U ser’s manual
( short form)
NVIP-4DN3552AH/IR-1P

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
2
IMPORTANT SAFEGUARDS AND WARNINGS
EMC (2014/30/EU) and LVD (2014/35/EU ) Directives
CE Marking
Our products are manufactured to comply with requirements of the following directives and national
regulations implementing the directives:
 Electromagnetic compatibility EMC 2004/108/EC.
 Low voltage LVD 2006/95/EC with further amendment. The Directive applies to electrical
equipment designed for use with a voltage rating of between 50VAC and 1000VAC as well as
75VDC and 1500VDC.
WEEE Directive 2012/19/EU
Information on Disposal for Users of Waste Electrical and Electronic Equipment
This appliance is marked according to the European 1000VAC Directive on Waste Electrical and
Electronic Equipment (2012/19/EU) and further amendments. By ensuring this product is disposed of
correctly, you will help to prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or the documents accompanying the product, indicates that this appliance may not be
treated as household waste. It shall be handed over to the applicable collection point for used up electrical and
electronic equipment for recycling purpose. For more information about recycling of this product, please contact
your local authorities, your household waste disposal service or the shop where you purchased the product.
RoHS Directive 2011/65/EU
Out of concern for human health protection and friendly environment, we assure that our products
falling under RoHS Directive regulations, regarding the restriction of the use of hazardous substances
in electrical and electronic equipment, have been designed and manufactured in compliance with the
above mentioned regulations. Simultaneously, we claim that our products have been tested and do
not contain hazardous substances whose exceeding limits could have negative impact on human
health or natural environment
Information
The device, as a part of professional CCTV system used for surveillance and control, is not designed for self
installation in households by individuals without technical knowledge.
Excluding of responsibility in case of damaging data on a disk or other devices:
The manufacturer does not bear any responsibility in case of damaging or losing data on a disk or other devices
during device operation.
WARNING!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT DESCRIBED FOR THE GIVEN PRODUCT IN
USER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE PRODUCT, OR IF IT DOES
NOT ARISE FROM THE USUAL APPLICATION OF THE PRODUCT, MANUFACTURER
MUST BE CONTACTED UNDER THE RIGOR OF EXCLUDING THE MANUFACTURER’S
RESPONSIBILITY FOR THE RESULTS OF SUCH AN ACTION.

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
3
IMPORTANT SAFEGUARDS AND WARNINGS
WARNING!
THE KNOWLEDGE OF THIS MANUAL IS AN INDESPENSIBLE CONDITION OF A PROPER
DEVICE OPERATION. YOU ARE KINDLY REQUSTED TO FAMILIRIZE YOURSELF WITH
THE MANUAL PRIOR TO INSTALLATION AND FURTHER DEVICE OPERATION.
WARNING!
USER IS NOT ALLOWED TO DISASSEMBLE THE CASING AS THERE ARE NO
USER-SERVICEABLE PARTS INSIDE THIS UNIT. ONLY AUTHORIZED SERVICE
PERSONNEL MAY OPEN THE UNIT
INSTALLATION AND SERVICING SHOULD ONLY BE DONE BY QUALIFIED SERVICE
PERSONNEL AND SHOULD CONFORM TO ALL LOCAL REGULATIONS
1. Prior to undertaking any action please consult the following manual and read all the safety and operating
instructions before starting the device.
2. Please keep this manual for the lifespan of the device in case referring to the contents of this manual is
necessary;
3. All the safety precautions referred to in this manual should be strictly followed, as they have a direct
influence on user’s safety and durability and reliability of the device;
4. All actions conducted by the servicemen and users must be accomplished in accordance with the user’s
manual;
5. The device should be disconnected from power sources during maintenance procedures;
6. Usage of additional devices and components neither provided nor recommended by the producer is
forbidden;
7. You are not allowed to use the camera in high humidity environment (i.e. close to swimming pools, bath tubs,
damp basements);
8. Mounting the device in places where proper ventilation cannot be provided (e. g. closed lockers etc.) is not
recommended since it may lead to heat build-up and damaging the device itself as a consequence;
9. Mounting the camera on unstable surface or using not recommended mounts is forbidden. Improperly
mounted camera may cause a fatal accident or may be seriously damaged itself. The camera must be mounted
by qualified personnel with proper authorization, in accordance with this user’s manual.
10. Device should be supplied only from a power sources whose parameters are in accordance with those
specified by the producer in the camera technical datasheet. Therefore, it is forbidden to supply the camera
from a power sources with unknown parameters, unstable or not meeting producer’s requirements;
Due to the product being constantly enhanced and optimized, certain parameters and functions
described in the manual in question may change without further notice.
We strongly suggest visiting the www.novuscctv.com website in order to access the newest manual.

