Novelan LI 14 User manual

Operating Manual
UK
83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Air/Water Heat Pumps
Indoor Installation
LI 14(L) – LI 31(L)

283054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Please read rst
This operating manual provides important information
on the handling of the unit. It is an integral part of the
product and must be stored so that it is accessible in the
immediate vicinity of the unit. It must remain available
throughout the entire service life of the unit. It must be
handed over to subsequent owners or operators of the
unit.
Read the operating manual before working on or opera-
ting the unit. This applies in particular to the chapter on
safety. Always follow all instructions completely and wi-
thout restrictions.
It is possible that this operating manual may contain in-
structions that seem incomprehensible or unclear. In
case of questions or uncertainty, contact the factory cu-
stomer service department or the manufacturer’s local
service partner.
Since this operating manual was written for several dif-
ferent models of the unit, always comply with the para-
meters for the respective model.
This operating manual is intended only for persons as-
signed to work on or operate the unit. Treat all constitu-
ent parts condentially. The information contained he-
rein is protected by copyright. No part of this informa-
tion may be reproduced, transmitted, copied, stored in
electronic data systems or translated into another lan-
guage, either wholly or in part, without the express writ-
ten permission of the manufacturer.
Symbols
The following symbols are used in the operating manu-
al. They have the following meaning:
Information for operators.
Information or instructions for qualied
personnel.
DANGER!
Indicates a direct impending danger resul-
ting in severe injuries or death.
WARNING!
Indicates a possibly dangerous situation that
could result in severe injuries or death.
WARNING!
Indicates a possibly dangerous situation that
could result in medium or light injuries.
ATTENTION
Indicates a possibly dangerous situation, which
could result in property damage.
NOTICE.
Emphasized information.
€ENERGY SAVING TIP
Indicates suggestions that help to save energy,
raw materials and costs.
Reference to other sections of the operating
manual.
Reference to other documents of the manufac-
turer.

383054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Contents
INFORMATION FOR USERS AND QUALIFIED
PERSONNEL
PLEASE READ FIRST....................................................................2
SYMBOLS......................................................................................2
INTENDED USE ............................................................................4
DISCLAIMER.................................................................................4
EC CONFORMITY.........................................................................4
SAFETY AND SECURITY .............................................................4
CUSTOMER SERVICES.................................................................5
WARRANTY / GUARANTEE.........................................................5
WASTE DISPOSAL .......................................................................5
OPERATING PRINCIPLE OF HEAT PUMPS...............................6
AREA OF UTILISATION...............................................................6
HEAT QUANTITY RECORDING ..................................................6
OPERATION..................................................................................6
CARE OF THE UNIT .....................................................................7
MAINTENANCE OF THE UNIT....................................................7
Cleaning and rinsing of unit components........................7
MALFUNCTIONS .........................................................................7
INSTRUCTIONS FOR QUALIFIED TECHNICIANS
SCOPE OF DELIVERY...................................................................8
INSTALLATION AND ASSEMBLY...............................................8
Sound......................................................................................9
Installation location ........................................................... 11
Transport to installation location ....................................11
Installation ...........................................................................14
Mounting the air ducts......................................................14
Installation / connection to heating circuit ..................18
Condensate discharge .......................................................18
PRESSURE RELIEF......................................................................19
OVERFLOW VALVE ....................................................................19
BUFFER TANK.............................................................................19
CIRCULATING PUMPS ..............................................................19
WATER HEATING .......................................................................19
HOTWATER TANK.....................................................................19
ELECTRICAL CONNECTIONS...................................................20
RINSING, FILLING AND BLEEDING THE SYSTEM.................21
Water quality of the fill and additional water in hot
water heating systems.................................................21
INSULATING THE HYDRAULIC CONNECTIONS ...................23
INSTALLATION OF THE CONTROL ELEMENT .......................23
INSTALLATION AND REMOVAL OF THE SCREEN.................24
SET THE OVERFLOW VALVE.....................................................26
COMMISSIONING......................................................................26
Safety temperature limiter................................................27
DISMANTLING ...........................................................................27
TECHNICAL DATA / SCOPE OF DELIVERY
LI 14(L) – LI 31(L)..................................................................28
PERFORMANCE CURVES
Heating capacity/COP / power consumption /
Heat pump pressure loss
LI 14(L) ..................................................................................30
LI 18(L) ..................................................................................31
LI 25.1(L)................................................................................32
LI 31(L)...................................................................................33
DIMENSIONAL DRAWINGS AND INSTALLATION PLANS
LI 14 – LI 18
Dimensional drawings .......................................................34
LI 14L – LI 18L
Dimensional drawings .......................................................35
LI 14(L) – LI 18(L)
Installation plan version 1.................................................36
Installation plan version 2.................................................37
Installation plan version 3.................................................38
Installation plan version 4.................................................39
LI 25.1 – LI 31
Dimensional drawings ...................................................... 40
LI 25.1L – LI 31L
Dimensional drawings .......................................................41
LI 25.1(L) – LI 31(L)
Installation plan version 1.................................................42
Installation plan version 2.................................................43
Installation plan version 3................................................ 44
Installation plan version 4.................................................45
HYDRAULIC INTEGRATION
LI 14(L) – LI 25.1(L)
Row tank...............................................................................46
Separate buffer tank ..........................................................47
LI 31(L)
Row tank.............................................................................. 48
Separate buffer tank ..........................................................49
Legend Hydraulic integration...........................................50
TERMINAL DIAGRAMS
LI 14(L) – LI 25.1(L)...............................................................52
LI 31(L)...................................................................................53
CIRCUIT DIAGRAMS
LI 14(L) ..................................................................................54
LI 18(L) ..................................................................................57
LI 25.1(L)................................................................................60
LI 31(L)...................................................................................63
EC DECLARATION OF CONFORMITY.....................................67

