North DKE6 Owner's manual

Technical instruction
manual for use and maintenance
ELECTRIC GYROS
MODEL
DKE6 – DKE8 –MKDKE6- MKDKE8
These appliances comply with requirements of E.E.C 73/23/CEE EN 60335 1:02 EN 60335 2 – 48:03
SOTIRIOS D. PRODANAS
PROFESSIONAL ELECTRIC & GAS MACHINES FOR RESTAURANTS - PATISSERIES - SNACK BAR
OFFICE - FACTORY : 14km National road Thessaloniki - Serron (Liti) P.C. 545 00 – TEL. & AX: ++30 3940 72770-73185-73184
P.O BOX 400 70, P.C : 560 00 www.north.gr - e-mail : [email protected]

ELECTRIC GYROS-GRILL
SPECIFICATIONS
The tables below refer to the specifications of above models.
Appliance’s Dimensions
MODEL LENGTH (mm) WIDTH (mm) HEIGHT (mm)
MKDKE6 480 630 9 0
MKDKE8 480 630 1115
DKE6 480 630 9 0
DKE8 480 630 1110
Electrical Supply
MKDKE6 30V AC / 400V 3N AC 50Hz
MKDKE8 30V AC / 400V 3N AC 50Hz
DKE6- DKE8 30V AC / 400V 3N AC 50Hz
IP Grating
ΙP 0
Appliance’s Safety
Complies to ΕΝ 60335 1 and 60335 2 42 requirements.
CE marking.
Power
MODEL POWER IN TOTAL
MKDKE6 4. 00 Watt
MKDKE8 5.600 Watt
DKE6 4. 00 Watt
DKE8 5.600 Watt

Main Parts
• AISI 430 stainless steel body.
• AISI 304 stainless steel spit.
• AISI 430 stainless steel scoop.
Electrical Components
• Infrared Heating Elements
DKE6-MKDKE6: 6 x 700 Watt.
DKE8-MKDKE8: 8 x 700 Watt.
• Spit’s motor 1 Watt.
• Fire resistan wiring.
• Terminals’ fasteners.
• Spit’s start up switch with indicating lamp.
• Four position knobs (0,1, ,3), one for every pair of heating elements.
MKDKE6: 3 pcs.
DKE8,MKDKE8: 4pcs.
• Gland for supply cord.
• Earth terminal.
• Potential equivalent terminal, marked Ρ.Α.
• Six polar polyamide connection for supply cord.

1. GENERAL INFORMATION
⇒ This technical manual includes instructions for the installation, operation, care and maintenance of
gyros-grills manufactured by NORTH. Please, read carefully and keep it for future reference. This
manual should be referred to both by installing or service technicians and the operators of the
equipment.
⇒ After you remove the packing make sure that no damage was caused during shipping. If in doubt,
we recommend that an authorized technician examine the appliance before you proceed with the
installation.
⇒ The appliance requires electrical connection. Before proceeding, make sure that main voltage
meet the requirements of the appliance. This information is available on a label, on the right side
of the appliance, as you face it. In case of incongruence or if in doubt, do not connect the
apparatus. Ask for the equipment to be checked by specialized personnel.
⇒ NORTH Gyros-grills equipment are commercial grade appliances and should, there for, be used
by personnel who are specially trained in their use.
⇒ All procedures concerning installation and connection of the appliance must be carried out
exclusively by specialized technicians according to specifications valid in the country where
installation is taking place.
⇒ Before any routine cleaning, disconnect from electricity mains. The same procedure must be
followed in case of malfunction of
the appliance, while waiting for the service technician.
⇒ Any repairs must be exclusively carried out by authorized personnel using original spare parts
only.
⇒ The manufacturer cannot be held responsible for damage caused to persons, animals or property
due to misuse, tampering, unauthorized modification, or uses other than ones mentioned and / or
considered in this manual.

2. TECHNICAL INSTRUCTIONS
INSTALLATION
AND
SERVICE INSTRUCTIONS
NORTH GYROS-GRILLS ARE PROFESSIONAL EQUIPMENT.
ALL ASSEMBLY AND CONNECTION PROCEDURES,
TESTING AND REQUIRED REPAIRS
MUST BE CARRIED OUT
BY SPECIALIZED AND AUTHORIZED PERSONNEL ONLY.
.......................................................................................................
NORTH ENTERPRISES CANNOT BE HELD RESPONSIBLE
FOR ANY NEGATIVE CONSEQUENCES IN CASE OF
INTERVENTIONS BY NON-SPECIALIZED TECHNICAL PERSONNEL
OR DUE TO NONCOMPLIANCE WITH FACTORY INSTRUCTIONS.

