Nu-Flame EMOTIVO User manual

EMOTIVO
Instructions for use and safety
READ CAREFULLY BEFORE USE
Please store these safety warnings in a safe place for future reference.
NOTICE: BUYER ASSUMES ALL RESPONSIBILITY FOR
SAFETY AND USE THAT IS NOT IN ACCORDANCE WITH
INSTRUCTIONS AND WARNINGS.
We all understand fire is dangerous but for many years it has been safely used and enjoyed when
properly handled. To insure your safety and enjoyment we provide a safety manual that explains
the correct use of your Nu-Flame fireplace and the basic risk of using the product. It is the sole
responsibility of the consumer of any product sold by Bluworld® or its resellers to obtain proper
instruction from the safety manual and to always act safely, wisely and with caution while using
our products.
Failure to follow these instructions could result in property damage, bodily injury or even death.

SETUP INSTRUCTIONS FOR EMOTIVO
Read and Understand the entire Nu-Flame Manual prior to use.
Make certain to inspect the package thoroughly. Carefully remove and unwrap your Nu-Flame
fireplace.
Your fireplace will have the following components:
1. Fireplace
2. Burner
3. Safety Mounting Bracket (3 pieces)
4. Hardware Bag
5. Snuffer Tool
You may wish to purchase a funnel for pouring fuel into the burner
Mark on your wall exactly where you wish to
hang the fireplace using the overall height and
width. Once you are satisfied with the
placement make a mark on the wall 8.5” down
from the very top of where you want the
fireplace to be mounted. This is where the
bottom of the horizontal mounting bracket will
sit.
Using a level draw a line horizontally on the
mark you just made.
Take the horizontal mounting
bracket piece (piece with tabs
at top) and place it on the level
line you drew. Mark the holes
with a pencil and remove the
bracket. Using a ¼” drill bit, drill
the holes you just marked. Take
the white plastic anchor and tap
one into each drilled hole using
a hammer. Make certain the
anchor is flush with the wall.

Place the horizontal bracket on the wall in line
with the anchors and using the anchor screws
secure and tighten the bracket to the wall.
Hang the vertical brackets off each tab on the
horizontal bracket. Using a level, level each side
bracket and mark the holes.
Remove the bracket and drill
the newly marked holes. Tap
into each hole one plastic wall
anchor.
Replace the vertical brackets and using the
anchor screws secure and tighten each vertical
bracket to the wall. Your fireplace is now ready
to be mounted.

Line up the tabs on the horizontal mounting
bracket with the two mounting cutouts located
on the back of the backer. Lift the fireplace into
position and make certain the tabs are locked
into the mounting holes and the unit is seated
securely on the wall. The tabs on the vertical
bracket will sit under the backer.
Place the burner cup into the burner holder,
Make certain the burner is well seated and
sitting level.
Screw in the two smallest screws to secure the
unit to the wall. These screws have one small
washer each. Align the vertical mounting tabs
at the bottom of the fireplace with the screw
holes, thread and tighten the screws to secure.
The burner is filled with a high heat ceramic fiber. Do not remove the ceramic fiber from inside the burner.
Use only a recommended Ventless Fireplace Fuel like “Nu-Flame Bio-Ethanol Fuel”. Make certain the
sliding dampener on the burner slides easily back and forth and is completely open prior to filling. Make
certain the burner is clean and free of dirt or packing debris. Pour fuel into the burner using a funnel. The
burner should be no more than 2/3 full. DO NOT OVERFILL. Wipe up any spilled fuel. Use a long match or
extended lighter to ignite the fuel.
Use the included snuffer tool to extinguish the fire.
CAUTION: The flame starts out slowly. Please allow 15 minutes to reach the optimum
temperature and flame height. DO NOT ASSUME THE FUEL DID NOT IGNITE. Follow the refilling
instructions in this manual.