483054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Intended use
The unit may be used only for the intended purpose.
That means:
•for heating.
•for heating hot water.
The unit may be operated only within its technical pa-
rameters.
Overview “Technical data / scope of delivery”.
NOTICE.
Notify the responsible power supply company
of the use of a heat pump or heat pump system.
CAUTION!
The unit is not suitable for use in IT network sys-
tems.
Disclaimer
The manufacturer will not be liable for damage resulting
from unauthorized use of the unit.
The manufacturer’s liability will also be voided in the
following cases:
•if work is performed on the unit and its compon-
ents in a manner that does not comply with the
terms of this operating manual;
• if work is performed on the unit and its compon-
ents in an improper manner;
•if work is performed on the unit that is not descri-
bed in this operating manual, and this work was
not expressly approved in writing by the manuf-
acturer;
•if the unit or components in the unit are modi-
ed, redesigned or removed without the express
written permission of the manufacturer.
EC conformity
The unit bears the CE mark of conformity.
EC declaration of conformity
Safety and Security
The unit is operationally safe when used for the inten-
ded purpose. The construction and design of the unit
conform to the state of the art, all relevant DIN/VDE re-
gulations and all relevant safety regulations.
Every person who performs work on the unit must ha-
ve read and understood the operating manual prior to
starting any work. This also applies if the respective per-
son has already worked with such a unit or a similar unit
or has been trained by the manufacturer.
Every person who performs work on the unit must com-
ply with the applicable accident prevention and safety
regulations. This applies in particular to the wearing of
personal safety gear.
DANGER!
Unit operates under high electric voltage!
DANGER!
Danger of fatal injury due to electric current!
Electrical connections may be installed only
by qualied electricians.
Before opening the unit, disconnect the sys-
tem from the power supply and secure it
from being switched back on!
ATTENTION
If using the unit in 3~230V systems, please note
that the residual-current circuit breaker (RCCB)
used must be AC-DC sensitive.
DANGER!
Only qualied technicians (trained heating,
cooling and electrical technicians) may per-
form work on the unit and its components.
WARNING!
Observe safety labels on and in the unit.
WARNING!
Unit contains refrigerants!
Leaking refrigerant could result in personal
injury or material damage. Therefore:
– Shut down unit.
– Notify the manufacturer’s authorized
service center.

