Novatel 600-LB Operation manual

WARRANTY POLICY
NovAtel Inc. warrants that its Global Positioning System (GPS) products are free from defects
in materials and workmanship, subject to the conditions set forth below, for the following
periods of time:
GPSAntenna™ Modules One (1) Year
Cables and Accessories Ninety (90) Days
Date of sale shall mean the date of the invoice to the original customer for the product.
NovAtel's responsibility respecting this warranty is limited solely to product repair at an
authorized NovAtel location only. Determination of repair will be made by NovAtel
personnel or by technical personnel expressly authorized by NovAtel for this purpose.
THE FOREGOING WARRANTIES DO NOT EXTEND TO (I) NONCONFORMITIES,
DEFECTS OR ERRORS IN THE PRODUCTS DUE TO ACCIDENT, ABUSE, MISUSE OR
NEGLIGENT USE OF THE PRODUCTS OR USE IN OTHER THAN A NORMAL AND
CUSTOMARY MANNER, ENVIRONMENTAL CONDITIONS NOT CONFORMING TO
NOVATEL'S SPECIFICATIONS, OR FAILURE TO FOLLOW PRESCRIBED
INSTALLATION, OPERATING AND MAINTENANCE PROCEDURES, (II) DEFECTS,
ERRORS OR NONCONFORMITIES IN THE PRODUCTS DUE TO MODIFICATIONS,
ALTERATIONS, ADDITIONS OR CHANGES NOT MADE IN ACCORDANCE WITH
NOVATEL'S SPECIFICATIONS OR AUTHORIZED BY NOVATEL, (III) NORMAL
WEAR AND TEAR, (IV) DAMAGE CAUSED BY FORCE OF NATURE OR ACT OF
ANY THIRD PERSON, (V) SHIPPING DAMAGE; OR (VI) SERVICE OR REPAIR OF
PRODUCT BY THE DEALER WITHOUT PRIOR WRITTEN CONSENT FROM
NOVATEL.
IN ADDITION, THE FOREGOING WARRANTIES SHALL NOT APPLY TO PRODUCTS
DESIGNATED BY NOVATEL AS BETA SITE TEST SAMPLES, EXPERIMENTAL,
DEVELOPMENTAL, PREPRODUCTION, SAMPLE, INCOMPLETE OR OUT OF
SPECIFICATION PRODUCTS OR TO RETURNED PRODUCTS IF THE ORIGINAL
IDENTIFICATION MARKS HAVE BEEN REMOVED OR ALTERED.
THE WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, WRITTEN OR ORAL, INCLUDING THE
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE ARE EXCLUDED.
NOVATEL SHALL NOT BE LIABLE FOR ANY LOSS, DAMAGE OR EXPENSE
ARISING DIRECTLY OR INDIRECTLY OUT OF THE PURCHASE, INSTALLATION,
OPERATION, USE OR LICENSING OR PRODUCTS OR SERVICES. IN NO EVENT
SHALL NOVATEL BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND OR NATURE DUE TO ANY CAUSE.
There are no user-serviceable parts in the GPSAntenna and no maintenance is required. When
the GPSCard status code indicates that the unit is faulty, replace with another unit and return
the faulty unit to NovAtel Inc.
You must obtain a RETURN MATERIAL AUTHORIZATION (RMA) number by calling
GPS Customer Service at 1-800-280-2242 (North America only) or 403-295-4900 before
shipping any product to NovAtel or Dealer.
Once you have obtained an RMA number, you will be advised of proper shipping procedures
to return any defective product. When returning any product to NovAtel, please return the
defective product in the original packaging to avoid ESD and shipping damage.
© 2002-2003 NovAtel Inc. All rights reserved
Unpublished rights reserved under International copyright laws.
Printed in Canada on recycled paper. Recyclable.
May 6, 2003
OM-20000068 Rev 3
NovAtel Inc.
1120 – 68th Avenue N.E.
