Installing the 2GIG Z-Wave Module
The 2GIG Z-Wave Module (2GIG-ZWM-500) provides the GC3 Security &
Automation System with the abilityto communicate with up to 232 smart home
devices using the Z-Wave wireless communication protocol.
Box Contents
Verifythat the package includes the following:
1—2GIG Z-Wave Module (2GIG-ZWM-500)
STM-5
94V-O
2014 GC3 Z–Wave Rev 3.0
FCC ID: WDQ-ZWM-500
IC ID: 7794A-ZWM500
Figure 1 2GIG Z-Wave Module
Install the Z-Wave Module
To install the 2GIGZ-Wave Module into a Control Panel, do the following:
1. If the Cellular Radio Module bay is locked, remove the faceplate and then
move the door-lockscrew to the UNLOCK position. See "(Optional)
Lock/Unlock the Cellular Radio Module Door" on the next page.
Otherwise, continue with step 2.
2. Remove the hinged door from the GC3 Control Panel.
Figure 2 Cellular Radio Module—Hinged Door
3. If a Cellular Radio Module is present in the system, pull the tab to remove
remove it. Otherwise, skip this step and continue with step 4.
4. Remove the backplate's screw lock from the bottom of the GC3 Panel.
This unlocks the panel's backplate from the rest of the chassis..
Figure 3 GC3 Panel Backplate—Locking Screw
5. Separate the backplate from the GC3 Panel.
6. Disconnect the wired backup battery pin from the PCBbattery connector.
lin e- gc3-bac kup-b a tt ery -en
Figure 4 GC3 Panel—Backup Battery Connector
7. Disconnect the Piezo Sounder connector.
lin e -gc3-pie z o-sounde r-en
Figure 5 GC3 Panel—Piezo Sounder Connector
8. Disconnect the internal siren/speaker connector.
lin e- gc3-panel-speake r-en
Figure 6 GC3 Panel—Internal Siren/Speaker Connector
9. Remove the two screws that secure the rear plate to the chassis and
remove the plate.
Figure 7 GC3 Panel—Rear Plate
2GIG® GC3 Security & Automation System
2GIG-ZWM-500 Z-Wave Module Installation Instructions
10008951A | Proprietary & Confidential

Nortek Security &Control | 1950 Camino VidaRoble, Suite 150 | Carlsbad, CA92008-6517 | USA | 800-421-1587 | www.nortekcontrol.com
Copyright © 2015 Nortek Security &Control LLC. 2
10. Insert the 2GIG Z-Wave module into the STM-5 connector on the PCB
and secure with the Phillips head screw.
Figure 8 GC3 Panel—Install the Z-Wave Module
11. Replace the rear plate and secure it with two Phillips head screws.
12. Connect the internal siren/speaker connector, the Piezo Sounder
connector, and the backup battery connector to their respective PCB
connectors.
13. Install the backplate to the chassisand secure with the screw lock on the
bottom of the Control Panel.
14. Install the Cellular Radio Module, if one was present.
15. Install the hinged door.
(Optional) Lock/Unlock the Cellular Radio Module Door
The Cellular Radio Module fits into the bay on the side of the GC3 Panel and
features a built-in door lock under the faceplate. The Control Panel ships with the
door-lock screw in the UNLOCK position. To limit the possibilityof someone
removing the door, installers have the option of moving the screw to the LOCK
position.
A
B
Figure 9 GC3 Cellular Radio Module Door Lock
To lock and unlock the Cellular Radio Module door:
1. Use your fingertips or carefullyinsert a screwdriver at the edge of the
faceplate. Then gently pry the faceplate from the chassis.
Figure 10 GC3 Panel—Removeable Faceplate
2. Remove the door-lock screw from the UNLOCK position on the right.
Figure 11 GC3 Panel—UNLOCK position
3. Install the screw into the LOCK position on the left. This locks the hinged
door on the GC3 Control Panel.
Figure 12 GC3 Panel—LOCK position
4. Snap the faceplate back on the GC3 Control Panel.
FCCPart 15: Class B Digital Device Statement
for the 2GIG-ZWM-500
If the module's label is not visible when installed, then an additional permanent
label referring to the enclosed module: "Contains Transmitter Module FCC ID:
WDQ-ZWM500" must be placed on the rear panel in a visible location.
FCC ID: WDQ-ZWM500
IC ID: 7794A-ZWM500
This device has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept interference received, including interference that
may cause undesired operation.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates and can radiate
2GIG® GC3 Security & Automation System
2GIG-ZWM-500 Z-Wave Module Installation Instructions
10008951A | Proprietary & Confidential

Nortek Security &Control | 1950 Camino VidaRoble, Suite 150 | Carlsbad, CA92008-6517 | USA | 800-421-1587 | www.nortekcontrol.com
Copyright © 2015 Nortek Security &Control LLC. 3
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference byone (1) or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
NOTE: Any changes or modifications made to this device that are not
approved by 2GIG may void the authority granted to the user by the
FCCto operate this equipment.
Industry Canada (IC)Compliance Notice
This device complies with Industry Canada license-exempt Radio Standard
Specifications (RSS). Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept interference received, including interference that
may cause undesired operation.
According to regulations of Industry Canada, this radio transmitter can operate
with an antenna of a type and a maximum gain (or lower) approved for the
transmitter by Industry Canada. In order to reduce the riskof radio interference for
other users, choose the type of antenna and its gain so that the Effective Isotropic
Radiated Power (EIRP) is not more than the necessary intensity to establishment
of successful communication.
NOTE: Unauthorized modifications made to this device that are not
approved by 2GIG may void the authority granted to the user by the
Industry Canada label to operate this equipment.
Avis de Conformité d'Industrie Canada (IC)
Le présent appareil est conforme aux les Cahiers des charges sur les Normes
Radioélectriques (CNR) d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:
1. l’appareilne doit pasproduire de brouillage, et
2. l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le
fonctionnement.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio
peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur)
approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques
de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le
type d'antenne et son gain de sorte que la Puissance Isotrope Rayonnée
Équivalente (P.I.R.E.) ne dépasse pas l'intensité nécessaire à l'établissement
d'une communication satisfaisante.
NOTE: Les modifications non autorisées apportées à cet appareil
qui ne sont pas approuvés par Nortek Security &Control LLC peut
annuler le pouvoir d'accorder à l'utilisateur par l'étiquette d'Industrie
Canada à utiliser ce équipement.
Limited Warranty
This product is warranted against defects in material and workmanship for one (1)
year. This warranty extends only to wholesale customers who buy directly from
Nortek Security &Control LLC or through Nortek Security &Control’s normal
distribution channels. Nortek Security &Control LLC does not warrant this product
to consumers. Consumers should inquire from their selling dealer as to the nature
of the dealer’s warranty, if any.
There are no obligations or liabilities on the part of Nortek Security &Control LLC
for consequential damages arising out of or in connection with use or performance
of this product or other indirect damages with respect to lossof property, revenue,
or profit, or cost of removal, installation, or re-installation. All implied warranties for
functionality are valid only until the warranty expires. This Nortek Security
&Control LLC Warranty is in lieu of all other warranties, expressed or implied.
All productsreturned for warranty service require a Return Authorization Number
(RA#). Contact Returns at 1-855-546-3351 for an RA# and other important
details.