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
4
TABLE OF CONTENTS.................................................................................................4
1. FOREWORD INFORMATION..................................................................................5
1.1. General characteristics .....................................................................................5
1.2. Technical specification ....................................................................................6
1.3. Camera dimension ...........................................................................................7
1.4. Package contents..............................................................................................7
2. START-UP AND INITIAL IP CAMERA CONFIGURATION ................................8
2.1. Description of connectors and control tools ......................................................8
2.2. Connecting power supply to the camera..........................................................9
2.3. Cameras mounting ...........................................................................................9
2.4 Starting the IP camera……….………...…..……………....…......……...……...10
2.5. Initial configuration via the web browser……………………………………...11
2.6 Security recommendations for network architecture and configuration ……….12
3. NETWORK CONNECTION UTILIZING WEB BROSWER ...............................13
3.1. Recommended PC specification for web browser............................................13
3.2. Connection with IP camera via web browser...................................................13
4. USING AND CONFIGURING..................................................................................15
4.1. Remote Preview Interface. ..............................................................................15
4.1. Focus and Zoom Settings . ..............................................................................16
5. ELECTRIC CONNECTORS AND ACCESORIES ...............................................16
5.1. Connecting power supply to the camera. ........................................................16
5.2. Camera control RS..........................................................................................16
5.3. Connecting alarm inputs/outputs.....................................................................16
5.4. SD card installation.........................................................................................17
6. RESTORING FACTORY DEFAULTS ..................................................................18
6.1. Restoring software factory defaults .................................................................18
6.2. Restoring factory defaults by hardware means ................................................18
TABLE OF CONTENTS

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
5
1. FOREWORD INFORMATION
1.1. General Characteristics
 Imager resolution: 4.0 megapixels
 Mechanical IR cut filter IR operation capability
 Min. Illumination from 0 lx with IR LED on
 Wide Dynamic Range (WDR) for enhanced image quality in diverse light conditions
 Digital Noise Reduction (DNR)
 Lens type: motor-zoom, , f=9 ~ 22 mm/F1.4
 Auto-focus
 Built-in LED illuminator: 4 LED diods
 Compression: H.264 / H.265
 Max video processing resolution: 2592 x 1520
 Multi streaming: compression, resolution, speed and quality defined individually for each video
stream
 RTP/RTSP protocol support for video transmission
 SD card up to 128 GB
 Audio input
 Audio output
 BNC output
 Alarm Input/Output
 Built-in webserver: camera configuration through the website
 Wide range of responses to alarm events: e-mail with attachment, saving file on FTP server
and triggering alarm output, saving file on SD card
 Software: NMS (NOVUS MANAGEMENT SYSTEM) for video recording, live monitoring,
playback and remote IP devices administration
 Video Content Analysis (VCA):
Exception
Line Crossing
Intrusion
 Power supply: 12VDC, PoE (Power over Ethernet)
FOREWORD INFORMATION

