Novus NVIP-1DN5001H/IRH-1P User manual

U s e r ’s m a n u a l
( s ho rt f o rm )
NVIP-1DN5001H/IRH-1P

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
2
IMPORTANT SAFEGUARDS AND WARNINGS
EMC (2004/108/EC) and LVD (2006/95/EC ) Directives
CE Marking
Our products are manufactured to comply with requirements of the following directives and national regulations
implementing the directives:
Electromagnetic compatibility EMC 2004/108/EC.
Low voltage LVD 2006/95/EC with further amendment. The Directive applies to electrical
equipment designed for use with a voltage rating of between 50VAC and 1000VAC as well as
75VDC and 1500VDC.
WEEE Directive 2002/96/EC
Information on Disposal for Users of Waste Electrical and Electronic Equipment
This appliance is marked according to the European Directive on Waste Electrical and Electronic Equipment
(2002/96/EC) and further amendments. By ensuring this product is disposed of correctly, you will help to
prevent potential negative consequences for the environment and human health, which could otherwise be
caused by inappropriate waste handling of this product.
The symbol on the product, or the documents accompanying the product, indicates that this appliance may not be
treated as household waste. It shall be handed over to the applicable collection point for used up electrical and
electronic equipment for recycling purpose. For more information about recycling of this product, please contact
your local authorities, your household waste disposal service or the shop where you purchased the product.
RoHS Directive 2002/95/EC
Out of concern for human health protection and friendly environment, we assure that our products
falling under RoHS Directive regulations, regarding the restriction of the use of hazardous
substances in electrical and electronic equipment, have been designed and manufactured in
compliance with the above mentioned regulations. Simultaneously, we claim that our products have
been tested and do not contain hazardous substances whose exceeding limits could have negative
impact on human health or natural environment
Information
The device, as a part of professional CCTV system used for surveillance and control, is not designed for self
installation in households by individuals without technical knowledge.
Excluding of responsibility in case of damaging data on a disk or other devices:
The manufacturer does not bear any responsibility in case of damaging or losing data on a disk or other devices
during device operation.
WARNING!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT DESCRIBED FOR THE GIVEN PRODUCT IN
USER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE PRODUCT, OR IF IT DOES
NOT ARISE FROM THE USUAL APPLICATION OF THE PRODUCT, MANUFACTURER MUST BE
CONTACTED UNDER THE RIGOR OF EXCLUDING THE MANUFACTURER’S RESPONSIBILITY FOR
THE RESULTS OF SUCH AN ACTION.

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
3
IMPORTANT SAFEGUARDS AND WARNINGS
WARNING!
THE KNOWLEDGE OF THIS MANUAL IS AN INDISPENSIBLE CONDITION OF A PROPER
DEVICE OPERATION. YOU ARE KINDLY REQEUSTED TO FAMILIARIZE YOURSELF WITH
THE MANUAL PRIOR TO INSTALLATION AND FURTHER DEVICE OPERATION.
WARNING!
USER IS NOT ALLOWED TO DISASSEMBLE THE CASING AS THERE ARE NO USER
-SERVICEABLE PARTS INSIDE THIS UNIT. ONLY AUTHORIZED SERVICE PERSONNEL
MAY OPEN THE UNIT
INSTALLATION AND SERVICING SHOULD ONLY BE DONE BY QUALIFIED SERVICE
PERSONNEL AND SHOULD CONFORM TO ALL LOCAL REGULATIONS
1. Prior to undertaking any action please consult the following manual and read all the safety and operating
instructions before starting the device.
2. Please keep this manual for the lifespan of the device in case referring to the contents of this manual is
necessary;
3. All the safety precautions referred to in this manual should be strictly followed, as they have a direct
influence on user’s safety and durability and reliability of the device;
4. All actions conducted by the servicemen and users must be accomplished in accordance with the user’s
manual;
5. The device should be disconnected from power sources during maintenance procedures;
6. Usage of additional devices and components neither provided nor recommended by the producer is
forbidden;
7. You are not allowed to use the camera in high humidity environment (i.e. close to swimming pools, bath tubs,
damp basements);
8. Mounting the device in places where proper ventilation cannot be provided (e. g. closed lockers etc.) is not
recommended since it may lead to heat build-up and damaging the device itself as a consequence;
9. Mounting the camera on unstable surface or using not recommended mounts is forbidden. Improperly
mounted camera may cause a fatal accident or may be seriously damaged itself. The camera must be mounted
by qualified personnel with proper authorization, in accordance with this user’s manual.
10. Device should be supplied only from a power sources whose parameters are in accordance with those
specified by the producer in the camera technical datasheet. Therefore, it is forbidden to supply the camera
from a power sources with unknown parameters, unstable or not meeting producer’s requirements;
Due to the product being constantly enhanced and optimized, certain parameters and functions described in the
manual in question may change without further notice. We strongly suggest visiting the www.novuscctv.com
website in order to access the newest manual
Data included in the following user’s manual is up to date at the time of printing. AAT Holding Sp z o.o. holds
exclusive rights to modify this manual. The producer reserves the rights for device specification modification
and change in the design without prior notice.

