NTS POLARIS User manual

NTS Remotes
continued on back...
POLARIS REMOTE CONTROL
Use SETUP for all programming sequences.
To turn on your television or set-top box, press TV or CBL once.
Press REC twice to activate recording.
MENU displays your DTV screen menu.
INFO displays current channel and program information.
Use SELECT/OK as ENTER for ordering PPV events, and to tune
programs from the program guide.
ARROW keys move the cursor in the program guide and menu
screens.
Use EXIT to exit out of any menu or guide display.
GUIDE displays the program guide and other tabs with channel
groupings (Subscribed, All, Favorites, HD and PPV).
Use CH+/- to select the next higher (or lower) channel.
MUTE turns sound off or on.
VOL +/- raises (or lowers) the sound volume.
PAGE +/- moves up (or down) through menu screens and the
program guide.
DAY +/- moves a day forward (or back) on your DTV program
guide.
Use the keypad (0-9) to directly select channels.
TITAN REMOTE CONTROL
Press POWER once to turn on or off selected devices.
Use SETUP for all programming sequences.
Press AUD, DVD, AUD, TV, or STB to select a device to control.
SKIP BACK instantly replays the last 7 seconds of your program.
Press LIVE to return to watching LIVE TV.
These keys to control playback on your DVD player or DVR.
GUIDE displays the program guide. MENU displays the options
menu. INFO displays the current channel and program information.
EXIT directly exits menus, guides, and applications.
PAGE+/- pages up (or down) menu screens and program guide.
Arrow keys move the cursor and navigate the program guide.
OK & ENTER select PPV events, and select programs on the guide
CH+/- selects the next higher (or lower) channel.
DAY+/- moves a day forward (or back) on your program guide.
VOL+/- raises (or lower) the volume.
FAV cycles through your favorite channels.
MUTE turns sound off; press again to turn sound back on.
Use the keypad numbers (1-9, and 0) to directly tune channels.
TO PROGRAM YOUR REMOTE
1. Turn the device (TV) on.
2. Press TV button (blinks twice).
3. Press and hold the SETUP (TV LED blinks
twice).
4. Press 9-9-1 (TV LED blinks twice again).
5. Press and release the CH+ over and over
slowly until the TV turns off. (Do Not press
the CH+ again or you will advance the
code).
6. When the device turns off, press SETUP
(TV button will blink twice). Done.
TO TROUBLESHOOT
1. Press CBL button.
2. Power cycle the set-top box.
3. Make sure there are no obstructions
between the remote and set-top box.
4. Replace the remote’s batteries.
5. Replace the remote.
TO PROGRAM YOUR REMOTE
1. Turn the device (TV) on.
2. Press the device key you wish to
program (AUD, DVD, AUD, TV or STB).
3. Press and hold the SETUP (LED blinks
twice).
4. Press 9-9-1 (LED blinks twice).
5. Designate device: press 1 for TV,2 for
DVD/VCR,3 or AUD.
6. Press the POWER key.
7. Press and release the CH+ over and over
slowly until the TV turns off. (Do Not press
the CH+ again or you will advance the
code).
8. When the device turns off, press SETUP
(device button will blink twice). Done.
TO TROUBLESHOOT
1. Press CBL/STB button.
2. Power cycle the set-top box.
3. Make sure there are no obstructions
between the remote and set-top box.
4. Replace the remote’s batteries.
5. Replace the remote.

R
C
U
S
E
T
U
P
V
I
E
W
L
I
V
E
T
V
VOD
MENU
GUID
EE
XIT
TV
AUDDVDAUX
STB
MASTER POWER
DVR
LIST
R
CH
MUTE LAST
NETWORK
MY MEDIA
INPUT
TV/VIDEO
WWW
MOVESWAPPIP
SAP
PHONE
CC
123
abcdef
4
7
5
8
0
6
9
*#
jklgh
im
no
tuvpqrs
DEL
wxyz
VOL
DAYPG DAY
POWER
OK
INFO
TV DVD
STB
AV SETUP
SHIFT
2ABC
5JKL
8TUV
4GHI
7PQRS
CC
OK
++
--
0_
3DEF
6MNO
9WXY
VOL PG CH
GUIDE
RECALL
MENU
BACK EXIT
INFO
1_
ADB POTENZA REMOTE CONTROL
Press AUX, DVD, AUD, TV, or STB to select a device to control.
POWER turns on or off the selected component.
These keys to control playback on your DVD player or DVR.
These keys to control playback on your DVD player or DVR.
MENU displays the settings menu. INFO displays current channel
and program information.
ARROW KEYS move the cursor in the on-screen guides.
OK makes a selection or choose options on the program guide.
GUIDE displays the program guide. EXIT will exit out of the menu,
guide or any function.
PAGE +/- scrolls through menu screens and the program guide.
DAY+/- moves a day forward (or back) on your program guide.
VOL+/- raises (or lowers) the sound volume.
CH+/- select the next higher (or lower) channel or in the guide
these buttons will allow you to page up and down.
MUTE button will shut off sound on the TV.
LAST recalls the last channel and will page back one screen in
the main menu. Pushing Last again and again will let you go
back and forth between the last two channels that were viewed.
Use the NUMBER KEY PAD (0-9) to directly select channels.
CLOSED CAPTION is for turning the closed captioning on and
off. However, this does depend on the TV, channel, and
programming for availability.
TV/VIDEO INPUT switches the mode between TV or Video.
ADB SILVER REMOTE CONTROL
Press TV, DVD, or STB to select a device to control.
Use SETUP for all programming sequences.
POWER turns on or off the selected component.
Use the NUMBER KEY PAD (0-9) to directly select channels.
MUTE button will shut off sound on the TV.
VOL+/- raises (or lowers) the sound volume.
PG+/- or CH+/- select the next higher (or lower) channel or in the
guide these buttons will allow you to page up and down.
GUIDE displays the program guide. EXIT will exit out of the menu,
guide or any function.
MENU displays the settings menu. INFO displays current channel
and program information.
ARROW KEYS move the cursor in the on-screen guides.
OK makes a selection or choose options on the program guide.
BACK recalls the last channel and will page back one screen
in the main menu. Pushing Last again and again will let you go
back and forth between the last two channels that were viewed.
EXIT directly exits menus, guides, and applications.
These keys to control playback on your DVD player or DVR.
TO PROGRAM YOUR REMOTE
1. Press and release the TV button.
2. Press and hold the RCU SETUP until the TV
button blinks twice.
3. Enter in 9-9-1 and the TV button will blink
twice.
4. Aim the remote at the TV and press and
release the POWER button.
5. Press and release the CH+ over and over
slowly until the TV turns off. (Do Not press
the CH+ again or you will advance the
code).
6. Press the POWER button to turn the TV on.
(If the TV did not turn on, press CH- once
and try again.)
7. Press the RCU SETUP button to store the
code for the TV. The TV button will blink
twice. The remote is now ready to
operate the TV.
TO TROUBLESHOOT
1. Press STB button.
2. Power cycle the set-top box.
3. Make sure there are no obstructions
between the remote and set-top box.
4. Replace the remote’s batteries.
5. Replace the remote.
TO PROGRAM YOUR REMOTE
1. Make sure your TV is on.
2. Press the TV key on the remote.
3. Press and hold down SHIFT key until the
red light blinks twice.
4. Press 9-9-1. The red light will blink twice.
5. Aim the remote at your TV and press
CH+ over and over slowly until the TV turns
off.
6. Once the TV shuts off, press SHIFT key to
save the code.
TO TROUBLESHOOT
1. Press STB button.
2. Power cycle the set-top box.
3. Make sure there are no obstructions
between the remote and set-top box.
4. Replace the remote’s batteries.
5. Replace the remote.

