Novoferm Helix S600 User manual

USER MANUAL / ELECTRIC DRIVE - IMPULSE OPERATION
Helix / S600
ENG
B
a
u
m
u
s
t
e
r
g
e
p
r
ü
f
t
Zertifizierung

2
User manual 2015/05
Contents
General information ..................................................................................................................................3
Warnings and safety instructions ..........................................................................................................3
Checks / maintenance...........................................................................................................................4
Exercise extreme caution in the event of a cable or chain breakage!...................................................4
Operation ..............................................................................................................................................4
Control method .....................................................................................................................................4
Electric drive - impulse operation ...........................................................................................................5
User instructions, Helix / S600 with electric drive - impulse operation..................................................5
Opening the door ..................................................................................................................................5
Closing the door ....................................................................................................................................5
Stop! button...........................................................................................................................................6
Emergency opening and closing ...........................................................................................................6
Inspection report.......................................................................................................................................7

3
User manual 2015/05
Warnings and safety instructions
4. Never open the door in this way
3. Caution, risk of pinching/crushing!
1. Caution, risk of pinching/crushing!
5. Do not place goods or objects in the
area of the door.
2. Caution, risk of pinching/crushing!
6. Never use the door to lift persons or
goods.
General information

4
User manual 2015/05
Checks / maintenance
1. Regularly check that the door still operates correctly, the lifting cables must run freely.
Check components and parts for wear. Pay particular attention to:
• various fasteners • the track system
• hinges + rollers • drive components (chain, cables and chain tensioner)
• the door leaf
2. Regularly clean the door leaf with copious amounts of water and a mild (non-caustic)
cleaning agent.
3. In the event of breakdowns, problems and questions,
please always contact a specialised door company.
Exercise extreme caution in the event of a cable or chain breakage!
• immobilise the door
• block access to the area around the door
• inform/warn users / company operating the door / authorised persons
• inform specialised door company
Operation
Ensure that a number of people are familiar with door operation.
Type of operation
electric drive emergency
chain hoist

5
User manual 2015/05
User instructions, Helix / S600 with electric drive - impulse operation
These instructions must be strictly adhered to in order to prevent injury and avoid material damage.
These instructions apply to sectional doors in combination with all track system types and an electric drive with impulse operation.
Opening the door
Closing the door
Electric drive - impulse operation
1. Caution! Only use this control button
when nobody/no objects are in the area
of the door.
2. Briey press the ‘open’ ( )button and
the door will move to the fully open
position
1. Caution! Only use this control button
when nobody/no objects are in the area
of the door.
2. Briey press the ‘close’( )button and
the door will move to the fully closed
position
3. Caution, risk of pinching/crushing!
The bottom safety edge does not
operate for technical reasons in the
lowest area of door movement
(approximately 20 - 40 mm).

6
User manual 2015/05
Stop! button
Emergency opening and closing
Using the ‘stop’ ( ), button stops door
movement throughout the range of travel.
Caution! Only use this control button when nobody/no objects are in the area of the door.
Switch o the electric drive (switch o the power supply) and secure the motor to ensure that it cannot be switched back on
without authorisation. Pulling the cord with the red label (1) engages the emergency chain hoist. You can use the emergency chain
hoist to open (2) or close (3) the door to any required height. As soon as you can operate the door again in the normal manner, you
disengage the emergency chain hoist by pulling the cord with the green label (4). The electric drive can now be used again.
STOP
1
2
3
4

7
User manual 2015/05
Annual inspection
month / year Inspected by Remarks
20,000 cycle inspection
Cycles Inspected by Remarks
Inspection report

8
User manual 2015/05
Annual inspection
month / year Inspected by Remarks
20,000 cycle inspection
Cycles Inspected by Remarks