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
4
TABLE OF CONTENTS.....................................................................................................4
1. FOREWORD INFORMATION .....................................................................................5
1.1. General Characteristics........................................................................................5
1.2. NVIP-1DN5001H/IRH-1P tech specification ....................................................6
1.3. Camera dimension ..............................................................................................7
1.4. Package contents..................................................................................................8
2. START-UP AND INITIAL IP CAMERA CONFIGURATION .................................9
2.1. Description of connectors and control tools ........................................................9
2.2. Cable connectors..................................................................................................9
2.3. NVIP-1DN5001H/IRH-1P mounting ................................................................10
2.4. Starting the IP camera........................................................................................12
2.5. Initial configuration via the Web browser.........................................................13
3. NETWORK CONNECTION UTILIZING WEB BROSWER ................................14
3.1. Recommended PC specification for web browser .............................................14
3.2. Connection with IP camera via the Internet Explorer ........................................14
4. WWW INTERFACE - WORKING WITH IP CAMERA.........................................16
4.1. Displaying live pictures......................................................................................16
5. ELECTRIC CONNECTORS AND ACCESORIES .................................................18
5.1. Connecting power supply to the camera. ..........................................................18
6. RESTORING FACTORY DEFAULTS .....................................................................18
6.1. Restoring software factory defaults....................................................................18
6.2. Restoring hardware factory defaults in IP cameras............................................19
TABLE OF CONTENTS

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
5
1. FOREWORD INFORMATION
1.1. General Characteristics
Imager resolution: 1.3 fmegapixels
Mechanical IR cut filter
IR operation capability
Min. Illumination from 0,034 lx/F=2.2 , 0 lx (IR on)
Digital Slow Shutter (DSS)
Digital Noise Reduction (DNR)
Lens f=3.6m/F=2.2
Built-in IR LED - 2 pcs., up to 15 m
Privacy zones: 5
Compression: H.264, M-JPEG
Max video processing resolution: 1280x960
Double stream mode: compression, resolution, speed and quality defined individually for each
video stream
RTP/RTSP protocol support for video transmission
Pre & post-alarm functions
Hardware motion detection
Built-in webserver: camera configuration through the website
Wide range of responses to alarm events: e-mail with attachment, saving file on FTP and NAS
server,
Network protocol support : ONVIF (2.2)/Profile S, HTTP, TCP/IP, IPv4/v6, UDP/IP, RTSP,
FTP, DHCP, NTP, PPPoE, SMTP
Software: NMS (NOVUS MANAGEMENT SYSTEM) for video recording, live monitoring,
playback and remote IP devices administration
Degree of protection IP66
Built-in heater
Power supply: 12VDC, PoE (Power over Ethernet)
FOREWORD INFORMATION