AB
C
TV INPUT SET UP
POWER
TV DVD AUX STB
SKIPREPLAY
DAY
RECORDINGS
BACK
P
L
A
Y
P
A
U
S
E
S
T
O
P
F
W
D
O
N
D
E
M
A
N
D
R
W
D
R
E
C
O
R
D
MENU
GUIDE
LAST
MUTE
OK
DVR
EXIT
INFO
+
-
VOL
+
-
CH
abc
123
456
789
DELETE
TEXT/CC MY MEDIA SAP
0ENTER
def
mno
wxyztuv
jkl
ghi
pqrs
*
TV
STB
Rewind Play Pause Fast-Fwd
Record Pg Up Pg Down Stop
Refresh Pg Back Pg Fwd Home
symbol
123
456
789
0
abc def
ghi jkl mno
pqrs tuv wxyz
Delete Aa
MUTE
MENU
OK
LAST
CH
AV
VOL CH
++
--
ADB BLACK REMOTE CONTROL
POWER turns on or off the selected component.
These keys to control playback on your DVD player or DVR.
Press TV, DVD, AUX, or STB to select a device to control.
These keys to control playback on your DVD player or DVR.
MENU displays the settings menu. INFO displays current channel
and program information.
ARROW KEYS move the cursor in the on-screen guides.
OK makes a selection or choose options on the program guide.
GUIDE displays the program guide. EXIT will exit out of the menu,
guide or any function.
VOL+/- raises (or lowers) the sound volume.
CH+/- select the next higher (or lower) channel or in the guide
these buttons will allow you to page up and down.
MUTE button will shut off sound on the TV.
Use the NUMBER KEY PAD (0-9) to directly select channels.
AMINO SILVER REMOTE CONTROL
POWER turns on or off the selected component.
Press TV or STB to select a device to control.
Use the NUMBER KEY PAD (0-9) to directly select channels.
MUTE button will shut off sound on the TV.
VOL+/- raises (or lowers) the sound volume.
CH+/- select the next higher (or lower) channel or in the guide
these buttons will allow you to page up and down.
ARROW KEYS move the cursor in the on-screen guides.
OK makes a selection or choose options on the program guide.
These keys to control playback on your DVD player or DVR.
TO PROGRAM YOUR REMOTE
1. Turn on all the devices you wish to control.
2. Press the mode key you want to program
(TV, DVD, AUX, or STB).
3. Press and hold SETUP until the
selected button blinks twice.
4. Enter 9-1-1. The mode LED should blink
twice.
5. Aim the remote control at the device
and press CH+ slowly until the device turns
off.
TO TROUBLESHOOT
1. Press STB button.
2. Power cycle the set-top box.
3. Make sure there are no obstructions
between the remote and set-top box.
4. Replace the remote’s batteries.
5. Replace the remote.
TO PROGRAM YOUR REMOTE
1. Find the 3-digit code for your device in the
Code List from the web link below.
(http://www.mintel.net/docs/
Aminoremotecodes.pdf.)
2. Make sure your TV is on
3. Simultaneously press and hold the TV and
OK buttons on the remote. The TV button
will light.
4. Release the TV and OK buttons (the TV
button remains illuminated.)
5. Now enter the 3-digit code for your TV
6. When the third digit has been entered, the
TV button will go out and the remote is
ready to operate your TV.
TO TROUBLESHOOT
1. Press STB button.
2. Power cycle the set-top box.
3. Make sure there are no obstructions
between the remote and set-top box.
4. Replace the remote’s batteries.
5. Replace the remote.
