Numark Party Mix Pro User manual

Confidential Numark Service Manual
Numark
Party Mix Pro
[NPA3]
Service Manual
v1.0
The information in this document contains privileged and confidential information. It is intended only for the use of
those authorized by Numark. If you are not the authorized, intended recipient, you are hereby notified that any review,
dissemination, distribution or duplication of this document is strictly prohibited. If you are not authorized, please
contact Numark and destroy all copies of this document. You may contact Numark at [e-mail].
© Copyright Numark
ATTENTION!
This document contains sensitive proprietary information.
All recipients must have a current non-disclosure agreement on file
with Numark.
Do not make illegal copies of this document.

Confidential Numark Service Manual
Preface
This document is intended to assist the service technician in the operation, maintenance and repair of the Numark
device. Together with the User Reference Manual, this document provides a complete description of the
functionality and serviceability of the Device. Any comments or suggestions you may have pertaining to the
document are welcome and encouraged.
Read This!
In addition to any purchase price that Numark may charge as consideration for Numark selling or otherwise
transferring this service manual (“Manual”) to you, if you are not a service and repair facility (“Service Center”)
authorized by Numark in writing to be an authorized Service Center, Numark sells or transfers the Manual to you on
the following terms and conditions:
Only Service Centers authorized by Numark in writing are authorized to perform service and repairs covered by an
Numark warranty (if any), and transfer of the Manual to you does not authorize you to be an authorized Service
Center. Therefore, if you perform, or if the Manual is used to perform, any service or repairs on any Numark
product or part thereof, any and all warranties of Numark as to that product and any service contract with
Numark for that product shall be voided and shall no longer apply for such product, even if your services or
repairs were done in accordance with the Manual.
All service or repairs done by you or with reference to the Manual shall be solely your responsibility, and Numark
shall have no liability for any such repairs or service work. All such service or repairs are performed at the sole
risk of the person performing the service or repairs. You agree that all such work will be performed in a
competent, professional and safe manner at all times and to indemnify and fully hold Numark and its successors
and assigns harmless in the event of any failure to so perform.
Your purchase of the Manual shall be for your own ultimate use and shall not be for purposes of resale or other
transfer.
As the owner of the copyright to the Manual, Numark does not give you the right to copy the Manual, and you agree
not to copy the Manual without the written authorization of Numark. Numark has no obligation to provide to you
any correction of, or supplement to, the Manual, or any new or superseding version thereof.
Numark shall have the right to refuse to sell or otherwise transfer repair parts or materials to you in its sole
discretion. You shall not use, sell or otherwise transfer spare or replacement parts supplied by Numark to you (i) to
repair or be used in products manufactured for or by third parties or (ii) to any third parties for any purpose.
You shall not make any warranties or guarantees with respect to the products of Numark or the use thereof on
behalf of Numark or in your own name.
The foregoing describes the entire understanding related to sale or transfer of the Manual to you, and no other
terms shall apply unless in a writing signed by an authorized representative of Numark.
All Trademarks are property of their respective companies.

Confidential Numark Service Manual
Warnings
TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE THIS PRODUCT TO WATER OR
MOISTURE.
The arrowhead symbol on a lightning flash inside a triangle is intended to alert the user to
the presence of uninsulated “dangerous voltage” within the enclosed product which may
be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point inside a triangle is intended to alert the user to the presence of
important operating, maintenance and servicing instructions in the literature which
accompanies the product.
REPAIR BY ANY PERSON OR ENTITY OTHER THAN AN AUTHORIZED NUMARK SERVICE CENTER
WILL VOID THE NUMARK WARRANTY.
PROVISION OF THIS MANUAL DOES NOT AUTHORIZE THE RECIPIENT TO COMPETE WITH ANY
NUMARK DISTRIBUTOR OR AUTHORIZED REPAIR SERVICE CENTER IN THE PROVISION OF REPAIR
SERVICES OR TO BE OR MAKE REPAIRS AS AN AUTHORIZED SERVICE CENTER.
ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED NUMARK SERVICE CENTER
SHALL BE SOLELY THE RESPONSIBILITY OF THAT ENTITY, AND NUMARK SHALL HAVE NO LIABILITY
TO THAT ENTITY OR TO ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.
Regarding the Power Supply Fuse
Caution: The product under service may employ the use of a replaceable fuse. Danger of
fire or electrocution if fuse is incorrectly replaced. Replace with only the same type or
equivalent type recommended by the equipment manufacturer.
Regarding the Internal Battery
Caution: The product under service may employ the use of a internal battery. Danger of
explosion if battery is incorrectly replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries according to the
manufacturer’s instruction.

Confidential Numark Service Manual
Safety Instructions
Carefully read the applicable items of the operating instructions and these safety suggestions before using this
product. Use extra care to follow the warnings written on the product itself and in the operating instructions. Keep
the operating instructions and safety suggestions for reference in the future.
1. Power Source. The product should only be connected to a power supply which is described either in the
operating instructions or in markings on the product.
2. Power Cord Protection. AC power supply cords should be placed such that no one is likely to step on the
cords and such that nothing will be placed on or against them.
3. Periods of Non-use. If the product is not used for any significant period of time, the product’s AC power supply
cord should be unplugged from the AC outlet.
4. Foreign Objects and Liquids. Take care not to allow liquids to spill or objects to fall into any openings of the
product.
5. Water or Moisture. The product should not be used near any water or in moisture.
6. Heat. Do not place the product near heat sources such as stoves, heat registers, radiators or other heat
producing equipment.
7. Ventilation. When installing the product, make sure that the product has adequate ventilation. Improperly
ventilating the product may cause overheating, which may damage the product.
8. Mounting. The product should only be used with a rack which the manufacturer recommends. The
combination of the product and rack should be moved carefully. Quick movements, excessive force or uneven
surfaces may overturn the combination which may damage the product and rack combination.
9. Cleaning. The product should only be cleaned as the manufacturer recommends.
10. Service. The user should only attempt the limited service or upkeep specifically described in the operating
instructions for the user. For any other service required, the product should be taken to an authorized service
center as described in the operating instructions.
11. Damage to the Product. Qualified service personnel should service the unit in certain situations including
without limitation when:
a. Liquid has spilled or objects have fallen into the product,
b. The product is exposed to water or excessive moisture,
c. The AC power supply plug or cord is damaged,
d. The product shows an inappropriate change in performance or does not operate normally, or
e. The enclosure of the product has been damaged.

Stage Part Number Part Name Specification Usage Location
..2 10520184 Snap ring E ring,T=0.5mm,V1.0 2
..2 30090009 Bundle line 2.5*120mm,Black 3
..2 30060079 Foam 50*150*5mm 4
..2 12030031 Rockerswitch AN-S331,RF-1003-BB4,BBG8E2L1T,no silkscreen 1
..2 13110033 switch power supply AN-T90034,16280,100-240VAC,50/60Hz,16.5VDC,4.1A 1
..2 16040913 Plug attachment AN-W4473,2P,18#,UL1007,220mm 1
..2 16040915 Plug attachment AN-W4475,2P,22#,UL1007,220mm 1
..2 16041047 Plug attachment AN-W4608,22#,UL1617,200mm 1
..2 16041078 Plug attachment AN-W4639,2P,18#,UL1007,250mm 1
..2 16060103 ground wire AN-W700,18#,UL1015,230mm 1
..2 20120017 Fader cap DN-PL2014,KGK-011A,V1.0 3
..2 20290083 Bracket DN-PB0076,ABS,,UL94V-2,black,ROHS,V1.0 3
..2 20410119 Button DN-PEB075,(3),ABS,,black,ROHS,V1.0 2
..2 20460013 Fixed buckle KY-CLT-2,94V-2,19.7*5.3*4.4 1
..2 20630094 Reflector ISP31-B,PC,Transparent,ROHS,V1.0 3
..2 20630129 Platter ABS,UL94-HB,80%,black,top silkscreen Pantone877Csilver,ROHS,V1.0 2
..2 30060095 Foam 10*1000*1mm,EVA1030,black 1
..2 30060452 Foam black,50*270*5mm,,V1.0 4
..2 30090002 Bundle line 2.5*80mm,black 9
..2 20580005 Washer vulcanized fibre,T=0.5mm,,V1.0 8
..2 30150178 Double Sided Adhesive Tape 3M9495,(2),141.5*33.0*0.1mm,,V1.0 1
..2 40010051 Powersupply socket AN-J0150,DB-14-2,0.8T,3P 1
..2 60100023 antenna 2.4G,2DBi,black,ROHS,L=280mm 1
..2 70010088 Full tooth screw Φ3*8mm,Crosshead D5.5mm ,black zinc,hardened 18
..2 70010605 Full tooth screw Φ2.6*7mm,Crosshead D4.5mm ,black zinc, hardened 6
..2 70010859 Full tooth screw Φ2*5mm,Crosshead D4.5mm ,black zinc,hardened 8
..2 70010893 Full tooth screw Φ3*10mm,Crosshead D9.5mm ,black zinc,hardened 4
..2 70010912 Full tooth screw
Φ3.0*12mm,Hexagonflathead,D6.0mm,Selftapping sharp tailed teeth,
black zinc,hardened
6
..2 CR011232 NPA3 AMP NPA3 AMP ASSY 1
..2 CR011234 NPA3 DJ Controller NPA3 DJ Controller ASSY 1
..2 CR011269 NPA3 PER(NEW) NPA3 PER(NEW) ASSY 1
..2 CR011271 NPA3 DLED NPA3 DLED ASSY 1
..2 DR001956 NK47 button with silkscreen ASSY DN-PC6704,(2),PC+Silicon,diffusers,UL94-HB,(1)silkscreen black,V1.0 2
..2 DR001957 NK47 button with silkscreen ASSY DN-PC6704,(2)PC+Silicon, diffusers,UL94-HB,(2)silkscreen black,V1.0 2
NPA3 Level One BOM