583054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
ATTENTION
For safety reasons:
Never disconnect the unit from the power sup-
ply, unless the unit is being opened.
ATTENTION
Install the heat pump only indoors and operate
only with outside air as the heat source. The air
ducts must discharge into the open air. Do not
restrict or block the air ducts.
Dimensional drawing and installation plan for
respective model.
WARNING!
Switch on unit only if air ducts are mounted
on the unit.
Take measures on the fan side to prevent in-
juries from the rotating fan (above-ground
air duct discharge: below-ground air-chan-
nel discharge: wire mesh grille – accessories
not included in scope of delivery).
ATTENTION
The integration of the heat pump in ventila-
tion systems is not permissible. The use of the
cooled air for cooling purposes is not permitted.
ATTENTION
The ambient air in the location where the he-
ating pump is installed and also the intake air
which is used as a source of heat must not con-
tain any kind of corrosive components!
Components such as ammonia, sulphur, chlo-
rine, salt, sewer gas, ue gases etc. may cause
damage leading to complete failure or even a
total write-o of the heating pump!
WARNING!
In the air outlet area the air temperature is
ca. 5 K below the ambient temperature. Un-
der certain climatic conditions, therefore,
an ice layer can form in the air outlet area.
Install the heat pump so that the air blower
does not blow in the direction of footpaths.
Customer Services
For technical assistance, please contact your qualied
technician or the manufacturer‘s local service partner.
For a current list and additional partners of the manuf-
acturer, please visit
DE: www.novelan.de
EU: www.novelan.com
Warranty / Guarantee
For warranty and guarantee conditions, please refer to
the purchase documents.
NOTICE.
Please contact your dealer concerning warran-
ties and guarantees.
Waste disposal
When decommissioning the unit, always comply with
applicable laws, directives and standards for the recove-
ry, recycling and disposal of materials and components
of cooling units.
"Dismantling".

683054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Operating principle of heat
pumps
Heat pumps operate on the principle of a refrigerator:
the same technology, only with the opposite eect. The
refrigerator extracts heat from foods, which is released
into the room through ns on the back.
The heat pump extracts heat from our environment:
air, earth or ground water. The extracted heat is con-
ditioned in the unit and supplied to the heating water.
Even when it is extremely cold outside, the heat pump
draws enough heat to heat a house.
Example: drawing of a brine/water heat pump with oor
heating:
4/4= usable energy
approx. 3/4= environmental energy
approx. 1/4= external
electrical energy
Area of utilisation
Taking into consideration the ambient conditions, limits
of application and the applicable regulations, every he-
at pump can be utilized in new or existing heating sys-
tems.
Overview "Technical data/ scope of delivery".
Heat quantity recording
In addition to the proof of the unit's eciency, EEWaer-
meGalso meets the demand for a heat quantity recor-
ding (hereafter refered to as HQR). The HQR is manda-
tory with air/water heat pumps. With brine/ water and
water/water heat pumps, a HQR may only be set up
when a forward ow temperature of ≥ 35 °C has been re-
ached. The HQR must record the total warm energy re-
lease (heating and hot water) in the building. In heat
pumps with heat quantity recording, the analysis is con-
ducted by the regulator. The regulator displays the ther-
mal energy that is exchanged from the heating system
in kWh.
Operation
Your decision to purchase a heat pump or a heat pump
system is a long-term contribution to protecting the en-
vironment through low emissions and reduced primary
energy use.
You can operate and control the heat pump system wi-
th the control element of the heating and heat pump re-
gulator.
NOTICE.
Make sure that the control settings are correct.
Operating manual of the heating and heat
pump regulator.
To ensure that your heat pump or heat pump system
operates eciently and ecologically, the following are
especially important:
€ENERGY SAVING TIP
Avoid unnecessarily high ow temperatures.
A lower ow temperature on the hot water side
increases the eciency of the system.
€ENERGY SAVING TIP
When letting in fresh air. do not leave windows
open for an extended period in order to save
energy and reduce your heating costs.

783054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Care of the unit
The outer surfacesof theunit can be cleaned with a
damp cloth and household cleaning products.
Do not use cleaning or care products that contain ab-
rasives, acids and/or chlorine. Such products would de-
stroy the surfaces and could also damage the technical
components of the unit.
Maintenance of the unit
The cooling circuit of the heat pump requires no regu-
lar maintenance.
According to EU regulation (EC) 517/2014, leak
inspections and maintenance of a log book are required
by law for certain heat pumps!
Log book for heat pumps, Section “Information
on use of the log book”.
The components of the heating circuit and the heat
source (valves, expansion vessels, circulating pumps, l-
ters, dirt traps) should be inspected as well as cleaned as
needed - at the very least annually - by a qualied hea-
ting or cooling system technician.
It is a good idea to have a maintenance contract with a
specialist company. The company will conduct the re-
quired maintenance at regular intervals.
ATTENTION
Check regularly to ensure that the condensate
can drain out of the unit unobstructed. To this
end, regularly check the condensate pan in the
unit and the condensate drain to ensure that
they are clean / free from obstructions and clean
as needed.
CLEANING AND RINSING OF UNIT COMPONENTS
WARNING!
Unit components may be cleaned and rinsed
only by customer service personnel autho-
rized by the manufacturer. Use only liquids
recommended by the manufacturer.
Rinsing of the liqueer with chemical clea-
ning agents must be followed by neutraliza-
tion of residue and intensive rinsing with wa-
ter. Always observe the technical data of the
manufacturer of the heat exchanger.
Malfunctions
In the event of a malfunction, you can detect the cause
of the malfunction via the diagnostic program of the he-
ating and heat pump regulator.
Operating manual of the heating and heat
pump regulator.
DANGER!
Service and repair work on the components
of the unit may be performed only by custo-
mer service personnel authorized by the ma-
nufacturer.
Note that no malfunction is displayed if the safety tem-
perature limiter on the electric heating element has be-
en triggered (depending on model).
“Commissioning”, “Safety temperature limiter”
section.

