ELECTRIC CHURRASCO GRILL
HKB-7, HKB-7S, R7
SPECIFICATIONS
The tables below refer to the specifications of models HKB
Appliance’s Dimensions
MODEL LENGTH x WIDTH x HEIGHT
(mm)
Spit Distance
(mm)
Dist. Spit Per
Spit (mm)
KG
HKB-7 860 Χ 650 Χ 825 570 65 51
HKB-7 860 Χ 650 Χ 1640 570 65 101
R7 690 Χ 380 Χ 440 440 65 40
Electrical Supply
400V ~ AC 50/60Hz – 3P+Ν
230/400V ~ AC - 50/60Hz – 3P+N
IP Grating
ΙP 20
Appliance’s Safety
Complies to ΕΝ 60335 1 and 60335 2 38requirements.
CE marking.
Power
MODEL POWER IN TOTAL
HKB-7 10.400Watt
HKB-7 10.400Watt
R7 6.500Watt

Main Parts
• AI I 430 stainless steel body.
• AI I 430 Water fat collecting drawer
• Worm wheel
• pits AI I 316
Electrical Components
• Wire Tubular heating elements
• 4 position switch
• On/off switch
• Fire resistant wiring.
• Terminals’ fasteners.
• Gland for supply cord.
• Earth terminal.
• Equivalent earth terminal.
• Connector strip for supply cord.

1. GENERAL INFORMATION
⇒ This technical manual includes instructions for the installation, operation,
care and maintenance of churrasco-grills type HKB-7, HKB-7
manufactured by NORTH. Please, read carefully and keep it for future
reference. This manual, should be referred to both by installing or service
technicians and the operators of the equipment.
⇒ After you remove, the packing parts make sure that no damage, was
caused during shipping. If in doubt, we recommend that an authorized
technician examine the appliance before you proceed with the installation.
⇒ The appliance requires electrical connection. Before proceeding, make
sure that main voltage meet the requirements of the appliance. This
information is available on a label, on the right side of the appliance, as you
face it. In case of incongruence or if in doubt, do not connect the
apparatus. Ask for the equipment to be checked by specialized
personnel.
⇒ NORTH Water-grill equipment is commercial grade appliances and should,
be used by personnel who are specially trained in their use.
⇒ All procedures concerning installation and connection of the appliance must
be carried out exclusively by specialized technicians according to
specifications valid in the country where installation is taking place.
⇒ Before any routine cleaning, disconnect from electricity mains. The same
procedure must be followed in case of malfunction of the appliance, while
waiting for the service technician.
⇒ Authorized personnel using original spare parts only must exclusively carry
out any repairs.
⇒ The manufacturer cannot be held responsible for damage caused to
persons, animals or property due to misuse, tampering, unauthorized
modification, or uses other than ones mentioned and / or considered in this
manual.

2. TECHNICAL INSTRUCTIONS
INSTALLATION
AND
SERVICE INSTRUCTIONS
NORTH CHURRA CO-GRILL I PROFE IONAL EQUIPMENT.
ALL A EMBLY AND CONNECTION PROCEDURE ,
TE TING AND REQUIRED REPAIR
MU T BE CARRIED OUT
BY PECIALIZED AND AUTHORIZED PER ONNEL ONLY.
.......................................................................................................
NORTH ENTERPRI E CANNOT BE HELD RE PON IBLE
FOR ANY NEGATIVE CON EQUENCE IN CA E OF
INTERVENTION BY NON- PECIALIZED TECHNICAL PER ONNEL
OR DUE TO NONCOMPLIANCE WITH FACTORY IN TRUCTION .

2.1 INSTALLATION OF THE APPLIANCE........................................................
After making sure the appliance is intact, place it in position so that it is stable
and there is adequate operating space around it.
Make sure that all parts are at hand, i.e.:
• CHURRA CO-grill HKB.
• Water through.
• Instruction manual.
Attention! To avoid accidents, keep all packing materials (cardboard, plastic
bags, metal items, etc) away from children.
Important! Install the churrasco-grill on a flat non-flammable surface, away
from flammable walls.
2.2 ELECTRICAL CONNECTION......................................................................
The appliance, should be connected ONLY on 3phases electric power supply.
HO7RNF wire 5x2.5
Connect the phases to L1, L2 & L3
Connect the earth neutral to Ν1 or Ν2.
Connect the earth.
Electric fuse board is obligated to have escape relay
IT IS STRONGLY RECOMMENDED TO USE A QUALIFIED
ELECTRICIAN FOR ALL ELECTRICAL CONNECTIONS.
THE MANUFACTURER CANNOT BE HELD RESPONSIBLE FOR
ACCIDENTS AND DAMAGE CAUSED TO PERSONS, ANIMALS OR
PROPERTY DUE TO NONCOMPLIANCE WITH THESE INSTRUCTIONS.