..2 DR001958 NK47 button with silkscreen ASSY DN-PC6705,(3),ABS,UL94-HB, ,black,(1)silkscreen white,V1.0 1
..2 DR001959 NK47 button with silkscreen ASSY DN-PC6705,(3),ABS,UL94-HB, ,black,(2)silkscreen white,V1.0 1
..2 DR001960 NK47 Fader cap with silkscreen ASSY DN-PL2013,ABS,UL94-HB,80%,black,silkscreen white,V1.0 2
..2 DR001961 NK47 button with silkscreen ASSY DN-PC6703,PC+Silicon, (1) diffusers,UL94-HB,silkscreen black,V1.0 2
..2 DR001993 NPA3 plate with silkscreen ASSY DN-PC1081,ABS(UL94V-2),80%,black,silkscreen Pantone White C,V1.0 1
..2 DR001994 NPA3 Top housing with silkscreen ASSY DN-PC2120,ABS,UL94-2,80%,silkscreen Pantone White C/RED032C,V1.0 1
..2 DR001995 NPA3 Lens with silkscreen ASSY
DN-PL1133,PC,T=0.8mm,Transparent,silkscreen Black C/White C/032
C,V1.0
1
..2 20110149 Lens DN-PL1117,V1.0 1
..2 16010449 Color FlatCable AN-W4320,7P,24#,UL1007,550mm 1 CN11 to CN1-A1
..2 30150163 Mesh cloth grey,329*304*0.3mm,V1.0 1
..2 30060227 Foam 12*1000*2.0mm,防火EVAE1030, ,black 0.6
..2 30060452 Foam black,50*270*5mm,,V1.0 3
..2 30090002 Bundle line 2.5*80mm,black 3
..2 30110004 Washer IPA76C,vulcanized fibre,T=1mm,Φ3.5*Φ12mm,ROHS.V1.0 8
..2 70010556 Full tooth screw Φ2.6*6mm,crosshead,D7.0mm ,black zinc,hardened 8
..2 70010605 Full tooth screw Φ2.6*7mm,Crosshead D4.5mm ,black zinc, hardened 16
..2 30060494 Foam EVA1030,black,10*5*2mm,,V1.0 8
..2 CR011089 IPA82 LED03 IPA82 LED03 ASSY 1
..2 CR011091 IPA82 LED01 IPA82 LED01 ASSY 1
..2 CR011093 IPA82 LED02 IPA82 LED02 ASSY 1
..2 10410204 Grille DN-ME5159,SPCC,T=1mm,V1.0 1
..2 30060452 Foam black,50*270*5mm,,V1.0 1
..2 30150179 Double Sided Adhesive Tape 3M9495,(1)74.4*16.4*0.1mm 1
..2 10520106 Castor JD180D 2
..2 16040502 Plug attachment AN-W4V3,2P,18#,UL1015,500mm,red and white 1
..2 16041152 Plug attachment AN-W4612,1P,16#,UL1015,600mm 1
..2 16041153 Plug attachment AN-W4613,1P,16#,UL1015,600mm,blue 1
..2 16141043 Multi core electronic wire 1P,22#,UL1007,L=350mm,black 1
..2 16141044 Multi core electronic wire 1P,22#,UL1007,L=350mm,brown 10mm 1
..2 17050074 Nonpolarity Electrolytic capacitor 6.8uF/50V,±10%,-40/+85℃,Φ6*17mm,black,川远 1
..2 20210165 Knob cap DN-PN2124,ABS(UL94-HB),,black,texture,ROHS,V1.0 1
..2 20210166 Knob cap DN-PN2125,KGK-012A,V1.0 9
..2 20210180 Knob cap DN-PN2137,KGK-012A,冷灰5C,V1.0 2
..2 20300115 Footpad TPU,80%,black,hardness 70°,表面蚀11010纹理,ROHS,V1.0 2
..2 20310041 beam DN-PE1025,TPU,black,hardness90A,ROHS,V1.0 8
..2 20320030 Handle DN-PE2030,ABS,80%,UL94V-2,black,ROHS,V1.0 2

..2 20330072 Badge DN-PE3060,ABS,UL94-2,black,V1.0 1
..2 20440026 Spacer column PC19-5,Φ6.5*6.95mm 4
..2 20660042 mound layer DN-PC6038,(1),ABS, ,black,MT11O20,Foam,V1.1 1
..2 20660043 mound layer DN-PC6037,(2),ABS, ,black,MT11020,Foam,V1.1 1
..2 20660044 mound layer DN-PC6036,(3),ABS, ,black,MT11020,Foam,V1.1 1
..2 21010604 Wooden box DN-X10247,MDF,T=9mm,CARB,V1.3 1
..2 22011245 Userguide NPA3,userguide ,V1.7 1
..2 22050006 desiccant 50g,Mineral desiccant,non-woven fabric,SGS 1
..2 22140017 Cue Card NK47,279*177mm,black and white print,matt,V1.2 1
..2 23010533 Package bag （290+390）*750*0.1mm, red print,punching,V1.1 1
..2 23010562 Package bag PE,120*280*0.06mm,punching,red print,V1.0 1
..2 23010563 Package bag PE,160*260*0.025mm,punching,red printV1.0 1
..2 23020328 polyfoam
NPA3,上,EPS,white,The foaming coefficient is 60
times,520*381*87.5mm,V1.1
1
..2 23020329 polyfoam NPA3,下,EPS,white,The foaming coefficientis 60
times,520*381*80mm,V1.1 1
..2 16150008 USB cable AN-W1506,28#,UL2725,1800mm 1
..2 23031485 Master carton A=A,T=6.0mm,552.5*409*556mm,black,V1.0 1
..2 23070029 PE foam LGA8,500*350*2mm,V1.0 2
..2 23090869 Giftbox 300G灰纸+C3+A3,T=6mm,532*381*529mm,colored 1
..2 30060079 Foam 50*150*5mm,black 3
..2 30060095 Foam 10*1000*1mm,EVA1030,black 1.2
..2 30060227 Foam 12*1000*2.0mm,防火EVAE1030, ,black 1.4
..2 30060336 Foam Foam-2,blackEVA1030,1000*8*0.5mm,,V1.0 1.67
..2 30060423 Foam EVA1030,black,288.5*6*1mm,T=1mm,V1.0 2
..2 30060424 Foam EVA1030,black,(2),315*6*1mm,V1.0 4
..2 30090009 Bundle line 2.5*120mm,black 5
..2 30150142 pull rod alufer,black,295*88mm,V1.0 1
..2 60190172 Battery AN-E1920,RT1290,12VDC,9Ah 1
..2 70010105 Full tooth screw
Φ3*10mm,,Cross flathead D6mm,Selftapping sharp tailed teeth,black
zinc,hardened
5
..2 70010151 Full tooth screw
Φ3*15mm,Crosshead D5.5mm,Selftapping sharp tailed teeth,black zinc,
hardened
12
..2 70010236 Full tooth screw
Φ4*16mm,Crosshead D7mm,Selftapping sharp tailed teeth,black zinc,
hardened
8
..2 70010237 Full tooth screw M4*16mm,Crosshead D9mm,Metric flat tooth pad, black zinc, hardened 4
..2 70010300 Full tooth screw
AN-C10300,M5*25mm,Crosshead D9mm,Metric toothmachine,black zinc,
hardened.
4
..2 70010691 Full tooth screw M4*26mm,Crosshead D8mm,Metric toothmachine,black zinc ,hardened 6