883054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Scope of delivery
Example of scope of delivery:
View 1:
View 2:
Unit with a completely hermetically
enclosed compressor, all safety-
related components for monitoring
of the cooling circuit, integrated
heating and heat pump regulator,
sensors mounted in the unit for
the monitoring of hot gas, heating
water forward ow and return
ow temperatures, as well as a
hose for condensate discharge
(connected to heat pump side)
Proceed as follows:
Inspect delivery for outwardly visible signs of da-
mage.
Check to make sure that delivery is complete.
Any defects or incorrect deliveries must be claimed
immediately.
NOTICE.
Note the model. Check the air blow-out direc-
tion of the unit.
– Units with the abbreviation L in the mo-
del designation blow the air out to the left
(when viewed from the control side).
Overview "Technical data / scope of delivery".
ACCESSORIES NECESSARY FOR OPERATION
ATTENTION
Use only original accessories from the manufac-
turer of the unit.
With the LI 31(L), you must select the electrical heating
element for the specic system and order it separately.
Air ducts (with air duct accessories) must be ordered se-
parately.
ADDITIONAL ACCESSORIES
The installation accessories (vibration decouplers) for
air/water indoor installation heat pumps must be orde-
red separately.
Installation and assembly
Observe the following when performing all work:
NOTICE.
Always comply with applicable accident pre-
vention regulations, statutory regulations, ordi-
nances and directives.
NOTICE.
Observe the sound levels of the respective
model.
Overview “Technical data / scope of delivery”,
“Sound” section.

9
83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
NOTE.
The following sound pressure levels are calcula-
ted values. Other constellations, adjoining other
buildings or even reecting surfaces may lead to
a level increase. An exact specication of each
sound pressure level is possible only through a
measurement spot when the heat pump is al-
ready installed.
The following sound pressure levels result, depending on the distance and installation variant with directivity factor Q
(see sketches page 10):
LI
14(L)
Distance from the heat pump in m
12345678910 11 12 13 14 15 16 17 18 19 20
Directivity
factor Sound pressure level at max. heating output in dB(A)
Q
2- - - - - - - - - - - - - - - - - - - -
451 45 41,5 39 37 35,4 34,1 32,9 31,9 31 30,2 29,4 28,7 28,1 27,5 26,9 26,4 25,9 25,4 25
854 48 44,5 42 40 38,4 37,1 35,9 34,9 34 33,2 32,2 31,7 31,1 30,5 29,9 29,4 28,9 28,4 28
LI
18(L)
Distance from the heat pump in m
12345678910 11 12 13 14 15 16 17 18 19 20
Directivity
factor Sound pressure level at max. heating output in dB(A)
Q
2- - - - - - - - - - - - - - - - - - - -
452 46 42,5 40 38 36,4 35,1 33,9 32,9 32 31,2 30,4 29,7 29,1 28,5 27,9 27,4 26,9 26,4 26
855 49 45,5 43 41 39,4 38,1 36,9 35,9 35 34,2 33,4 32,7 32,1 31,5 30,9 30,4 29,9 29,4 29
LI
25.1(L)
Distance from the heat pump in m
12345678910 11 12 13 14 15 16 17 18 19 20
Directivity
factor Sound pressure level at max. heating output in dB(A)
Q
2- - - - - - - - - - - - - - - - - - - -
453 47 43,5 41 39 37,4 36,1 34,9 33,9 33 32,2 31,4 30,7 30,1 29,5 28,9 28,4 27,9 27,4 27
856 50 46,5 44 42 40,4 39,1 37,9 36,9 36 35,2 34,4 33,7 33,1 32,5 31,9 31,4 30,7 30,4 30
LI
31(L)
Distance from the heat pump in m
12345678910 11 12 13 14 15 16 17 18 19 20
Directivity
factor Sound pressure level at max. heating output in dB(A)
Q
2- - - - - - - - - - - - - - - - - - - -
453 47 43,5 41 39 37,4 36,1 34,9 33,9 33 32,2 31,4 30,7 30,1 29,5 28,9 28,4 27,9 27,4 27
856 50 46,5 44 42 40,4 39,1 37,9 36,9 36 35,2 34,4 33,7 33,1 32,5 31,9 31,4 30,7 30,4 30
SOUND
The noise emission from the heat pumps must be taken
into account in the respective installation plans for air /
water heat pumps. The respective regional regulations
must be complied with.