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
6
1.2. NVIP-1DN5001H/IRH-1P specification
FOREWORD INFORMATION
NVIP-1DN5001H/IRH-1P
Pick-up Element 1.3 MPX, CMOS imager, 1/3”
Number of Effective Pixels 1280 (H) x 960 (V)
Min. Illumination 0.67 lx/F=2.2 –color mode,DSS OFF
0.034 lx/F=2.2 –color mode,DSS ON
0 lx (IR on) –b/w mode
Digital Slow Shutter (DSS) x5
Digital Noise Reduction (DNR) Yes
LENS
Type Standard, f=3.6/F=2.2
Angle of View (H) 73°
DAY/NIGHT
Type Mechanical IR cut filter
Switch Mode Auto,manual
NETWORK
Stream Resolution 1280 x 960, 1280 x 720 (HD ), 720 x 576 (D1), 640 x 480 (VGA)
640 x 360, 352 x 288 (CIF), 320 x 240 (QVGA), 176 x 144 (QCIF)
Frame Rate 30 fps for each resolution
Multistreaming Mode 2 streams
Video/Audio Compression H.264, M-JPEG, M-JPEG
Network Protocols Support ONVIF (2.2)/Profile S, HTTP, TCP/IP, IPv4/v6, UDP/IP, RTSP, FTP,
DHCP, NTP, PPPoE, NTP, SMTP
PC Software NOVUS NMS, Internet Explorer, Google Chrome, Opera, Mozilla, Firefox
OTHER FUNCTIONS
OSD IE browser, Polish, English, Russian, other
Privacy Zones 5
Motion Detection Yes
Prealarm/Postalarm 5MB /0s - 86400s
System Reaction to Alarm Events E-mail with attachment, saving file on: FTP/NAS server
IR LED
Number 2
Range 15 m
Angle 90°
INTERFACES
Network Interface 1 x Ethernet - RJ-45 interface, 10/100 Mbit/s
INSTALLATION PARAMETERS
Dimensions (mm) 70 (W) x 63 (H) x 90 (L)
Weight 473 g
Enclosure Aluminium, white
Power Supply PoE,12 VDC
Power Consumption 3,5W, 5,5W (IR on), 8,5W (IR and heater on)
Operating Temperature -40°C ~ 55°C
Cold Start Minimum Temperature -25°C
Degree of Protection IP 66

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
7
FOREWORD INFORMATION
1.3. Camera dimensions

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
8
1.4. Package contents
After you open the package make sure that the following elements are inside:
IP camera
230 VAC / 12 VDC power supply
Accessories bag
Short version of user’s manual
CD containing manual and software
If any of this elements has been damaged during transport, pack all the elements back into the original
box and contact your supplier for further assistance.
CAUTION!
If the device was brought from a location with lower temperature, please wait until it reaches the
temperature of location it is currently in. Turning the device on immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.
1.4. Package contents
After you open the package make sure that the following elements are inside:
IP camera
Accessories bag
Mounting Template
Short version of user’s manual
CD containing manual and software
If any of this elements has been damaged during transport, pack all the elements back into the original
box and contact your supplier for further assistance.
CAUTION!
If the device was brought from a location with lower temperature, please wait until it reaches the
temperature of location it is currently in. Turning the device on immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.
FOREWORD INFORMATION

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
9
2. START-UP AND INITIAL IP CAMERA CONFIGURATION
2.1. Camera overview
2.2. Cabel connectors
START-UP AND INITIAL CAMERA CONFIGURATION
No. Description
1 RJ-45 network connector
2 12V DC Power In 2.1 mm x 5.5 mm
1
2

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
10
2.3. NVIP-1DN5001H/IRH-1P mounting
1. Unpack the camera from box, checking for any missing parts.
2. Loosen the adjustment nut on bracket, turn anti-clockwise
3. Plan the camera installation site remembering to include the position of the camera relative to the
plane of the installation.
To mount the camera on the ceiling bend the attachment base relative to the camera at an angle of 90
degrees and tighten the locking ring clockwise rotation.
Attach the camera base or template to the mounting place and mark the fixing pins and possible cable
exit holes.
START-UP AND INITIAL CAMERA CONFIGURATION

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
11
When installing on the wall put your camera in the desired location, and set the camera position then
tighten the locking ring clockwise rotation.
Mark the fixing points and transition to cable using camera base or template in desired position.
4. Mount the camera in a designated area using the included mounting studs. Connect power network
as required either before or after bracket is attached to surface, if you are making hole for cable in
surface for pass-thought then be sure this task is completed before the bracket is attached to the
surface.
Caution : Make sure to follow the correct polarity if connecting the camera to DC power. The
central pin is positive polarity .
START-UP AND INITIAL CAMERA CONFIGURATION