..2 70010848 Full tooth screw
Φ3.5*15mm,Hexagonflathead,D7mm,Selftapping sharp tailed teeth,
black zinc,hardened
35
..2 70010930 Full tooth screw
Φ3.5*18mm,Hexagonflathead,D7mm,Selftapping sharp tailed teeth,
black zinc,hardened
2
..2 70010855 Full tooth screw Φ4*25mm,D9mm,black,hardened 2
..2 70010912 Full tooth screw
Φ3.0*12mm,Hexagonflathead,D6.0mm,Selftapping sharp tailed teeth,
black zinc,hardened
6
..2 80130048 8" woofer AN-LD42,2ohm,50W 1
..2 80320006 3" tweeter AN-LX06,2ohm,10W,YA100F60CXB0210-02 1
..2 90021791 SN sticker NPA3,Black on white,55*15mm,V1.2 6
..2 90041754 Barcode sticker NPA3,Black on white,38*26mm,V1.1 2
..2 90060189 Compliance sticker NPA3,silver on black,170*50mm ,V1.0 1
..2 90080001 Destination sticker GA0/GA1/GA2,yellow background 3
..2 90220078 Special sticker ALESIS,30*30mm,PANTONE 361C sticker ,V1.0 1
..2 90220654 Special sticker NK48,Customer supply,300*74mm ,V1.0 1
..2 90250055 CARB sticker silver on black,100*31.5mm,V1.3 1
..2 90270024 Date sticker silver on black,20*5mm ,V1.2 1
..2 GR000769 NPA3 packing optioin NPA3 packing option ASSY 1
...3 16070050 Power Cable AN-W953,3G,0.75mm2,H05VV-F,1830mm,black,France 1
...3 16070073 PowerCable AN-W976,3C,0.75mm2,VCTF,1830mm,black,JP 1
...3 16070017 PowerCable AN-W920,3C,1.0mm2,H05VV-F,1830mm,black,3A Britain 1
...3 16070140 PowerCable AN-W1038,3G,0.75mm2,H05VV-F,1830mm,black,Israel 1
...3 16070080 PowerCable AN-W982,3C,0.75mm2,H05VV-F,1830mm,black,Australian 1
...3 16070141 PowerCable AN-W1039,3G,0.75mm2,H05VV-F,1830mm,black,Switzerland 1
...3 16070013 PowerCable AN-W915,3C,18#,SVT,1830mm,black,US 1
...3 16070240 PowerCable AN-W1123,3G,0.75mm2,H05VV-F,1830mm,blcak Europe California 65 1
...3 90041659 Barcode sticker NPA3,Black on white,76*50mm ,For US V1.0 1
...3 90200056 Label sticker BLACK&361C print,Φ30mm,V1.0 1
...3 90220738 Special sticker Numark,DINP,95*10.5,V1.1 1
...3 22011492 Safty manual NUMARK,safty manual,7-51-1373-H 1
...3 22011109 Userguide NPK2,user guide,V1.1 1

Stage Part Number Part Name Specification Usage Location
0 NPA3 NPA3 0
.1 DR001939 NPA3 Assembly NPA3 ASSY 1
..2 10520184 Snap ring E ring,T=0.5mm,V1.0 2
..2 30090009 Bundle line 2.5*120mm,Black 3
..2 30060079 Foam 50*150*5mm 4
..2 12030031 Rockerswitch AN-S331,RF-1003-BB4,BBG8E2L1T,no silkscreen 1
..2 13110033 switch power supply AN-T90034,16280,100-240VAC,50/60Hz,16.5VDC,4.1A 1
..2 16040913 Plug attachment AN-W4473,2P,18#,UL1007,220mm 1
..2 16040915 Plug attachment AN-W4475,2P,22#,UL1007,220mm 1
..2 16041047 Plug attachment AN-W4608,22#,UL1617,200mm 1
..2 16041078 Plug attachment AN-W4639,2P,18#,UL1007,250mm 1
..2 16060103 ground wire AN-W700,18#,UL1015,230mm 1
..2 20120017 Fader cap DN-PL2014,KGK-011A,V1.0 3
..2 20290083 Bracket DN-PB0076,ABS,,UL94V-2,black,ROHS,V1.0 3
..2 20410119 Button DN-PEB075,(3),ABS,,black,ROHS,V1.0 2
..2 20460013 Fixed buckle KY-CLT-2,94V-2,19.7*5.3*4.4 1
..2 20630094 Reflector ISP31-B,PC,Transparent,ROHS,V1.0 3
..2 20630129 Platter ABS,UL94-HB,80%,black,top silkscreen Pantone877Csilver,ROHS,V1.0 2
..2 30060095 Foam 10*1000*1mm,EVA1030,black 1
..2 30060452 Foam black,50*270*5mm,,V1.0 4
..2 30090002 Bundle line 2.5*80mm,black 9
..2 20580005 Washer vulcanized fibre,T=0.5mm,,V1.0 8
..2 30150178 Double Sided Adhesive Tape 3M9495,(2),141.5*33.0*0.1mm,,V1.0 1
..2 40010051 Powersupply socket AN-J0150,DB-14-2,0.8T,3P 1
..2 60100023 antenna 2.4G,2DBi,black,ROHS,L=280mm 1
..2 70010088 Full tooth screw Φ3*8mm,Crosshead D5.5mm ,black zinc,hardened 18
..2 70010605 Full tooth screw Φ2.6*7mm,Crosshead D4.5mm ,black zinc,hardened 6
..2 70010859 Full tooth screw Φ2*5mm,Crosshead D4.5mm ,black zinc,hardened 8
..2 70010893 Full tooth screw Φ3*10mm,Crosshead D9.5mm ,black zinc,hardened 4
..2 70010912 Full tooth screw
Φ3.0*12mm,Hexagonflathead,D6.0mm,Selftapping sharp tailed teeth,
black zinc,hardened
6
..2 CR011232 NPA3 AMP NPA3 AMP ASSY 1
...3 17010140 Electrolytic capacitor 22uF/25V,±20%,-40/+85℃,Φ5*11mm,P=2mm,black 1 C117
...3 20440026 Spacercolumn PC19-5,Φ6.5*6.95mm 4
...3 17010119 Electrolytic capacitor 100uF/25V,±20%,-40/+85℃,Φ5*11mm,P=2mm,black 1 C138
...3 17010523 Electrolytic capacitor 1000uF/25V,±20%,-40/+85℃,Φ8*20mm,P=3.5mm,black 6 C136,C148,C150,C120,C123,C3
NPA3 Full BOM