10 83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
The directivity factor Q for the dierent installation va-
riants:
Q = 4
Q = 8
In case of 2 or more units of the same heat pump type,
the respective level increase must be added to the cor-
responding sound pressure level from the following ta-
ble
Number of n equally
loud sound sources
Level increase
∆ L in dB
10,0
23,0
34,8
46,0
57,0
67,8
78,5
89,0
99,5
10 10,0
12 10,8
In case of dierent, not equally loud units, the level in-
crease is read o the following diagram:
Level increase in dB
Level dierence in dB
Example: If the level dierence between two unequal
sound sources is 5 dB, the level increase is an additio-
nal 1.2 dB.

11
83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
ATTENTION
Never use components and hydraulic connec-
tions on the unit for purposes of transport.
ATTENTION
Do not damage the hydraulic connections un-
der any circumstances.
ATTENTION
Do not tilt the unit more than a maximum of 45°
(in any direction).
LIFTING THE UNIT WITH PIPES
NOT POSSIBLE WITH THE LI 25.1L AND LI 31L!
The LI 14(L) and LI 18(L) units can be lifted with 3/4" and/
or 1" pipes (provided by customer) that are suitable for
the weight of the respective unit. Special holes are pro-
vided in the frame for this purpose.
Remove lower facing panels on the switch cabi-
net side (= operator side) side of the unit. To do so,
loosen quick-release screws. Turn counter-clock-
wise 90°…
1 Quick-release screws
2 Lower facing panel
INSTALLATION LOCATION
CAUTION.
Install the unit only indoors.
The installation area must be frost-free and dry. It must
meet the requirements of DIN EN 378. It must also fulll
applicable local regulations.
Dimensional drawing and installation plan for
respective model.
TRANSPORT TO INSTALLATION LOCATION
To prevent damage during transport, always transport
the unit to nal installation location in its original packa-
ging, using a lifting truck.
NOTICE.
You can underpin the LI 25.1(L) and LI 31(L) using
a lifting truck; transport the other units on the
wooden pallet.
LI 25.1(L) and LI 31(L)
If it is not possible to transport the unit to the nal in-
stallation location using a lifting truck, you can also
transport the heat pumps using a hand truck (not appli-
cable for the LI 25.1(L) and LI 31(L)).
Lifting the unit with pipes
DANGER!
Several people are required to transport the
unit. Do not underestimate the weight of the
unit.
Overview “Technical data / scope of delivery”,
“General unit data” section.
DANGER!
The unit is not fastened to the wooden pal-
let!. Danger of tipping over during transport!
This can result in personal injury and dama-
ge to the unit.
– Take suitable precautionary measures to
eliminate the danger of tipping.

12 83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Pull lower facing panel upwards and outwards, de-
tach and set securely to the side…
On the back of the unit, remove the sealing grom-
met…
Insert the pipes through the holes in the frame on
the switch cabinet side (= operator side)…
1 Holes in the frame
2 Inserted pipes
Make sure that pipes do not damage cable assem-
blies and components in the unit. Guide pipes care-
fully past cable assemblies and components in the
unit…
Guides pipes through the marked openings on the
back side of the unit…
Lift the unit on the pipes with at least four people
and carry it to its nal installation location…
Put the unit in its nal installation location. Make
sure that the frame of the unit is in full contact with
the underlying surface…
Remove the pipes and re-place the sealing grom-
mets on the back side of the unit…
If the electrical connections will not be carried out
directly thereafter, mount the lower facing panel
on the operating side.
RETRACTABLE VENTILATOR
In order to allow the unit to be easily transported
through tight cellar spaces and narrow doorways and/or
hallways, the ventilator retracts approx. 10 cm into the
body of the unit.
ATTENTION
Only retract the ventilator into the body of the
unit for transport purposes and extend it to its
original positions following transport.
Remove lower facing panels on the fan side of the
unit. To do so, loosen quick-release screws. Turn coun-
ter-clockwise 90°…
1 Quick-release screws
2 Lower facing panel