2.1 INSTALLATION OF THE APPLIANCE............................................................................................
After making sure the appliance is intact, place it in position so that it is stable and there is adequate
operating space around it.
Make sure that all parts are at hand, i.e.:
• Gyros-grill – Spit - Round tray to support the meat. - Fat collecting drawer - Meat scoop – Manual
Attention ! To avoid accidents, keep all packing materials (cardboard, plastic bags, metal items, etc)
away from children.
Important ! Install the gyros-grill on a flat non-flammable surface, away from flammable walls.
2.2 ELECTRICAL CONNECTION.........................................................................................................
Remove the back cover of the appliance.
• Enter a suitable supply cord through the gland.
• Depending on the available power supply connect the cables.
a. Single phase power supply
MKDKE6,MKDKE8, DKE6, DKE8
. Remove the provided bridges and
short circuit L1, L and L3.
Connect the phase to L1 or L or L3,
the neutral to Ν1 or Ν and the earth
to earth terminal.
b. Three Phase power Supply
MKDKE6,MKDKE8, DKE6, DKE8
Connect the phases to L1, L and L3.
Connect the neutral to Ν1 or Ν .
Connect the earth.
• Connect P.A. terminal to water piping using a 10 mm² wire.
IT IS STRONGLY RECOMMENDED TO USE A QUALIFIED ELECTRICIAN FOR ALL
ELECTRICAL CONNECTIONS.
THE MANUFACTURER CANNOT BE HELD RESPONSIBLE FOR ACCIDENTS AND
DAMAGE CAUSED TO PERSONS, ANIMALS OR PROPERTY DUE TO NONCOMPLIANCE WITH
THESE INSTRUCTIONS.

2.3 POSSIBLE PROBLEM…...…………………………………………………………………………………
Even if the appliance is used correctly, some problems may arise for various reasons. The table that
follows mentions some possible problems and some possible causes.
In case of problem we control
first if the electrical supply to the machine is right or not.
POSSIBLE PROBLEM POSSIBLE CAUSES
Machine is not operating Drop of main voltage.
Heating element is not operating
Check if there is damage to 1)the heating
element )the edge of supply cord connected
with heating element. 3) the contactor of switch
4) the switch
Motor is not operating Check if there is damages to 1)switch on-
off
)the motor coil or gear. 3) fat grouping to the
axis of rotation.
2.3 REPLACEMENT OF ELECTRICAL ELEMENTS.............................................................................
To replace heating elements, switches and indicating lamps disconnect the appliance from power
supply then remove the back cover of the appliance. Release heating elements, switches and
indicating lamps and replace.
Remount the rear plate.
CUT OFF THE POWER SUPPLY BEFORE COVER REMOVAL.
2.4 TRAINING.........................................................................................................................................
The personnel who are to install and connect the appliance must train the users appropriately so that
they can handle the operation and safety measures of the appliance.
ATTENTION !!!
• Check that main voltage in your working area is suitable for the settings on the label and that the
appliance is properly earthed.
• Before any service activity takes place or any parts are replaced on the appliance, make sure that
pains supply is turned off.
THE MANUFACTURER CANNOT BE HELD RESPONSIBLE FOR ACCIDENTS AND DAMAGE
CAUSED TO PERSONS, ANIMALS OR PROPERTY DUE TO NONCOMPLIANCE WITH THESE
INSTRUCTIONS.

3. OPERATION INSTRUCTIONS
INSTRUCTIONS TO PERSONNEL
FOR OPERATION AND CARE
OF GYROS-GRILLS
NORTH GYROS-GRILLS ARE PROFESSIONAL EQUIPMENT.
ALL ASSEMBLY AND CONNECTION PROCEDURES,
TESTING AND REQUIRED REPAIRS MUST BE CARRIED OUT
BY SPECIALIZED AND AUTHORIZED PERSONNEL ONLY.
..............................................................................................................
NORTH ENTERPRISES CANNOT BE HELD RESPONSIBLE FOR ANY
NEGATIVE CONSEQUENCES IN CASE OF INTERVENTIONS BY
NON-SPECIALIZED TECHNICAL PERSONNEL OR DUE TO
NONCOMPLIANCE WITH FACTORY INSTRUCTIONS.

3.1 TURNING ON THE APPLIANCE .....................................................................................................
After making sure the appliance has been correctly connected to electricity, you can start using it.
Motor switch
• Position 1 : Start spit’s rotation.
• Position 0 : Stop spit’s rotation.
Four position knobs (0,1,2,3)
Depending on the desire heating position select the respective knob and adjust. Each knob controls
the operation of two heating elements.
• Position 1 : Both side horizontal operate at low rate.
• Position : One side left operates at high rate.
• Position 3 : Both operate at high rate.
• Position 0 : Both are out of operation.
The indicating lamp is on for positions 1, and 3.
3.2 PREPARING THE SPIT...................................................................................................................
• Prepare the spit by setting the round meat base into place.
• Place the meat on the spit with the herbs and spices you have already prepared.
• Secure the spit on the lower base by placing the arm in the appropriate support position.
• Secure the top end of the spit in the appropriate position by locking the safety key.
Now the Gyros-grill appliance is ready to operate. All you have to do is set the desired heating
element-to-spit distance (about 10 cm) and start the rotation motor by pressing switch.
3.3 CLEANING AND MAINTENANCE....................................................................................................
∗ Turn off the heating elements before any cleaning or maintenance procedures. Let the appliance
cool and make sure it has been unplugged from the main supply.
∗ At the end of the working day, remove the arm and clean it thoroughly. Empty and clean fat
collecting drawer as well as the peat scoop.
∗ Clean with a wet cloth the reflecting surfaces on the sides of the appliance and the base of the
spit.
∗ Never use running water to clean the Gyros-grill appliance.
∗ Never use running water to clean the appliance.