...3 50030166 Metallized polyester capacitor 474J,100V,±5%,Vertical boxtype,grey,7.2(W)*7.5(H)*3.5(T),taping 2 C130,C131
...3 40370357 Male socket AN-JP512,PHS2.0-2P,white,2P,with Buckle 1 CN15-B
...3 40370346 Male socket AN-JP528,HT-2.5-02P-01D,white,2P,with Buckle 1 CN14-A
...3 40370098 Male socket AN-JP410,VH-2A,P=3.96mm,180 degree,white 2 CN13-A,SW4-A
...3 40370326 Male socket AN-JP410,VH-2A,P=3.96mm,180 degree,red 1 CN1
...3 40370405 Male socket AN-JP560,HT-2.5-04P-01DK,P=2.54mm,180 degree,white,with buckle 1 CN10-B
...3 40370404 Male socket AN-JP559,8P,PHS2.0-8A,180 degree,with buckle 1 CN12-B
...3 40370376 Male socket AN-JP531,XHS2.5-7A,180 degree,white,with buckle 1 CN11
...3 40360350 Pin AN-JP413,1P,TJC1-1A,180 degree 2 H1,H2
...3 10490022 inserts width 6.35,T=0.8,立式,PCH250 2 B-,B+
...3 14040978 IC LM317TG,1.5A,TO-220,ON 1 U17
...3 10070018 Crystal radiator DN-MH7012,48*23.5,alufer 1
...3 10080255 radiator DN-MH0174,ICradiator,alufer,V1.0 1
...3 70010515 Full tooth screw AN-C10515,M3*10mm,Crosshead D5.5mm,Metric tooth machine,black zinc 1
...3 70010048 Full tooth screw
AN-C10048,M3*6mm,Crosshead D5.5mm,Metric tooth machine,black zinc,
hardened
2
...3 30050006 Mica sheet 13*18*0.1mm 1
...3 20500006 Insulating particles W05-253，￠5.3*1.8MM(material:NYLON46;Fire rating:94V-0) 1
...3 CR011233 NPA3 AMP SMT NPA3 AMP SMT ASSY 1
....4 26021105 FR4 double sided plate AN-B20710,AMP,160.2*107.5*1.6mm,blue,V1.7 1
....4 11170350 chip resistor 1/10W,0Ω,±5%,0603 3 R80,R81,R82
....4 11171106 chip resistor 1/10W,3.3Ω,±1%,0603,taping 2 R163,R164
....4 11171249 chip resistor 1/10W,4.99Ω,±1%,0603 1 R176
....4 11171353 chip resistor 1/10W,21.5Ω,±1%,0603 1 R178
....4 11170453 chip resistor 1/10W,37.4Ω,±1%,0603 1 R175
....4 11170364 chip resistor 1/10W,100Ω,±5%,0603 3 R150,R151,R168
....4 11171184 chip resistor 1/10W,124Ω,±1%,0603 1 R180
....4 11170491 chip resistor 1/10W,1.82KΩ,±1%,0603 1 R182
....4 11170395 chip resistor 1/10W,3.3KΩ,±5%,0603 2 R155,R171
....4 11170536 chip resistor 1/10W,10KΩ,±1%,0603 15
R86,R153,R156,R158,R167,R170,R183,R184,R185,R186,R187,R188,R
197,R199,R200
....4 11171189 chip resistor 1/10W,11.5KΩ,±1%,0603 1 R181
....4 11170849 chip resistor 1/10W,16.9KΩ,±1%,0603,taping 1 R193
....4 11170549 chip resistor 1/10W,20KΩ,±1%,0603 3 R152,R165,R169
....4 11171042 chip resistor 1/10W,39KΩ,±1%,0603 1 R83
....4 11170838 chip resistor 1/10W,49.9KΩ,±1%,0603,taping 1 R195
....4 11170576 chip resistor 1/10W,100KΩ,±1%,0603 10 R189,R192,R84,R85,R157,R160,R166,R196,R198,R201
....4 11171123 chip resistor 1/10W,137KΩ,±1%,0603 1 R190

....4 11170434 chip resistor 1/10W,200KΩ,±5%,0603 1 R194
....4 11171179 chip resistor 1/10W,243KΩ,±1%,0603 1 R191
....4 11170444 chip resistor 1/10W,1MΩ,±5%,0603 2 R172,R173
....4 11170009 chip resistor 1/8W,10Ω,±5%,0805 2 R161,R162
....4 11170266 chip resistor 1/8W,10KΩ,±1%,0805 1 R1
....4 11171120 chip resistor 1/2W,0.22Ω,±1%,2010 1 R202
....4 50050137 Chip ceramic capacitor 331,VDC50,±10%,X7R,0603,taping 2 C128,C129
....4 50050159 Chip ceramic capacitor 471,VDC50,±5%,NPO,0603,taping 1 C113
....4 50050052 Chip ceramic capacitor 102,VDC50,±10%,X7R,0603,taping 4 C118,C121,C134,C135
....4 50050063 Chip ceramic capacitor 103,VDC50,±10%,X7R,0603,taping 3 C132,C133,C144
....4 50050074 Chip ceramic capacitor 104,VDC50,±10%,X7R,0603,taping 9 C119,C122,C137,C139,C147,C149,C151,C1,C2
....4 50050497 Chip ceramic capacitor 224,VDC50,±10%,X7R,0603,taping 5 C124,C125,C126,C127,C143
....4 50050169 Chip ceramic capacitor 474,VDC50,±10%,X7R,0603,taping 2 C145,C146
....4 50050355 Chip ceramic capacitor 1UF,VDC25,±10%,X7R,0603,taping 4 C90,C91,C92,C142
....4 50050332 Chip ceramic capacitor 105,VDC50,±10%,X5R,0603,taping 1 C140
....4 50050414 Chip ceramic capacitor 10UF,VDC50,±10%,X5R,0805,taping 1 C141
....4 24040071 chip inductor AN-I4049,2.2UH,±10%,0603,CI1608-2R2 2 L7,L8
....4 24010016 Chip Bead FB120,3A,1206,BLM31PG121SN1L MURATA 4 FB14,FB15,FB18,FB1
....4 24010038 Chip Bead 150Ω,100MHz,±25%,6A,1812 1 FB13
....4 24060115 Ferrite Inductor AN-I6103,CDRH127T-100M,10uH,5A,SMT 2 L9,L10
....4 18010075 General purpose diode AN-D10075,LL-34,1N4148,taping 2 D2,D4
....4 18030044 Zener diode ZMM5V6,LL-34,1/2W,5.6V,taping 1 ZD1
....4 18010238 General purpose diode SK54LSC-KCTR,40V/5A,SMC,DO-214AB,taping,Star-Wing 4 D5,D3,D6,D7
....4 14010077 NPN triode MMBT3904LT1,SOT23,ONSEMI,code:1AM 6 Q4,Q24,Q25,Q31,Q33,Q34
....4 14020070 PNP triode MMBT3906LT1,SOT23,ONSEMI,code:2A 2 Q28,Q30
....4 14050040 NFET BSS138LT1G,SOT-23,silkscreen :J1 1 Q26
....4 14060014 PFET HCR3401P-M3TR,-30V/-4.1A,SOT23-3,SAMHOP 1 Q27
....4 14060010 PFET CEM4435A,SO-8,CET, 3 Q23,Q29,Q32
....4 14040872 IC LM4041DIM7-ADJ,SC70,NS,code:RAD 1 U19
....4 14040871 IC TS391ILT,SOT23-5,ST,code:K511 1 U18
....4 14040229 IC LM393DT,SOP8,PHILIPS,silkscreen :393 1 U16
....4 14041019 IC TPA3116D2,HTSSOP-32,A2L846T,silkscreen :G4 1 U13
..2 CR011234 NPA3 DJ Controller NPA3 DJ Controller ASSY 1
...3 17020050 Subminiature Electrolytic capacitor 47uF/25V,±20%,-40/+85℃,Φ6.3*7mm,P=2.5mm,black 2 C69,C71
...3 24100051 Magnetic ring EMC CORE V18003,19.5*18*9mm 1
...3 24100061 Magnetic ring V180184T,25*15*10mm 1
...3 17020054 Subminiature Electrolytic capacitor 100uF/10V,±20%,-40/+85℃,Φ5*7mm,P=2.0mm,black 1C5
...3 15010518 Rotary potentiometer AN-V1218,single,B10K,R11102NOBXH1-B103a-27.5F012P-000,L=27.5mm 5 P3-6,P9