13
83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Pull lower facing panel upwards and outwards, de-
tach and set securely to the side…
Remove the screws located on the lower side of the
upper facing panel…
Slant the facing panel upwards, remove and set
aside in a safe place…
Then remove side facing panels from the unit too
and store safely…
At the fan, thread the two guide rods supplied
through the metal tab and fan…
Then, on both sides, hook the guide rods in the key-
hole slot pattern of the upper metal tab inside the
unit…
On the inside of the device, undo all four nuts (M12)
of the fan's connections and remove together with
the spring washers…
Push the fan in the direction of the evaporator up
to the top metal tab inside the unit…
1 top metal tab inside the unit

14 83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
MOUNTING THE AIR DUCTS
NOTICE.
Note the air blow-out direction of the unit.
– Units with the abbreviation L in the mo-
del designation blow the air out to the left
(when viewed from the control side).
ATTENTION
Use only original accessories or air ducts recom-
mended by the manufacturer (breglass light-
weight concrete ducts).
Mount air ducts only according to the installa-
tion plan for the respective unit.
Installation plan for respective model.
WALL DUCTS ASSEMBLY
Remove the parts necessary for the assembly of the
wall duct(s) from their respective boxes...
Next, interlock the 2 pieces of the wall duct(s) that
belong together, as illustrated in the following
drawing. Use the lubricant supplied upon delivery
to help in this process...
Push the screws M12 x 40 (2x) supplied through
the fan and the top metal tab and secure with nuts
M12…
Lower the unit at the installation location. Make su-
re that the frame of the unit is in full contact with
the underlying surface and the unit is positioned
horizontally…
Undo the mounting nuts at the top metal tab and
remove the corresponding screws.
Then pull the fan out of the unit and screw tightly
back onto the unit frame (do not forget the spring
washers)…
Remove guide rods and attach all facing panels
back onto the unit.
INSTALLATION
Set the unit on a stable, solid and level, preferably
sound-insulated surface. Make sure that the foundation
is designed for the weight of the heat pump.
ATTENTION
In the air outlet area the air temperature is ca.
5 K below the ambient temperature. Under cer-
tain climatic conditions, therefore, an ice layer
can form in the air outlet area.
Install the heat pump so that the air blower does
not blow in the direction of footpaths.
ATTENTION
Do not tilt the unit more than a maximum of 45°
(in any direction).
NOTICE.
Always observe the installation plan for the re-
spective model. Note the size and minimum
clearances.
Installation plan for respective model.
Set up the unit so that the switch cabinet side (= opera-
ting side) is accessible at all times.

15
83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Install the wall duct in the masonry from the
house exterior. This can either be done during
the construction phase (by means of sealing)...
NOTICE.
Mount the wall ducts 1 cm above the nished
outer facade.
1 Masonry of the house exterior
2 Insert the wall duct in the
masonry (1 cm above the
nished outer facade)
or retrot (using foam in the masonry):
1 Finished outer facade
NOTICE.
Wall ducts x wall openings, help avoid cold air
transmission in the masonry as well as assist in
the assembly of weather / rain guards and wire
mesh grilles
Ax an additional part as illustrated...
Rotate the already-interlocked parts 90° and ax
the nal piece at the bottom...
Rotate the already-interlocked parts by 90° once
again and set up the nal connection...
Stabilise the wall duct from the inside using the
chipboard included with delivery...