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
6
1.2. Technical specification
FOREWORD INFORMATION
Image Sensor 4 MPX CMOS sensor 1/3” OV
Number of Effective Pixels 2688 (H) x 1520 (V)
Min. Illumination 0.07 lx/F1.4 - color mode ,
0 lx (IR on) - B/W mode
Electronic Shutter auto/manual: 25 s ~ 1/100000 s
Wide Dynamic Range (WDR) yes (double scan sensor), 120dB
Digital Noise Reduction (DNR) 2D, 3D
Defog Function (F-DNR) yes
Highlight Compensation (HLC) yes
Back Light Compensation (BLC) yes
Lens
Lens Type motor-zoom, f=9 ~ 22 mm/F1.4
Auto-focus continuous, zoom trigger, day/night mode trigger, manual trigger
DAY/NIGHT
Switching Type mechanical IR cut filter
Switching Mode auto, manual, time
Switching Level Adjustment yes
Switching Schedule yes
Visible Light Sensor yes
NETWORK
Stream Resolution 2592 x 1520, 2560 x 1440 (QHD), 2304 x 1296, 1920 x 1080 (Full HD), 1280 x 720 (HD), 720 x 576
(D1), 352 x 288 (CIF)
Frame Rate 30 fps for 2592 x 1520 and lower resolutions
Multistreaming Mode 3 streams
Video/Audio Compression H.264, H.265, MJPEG/G.711
Number of Simultaneous Connections max. 5
Bandwidth 30 Mb/s in total
Network Protocols Support HTTP, TCP/IP, IPv4, UDP, FTP, DHCP, DDNS, NTP, RTSP, PPPoE, SMTP
ONVIF Protocol Support Profile S (ONVIF 2.3)
Camera Configuration from Internet Explorer browser
languages: Polish, English, Russian, and others
Compatible Software NMS
OTHER FUNCTIONS
Privacy Zones 4
Motion Detection yes
Region of interest (ROI) 3
Video Content Analysis (VCA) tamper, abandoned object, object disappearance, line cross, zone entrance
Image Processing 180˚ image rotation, sharpening, mirror effect, corridor mode
Prealarm/Postalarm -/up to 120 s
System Reaction to Alarm Events e-mail with attachment, saving file on FTP server, saving file on SD card, alarm output activation
IR LED
LED Number 4
Range 100 m
INTERFACES
Video Output BNC, 1.0 Vp-p, 75 Ohm
Audio Input/Output 1 x Jack (3.5 mm)/1 x Jack (3.5 mm)
Alarm Input/Output 1 (NO/NC)/1
Network Interface 1 x Ethernet - RJ-45 interface, 10/100 Mbit/s
Memory Card Slot SD - capacity up to 128GB
INSTALLATION PARAMETERS
Dimensions (mm) with bracket: 109 (Ф) x 360 (L)
Weight 1.7 kg
Degree of Protection IP 66 (details in the user’s manual)
Enclosure aluminium, white, fully cable managed wall mount bracket in-set included
Power Supply PoE, 12 VDC
Power Consumption 8 W,
16 W (IR on)
Operating Temperature -20°C ~ 50°C

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
7
FOREWORD INFORMATION
1.3. Camera dimensions
Cameras NVIP-4DN3552AH/IR-1P,
1.4. Package contents
After you open the package make sure that the following elements are inside:
 IP camera
 Accessories bag
 Short version of user’s manual
If any of this elements has been damaged during transport, pack all the elements back into the original
box and contact your supplier for further assistance.
CAUTION!
If the device was brought from a location with lower temperature, please wait until it reaches
the temperature of location it is currently in. Turning the device on immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
8
1.4. Package contents
After you open the package make sure that the following elements are inside:
 IP camera
 230 VAC / 12 VDC power supply
 Accessories bag
 Short version of user’s manual
 CD containing manual and software
If any of this elements has been damaged during transport, pack all the elements back into the original
box and contact your supplier for further assistance.
CAUTION!
If the device was brought from a location with lower temperature, please wait until it reaches the
temperature of location it is currently in. Turning the device on immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.
2. START-UP AND INITIAL CAMERA CONFIGURATION
2.1 Description of connectors and control tools
Camera NVIP-4DN3552AH/IR-1P
1. BNC video output
2. Audio output
3. Audio input
4. Power supply 12VDC
5. 100 Mb/s Ethernet port (RJ-45 connector)
6. Alarm COM - Alarm output
7. Alarm NO - Alarm output
8. Alarm IN - Alarm input
9. Alarm GND - Alarm input
10. RS485 T+
11. RS485 T-
Internal slots:
1. SD card slot
2. Network indicator
3. 3 pin connector. Video output and power supply -
maintenance only
4. Reset button
START-UP AND INITIAL CAMERA CONFIGURATION
1
2
3
4
9
1
2
4
3
5
6
7
10
8
11

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
9
2.2. Connecting power supply to the camera.
Camera can be supplied using external power supply unit corresponding with the camera parameters or
by using RJ45 network socket and PoE (802.3af) power supply unit.
Camera can be supplied using external power supply unit corresponding with the camera parameters or
by using RJ45 network socket and PoE (802.3af) power supply unit.
Caution:
In order to provide protection against voltage surges/lightning strikes, usage of appropriate surge
protectors is advised. Any damages resulting from surges are not eligible for service repairs.
2.3 Cameras mounting
To mount a camera please follow the instructions below:
1. Drill the screw holes and the cable hole on the wall according to the drill template.
2. Route the cables to the cable hole and connect the cables.
3. Using included screws mounting base on smooth surface providing declared degree of IP protection.
4. Optionally open service compartment to insert SD card and connect monitor through DCIN/CVBS
cables.
5. Using allen key loosen screws 1, 2 and 3. Then adjust camera position and tight lock screws.
CAUTION!!!
The declared degree of protection of the camera relates to its housing and does not take into
account the possibility of moisture infiltration into the interior of the camera by connecting
cables. Connection cables protection through i.e. sealing up is the responsibility of the camera
installer. The manufacturer is not liable for any damages to the camera caused as a result of
failing in performing that activity by installer, which also means that camera damaged in that
START-UP AND INITIAL CAMERA CONFIGURATION
12 VDC +
GND
Power Supply Scheme12 VDC
1 2 3

