
treadmill.
15
94
1
1
1
1
1
1
66
130

16
16. Identify the Right Base Cover (98). Slide the
Right Base Cover under the Belly Pan Wire (80)
and onto the Upright Base (101). Make sure
that the Right Base Cover is under the Belly
Pan Wire.
Repeat this step on the left side of the tread-
mill with the Left Base Cover (not shown).
Note: There is not a wire on the left side.
16
80
101
98
17. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the treadmill. To
avoid damage to the console, keep the treadmill out of direct sunlight. Keep the included hex keys in a secure
place; one of the hex keys is used to adjust the walking belt (see page 32). Note: Extra hardware may be
included.

17
This product must be earthed. If it should malfunc-
tion or break down, earthing provides a path of least
resistance for electric current to reduce the risk of
electric shock. This product’s power cord has an
equipment-earthing conductor and an earthing plug.
IMPORTANT: If the power cord is damaged, it must
be replaced with a manufacturer-recommended
power cord.
Follow the steps below to plug in the power cord.
1. Plug the indicated end of the power cord (A) into the
socket (B) on the treadmill.
2. Plug the other end of the power cord (A) into an
appropriate outlet (C) that is properly installed and
earthed in accordance with all local codes and
ordinances.
DANGER: Improper connection of
the equipment-earthing conductor can result
in an increased risk of electric shock. Check
with a qualified electrician or serviceman if
you are in doubt as to whether the product
is properly earthed. Do not modify the plug
provided with the product—if it will not fit
the outlet, have a proper outlet installed by a
qualified electrician.
IT
FR/SP
UK
GR
RU
HU
BA
IT
FR/SP
UK
GR
RU
HU
UK
Dubai
DU
GR
RU
HU
CZ
TR
RO
BU
UKR
SW
FR/
SP/
PL/
SK
IT
AUS
AUS
TYPE E
TYPE F
UK Australia
A
C
A
C
HOW TO PLUG IN THE POWER CORD

18
ETNT17123
FEATURES OF THE CONSOLE
The advanced console offers a selection of features
designed to make your workouts more effective and
enjoyable.
When you use the manual mode of the console, you
can change the speed and incline of the treadmill with
a touch of a button. As you exercise, the console will
display instant exercise feedback.
You can even monitor your heart rate when you use
a compatible heart rate monitor. To purchase a
compatible heart rate monitor, see page 29.
The console also features wireless technology that
enables the console to connect to iFIT®. With iFIT, you
can choose from a rotating selection of featured work-
outs that automatically control the speed and incline of
the treadmill as iFIT trainers guide you through immer-
sive exercise sessions.
With an iFIT subscription, you can access a large and
varied library of thousands of on-demand destination
and studio workouts, create your own workouts, track
your workout results, and access many other features.
To turn on and turn off the console, see page 19. To
learn how to use the touch screen, see page 19. To
set up the console, see page 20.
HOW TO USE THE TREADMILL

19
HOW TO TURN ON THE CONSOLE
IMPORTANT: If the treadmill has been exposed to
cold temperatures, allow it to warm to room tem-
perature before you turn on the console. If you do
not do this, you may damage the console displays
or other electrical components.
Plug in the power cord (see
page 17). Next, locate the
power switch on the treadmill
frame near the power cord.
Press the power switch into
the reset position (A).
Next, stand on the
foot rails of the
treadmill. Locate
the clip (B) attached
to the key (C), and
slide the clip securely
onto the waistband
of your clothes.
Then, insert the key
into the console.
Note: It may take
up to a few minutes for the console to be ready for
use. IMPORTANT: In an emergency, the key can be
pulled from the console, causing the walking belt
to slow to a stop. Test the clip by carefully taking
a few steps backward; if the key is not pulled from
the console, adjust the position of the clip.
Note: The console can display speed and distance
in either miles or kilometers. To find which unit of
measurement is selected, see HOW TO CHANGE
CONSOLE SETTINGS on page 26.
HOW TO TURN OFF THE CONSOLE
When you are finished using the treadmill, first remove
the key from the console and put it in a secure place.
Then, press the power switch into the off position and
unplug the power cord. IMPORTANT: If you do not do
this, the electrical components of the treadmill may
wear prematurely.
IMPORTANT: Before you fold the treadmill, make
sure that the incline is adjusted to the appropri-
ate level (see HOW TO FOLD AND MOVE THE
TREADMILL on page 30).
HOW TO USE THE TOUCH SCREEN
The console features a tablet with a full-color touch
screen. The following information will help you become
familiar with the tablet’s advanced technology:
• The console functions similarly to other tablets. You
can slide or ick your nger against the screen to
move certain images on the screen, such as the
displays in a workout.
• The screen is not pressure sensitive. You do not
need to press hard on the screen.
• To type information into a text box, rst touch the text
box to view the keyboard. To use numbers or other
characters on the keyboard, touch ?123. To view
more characters, touch ~[<. Touch ?123 again to
return to the number keyboard. To return to the letter
keyboard, touch ABC. To use a capital character,
touch the shift button (upward-facing arrow symbol).
To use multiple capital characters, touch the shift
button again. To return to the lowercase keyboard,
touch the shift button a third time. To clear the last
character, touch the clear button (backward-facing
arrow with an X symbol).
A
B
C

20
HOW TO SET UP THE CONSOLE
Before you use the treadmill for the first time, set up
the console.
1. Connect to your wireless network.
To use iFIT workouts and to use several other
features of the console, the console must be con-
nected to a wireless network. Follow the prompts
on the screen to connect the console to your wire-
less network.
2. Customize settings.
Follow the prompts on the screen to set the desired
unit of measurement and your time zone.
Note: To change these settings later, see HOW TO
CHANGE CONSOLE SETTINGS on page 26.
3. Log into or create an iFIT account.
Follow the prompts on the screen to log into your
iFIT account or to create an iFIT account.
4. Check for firmware updates.
Touch the menu button (three horizontal lines sym-
bol), touch Settings, touch Maintenance, and then
touch Update. The console will check for firmware
updates. For more information, see step 6 on
page 27.
Firmware updates are always designed to
improve your exercise experience. As a result,
new settings and features may not be described
in this manual. Also, some settings and features
described in this manual may no longer be
enabled. Take time to explore the console to learn
how new settings and features work.
5. Calibrate the incline system.
Touch the menu button (three horizontal lines
symbol), touch Settings, touch Maintenance, and
then touch Calibrate Incline and follow the prompts
on the screen. The frame will rise and lower as it
calibrates. For more information, see step 7 on
page 27.
The console is now ready for you to begin working out.
The following pages explain the workouts and other
features that the console offers.
To use the manual mode, see page 21. To use a
featured workout, see page 22. To create a draw-
your-own-map workout, see page 24. To use an iFIT
workout, see page 25.
To change console settings, see page 26. To
connect to a wireless network, see page 28.
IMPORTANT: If there are sheets of plastic on the
console, remove the plastic. To prevent damage
to the walking platform, wear clean athletic shoes
while using the treadmill. The first time you use
the treadmill, observe the alignment of the walking
belt, and center the walking belt if necessary (see
page 32).