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
12
2.4. Starting the IP camera
To run NOVUS IP camera you have to connect ethernet cable between camera and network switch
with PoE support (IEEE 802.3af).
You can also connect it directly via power supply adapter with parameters compatible with camera
power supply specification.
Initialization process is then started which can take about 2 minutes. You can then proceed to connect
to the camera via web browser.
The recommended way to start an IP camera and perform its configuration is a connection directly
to the network switch which is not connected to other devices. To obtain further information about
network configuration parameters (IP address, gateway, network mask, etc.) please contact your
network administrator.
Connection utilising network switch with PoE support
Connection utilising external power supply and network switch
START-UP AND INITIAL CAMERA CONFIGURATION
Power supply and
network transmission
Computer
IP Camera
Network Switch
PoE
Network transmission
IP Camera
Network transmission
Network Switch Computer
Network transmission

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
13
Connection utilising external power supply directly to the computer
Information:
Power supply adapter is not included. Please use power adapter with parameters specified in user‘s
manual.
Caution:
In order to provide protection against voltage surges/lightning strikes, usage of appropriate surge
protectors is advised. Any damages resulting from surges are not eligible for service repairs.
2.5. Initial configuration via the web browser
The default network settings for NVIP-1DN5xxx IP camera series are :
1. IP address= 192.168.1.200
2. Network mask - 255.255.255.0
3. Gateway - 192.168.1.1
4. User name - root
5. Password - pass
Knowing the camera’s IP address you need to appropriately set PC IP address, so the two devices can
operate in one network subnet ( e.g. for IP 192.168.1.1, appropriate address for the camera ranges from
192.168.1.2 to 192.168.1.254, for example 192.168.1.60). It is not allowed to set the same addresses for
camera and PC computer
You can either set a network configuration (IP address, gateway, net mask, etc.) of NOVUS IP camera
yourself or select DHCP mode (DHCP server is required in this method in target network) by using
web browser or by NMS software. When you use DHCP server check IP address lease and its linking
with camera MAC address to avoid changing or losing IP address during device operation or network/
DHCP server breakdown. You have to remember to use a new camera IP address after changing
network parameters.
After network setting configuration has been done, the camera can be connected to a target network.
START-UP AND INITIAL CAMERA CONFIGURATION
Network transmission - cross over cable
IP Camera Computer

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
14
3. NETWORK CONNECTION UTILIZING WEB BROSWER
3.1. Recommended PC specification for web browser connections
Requirements below apply to connection with an IP camera, assuming smooth image display
in 1280x960 resolution and 25 fps speed.
1. CPU Intel Pentium IV 3 GHz or newer
2. RAM Memory min. 512 MB
3. VGA card (any displaying Direct 3D with min. 128 MB RAM memory)
4. OS Windows XP / VISTA /Windows 7 / Windows 8
5. Direct X version 9.0 or newer
6. Network card 10/100/1000 Mb/s
3.2. Connection with IP camera via the Internet Explorer
You have to enter camera IP address in the Internet Explorer address bar. If IP address is correct user
login window will be displayed:
Default user is root and default password is pass.
In the Language box you can change the display language. The default language is English.
For safety reasons, it is recommended to change default user name and password.
It is possible to connect to the camera using Internet Explorer, Mozilla Firefox, Chrome or Opera
browsers. Running the IP camera in this browsers are very similar.
NETWORK CONNECTION UTILIZING WEB BROWSER

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
15
If your computer has Flash Player ins t a ll ed, the main screen for the camera web interface opens.
From here you can view and configure the ca m e ra .
Caution: If your computer does not have Flash Player ins t a ll ed, you will be prompted t o select if
y o u would like t o use Activ eX or Flash Play er t o connect to the ca m e ra:
Click Click here to shift playing life video with short delay widget! to play live video with ActiveX
control to reduce latency (recommended): Uses an ActiveX plug-in to connect to the camera. To
install the plug-in, click on the video area, and select Install this Add-on for all users on this
computer, and follow the prompts.
Caution: Please open the Security settings of IE browser, and enable the Download unsigned
ActiveX controls.
Click Please download the latest version of Flash Player to play live video: Opens a link to
download Flash Player from Adobe’s website. After completing the installation, restart your
browser and reconnect to the camera.
Caution: When working in Windows Vista/7/8 the ActiveX applet may be blocked by Windows
Defender or User account control. In such case you should allow to run this applet, or simply
disable these functions.
NETWORK CONNECTION UTILIZING WEB BROWSER