...3 15010519 Rotary potentiometer AN-V1219,single,B10K,R11102NOBXH1-B103a-27.5F012P-01C,L=27.5mm 4 P1,P7,P8,P16
...3 15020028 Sliding potentiometer AN-V227,single,B10K,C04508NOAXH1-B103b,AD pin L=15mm 4 P11-14
...3 15020027 Sliding potentiometer AN-V226,dual,B10K,RA45D2F-211-12C2-B10K,C2 pin L=12mm, 1 P10
...3 12040001 TactSwitch AN-S401,TSF6273DJ-250AH 2 SW67,SW73
...3 12080021 Coding switch AN-S821,E1201MX1H1-0065,24P24,A1E30F12,L=30mm 1 ENC1
...3 18040294 LED AN-L0252,SL-RUB1V1D-C,square,2*5*7,red 6 D1,D2,D38,D40,D66,D67
...3 18040291 LED AN-L0249,SL-RG61V1D-C,square,2*5*7,green 2 D65,D68
...3 18040292 LED AN-L0250,SL-RB51V1D-C,square,2*5*7,blue 2 D48,D53
...3 18040293 LED AN-L0251,SL-RJC1V1D-C,square,2*5*7,orange 16 D3,D4,D28,D33,D39,D41-47,D49,D54-55,D59
...3 20260083 LED cap LED3B-5.5 6 D42,D44,D46,D47,D49,D59
...3 20260084 LEDcap LED3B-4 20 LED
...3 60020007 Optocoupler AN-E0207,RPI-352,DIP,6.5*4.2*5.5mm,ROHM 4 SEN5-8
...3 16041155 Plug attachment AN-W4615,5P,24#,UL2468,220mm 1 J9 to CN7
...3 16050278 barrierwire AN-W5276,3P,24#,UL2547,380mm 1
...3 16110074 barrierattached wire AN-WD72,5P,28/26#,UL2725,500mm 1 MAIN board J6 to NPA3 MIC/USB CN5
...3 CR011840 NPA3 DJ Controller AI NPA3 DJ Controller AI ASSY 1
....4 12040050 TactSwitch AN-S450,TC-138A/5H,6.2*6.2,120g,taping 20 SW2-11,SW65,SW69-72,SW75-79
...3 CR011241 NPA3 DJ Controller SMT NPA3 DJ Controller SMT ASSY 1
....4 26021138 FR4 double sided plate AN-B20629,MAIN,316*179*1.6mm,black,V1.6 1
....4 11170771 chip resistor 1/16W,22.1Ω,±1%,0402 2 R21,R23
....4 11171019 chip resistor 1/16W,10KΩ,±1%,0402 32 R26-27,R29,R31-45,R76-77,R79-90
....4 11171140 chip resistor 1/16W,1MΩ,±5%,0402 1 R24
....4 11170692 chip resistor 1/10W,0Ω,±1%,0603 3 R96-97,R104
....4 11170454 chip resistor 1/10W,47Ω,±1%,0603 16 R4,R8,R10,R19,R20,R46-48,R50,R117-119,R436,R449-451
....4 11170451 chip resistor 1/10W,10Ω,±1%,0603 3 R11,R60-61
....4 11170778 chip resistor 1/10W,100Ω,±1%,0603,taping 2 R91,R94
....4 11171346 chip resistor 1/10W,113Ω,±1%,0603 2 R293,R324
....4 11171347 chip resistor 1/10W,130Ω,±1%,0603 8 R311-313,R315-317,R335,R342
....4 11170465 chip resistor 1/10W,324Ω,±1%,0603 2 R309,R326
....4 11170466 chip resistor 1/10W,330Ω,±1%,0603 4 R28,R52,R65,R69
....4 11171348 chip resistor 1/10W,523Ω,±1%,0603 2 R72,R74
....4 11170839 chip resistor 1/10W,562Ω,±1%,0603,taping 4 R25,R51,R64,R68
....4 11171349 chip resistor 1/10W,649Ω,±1%,0603 4 R53,R55,R275,R283
....4 11171350 chip resistor 1/10W,665Ω,±1%,0603,taping 2 R310,R327
....4 11171351 chip resistor 1/10W,698Ω,±1%,0603,taping 6 R284-286,R321-323
....4 11170497 chip resistor 1/10W,2.43KΩ,±1%,0603 2 R58-59
....4 11170518 chip resistor 1/10W,4.99KΩ,±1%,0603 4 R2,R54,R56-57
....4 11170536 chip resistor 1/10W,10KΩ,±1%,0603 12 R3,R49,R63,R67,R71,R92-93,R95,R12-13,R22,R73

....4 11171044 chip resistor 1/10W,22KΩ,±1%,0603 4 R30,R62,R66,R70
....4 11170957 chip resistor 1/10W,820KΩ,±5%,0603 1 R15
....4 11170742 chip resistor 1/10W,1MΩ,±1%,0603 1 R1
....4 11170186 chip resistor 1/8W,1KΩ,±1%,0805 3 R7,R9,R148
....4 11170123 chip resistor 1/4W,0Ω,±5%,1206 1 R78
....4 11170483 chip resistor 1/10W,1KΩ,±1%,0603,taping 3 R5-6,R17
....4 50050464 Chip ceramic capacitor 100PF,VDC50,±5%,NPO,0402 2 C60,C63
....4 50050392 Chip ceramic capacitor 104,X7R,±10%,10V,0402,Murata,GRM155R71A104KA01D 5 C1,C59,C68,C70,C73
....4 50050340 Chip ceramic capacitor 104,VDC16,±10%,X5R,0402,taping 1 C57
....4 50050347 Chip ceramic capacitor 105,VDC6.3,±10%,X7R,0402,taping 7 C30,C48,C52-53,C64,C66,C74
....4 50050395 Chip ceramic capacitor 2u2,X5R,±20%,6.3V,0402,Murata,GRM155R60J225ME 2 C54,C56
....4 50050364 Chip ceramic capacitor 10UF,VDC6.3,±10%,X5R,0603,taping 8 C20,C22-24,C58,C61-62,C72
....4 50050474 Chip ceramic capacitor 22uF,VDC6.3,±20%,X5R,0603 1 C12
....4 50050031 Chip ceramic capacitor 33PF,VDC50,±5%,NPO,0603,taping 2 C37,C39
....4 50050063 Chip ceramic capacitor 103,VDC50,±10%,X7R,0603,taping 2 C19,C25
....4 50050073 Chip ceramic capacitor 104,VDC50,±5%,X7R,0603,taping 29
C4,C7-10,C13,C15-16,C21,C26-29,C31-36,C38,C40-43,C46-
47,C49,C102,C195
....4 50050355 Chip ceramic capacitor 1UF,VDC25,±10%,X7R,0603,taping 3 C3,C51,C55
....4 50050075 Chip ceramic capacitor 104,VDC50,±10%,X7R,0805,taping 8 C11,C14,C17,C100-101,C103,C105-106
....4 50050061 Chip ceramic capacitor 103,VDC25,±10%,X7R,0805,taping 1 C2
....4 17090016 SMD钽Electrolytic capacitor 10uF/16V,±10%,-40/+85℃,B type,yellow 1 C18
....4 17070007 V-CHIPElectrolytic capacitor 3.3uF/50V,±20%,-40/+85℃,Φ4*5.4,Alu 2 C78-79
....4 17070019 V-CHIPElectrolytic capacitor 47uF/6.3V,±20%,-40/+85℃,Φ4*5.4,Alu 1 C75
....4 25020036 SMD crystal resonator AN-0239,49SMD-24M-18-20,24MHZ ±20PPM,18PF,SMD 1 X2
....4 24010009 Chip Bead 600Ω@100MHZ,0.5A,±25%,0805,FB0805-601 1 L35
....4 24010047 Chip Bead FCM1608KF-600T05,100MHZ,0.5A,0603 4 R14,R16,R18,R116
....4 18010063 General purpose diode SOT23,MMBZ5242B,12V,taping,code:D9 1 U5
....4 18010076 General purpose diode MMBD4148LT1,SOT23,DIODES,taping 2 D12,D16
....4 14010079 NPN triode MMBT4401LT1,SOT23,ONSEMI,silkscreen :2X 5 Q2,Q9-11,Q5
....4 14010158 NPN triode 2SD2114K,SOT23 2 Q4,Q18
....4 14020119 PNP triode MMBT4403,SOT-23,DIODES,code:2T 1 U8
....4 14020147 PNP triode MMBT2907ALT1G,SOT-23,ON 1 Q1
....4 14041057 IC SN74HC165DR,SOIC16,TI,silkscreen :HC165 4 U12,U14,U24,U66
....4 14040857 IC USBLC6-2-SC6,ST 1 U3
....4 14040850 IC FDC6306P,SOT-6,FAIRCHILD 1 Q3
....4 14040884 IC NJU7223DL1-33,TO-252,JRC 1 U1
....4 14040393 IC 74HC14D,SO14,PHILIPS 1 U6
....4 14040971 IC NCP2811AD TSSOP-14 1 U18
....4 14041055 IC CD74HC4067M,SOIC24,TI 1 U22

