NSL LED Neon Flex Manual

LED
Neon Flex
NFLX-XX-YY
Applications:
• Building outlines
• Stairway and aisle lighting
• Signs
• Decks
• Pathway Lighting
• Billboards
• Highlighting architectural features
D) Insert the joined pieces into the aluminum base of the
connector.
E) Apply silicone glue on top of the joined pieces, and on the
connector’s clear cover.
F) Place the clear cover on top of the assembly, and tighten
the screws. Wipe the excess of silicone with a clean towel.
NOTE: for installation of L, and T type connectors, please
follow the same procedure outlined above.
INSTALLATION GUIDE
INDOOR/OUTDOOR DIMMABLE DRIVERS
TRE24L40DC
• Max recommended load 36W, min 8W
• 6.77” x 2.67” x 1.26” (171 x 68 x 32mm)
TRE24L96DC
• Max recommended load 90W, min 8W
• 6.77” x 2.67” x 1.26” (171 x 68 x 32mm)
NON-DIMMABLE DRIVERS
LEDDR-24-120W (Indoor/Outdoor Driver)
• Max recommended load:
90W per single tap
120W combined two secondary taps
• 120W hardwire
• Input: 100-240V AC
• Output: 24V DC
• 10” x 3 3/8” x 3 3/16” (254 x 85.7 x 80.9mm)
NON-DIMMABLE PLUG-IN DRIVERS
LMS-24-18W and LMS-24-60W
ACCESSORIES
NFLX-CONKIT-6FT
(Power feed connector, 6FT)
NFLX-ENDS
(End cap)
NFLX-CLIPS
(Mounting clips)
NFLX-CHANNEL
(Aluminum mounting
channel 1M [3.28FT])
NFLX-L-SPLICE
(L splice connector)
NFLX-SPLICE
(In-line splice connector)
NFLX-T-SPLICE
(T splice connector)
NFLX-JUMP
(Jumper connector, 15CM [6in])
NFLX-PINS
(Single color pins)
www.nslusa.com

WARNING: Risk of re and electric shock
1. Do not cover this product as covering may cause cause the
exible light to overheat and melt or ignite.
2. Do not operate the exible light tightly coiled.
3. Do not route the cord or exible light through walls, ceiling,
doors, windows or any like part of the building structure.
4. Do not submerge exible light in liquids or use the product in
the vicinity of standing water.
5. Do not use if there is any damage to the exible light or cord
insulation.
6. Do not secure the cord or the exible light with staples, nails or
like means that may damage the insulation.
7. Do not install on gates or doors, where subject to exing.
8. Do not install in cabinets, tanks or enclosures of any kind.
FOR OUTDOOR INSTALLATIONS:
9. Ground Fault Circuit Interrupter (GFCI) protection should be
provided on the circuit or outlet.
10. All 120V electrical connections should be carried out by a
qualied electrician.
11. Products should be installed in accordance to these
instructions, current building codes, current Canadian Electrical
Code, or National Electrical Code.
WARNING
DO NOT modify this xture. Any modications may render the
product unsafe and void warranty.
R50mm
15mm
26.5mm
IMPORTANT: Read all instructions in order to
ensure safety and proper installation.
INSTALLATION GUIDE
1. CONNECTING NEON FLEX TO POWER
Neon Flex runs on 24V DC power supply. Use only pow-
er supplies from NSL approved for use with Neon Flex.
Use only extension cords and power cords provided by
NSL. Make sure all the end caps and connections are rmly
seated to preclude the entry of water.
A) Cut Neon Flex to desired length at the cutting marks, using
a sharp knife or cable cutters.
NOTE: Neon Flex is cuttable every 4”. Cutting anywhere
else, will damage the product.
B) Holding the smooth side of the power pins with a pair of
pliers, line up the barbed side of the pins with the two wires
of the exible light. Push barbed pins into the Neon Flex,
making sure to make solid contact with internal wires.
C) Apply silicone glue inside the connector sheath, then push
the cord sheath onto the assembly until fully seated. Wipe
any excess of glue, using a clean towel.
D) Apply silicone glue inside the end cap.
E) Attach the end cap to cover the dead end of the exible
light. Wipe the excess silicone with a dry towel.
F) Leave the assembly to dry for several hours.
G) Connect wires from connector to low voltage power
supply. Connect black wire to (+) and white wire to (-).
H) Connect power supply to main power.
NOTE: 120V connections to power supply should be
carried out by a qualied electrician.
2. JOINING 2 PIECES OF NEON FLEX
TOGETHER USING IN-LINE CONNECTORS
CAUTION: When joining two pieces of Neon Flex
together, make sure combined lengths do not exceed
100W in power consumption. Do not exceed rated
wattage of the power supply.
A) Line up the barbed pins with with the internal wires of
the exible light and push the pins into the light, making
sure to make solid contact with the internal wires.
B) Repeat the procedure for the other cut length to be
joined.
C) Apply silicone glue on the aluminum base of the
connector.
INSTALLATION GUIDE
Limited Warranty The warranty applies to the product from the original date of purchase for three (3) years against manufacturing defects. The owner must provide a copy of the
original proof of purchase. The manufacturer’s obligation under this warranty is limited to repairing or replacing the component. It is not related in any way to the cost of connection, the
installation of the replacement parts or cost of transport.
3
WARNING
DO NOT twist, hang vertically, suspend unsupported in the middle
or bend along short side.
A, B C D
EEF