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
16
NETWORK CONNECTION UTILIZING WEB BROWSER
Caution: If you are running Windows Vista/7/8 with Internet Explorer 11, the ActiveX applet can be
blocked through browser security settings. In this situation, you should: add the IP address of the
camera to the view of compatibility (Tools -> Compatibility View Settings, click Add).
Then, in the security settings options, add the camera address to trusted sites and lower the security
level to a minimum.

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
17
NETWORK CONNECTION UTILIZING WEB BROWSER
After making the changes, restart the browser, re-connect to the camera and log on.

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
18
4. WWW INTERFACE - WORKING WITH IP CAMERA
4.1. Displaying live
1. Camera settings
Live Video - Live video preview
Playback - Local recordings playback
Device Info - Device information
Stream Configuration - Video and audio settings for each stream
Device Configuration - Device configuration (e.g. Local Network, Date&Time)
External Device - External device configuration (function unavailable)
Alarm Configuration - Alarm Configuration (Motion alarm, Alarm I/O)
Local Record - Local Record Configuration
Privacy Masking - Configuration up to 5 privacy masks
Network Service - Network services configuration (e.g. DDNS)
Service Center - Service center configuration (e.g. SMTP)
Privilege Manager - users and groups management
Protocol - Protocols settings (e.g. ONVIF)
Device Log - Device Log contains: Operation Log, Alarm Log and Collect Log
Maintenance - Device Restart and restoring Default Settings
WWW INTERFACE - WORKING WITH IP CAMERA
3.
4.
1. 2.

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
19
2. Video Parameter
Stream - Stream configuration (ID: 1~3)
Bite Rate Type - Information about selected bit rate type (VBR or CBR)
Bit Rate (kbps) - Information about bit rate configuration (500 ~ 12000 kbps)
I Frame Interval - Information about I frame interval configuration (available values 1 ~ 60)
Quality - Information about quality configuration (available values 1 ~ 9)
3. Camera Control
Function unavailable.
4. Menu bar
Change Password - Change users password
Sign Out - Log out from camera
WWW INTERFACE - WORKING WITH IP CAMERA

NVIP-1DN5001H/IRH-1P User’s manual ver.1.0
(short form)
All rights reserved © AAT Holding sp. z o.o.
20
5. ELECTRIC CONNECTORS AND ACCESORIES
5.1. Connecting power supply to the camera.
The camera can be supplied by using RJ45 network socket or by power connector. To run NOVUS IP
camera you can connect ethernet cable between camera and network switch with PoE support (IEEE
802.3af). You can also use a power injector compatible with (IEEE 802.3af) standard. Use power
supplay with parameters compatible with camera specification to power camera via power in jack.
Information:
Power supply adapter is not included. Please use power adapter with parameters specified in user’s
manual.
Caution : Make sure to follow the correct polarity if connecting the camera to DC power. The
central pin is positive polarity .
In order to provide protection against voltage surges/lightning strikes, usage of appropriate surge
protectors is advised. Any damages resulting from surges are not eligible for service repairs.
6. RESTORING FACTORY DEFAULTS
NOVUS IP cameras allow to restore defaults via:
Software (web browser level) resetting the camera settings
Hardware (using reset) restores factory defaults.
6.1. Restoring software factory defaults
Restoring factory software default can restore default settings of the IP camera , optionally network
settings can be saved.
Logon to the camera and choose MAINTENANCE> DEFAULT SETTINGS
Check the Save the IP setting box to preserve IP setting after restore.
Click Restore button. The camera re-starts then, taking about two minutes to complete.
Log on approx. using default user name (root) and password (pass)
ELECTRIC CONNECTORS AND ACCESORIES