....4 14041329 IC CY8C3246LTI-125,QFN-48,CYPRESS 1 U23
....4 14041056 IC AK4430ET,TSSOP16,AKM,silkscreen :AKM 4430ET 2 U2,U7
....4 14040073 IC 74HC595D,SOP16,PHILIPS 4 U36-39
....4 40360307 Pin AN-JP369,2*5,SMT,SAMTEC:FTSH-105-01-L-DV-K 1 J2
..2 CR011269 NPA3 PER(NEW) NPA3 PER(NEW) ASSY 1
...3 17010212 Electrolytic capacitor 220uF/16V,±20%,-40/+85℃,Φ6.3*11mm,P=2.5mm,black 2 C161,C136
...3 40370345 Male socket AN-JP527,HT-2.5-03P-01D,white,3P,with buckle 1 CN2
...3 40370374 Male socket AN-JP529,HT-2.5-05P-01DK,white,180 degree,P=2.5mm,with buckle 1 CN5
...3 40370406 Male socket AN-JP561,10P,PH2.0-10A,P=2mm,180 degree,white,with buckle 1 CN4-B
...3 40370296 Male socket AN-JP464,PH-6A,6PIN-2.0mm,vertical 1 CN3-A
...3 40430001 USB socket AN-J4301,Y11-208,USB BF 90 degree,DIP 1 J5
...3 40040038 3.5 jack AN-J0438,PJ-306D,black 3 J1,J2,J3
...3 40030050 6.35 jack AN-J0349,SJ-6325B-3P 1 J4
...3 24130025 Common mode inductance T14*08*07C,12mH,18*12*5mm 1 L9
...3 16041154 Plug attachment AN-W4614,2P,24#,UL2468,250mm 1 MIC/USB board CN15-A to AMP board CN15-B
...3 16010395 Color FlatCable AN-W4268,6P,26#,UL2468,60mm 1 CN3-B to CN3-A
...3 CR011270 NPA3 PER(NEW) SMT NPA3 PER(NEW) SMT ASSY 1
....4 26021062 FR4 double sided plate AN-B20709,PRE,150*105.1*1.6mm,blue,V1.6 1
....4 11170778 chip resistor 1/10W,100Ω,±1%,0603,taping 3 R30,R31,R54
....4 11170483 chip resistor 1/10W,1KΩ,±1%,0603,taping 7 R10,R11,R14,R15,R38,R97,R98
....4 11170486 chip resistor 1/10W,1.3KΩ,±1%,0603 2 R12,R13
....4 11170517 chip resistor 1/10W,4.7KΩ,±1%,0603 1 R40
....4 11170792 chip resistor 1/10W,4.99KΩ,±1%,0603,taping 2 R34,R35
....4 11170529 chip resistor 1/10W,7.15KΩ,±1%,0603 1 R55
....4 11170830 chip resistor 1/10W,6.81KΩ,±1%,0603,taping 2 R18,R19
....4 11171320 chip resistor 1/10W,9.76KΩ,±1%,0603 1 R206
....4 11170536 chip resistor 1/10W,10KΩ,±1%,0603 14 R1,R2,R3,R4,R5,R6,R7,R8,R24,R25,R26,R27,R159,R208
....4 11170537 chip resistor 1/10W,10.2KΩ,±1%,0603 4 R16,R17,R99,R100
....4 11171246 chip resistor 1/10W,11.3KΩ,±1%,0603 2 R28,R29
....4 11171189 chip resistor 1/10W,11.5KΩ,±1%,0603 2 R20,R21
....4 11171194 chip resistor 1/10W,12.7KΩ,±1%,0603 3 R22,R23,R39
....4 11170549 chip resistor 1/10W,20KΩ,±1%,0603 3 R32,R33,R41
....4 11170421 chip resistor 1/10W,47KΩ,±5%,0603 2 R203,R204
....4 11171335 chip resistor 1/10W,52.3KΩ,±1%,0603 1 R207
....4 11171126 chip resistor 1/10W,80.6KΩ,±1%,0603 2 R36,R37
....4 11170011 chip resistor 1/8W,22Ω,±5%,0805 1 R9
....4 50050036 Chip ceramic capacitor 47PF,VDC50,±5%,NPO,0603,taping 12 C5,C6,C7,C8,C24,C25,C29,C30,C42,C43,C45,C70
....4 50050045 Chip ceramic capacitor 101,VDC50,±5%,NPO,0603,taping 4 C22,C23,C35,C36

....4 50050137 Chip ceramic capacitor 331,VDC50,±10%,X7R,0603,taping 8 C16,C17,C18,C19,C20,C21,C94,C95
....4 50050052 Chip ceramic capacitor 102,VDC50,±10%,X7R,0603,taping 2 C38,C39
....4 50050161 Chip ceramic capacitor 472,VDC50,±10%,X7R,0603,taping 2 C33,C34
....4 50050073 Chip ceramic capacitor 104,VDC50,±5%,X7R,0603,taping 13 C9,C27,C28,C37,C48,C90,C91,C116,C133,C134,C135,C137,C160
....4 50050423 Chip ceramic capacitor 224,VDC25,±10%,X7R,0603,taping 2 C40,C41
....4 50050455 Chip ceramic capacitor 4.7UF,VDC10,±10%,X5R,0603,taping 16 C1,C2,C3,C4,C10,C11,C12,C13,C14,C15,C26,C44,C46,C47,C96,C97
....4 50050364 Chip ceramic capacitor 10UF,VDC6.3,±10%,X5R,0603,taping 2 C31,C32
....4 50050414 Chip ceramic capacitor 10UF,VDC50,±10%,X5R,0805,taping 2 C92,C159
....4 24040071 chip inductor AN-I4049,2.2UH,±10%,0603,CI1608-2R2 2 L1,L2
....4 24040009 chip inductor AN-I4008,4.7uH,±5%,LQN3221F-4.7uH 1 L11
....4 24010047 Chip Bead FCM1608KF-600T05,100MHZ,0.5A,0603 2 L7,L8
....4 24010036 Chip Bead FCM1608K-601T,1400 OHMS @ 1GHz,0603 2 FB1,FB2
....4 24010023 Chip Bead CB1608-202,2K,100MHZ,0.5A,±25%,0603 1 FB17
....4 14010077 NPNtriode MMBT3904LT1,SOT23,ONSEMI,code:1AM 1 Q36
....4 14060014 PFET HCR3401P-M3TR,-30V/-4.1A,SOT23-3,SAMHOP 1 Q35
....4 14040920 IC MCP6001T-I/OT,SOT23-5,Microchip,silkscreen :AA 1 U8
....4 14041012 IC TPS560200DBVR,SOT23-5,TI,Mark:L562 1 U22
....4 14041253 IC TLV9002,SOIC8,TI 4 U1,U2,U3,U4
....4 60190108 ESD interference suppressor 0603ESDA-TR1 2 ESD1,ESD2
..2 CR011271 NPA3 DLED NPA3 DLED ASSY 1
...3 17010103 Electrolytic capacitor 10uF/25V,±20%,-40/+85℃,Φ5*11mm,P=2mm,black 1 C93
...3 16060131 ground wire AN-W728,18#,UL1015,250mm 1 MAIN board H 2to AMP board H2
...3 17010119 Electrolytic capacitor 100uF/25V,±20%,-40/+85℃,Φ5*11mm,P=2mm,black 5 C78,C101,C117,C118,C157
...3 17010212 Electrolytic capacitor 220uF/16V,±20%,-40/+85℃,Φ6.3*11mm,P=2.5mm,black 4 C109,C65,C69,C80
...3 17010233 Electrolytic capacitor 330uF/10V,±20%,-40/+85℃,Φ6.3*11mm,P=2.5mm,black 3 C103,C104,C128
...3 40370365 Male socket AN-JP520,XHS-4AW,4P,P=2.5mm,white,90 degree,with buckle 1 CN9-B
...3 40370377 Male socket AN-JP532,PH2.0-4A,180 degree,white 1 CN3_A
...3 40370369 Male socket AN-JP524,PHS-5A,180 degree,P=2mm,white,with buckle 1 CN7
...3 40430013 USBsocket AN-J4312,USB3.0,AF180 degree 1 USB1
...3 15010540 Rotary potentiometer AN-V1240,single,A10K,RV09BCF-40-30F,L=30mm 2 VR1,VR2
...3 16110072 barrier attached wire AN-WD70,8P,24#/26#,UL2468/UL1533,250mm 1 CN12-A to AMP CN12-B
...3 16110073 barrierattached wire AN-WD71,10P,26#,UL1533/UL2547,UL1007#24,400mm 1 CN4-A to CN4-B
...3 16010460 Color FlatCable AN-W4331,4P,22#,UL1007,210mm 1 CN9-A to CN9-B
...3 16030057 Single color FlatCable AN-W357,4P,26#,UL2468,180mm,white 1 CN3_B to CN3_A
...3 16010461 Color FlatCable AN-W4332,4P,22#,UL1007,280mm 1 CN10-A to CN10-B to AMP
...3 18040019 LED DIP,Φ3*5,BL-B2141 5 LED2,LED3,LED4,LED15,LED17
...3 18040024 LED DIP,Φ3*5,L-03R5A141D11-04, 1 LED5
...3 18040122 LED AN-L0122,DIP,BL-BB53C4,Φ3*5mm 1 LED1