16 83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
AIR DUCTS ASSEMBLY
Remove the parts necessary for the assembly of the
air duct(s) from their respective boxes...
The interlocking of the air ducts is carried out
as described in the section – entitled "Wall
duct(s) assembly".
SECURING THE AIR DUCT INTO THE WALL DUCT
Pull the roll seal included with delivery over the end
of the air duct...
Push this end of the air duct into the wall duct.
1 Wall duct
2 Air duct
3 Roll seal
4 Bentonite waterproong tape
(apply only after assembling the
unit's connection fastener)
NOTICE.
After the other end of the air duct has been se-
cured to the heat pump, close the opening bet-
ween the wall duct and the air duct using the
bentonite waterstop tape included with deli-
very.
SECURING THE AIR DUCT ON THE HEAT PUMP
Clip on the assembly rail and secure it using special
screws to the spots on the air duct designated as
the air intake side...
Stick the adapter base included with delivery on
the edge of the air duct...
Position the air duct on the respective opening of
the air intake side...
Hook the 4 tension springs included with delivery
into the holes provided for them on the air intake
side of heat pump...
Hook the tension springs into the assembly tail that
has been screwed on to the air duct...
Secure a protective cap over the assembly rail...
Repeat – the process on the air output side.
NOTICE.
Don't forget:
After the air ducts have been secured to the
heat pump, close the opening between the wall
duct and the air duct using the bentonite water-
stop tape included with delivery.

17
83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
From the outside of the house inwards, insert the
assembly frame into the wall duct on the air intake
side and secure with screws...
8 x
Position the wire mesh grille in the assembly fra-
me...
Set the weather / rain guards on the assembly fra-
me in the wall duct and screw down...
8 x
NOTICE.
If the wall duct is positioned above ground le-
vel, attach the weather guard.
If the wall duct is positioned in a light well (be-
low ground level), attach the rain guard.
Repeat – the process on the air output side.
NOTICE.
Secure the air ducts to the cover using appropri-
ate measures.
SCREEN FRAME ASSEMBLY
Screw the screen frame to the wall ducts on both the air
intake and output sides.
NOTICE.
The screen frame has no function, it is included
solely to provide an optically attractive transi-
tion to the wall duct.
WIRE MESH GRILLE AND WEATHER / RAIN GUARDS
ASSEMBLY
Remove the wire mesh grille and the weather / rain
guards as well as the assembly frame and fastening
material from their respective boxes...

18 83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
NOTICE.
During installation of the shut-o devices, the li-
queer of the heat pump can be rinsed, if neces-
sary.
Connect the unit to the pipes of the heating circuit
via vibration decouplers. They must be installed in or-
der to prevent damage from vibrations to the pipes.
NOTICE.
Vibration decouplers are available as accesso-
ries.
The connections for the heating water outow (forward
ow) and the hot water inow *(return ow) are marked
accordingly.
For positioining of the connections, reference
the dimensional drawing for the respective mo-
del.
CONDENSATE DISCHARGE
The condensation water that accumulated from the air
must be drained via the pre-mounted hose in the unit
for condensate discharge. To do so, connect the hose for
condendate discharge with a water drain.
For positioning of the connection for conden-
sate discharge, see dimensional drawings for
the respective model.
1 Hose for condensate discharge
in interior of unit
2 Connection for the condensate
discharge on the outside of the unit
ATTENTION
Guide the pre-mounted hose in the unit for con-
densate discharge in the interior of the unit as a
siphon, as shown in the illustration.
Discharge of the condensate into the sewage system is
permitted only via a funnel siphon, which must be ac-
cessible at all times.
INSTALLATION / CONNECTION TO HEATING
CIRCUIT
ATTENTION
Connect the unit to the heating circuit accor-
ding to the hydraulic diagram for the respective
model.
“Hydraulic connection” instructions.
NOTICE.
Check to make sure that the diameters and
lengths of the pipes for the heating circuit are
suciently dimensioned.
NOTICE.
Circulating pumps must be multi-stage, regula-
ted pumps. They must be able to deliver at least
the minimum hot water ow rate required for
your model.
Overview “Technical data / scope of delivery”,
“heating circuit” section.
ATTENTION
The hydraulic system must be equipped with a
buer tank, the required volume of which de-
pends on the model of your unit.
Overview “Technical data / scope of delivery”,
“heating circuit, buer tank” section.
ATTENTION
When installing the connections, always secure
the connections on the unit from twisting, in or-
der to prevent damage to the copper pipes in
the interior of the unit.
Rinse heating circuit thoroughly prior to connec-
ting the unit to the heating circuit…
NOTICE.
Contamination and deposits in the heating cir-
cuit can cause malfunctions.
Install shut-o devices for the hot water outow
(forward ow) and hot water inow (return ow) on
the heat pump side…