Calgary, Alberta, Canada T2E 8S5
http://www.novatel.com
NovAtel L1/L2/L-Band GPSAntenna™
Model 600-LB
- User Information -
INTRODUCTION
The performance of the Model 600-LB can be summarized as follows:
• Very good sensitivity to right hand circularly polarized signals over a wide range of
elevations and in all azimuth directions
• Excellent amplitude radiation pattern roll-off near the horizon, in effect eliminating
multipath-generated replicas of the original line-of-sight (LOS) signal
• Excellent reception of low elevation angle satellites (i.e. OmniSTAR, GPS)
• Common location and stable phase center for both L1 and L2 (The phase center in
the x and y-axis is located in the center of the antenna for both channels due to its
inherent symmetry and co-centric type design.)
• Enhanced immunity against electromagnetic interference
• Better radiation “hardening” from lightening or EMP (electromagnetic pulse) effects
• High-speed transient voltage suppressor
• Operational temperature range from cold to hot extremes
The Model 600-LB can be distinguished from other GPS-600 models by its grey rim.
DESCRIPTION
The Model 600-LB GPSAntenna is an active antenna designed to operate at the GPS L1
(1575.42 MHz), the GPS L2 (1227.60 MHz) and the OmniSTAR L-Band (LB) (1520-
1565 MHz) frequencies. The antenna element is coupled to a low-noise amplifier (LNA).
The unit is optimized to receive right-hand-circularly-polarized signals, and its radiation
pattern is shaped to ensure high quality signal reception from OmniSTAR and other geo-
stationary satellites. The antenna is also optimized to minimize multipath reception.
The Model 600-LB GPSAntenna is intended for kinematic positioning such as GIS,
marine and mobile applications. The sealed radome allows the antenna to be used in
severe weather, marine applications and hostile environments. The unit's compact size
and light weight ensure its portability.
Both the input DC power and the output RF signal flow over a single coaxial cable
connected to the unit's TNC female connector.
To mount the antenna, ensure that the adapter is screwed into the antenna base (finger
tighten only). It is best to leave this adapter in at all times as it protects the plastic threads

of the antenna itself. Screw the bottom of the adapter onto a range pole, tribrach, tripod or
other equivalent mount. Attach coaxial cable from the antenna connector to the antenna
port on your receiver.
Caution: Over tightening the metal adaptor into the plastic baseplate will damage
the baseplate.
The 600-LB antenna will allow you to achieve sub-meter accuracy in stand-alone
applications. It combines the advantage of dual GPS frequency performance and the
availability of differential GPS corrections from the OmniSTAR and other geo-stationary
satellites. Differential corrections coupled with the ability to know ionospheric
corrections will allow you to achieve sub-meter and even centimetre accuracy without
the need to use ground based reference stations.
–ELECTRICAL TECHNICAL SPECIFICATIONS –
3 dB pass band: LB 1520 − 1565 ΜΗz
L1: 1575 ±10 MHz
L2: 1228 ± 10 ΜΗz
Out-of-band rejection: L2: fc± 50 MHz: 20 dB (typical)
fc± 100 MHz: 40 dB (typical)
L1/LB 1420 MHz: 30 dB (typical)
1470 MHz: 10 dB (typical)
1625 MHz: 10 dB (typical)
1675 MHz: 30 dB (typical)
Antenna elev. pattern: θ = 90°: 7.0 dBic (L1/LB min.); 6.0 dBic (L2 min.)
(90°= zenith) 20°≤ θ < 90°: 4.0 dBic (L1/LB min.); 2.0 dBic (L2 min.)
5°≤ θ < 20°: 3.0 dBic (L1/LB min.); 1.0 dBic (L2 min.)
0°≤ θ < 5°: 0.0 dBic (L1/LB min.); -2.0 dBic (L2 min.)
LNA gain: 29 ± 3 dB
Polarization: Right-hand circular
Noise figure: ≤ 2.6 dB (typical)
Nominal impedance: 50 Ω
VSWR: ≤ 2.0:1
Power requirements: ≤ 50 mA @ +4 to +18 VDC, 40 mA (typical) @ 5 VDC
–MECHANICAL & ENVIRONMENTAL SPECIFICATIONS –
Finish: Weatherable polymer
Weight: ≈ 500 g (1.11 lb)
Altitude: 3000 m (9842.5 ft)
Temperature: -55 °C to +85 °C (-67 °F to +185 °F)
– MECHANICAL DRAWINGS –