2.3 POSSIBLE PROBLEM..............................................................................
Even if the appliance is used correctly, some problems may arise for various
reasons. The table that follows mentions some possible problems and some
possible causes.
In case of problem we control first if the electrical supply to the
machine is right or not.
POSSIBLE PROBLEM POSSIBLE CAUSES
Machine is not operating
Check if there is damage to 1) all
heating elements 2) the edge of cord
connected with the heating element
3) connector strip
Heating element is not operating
Check if there is damage to 1) the
heating element 2) the edge of cord
connected with heating element 3)
operation switch
Worm wheel is not operating Check if there is damage to 1)on/off
switch 2) motor 3)the edge of cord
connected with the motor
2.3 REPLACEMENT OF ELECTRICAL ELEMENTS........................................
To replace the operation switch & the on/off switch of the motor unscrew the 4
screw from the right side of the appliance.
Remove the operation knob and the cover and make the replacement.
To replace the heating element unscrew the 4 screws from the right side of
the appliance remove the screw from the left of the supporting sheet of metal
disconnect the heating element from inside of the appliance and pull out the
heating element and make the replacement
To replace the motor unscrew the 4 screws from the right side of the
appliance unscrew the ball baring base and the worm wheel disconnect the
motor and replace it with a new one.
CUT OFF THE POWER SUPPLY BEFORE COVER REMOVAL.
2.4 TRAINING.....................................................................................................
The personnel who are to install and connect the appliance must train the
users appropriately so that they can handle the operation and safety
measures of the appliance.
ATTENTION !!!
• Check that main voltage in your working area is suitable for the settings on
the label and that the appliance is properly earthed.
• Before any service activity takes place or any parts are replaced on the
appliance, make sure that pains supply is turned off.
THE MANUFACTURER CANNOT BE HELD RESPONSIBLE FOR
ACCIDENTS AND DAMAGE CAUSED TO PERSONS, ANIMALS OR
PROPERTY DUE TO NONCOMPLIANCE WITH THESE INSTRUCTIONS.

3. OPERATION INSTRUCTIONS
INSTRUCTIONS TO PERSONNEL
FOR OPERATION AND CARE
OF CHURRASCO-GRILLS
H
HH
HKB
KBKB
KB-
--
-7
77
7, H
, H, H
, HKB
KBKB
KB-
--
-7S
7S7S
7S, R7
, R7, R7
, R7
NORTH CHURRA CO-GRILL I PROFE IONAL EQUIPMENT.
ALL A EMBLY AND CONNECTION PROCEDURE ,
TE TING AND REQUIRED REPAIR MU T BE CARRIED OUT
BY PECIALIZED AND AUTHORIZED PER ONNEL ONLY.
..............................................................................................................
NORTH ENTERPRI E CANNOT BE HELD RE PON IBLE FOR ANY
NEGATIVE CON EQUENCE IN CA E OF INTERVENTION BY
NON- PECIALIZED TECHNICAL PER ONNEL OR DUE TO
NONCOMPLIANCE WITH FACTORY IN TRUCTION .

3.1 TURNING ON THE APPLIANCE ...............................................................
After making sure the appliance has been correctly connected to electricity,
you can start using it.
Each operation switch controls two heating elements:
A) Position 0: Both heating element are out of function.
B) Position 1: To sustain temperature
C) Position 2: One of the two heating element is at maximum power
D) Position 3: Both heating element are at maximum power
Activate the on/off switch of the motor for the rotation of spit
If we unscrew the two screws clamp from the appliance, (left - right), and we
push or pull the two moving handles simultaneous, we can control the
distance between spits and heating.
3.2 CLEANING AND MAINTENANCE..............................................................
∗ Turn off the heating elements before any cleaning or maintenance
procedures. Let the appliance cool and make sure it has been unplugged
from the main supply.
∗ Never use running water to clean the Churrasco-grill
appliance.