19
83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Circulating pumps
ATTENTION
Always note the model.
Do not use regulated circulating pumps.
Circulating pumps and domestic hot water cir-
culation pumps must be multi-stage pumps.
Water heating
Water heating with the heat pump requires an additio-
nal hot water circuit, parallel to the heating circuit. Ma-
ke sure that the heating water charge is not channeled
through the buer tank of the heating circuit.
“Hydraulic connection” instructions.
Hot-water tank
If the heat pump will be used for heating hot water, you
must integrate special hot-water tanks in the heat pump
system. The storage volume must be sucient so that
the required hot water quantity is available even during
a power outage.
NOTICE.
The heat exchanger surface of the hot water
tank must be dimensioned so that the heating
capacity of the heat pump is transferred with
minimal spreading.
We oer a variety of hot-water tanks for you to choose
from. They are optimized for use with your heat pump.
NOTICE.
Integrate the hot-water tank in the heat pump
system corresponding to the hydraulic diagram
for your system.
“Hydraulic connection” instructions.
Pressure relief
Equip the heating circuit in accordance with local stan-
dards and directives with a safety valve and an expansi-
on tank.
Also install lling and emptying devices, shut-o de-
vices and non-return valves in the heating circuit.
Overow valve
Use an overow valve for tanks integrated in series to
ensure the minimum ow rate of the heating circuit vo-
lume ow through the heat pump. The overow val-
ve must be dimensioned so that the minimum ow ra-
te of the volume ow through the heat pump is ensured
when the heating circuit is shut o.
“Set the overow valve”, page 26.
Buer tank
The hydraulic connection of the heat pump requires a
buer tank in the heating circuit. It ensures a minimum
operating time of the heat pump when the heating cir-
cuit valves are closed. The required volume of the buer
tank is calculated based on the following formula:
VBuffer tank =
minimum ow rate of heat circuit volume ow / hour
10
For the minimum ow rate of the heat circuit vo-
lume ow, see overview “Technical data / Scope
of delivery”, “Heating circuit” section.
In mono-energetic air/water systems, integrate the buf-
fer tank in the heating water outow (forward ow) be-
fore the overow valve.

20 83054403eUK – Translation into English of the original German operating manual – Subject to change without notice. www.novelan.com
Lead 230 V power cable, power cable for circulating
pumps and cable for external temperature sensor
through the rubber sockets on the facing panel in
the unit…
•
Cut out the rubber sockets on the facing panel…
For positioning of the rubber sockets for inser-
ting the wires, see "dimensional drawing" for the
respective model.
•
Insert the cables through the rubber sockets in the
unit…
The wires inside the unit are guided in a closed wire
duct to theterminals on the switch plate…
Install electric connections according to the termi-
nal diagram that applies to your model…
Terminal diagram for respective model.
ATTENTION
Ensure clockwise rotary eld of the load power
supply (compressor).
– An incorrect rotary eld of the compressor
during operation can cause serious, irrepa-
rable damage to the compressor.
ATTENTION
The power supply for the heat pump must be
equipped with an all-pole miniature circuit-
breaker with at least 3 mm contact spacing to
IEC 60947-2.
Residual current circuit breaker type A is suci-
ent.
Overview “Technical data / scope of delivery”,
“Electric” section.
ATTENTION
If using the unit in 3~230V systems, please note
that the residual-current circuit breaker (RCCB)
used must be AC-DC sensitive.
NOTICE.
Factory setting for the electric heating element
in units with integrated electic heating elements
is 6 kW (9 kW). It can be changed at contactor Q5
(Q6) for 2 (3) or 4 kW (6kW).
For further information, see the adhesive label
on the electric heating element.
Electrical connections
Observe the following when performing all work:
DANGER!
Danger of fatal injury due to electric current!
Electrical connections may be installed only
by qualied electricians.
Before opening the unit, disconnect the sys-
tem from the power supply and secure it
from being switched back on!
DANGER!
Observe the relevant EN-, VDE and/or appli-
cable local safety regulations during the in-
stallation and during all electrical work.
Comply with technical connection require-
ments of the responsible power supply com-
pany (if required by the latter)!
NOTICE.
All live wires must be stripped before they are
installed in the cable duct of the switch cabi-
nets!
POWER CONNECTION
If the unit is closed, open the facing panels on the
operating side…
"Installation".
Open electrical switch cabinet of unit…
Example of open
electrical switch cabinet…