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
10
2.4. Starting the IP camera
To run NOVUS IP camera you have to connect ethernet cable between camera and network switch.
To power it up you can connect it directly via power supply adapter with parameters compatible with
camera power supply specification, or camera can be powered with PoE (IEEE 802.3af ) compatible
switch.
After connecting power supply it takes about 30 seconds to start camera. Then You can proceed to
connect to the camera via web browser.
The recommended way to start an IP camera and perform its configuration is a connection directly
to the network switch which is not connected to other devices. To obtain further information about
network configuration parameters (IP address, gateway, network mask, etc.) please contact your
network administrator.
 Connection utilising network switch with PoE support
 Connection utilising external power supply and network switch
START-UP AND INITIAL CAMERA CONFIGURATION
IP Camera
Network transmission
Network Switch Computer
Network transmission
Power supply and
network transmission
Computer
IP Camera
Network Switch
PoE
Network transmission

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
11
 Connection utilising external power supply directly to the computer
Information:
Power supply adapter is not included. Please use power adapter with parameters specified in user ‘s
manual.
Caution:
In order to provide protection against voltage surges/lightning strikes, usage of appropriate surge
protectors is advised. Any damages resulting from surges are not eligible for service repairs.
2.5. Initial configuration via the web browser
The default network settings for NVIP-4DN3552AH/IR-1P… IP camera series are :
1. IP address= 192.168.1.200
2. Network mask - 255.255.255.0
3. Gateway - 192.168.1.1
4. User name - root
5. Password - pass
Knowing the camera’s IP address you need to appropriately set PC IP address, so the two devices can
operate in one network subnet ( e.g. for IP 192.168.1.1, appropriate address for the camera ranges from
192.168.1.2 to 192.168.1.254, for example 192.168.1.60). It is not allowed to set the same addresses for
camera and PC computer
You can either set a network configuration (IP address, gateway, net mask, etc.) of NOVUS IP camera
yourself or select DHCP mode (DHCP server is required in this method in target network) by using
web browser or by NMS software. When you use DHCP server check IP address lease and its linking
with camera MAC address to avoid changing or losing IP address during device operation or network/
DHCP server breakdown. You have to remember to use a new camera IP address after changing
network parameters.
After network setting configuration has been done, the camera can be connected to a target network.
START-UP AND INITIAL CAMERA CONFIGURATION
IP Camera
Network transmission - cross over cable
Computer

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
12
2.6. Security recommendations for network architecture and configuration
WARNING!
Below are shown security recommendations for network architecture and configuration
of CCTV systems that are connected to the Internet to reduce the risk
of unauthorized interference with the system by a third party.
1. Absolutely change the default passwords and user names (if the device gives this possibility) of
all applied network devices (recorders, cameras, routers, network switches, etc.) to the
severely complexity password. Use lowercase and uppercase letters, numbers, and special characters
if there is such possibility.
2. Depending on the available functionality in the order to restrict access to the used network devices at
the administrator account level, it is recommended to configure the users accounts accordingly.
3. Do not use DMZ function (Demilitarized zone) in your router. Using that function you open the
access to recorder system from the Internet on all ports, which gives possibility for an unauthorized
interference with the system.
Instead of DMZ use port forwarding redirect only the ports which are necessary for the performance
of the connection (detailed information about ports of communication in different models of recorders,
cameras, etc. can be found in the operating instructions).
4. Use routers with firewall function and make sure it is enabled and properly configured.
5. It is recommended to change the default network communication port numbers of used devices
if there is such possibility.
6. If used network devices has a UPnP feature and it is not used, turn it off.
7. If used network devices has a P2P feature and it is not used, turn it off.
8. If used network devices support HTTPS protocol for connection, it is recommended to use it.
9. If used network devices support IP filtering for authorized connections function, it is recommended
to use it.
10. If used recorder has two network interfaces it is recommended to use both of them to physically
separate network for cameras and network for Internet connection. The only device in the system,
accessible from Internet will be recorder - there will be no physically access directly to any camera.
START-UP AND INITIAL CAMERA CONFIGURATION