...3 20260043 LED cap LED3B-11 7 LED1,2,3,4,5,15,17
...3 18040204 LED BRL-10C05A06,high bright,0.5W,red,SMD 3 LED6,LED9,LED12
...3 18040205 LED BGL-10C05A06,high bright ,0.5W,green,SMD 3 LED7,LED10,LED13
...3 18040206 LED BBL-10C05A06,high bright,0.5W,blue,SMD 3 LED8,LED11,LED14
...3 CR011272 NPA3 DLED SMT NPA3 DLED SMT ASSY 1
....4 26021063 FR4 double sided plate AN-B20722,DLED,304*116.5*1.6mm,blue,V1.6 1
....4 11171008 chip resistor 1/16W,0Ω,±1%,0402 1 R64
....4 11170350 chip resistor 1/10W,0Ω,±5%,0603 1 R63
....4 11170356 chip resistor 1/10W,22Ω,±5%,0603,taping 1 R53
....4 11170778 chip resistor 1/10W,100Ω,±1%,0603,taping 3 R49,R71,R104
....4 11170483 chip resistor 1/10W,1KΩ,±1%,0603,taping 4 R45,R50,R65,R141
....4 11171237 chip resistor 1/10W,1.21KΩ,±1%,0603 9 R108,R112,R116,R120,R124,R128,R132,R136,R140
....4 11170494 chip resistor 1/10W,2KΩ,±1%,0603 1 R142
....4 11170391 chip resistor 1/10W,2.2KΩ,±5%,0603 4 R87,R88,R89,R90
....4 11171202 chip resistor 1/10W,390Ω,±1%,0603 1 R149
....4 11170517 chip resistor 1/10W,4.7KΩ,±1%,0603 3 R73,R205,R93
....4 11170792 chip resistor 1/10W,4.99KΩ,±1%,0603,taping 1 R101
....4 11170536 chip resistor 1/10W,10KΩ,±1%,0603 8 R46,R48,R74,R75,R154,R60,R91,R92
....4 11171028 chip resistor 1/10W,10.5KΩ,±1%,0603 1 R143
....4 11171194 chip resistor 1/10W,12.7KΩ,±1%,0603 1 R59
....4 11170549 chip resistor 1/10W,20KΩ,±1%,0603 11 R51,R52,R57,R58,R66,R67,R69,R70,R102,R103,R68
....4 11171191 chip resistor 1/10W,28.7KΩ,±1%,0603 1 R56
....4 11171203 chip resistor 1/10W,40.2KΩ,±1%,0603 1 R62
....4 11170900 chip resistor 1/10W,43.2KΩ,±1%,0603 1 R145
....4 11170421 chip resistor 1/10W,47KΩ,±5%,0603 1 R72
....4 11170838 chip resistor 1/10W,49.9KΩ,±1%,0603,taping 2 R146,R147
....4 11170901 chip resistor 1/10W,75KΩ,±1%,0603 2 R43,R144
....4 11170574 chip resistor 1/10W,86.6KΩ,±1%,0603 1 R42
....4 11170576 chip resistor 1/10W,100KΩ,±1%,0603 2 R44,R76
....4 11170580 chip resistor 1/10W,150KΩ,±1%,0603 2 R95,R148
....4 11171178 chip resistor 1/10W,180KΩ,±1%,0603 1 R94
....4 11171180 chip resistor 1/10W,357KΩ,±1%,0603 1 R96
....4 11170132 chip resistor 1/8W,10Ω,±1%,0805 1 R61
....4 11171378 chip resistor 1/4W,5.76Ω,±1%,1206 9 R107,R111,R115,R119,R123,R127,R131,R135,R139
....4 11171192 chip resistor 1/4W,8.2Ω,±1%,1206 6 R109,R113,R121,R125,R133,R137
....4 11171182 chip resistor 1/4W,15Ω,±1%,1206 3 R110,R122,R134
....4 11170909 chip resistor 1/4W,25.5Ω,±1%,1206 3 R114,R126,R138
....4 11171214 chip resistor 1/4W,30Ω,±5%,1206 6 R105,R106,R117,R118,R129,R130

....4 50050036 Chip ceramic capacitor 47PF,VDC50,±5%,NPO,0603,taping 5 C72,C85,C86,C98,C158
....4 50050045 Chip ceramic capacitor 101,VDC50,±5%,NPO,0603,taping 2 C50,C57
....4 50050052 Chip ceramic capacitor 102,VDC50,±10%,X7R,0603,taping 4 C125,C126,C127,C130
....4 50050136 Chip ceramic capacitor 273,VDC50,±10%,X7R,0603,taping 2 C51,C52
....4 50050146 Chip ceramic capacitor 333,VDC50,±10%,X7R,0603,taping 1 C106
....4 50050073 Chip ceramic capacitor 104,VDC50,±5%,X7R,0603,taping 33
C59,C60,C61,C62,C64,C66,C68,C71,C73,C74,C77,C79,C87,C102,C105,C
110,C111,C112,C113,C114,C119,C120,C121,C122,C123,C124,C129,C13
1,C132,,C152,C153,C155,C156
....4 50050169 Chip ceramic capacitor 474,VDC50,±10%,X7R,0603,taping 2 C55,C89
....4 50050355 Chip ceramic capacitor 1UF,VDC25,±10%,X7R,0603,taping 3 C154,C63,C67
....4 50050455 Chip ceramic capacitor 4.7UF,VDC10,±10%,X5R,0603,taping 12 C49,C53,C54,C56,C58,C75,C76,C83,C84,C88,C99,C100
....4 50050364 Chip ceramic capacitor 10UF,VDC6.3,±10%,X5R,0603,taping 1 C115
....4 50050414 Chip ceramic capacitor 10UF,VDC50,±10%,X5R,0805,taping 2 C107,C108
....4 24040071 chip inductor AN-I4049,2.2UH,±10%,0603,CI1608-2R2 2 L3,L4
....4 24040009 chip inductor AN-I4008,4.7uH,±5%,LQN3221F-4.7uH 1 L5
....4 24040083 chip inductor AN-I4061,XCRH127-33uH,±20% 1 L6
....4 24010036 Chip Bead FCM1608K-601T,1400 OHMS @ 1GHz,0603 8 FB3,FB4,FB5,FB7,FB8,FB16,FB13,FB14
....4 24010023 Chip Bead CB1608-202,2K,100MHZ,0.5A,±25%,0603 2 FB6,FB10
....4 24010016 Chip Bead FB120,3A,1206,BLM31PG121SN1L MURATA 3 FB9,FB11,FB12
....4 18010238 General purpose diode SK54LSC-KCTR,40V/5A,SMC,DO-214AB,taping,Star-Wing 1 D1
....4 14010077 NPNtriode MMBT3904LT1,SOT23,ONSEMI,code:1AM 9 Q6,Q8,Q10,Q12,Q14,Q16,Q18,Q20,Q22
....4 14020070 PNPtriode MMBT3906LT1,SOT23,ONSEMI,code:2A 1 Q2
....4 14010079 NPNtriode MMBT4401LT1,SOT23,ONSEMI,silkscreen :2X 9 Q5,Q7,Q9,Q11,Q13,Q15,Q17,Q19,Q21
....4 14010161 NPNtriode KTC2875-B-RTK/P,SOT-23,KEC,code:M 1 Q1
....4 14050040 NFET BSS138LT1G,SOT-23,silkscreen :J1 1 Q3
....4 14040973 IC STM8S003F3P6,TSSOP20,ST 1 U20
....4 14040920 IC MCP6001T-I/OT,SOT23-5,Microchip,silkscreen :AA 1 U10
....4 14041011 IC TLV70433DBVR,SOT23-5,TI,silkscreen :PA0 2 U9,U21
....4 14041013 IC TLV70450DBVR,SOT23-5,TI,Mark:PAX 1 U7
....4 14041012 IC TPS560200DBVR,SOT23-5,TI,Mark:L562 1 U11
....4 14040993 IC NJM2762RB2,TVSP10,JRC 1 U6
....4 14041069 IC TLV6002,SOIC8,TI,silkscreen :V6002 2 U5,U15
....4 14040227 IC LM339DT,SOIC-14,ST,silkscreen :339 1 U14
....4 14041077 IC HCR1530,SOP8 1 U12
....4 40330016 Connector IPEX,IPEX-001,SMD 1 ANT1
....4 12040052 TactSwitch AN-S452,TSTPP6650K-250BH-8,6*6*5H,SMD,taping 2 SW1,SW2
....4 60210097 Module NPA3,CSR BT module,JS-BTM8605,Party MixPro,V2.07 1 BT1
..2 DR001956 NK47 button with silkscreen ASSY DN-PC6704,(2),PC+Silicon,diffusers,UL94-HB,(1)silkscreen black,V1.0 2

