Nugens NC-A24P User manual

All-in-One PC
Model:NC-A24P
User Manual

Getting Started
Specifications
To help you use your Nugens All-In-One PC, we have designed a set of guides:
First off, the Setup Guide helps you get started with setting up your PC.
The Quick Guide introduces you to the basic features and functions of your new PC.
For more on how your PC can help you to be more productive.
To start your All-in-One PC for the first time:
1. Press the power button on your All-in-One PC on the bottom left side of the screen. Wait for
a few minutes until the setup screen appears.
2. From the setup screen, pick your Region and Language.
3. Carefully read the License Terms, then select “I Accept”.
4. Follow the onscreen instructions to configure the following basic items: Personalize, Get
online, Settings, Your Account.
5. Once the setup process is completed, the start screen appears.
Display 23.8-Inch FHD IPS LED 1920*1080 (5ms）, 10-Point Multi-Touch Screen
Processor Intel Core i5-4200M (Dual Core, 3M Cache, 2.5GHz, with Turbo Boost up
to 3.1GHz, Intel HD Graphics 4600)
Memory DDR3 1600 8GB
Storage SSD 256GB (optional 512GB)
Network &
Communication
802.11 b/g/n/ac, Bluetooth 4.0
Webcam 3M CMOS
Built-in Devices
Built-in dual- stereo speakers
Interfaces/Ports
(Side)
UBS 2.0 x1, Type-C x1, SD Slot x1
Interfaces/Ports
(Bottom)
USB 3.0 x2, USB 2.0 x2, RJ45 Gigabit lan x1, Audio out x1, Mic in x1,
HDMI out x1, VGA out x1, Power DC in
Operating System Windows 10 PRO
Power Input
12V / 7A
Bundles
SmartScheduler Digital Signage Advertising Software,
Nugens CamSwitcherPro Video Tool Software,
Nugens Slim Type Wireless Keyboard and Mouse Set (Matte Black),

Power Button
Mic Input
USB 2.0 USB 2.0 TYPE-C
SD Slot
VGA Output Power
USB 3.0 HDMI Output
Webcam
Audio Output
LAN
The Power Button is located on bottom right of your All-In-One PC.

Shutting down (turning off) the computer
To turn the Power Off, do any of the following:
Use the Windows Shut Down Command: Click “Start” > “Power” then click “Shut Down”.
If you need to power down the computer for a short while, but don’t want to completely shut it
down, you can put it into Hibernate by pressing the power button.
You can also put the computer in sleep mode by pressing the sleep hotkey <Fn> + <F4>.
Although you can turn off the computer with the power button, the recommended
procedure is to use the Windows Shut Down Command.
Connecting Bluetooth devices
Before you can use a Bluetooth device, you must establish a Bluetooth connection.
1. Type “Bluetooth” in the Search Box, and then select “Bluetooth and other devices settings”.
2. Enable Bluetooth, if it is not already enabled.
3. Select “Add Bluetooth or other device”, and then in the “Add a device” dialog box, select
“Bluetooth”.
4. Select your device from the list, and then follow the on-screen instructions.
Dialy maintenance
Please pay attention to the following points during use:
• Do not expose the computer to direct sunlight.
• Do not place it near sources of heat, such as a radiator.
• Do not expose the computer to temperatures below 0º C (32º F) or above 50º C (122º F).
• Do not subject the computer to magnetic fields.
• Do not expose the computer to rain or moisture.
• Do not spill water or any liquid on the computer.
• Do not subject the computer to heavy shock or vibration.
• Do not expose the computer to dust or dirt.
• Never place the computer on uneven surfaces.
Turning Your PC Off or Sleep
Connecting Bluetooth Devices
Daily Maintenance

初次設定
技術規格
首次啟動電腦時，會出現一系列畫面指導您設定Windows 10操作系統。
1.按下位於右側邊框旁的電源按鈕，等待幾分鐘直到設置完成。
2.選擇您的地區和語言。
3.仔細閱讀許可條款，選擇我接受。
4.按照畫面上的說明設定以下基本項目：
*個性化
*網路
*設置
*你的帳戶
5.設定完成後，將顯示Windows 10桌面。
顯示器 23.8 inch FHD IPS LED 1920*1080（5ms）、10 點觸控
處理器 Intel Core i5-4200M (Dual Core, 3M Cache, 2.5GHz, with Turbo Boost up to
3.1GHz, Intel HD Graphics 4600)
記憶體 DDR3 1600 8GB
硬碟 SSD 256GB
無線網路 802.11 b/g/n/ac , Bluetooth 4.0
Webcam 300 萬畫素 CMOS
多媒體 內建立體音雙聲道喇叭
側邊介面 UBS 2.0*1、Type-C*1、SD Slot*1
底部介面 USB 3.0*2、USB 2.0*2、RJ45 Gigabit lan*1、Audio out*1、Mic in*1、HDMI
out*1、VGA out*1、Power DC in
作業系統 Windows 10 Pro（專業版）
電源供應 12V / 7A
贈品 Nugens 無線鍵盤滑鼠組(太空黑)、SmartScheduler 好好播智能廣告排程軟體、
Nugens CamSwitcherPro 視訊工具軟體

按下位於右側的電源開關，並進入作業系統。
Power Button
Mic Input
USB 2.0 USB 2.0 TYPE-C
SD Slot
VGA Output Power
USB 3.0 HDMI Output
Webcam
Audio Output
LAN

關閉電腦
“關機”是指將所有打開的程式關閉，包含操作系統，然後關閉電腦。
在以下任何一種情況下，請關閉電腦：
1.需要查看電腦內部零件時。（非原廠專業人員請勿自行拆卸主機）
2.當您有不正常連接到USB、視訊接口、耳機或麥克風插孔的外部硬體設備時。
3.長時間不使用電腦並與外部電源斷開連接時。
儘管可以使用電源按鈕關閉電腦，但強烈建議使用Windows關機功能。
連接藍芽設備
必須先建立藍芽連接，然後才能使用藍芽設備。
1.在任務欄搜索框中鍵入藍芽，然後選擇藍芽和其他設備設置。
2.啟用藍芽（如果尚未啟用）。
3.選擇新增藍芽或其他設備，然後在新增設備對話框中，選擇藍芽。
4.從列表中選擇您的設備，然後按照畫面上的說明進行操作。
日常維護
1.使用時請注意散熱，尤其要注意以下幾點：
● 請勿將陽光直射在電腦主機上。
● 請勿將電腦主機放在熱源附近。
● 使用過程中，請勿用其他物品擋住電腦主機的散熱孔。
2.請勿將水和其他液體灑在電腦主機上。如果意外發生，則應立即斷開電腦主機
的電源。
3.灰塵也不利於使用電腦主機，應定期（例如半年）清潔電腦主機。
4.避免在LCD螢幕表面上施加壓力，並避免用水擦拭LCD螢幕表面。