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
13
3. NETWORK CONNECTION UTILIZING WEB BROSWER
3.1. Recommended PC specification for web browser connections
Requirements below apply to connection with an IP camera, assuming smooth image display
in 1920x1080 resolution and 25 fps speed.
1. CPU Intel Core i3 3 GHz or newer
2. RAM Memory min. 4 GB
3. VGA card (any displaying Direct 3D with min. 128 MB RAM memory)
4. OS Windows 7/8/8.1/10
5. Network card 100/1000 Mb/s
3.2. Connection with IP camera via web browser
You have to enter camera IP address in the address bar. When you connect to the camera, web browser
will download the applet for displaying images from the camera. In Internet Explorer it may be
necessary to accept an ActiveX control. To do this, click the right mouse button on the message, select
"Install Active X control" and then click Install. After successfully NetIPCamera plug in downloading
run and install it on a computer.
NETWORK CONNECTION UTILIZING WEB BROWSER

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
14
NETWORK CONNECTION UTILIZING WEB BROWSER
If the installation fails, changing security settings for the IE browser is required. In order to do that,
please choose: Tools > Internet options > Security tab > Custom level and:
 Under Download unsigned ActiveX controls - select either Enable or Prompt
 Under Initialize and script ActiveX controls not marked as safe - select Enable or Prompt
You can also add the camera’s IP address to “trusted zone” and set lowest security level for it.
In addition, when working in Windows Vista/7 the ActiveX applet may be blocked by Windows
Defender or User account control. In such case you should allow to run this applet, or simply disable
these functions.
After successful installation login window will be displayed. Default user is root and default password
is pass. For safety reasons, it is recommended to change default user name and password.
WARNING !!! If user forgets login and/or password for IP Camera, it is required to sent
IP Camera back to supplier. In this case, it is not possible for user to restore IP Camera factory
defaults on his own.

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
15
USING AND CONFIGURING
4. USING AND CONFIGURING
4.1 The Remote Preview Interface
1. View settings
Original size Automatic Size
Fill screen Full Screen
2. Camera functions
Live View On/Off Take a snapshoot
On/Off Sound Record Video
PTZ panel – unavailable
3. Motion detection
Motion detection Color change Clarity change Scene change
4. Camera buffer
There is three possible options of view: REAL-TIME, BALANCED, FLUENT
1 2
3
4
Zoom In/out (digital)
Lens Control

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
16
4.2 Focus and Zoom Settings
Camera got build in panel that allow user to set Zoom and Focus Value
Zoom Out
Zoom In
Focus -
Focus +
One key focus
Auto Zoom Menu On/Off
5. ELECTRIC CONNECTORS AND ACCESORIES
 5.1 Camera control - RS-485
Function unavailable.
5.2. Connecting alarm inputs/outputs.
Alarm input
 Alarm input connection
REMOTE PREVIEW
Alarm
input (-)
Alarm GND
IP Camera
Alarm
input (+)
Alarm IN
Switch/sensor

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
17
CONNECTORS AND ACCESORIES
Alarm output
Camera alarm output is an relay output type.
 Alarm output electric connections
5.4 SD card installation
Camera supports SD/SDHC cards up to a maximum size of 128GB. In order to install the card
properly, please follow the instructions below:
 Turn the camera off
 Remove front cover to get access to internal connectors
 Mount micro SD card, according to the picture:
 Close front cover
 Turn the camera on
 Check the SD card by checking its capacity in the “System Config” -> “SD Card” tab.
Alarm
Output (-)
Alarm COM
Alarm
Output (+)
Alarm NO
Indicator
power
supply
Indicator
IP Camera
Złącze karty SD

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
18
RESTORING FACTORY DEFAULTS
6. RESTORING FACTORY DEFAULTS
NOVUS IP cameras allow to restore defaults via:
 software (web browser level)
 hardware (using reset button)
6.1. Restoring factory defaults by software means
User can restore default settings of the IP camera except network settings. To restore to default settings
go to: “Advanced Config -> Config Backup & Restore” tab. Process of restoring takes about two
minutes.
6.2. Restoring factory defaults by hardware means
In order to restore factory defaults for the camera please follow the instructions:
 Remove front cover to get access to internal connectors
 Press the RESET button and hold on for 10 seconds
 Release button
 Close front cover off the camera
 Log on after approx. 30 seconds using default IP address (http://192.168.1.200) and default user
name (root) and password (pass)
Przycisk RESET

NVIP-4DN3552AH/IR-1P - User’s manual (short form) ver 1.0
All rights reserved © AAT Holding S.A.
19
NOTES
NOTES

2018-01-10 MF, MK ver. 1.0
AAT Holding S.A., ul. Puławska 431, 02-801 Warszawa, Polska
tel.: [phone], faks: 22 546 07 59
www.novuscctv.com