First-Time Use Instructions
Your Nu-Flame Fireplace is for decorative purposes only and not suitable for continuous operation.
Do not use the Fire to heat or boil water or as a cooking appliance. Do not put wood, charcoal, paper or other
combustible objects into the Fire.
1. PLACEMENT OF NU-FLAME FIREPLACE: This fireplace will use oxygen from the air inside the room where it is
operated. The rooms should be well ventilated with enough oxygen and fresh air being supplied (i.e. slightly open
windows if room is not vented). When ventilated, the room where the fireplace is operated in should not be
smaller than 215sq.ft. (to calculate the square footage of a room multiply the width x length. For example, If the
room is 15’ wide x 16’ long then 15’ x 16’ =240 sq.ft.) Freestanding and tabletop units must be placed on a safe,
level, stable, non-flammable area and 12” from glass windows or mirrors. Wall mounted fireplaces must be
installed on a flat, solid, sturdy wall with non-flammable wall covering in accordance with the enclosed
instructions and at least 60” from drapery.
2. OPERATION: Check that the burner’s slider/dampener is free from obstruction and operating smoothly (closing
and opening fully). This feature is not available on units with cup burners.
3. FUEL: Read Fuel Bottle label before use. Use only approved ethanol fuel. We recommend “Nu-Flame Bio-Ethanol
Fuel”. USE EXTREME CAUTION! - DANGER FLAMMABLE/IRRITANT Ethanol Fuel is a Class 3 flammable liquid and
presents real danger when not used in direct compliance with all Instructions and safety warnings. KEEP FUEL
OUT OF REACH OF CHILDREN AND PETS
4. POURING: Slowly pour fuel into clean burner or burner cup that is COOL TO THE TOUCH. Use a funnel to fill linear
burners. Fill burner or cup no more than 2/3 full. Don’t overfill or allow fuel to touch anything other than the
inside of the burner or cup. Clean any spills with water before lighting. Replace cap on bottle and place bottle 5
feet or more away from the fireplace before lighting. Store fuel bottles in cool dry space. Do not store in direct
sunlight or allow fuel to become heated. CAUTION: Spilled alcohol may mar or stain flooring or furniture.
5. LIGHTING: Use long match or extended lighter to light fuel. CAUTION: The flame starts out slowly. Please allow 15
minutes to reach the optimum temperature and flame height. DO NOT ASSUME THE FUEL DID NOT IGNITE.
6. BURNING: DO NOT MOVE OR TOUCH FIREPLACE WHEN LIT OR HEAT IS PRESENT. UNIT WILL BE VERY HOT. NEVER
LEAVE A BURNING OR HOT FIREPLACE UNATTENDED. KEEP AWAY FROM CHILDREN AND PETS; THIS IS NOT
INTENDED FOR CHILDREN. NEVER ALLOW THEM TO LIGHT OR EXTINGUISH A FLAME.
7. EXTINGUISHING: To extinguish the flame, only use the snuffer tool that came with your Nu-Flame fireplace or use
the slider/dampener tool to close the burner. DO NOT BLOW OUT FLAME or attempt to extinguish with water.
Snuff for 20 seconds or longer. DO NOT ASSUME FLAME IS OUT BECAUSE YOU CANNOT SEE IT.

Relighting & Refilling
WARNING: DO NOT ATTEMPT TO ADD
FUEL TO BURNER OR BURNER CUP IF
FLAME IS PRESENT OR BURNER/CUP
IS HOT, THIS MAY CAUSE A FLASH
FIRE AND SEVERE BURNS.
FLAME MAY BE NEARLY INVISIBLE:
APPROACH FIRE WITH CAUTION.
Always follow shut-off procedure before refueling
1. SHUT BURNER OFF WITH DAMPENER/SLIDER OR PROVIDED SNUFFER TOOL FOR CUPS OR ALLOW FUEL TO
BURN OUT COMPLETELY. ALLOW 30 MINUTES FOR UNIT TO COOL BEFORE REFUELING.
WAIT FOR THE FIREPLACE AND BURNER/CUP TO COOL TO ROOM TEMPERATURE. FLAME MAY BE DIFFICULT TO
SEE - DO NOT ASSUME THE UNIT IS OFF. MAKE SURE THAT THE FLAME IS OUT AND NO HEAT IS PRESENT!
CAREFULLY REFILL BURNER OR CUP NO NORE THAN 2/3 FULL. DO NOT OVERFILL.
2. Light with long match or extended lighter. CAUTION: The flame starts out slowly. DO NOT ASSUME THE FUEL DID
NOT IGNITE.
3. Never leave a burning or hot fireplace unattended. KEEP AWAY FROM CHILDREN AND PETS; THIS IS NOT
INTENDED FOR CHILDREN. NEVER ALLOW THEM TO LIGHT OR EXTINGUISH A FLAME.
4. Ethanol Fuel, when not used correctly and safely can cause serious burns, destruction of property, or even death.
Leftover fuel should be disposed of. Dispose unused fuel content and empty bottles in accordance with local
regulations for hazardous materials.
WARNINGS!
•Never leave a burning or hot fireplace unattended.
•Do not operate in a room with oxygen tanks in use or
if flammable vapors are present.
•Do not burn in a confined space, the flame
consumes oxygen.
•Glass will be hot when lit and for some time after
extinguishing, do not touch glass surface. Due to
high surface temperatures keep children, pets,
clothing, drapery and furniture away from the unit.
•Do not obstruct or inhibit flame.
•Do not use for cooking purposes.
•Allow fireplace to cool before touching or moving.
•Exercise the same precautions as you would an
open fire.
•Keep away from children and pets. This is not
intended for children.
•In case of emergency Dial 911. Extinguish fire with approved fire extinguisher.
