Release Notes for the
BayStack 10 Power Supply
Unit
*208560-B*

2
208560-B
Copyright © 2001 Nortel Networks
All rights reserved. July 2001.
The information in this document is subject to change without notice. The statements, configurations, technical data, and
recommendations in this document are believed to be accurate and reliable, but are presented without express or implied
warranty. Users must take full responsibility for their applications of any products specified in this document. The
information in this document is proprietary to Nortel Networks NA Inc.
The software described in this document is furnished under a license agreement and may be used only in accordance
with the terms of that license. The software license agreement is included in this document.
Trademarks
BayStack 10 Power Supply Unit, Nortel Networks, and the Nortel Networks logo are trademarks of Nortel Networks.
Acrobat Reader and Adobe are trademarks of Adobe Systems Incorporated.
All other trademarks and registered trademarks are the property of their respective owners.
Statement of Conditions
In the interest of improving internal design, operational function, and/or reliability, Nortel Networks NA Inc. reserves
the right to make changes to the products described in this document without notice.
Nortel Networks NA Inc. does not assume any liability that may occur due to the use or application of the product(s)
or circuit layout(s) described herein.

3
Release Notes for the BayStack 10 Power Supply Unit
Introduction
These release notes for the Nortel Networks* BayStack 10 Power Supply Unit*
provide information about software and operational issues not included in the
guides for the BayStack 10 Power Supply Unit.
These release notes cover the following topics:
•“Nonavailability in Japan,” next
•“Additional labels on rear panel of UPS” on page 4
•“Known issues” on page 4
•“Related publications” on page 5
•“How to get help” on page 6
Nonavailability in Japan
Currently, the RPSU portion of the BayStack 10 PSU is available in the Japanese
market. However, Nortel Networks does not support the uninterruptible power
supply (UPS) portion of the BayStack 10 PSU for the Japanese market. The UPS
portion consists of the following products, which are not available in Japan:
• UPS Controller module
• Battery pack
Warning: Do not change the MAC address of the BayStack 10 PSU
using the Console Interface (CI) menus or using SNMP. If you do change
the MAC address, it will no longer match the MAC address on the back of
the BayStack 10 PSU itself.

4Additional labels on rear panel of UPS
208560-B
Additional labels on rear panel of UPS
Additional labels appear on the rear panel of the UPS, as shown in Figure 1.
Figure 1 Rear panel of UPS with RPS configuration
Known issues
The following are the known issues with the BayStack 10 PSU chassis, the RPS
SNMP controller module, and the power supply modules:
•If you disable an individual 136-watt power supply module in the BayStack
10 PSU using SNMP, the System LED for that module on the front of the
chassis turns off and an rpsuHubPwrFail trap is sent to the management
station.
However, the Nortel hub, switch, or router connected to the BayStack 10 PSU
continues to function normally using AC power, despite LED and trap
indications.
•When using the CI menus, start entering data at the default cursor position.
Do not use the arrow key to backspace into the fields preceding the default
cursor position, or you may overwrite the default data field.
9643EA
DC receptacles
OUT
AC IN
ETHERNET
CONSOLE
EXT. BAT
DO NOT DISCONNECT UNDER LOAD
12
34
FOR PROPER SELECTION OF
THE POWER-SUPPLYCORD
SEE THE INSTRUCTION MANUAL
100/120V~, 12A, 60Hz
36V
35A
Power supply modules
24
3 1
BAR CODED
BAR CODED
S/N:SDEL06XXXXXX
MACADDRESS: XXXXXXXXXXXX
Max. AC O/P:800W / 1400VA
Max. DC O/P:according to each
provided SPS module
AC and DC combined O/P shall not
exceed 800w/ 1400VA

Related publications 5
Release Notes for the BayStack 10 Power Supply Unit
The workaround is to press the [Enter] key repeatedly, until the screen
displays the following line:
---------------------------------------
(M)odify any of this or (C)ontinue? [M]
At that point, press m and begin modifying the necessary data again at the
default cursor position.
•The factory defaults have been amended in the following manner:
—The default TFTP IP address is now 10.10.10.10.
—The System name, contact, and location fields are blank.
•When the battery needs to be replaced, the BL LED on the front of the
BS10PSU lights. You can hot-swap the battery module. However, to reset the
BL LED, you must power-cycle the BS10PSU.
•When the AC power goes off and the battery is discharged, the BL LED
(battery low) correctly lights, but no SNMP trap is generated.
•When the AC power goes off, the BU LED (battery undervoltage) correctly
lights, but no SNMP trap is generated.
•When you are operating with the 200 W power supply module, you will not
see an SNMP trap for this module when you power-up.
•When you switch the power to the UPS unit, the SNMP agent may send an
err200UPSCommFail trap. You can disregard this error; the BS10PSU is
operating normally.
Related publications
•BayStack 10 Power Supply Unit Installation Instructions, part number
208558-B
•Installation and Reference for the BayStack 10 Power Supply Unit, part
number 208296-C
You can print selected technical manuals and release notes free, directly from the
Internet. Go to the www.nortelnetworks.com/documentation URL. (The product
family is Data and Internet.) Find the product for which you need documentation.
Then locate the specific category and model or version for your hardware or

6How to get help
208560-B
software product. Use Adobe* Acrobat Reader* to open the manuals and release
notes, search for the sections you need, and print them on most standard printers.
Go to Adobe Systems at the www.adobe.com URL to download a free copy of the
Adobe Acrobat Reader.