...3 20670032 Button DN-PC6704,(2)PC+Silicon,diffusers,UL94-HB,ROHS,V1.0 1
..2 DR001957 NK47 button with silkscreen ASSY DN-PC6704,(2)PC+Silicon, diffusers,UL94-HB,(2)silkscreen black,V1.0 2
...3 20670032 Button DN-PC6704,(2)PC+Silicon,diffusers,UL94-HB,texture,ROHS,V1.0 1
..2 DR001958 NK47 button with silkscreen ASSY DN-PC6705,(3),ABS,UL94-HB, ,black,(1)silkscreen white,V1.0 1
...3 20670033 Button DN-PC6705,(3),ABS,UL94-HB,,black,texture,ROHS,V1.0 1
..2 DR001959 NK47 button with silkscreen ASSY DN-PC6705,(3),ABS,UL94-HB, ,black,(2)silkscreen white,V1.0 1
...3 20670033 Button DN-PC6705,(3),ABS,UL94-HB,,black,texture,ROHS,V1.0 1
..2 DR001960 NK47 Fader cap with silkscreen ASSY DN-PL2013,ABS,UL94-HB,80%,black,silkscreen white,V1.0 2
...3 20120016 Fader cap DN-PL2013,ABS,UL94-HB,80%,black,texture,ROHS,V1.0 1
..2 DR001961 NK47 button with silkscreen ASSY DN-PC6703,PC+Silicon, (1) diffusers,UL94-HB,silkscreen black,V1.0 2
...3 20670031 Button DN-PC6703,PC+Silicon,(1) diffusers,UL94-HB,texture,ROHS,V1.0 1
..2 DR001993 NPA3 plate with silkscreen ASSY DN-PC1081,ABS(UL94V-2),80%,black,silkscreen Pantone White C,V1.0 1
...3 20010147 Plate DN-PC1081,ABS(UL94V-2),,black,texture,ROHS,V1.0 1
..2 DR001994 NPA3 Top housing with silkscreen ASSY DN-PC2120,ABS,UL94-2,80%,silkscreen Pantone White C/RED032C,V1.0 1
...3 20020171 Top housing DN-PC2120,ABS,UL94-2,80%,black,texture,V1.0 1
..2 DR001995 NPA3 Lens with silkscreen ASSY
DN-PL1133,PC,T=0.8mm,Transparent,silkscreen Black C/White C/032
C,V1.0
1
...3 20110175 Lens DN-PL1133,PC,T=0.8mm,Transparent,V1.0 1
.1 DR002481 NPA3 Lamp panel assembly NPA3 Lamp panel ASSY 1
..2 20110149 Lens DN-PL1117,V1.0 1
..2 16010449 Color FlatCable AN-W4320,7P,24#,UL1007,550mm 1 CN11 to CN1-A1
..2 30150163 Mesh cloth grey,329*304*0.3mm,V1.0 1
..2 30060227 Foam 12*1000*2.0mm,防火EVAE1030, ,black 0.6
..2 30060452 Foam black,50*270*5mm,,V1.0 3
..2 30090002 Bundle line 2.5*80mm,black 3
..2 30110004 Washer IPA76C,vulcanized fibre,T=1mm,Φ3.5*Φ12mm,ROHS.V1.0 8
..2 70010556 Full tooth screw Φ2.6*6mm,crosshead,D7.0mm ,black zinc,hardened 8
..2 70010605 Full tooth screw Φ2.6*7mm,Crosshead D4.5mm ,black zinc,hardened 16
..2 30060494 Foam EVA1030,black,10*5*2mm,,V1.0 8
..2 CR011089 IPA82 LED03 IPA82 LED03 ASSY 1
...3 16020085 late discharge of solid fermentation AN-W285,12P,30#,UL2678,120mm,grey 2 J1-A1 to J1-B1,J2-A1 to J2-B1
...3 14070052 program IPA73P,US 0
...3 17010119 Electrolytic capacitor 100uF/25V,±20%,-40/+85℃,Φ5*11mm,P=2mm,black 1C8
...3 17010256 Electrolytic capacitor 470uF/25V,±20%,-40/+85℃,Φ8*14mm,P=3.5mm,black 2 C12,C15
...3 40370376 Male socket AN-JP531,XHS2.5-7A,180 degree,white,with buckle 1 CN1-A1
...3 CR011090 IPA82 LED03 SMT IPA82 LED03 SMT ASSY 1
....4 11170001 chip resistor 1/8W,0Ω,±5%,0805,taping 1 R306

....4 11170132 chip resistor 1/8W,10Ω,±1%,0805 1 R303
....4 11170207 chip resistor 1/8W,2KΩ,±1%,0805 1 R304
....4 11170269 chip resistor 1/8W,10.5KΩ,±1%,0805 1 R305
....4 11170353 chip resistor 1/10W,10Ω,±5%,0603 1 R312
....4 11170483 chip resistor 1/10W,1KΩ,±1%,0603,taping 48 R2,R10,R16,R22,R28,R34,R40,R46,R52,R268-R302,R308-R311
....4 11170536 chip resistor 1/10W,10KΩ,±1%,0603 10 R1,R11,R17,R23,R29,R35,R41,R47,R53,R313
....4 11170658 chip resistor 1/8W,56Ω,±1%,0805 12 R113,R116,R143,R146,R173,R176,R203,R206,R233,R236,R263,R266
....4 11170762 chip resistor 1/8W,27Ω,±1%,0805 24
R112,R114,R115,R117,R142,R144,R145,R147,R172,R174,R175,R177,
R202,R204,R205,R207,R232,R234,R235,R237,R262,R264,R265,R267
....4 11170576 chip resistor 1/10W,100KΩ,±1%,0603 1 R314
....4 11170836 chip resistor 1/10W,22.1KΩ,±1%,0603 1 R315
....4 11171040 chip resistor 1/10W,680Ω,±1%,0603 9 R12,R18,R3,R24,R30,R36,R42,R48,R54
....4 14010133 NPNtriode MPS8050S-D,STO-23,KEC,silkscreen :BHx 33 Q1,Q3-Q6,Q8,Q10,Q12,Q14,Q16,Q18,Q20,Q22,Q23-Q42
....4 14020129 PNPtriode MPS8550S-D,STO23,KEC 9 Q2,Q7,Q9,Q11,Q13,Q15,Q17,Q19,Q21
....4 14041058 IC GD32F130C8T6,LQFP48,GigaDevice 1 U2
....4 14041077 IC HCR1530,SOP8 1 U1
....4 14041099 IC SY8113B,SOT23-6 1 IC2
....4 18010111 General purpose diode MBRA340T3G 40V 3A SMA ON 1 D1
....4 18040311 LED AN-L0268,TO-5050BC-MRPBGGF-3,Antipolarity,code:05B 12
LED26,LED27,LED35,LED36,LED44,LED45,LED53,LED54,LED62,LED
63,LED71,LED72
....4 24010024 Chip Bead 1.5K@100MHZ,0.25A,±25%,CB2012-152,0805 2 L2,L3
....4 24040083 chip inductor AN-I4061,XCRH127-33uH,±20% 1 L1
....4 24040084 chip inductor AN-I4062,4*4*1.9mm,10UH,NR4018-100M 1 L4
....4 26021008 FR4 double sided plate AN-B20664,LED03,180*85.5*1.6mm,white,V1.5 1
....4 40350070 Pin male socket AN-JP250,双排,1.27-2*6P,H=4.9,L=7.0,180 degree,SMT 2 J1-B1,J2-B1
....4 50050025 Chip ceramic capacitor 22PF,VDC50,±5%,NPO,0603,taping 1 C22
....4 50050052 Chip ceramic capacitor 102,VDC50,±10%,X7R,0603,taping 4 C16,C18-C20
....4 50050074 Chip ceramic capacitor 104,VDC50,±10%,X7R,0603,taping 6 C2,C3,C4,C5,C6,C21
....4 50050075 Chip ceramic capacitor 104,VDC50,±10%,X7R,0805,taping 2 C11,C13
....4 50050147 Chip ceramic capacitor 333,VDC50,±10%,X7R,0805,taping 1 C10
....4 50050364 Chip ceramic capacitor 10UF,VDC6.3,±10%,X5R,0603,taping 1 C1
....4 50050484 Chip ceramic capacitor 22uF/10V,±20%,0805,X5R,taping 1 C9
..2 CR011091 IPA82 LED01 IPA82 LED01 ASSY 1
...3 CR011092 IPA82 LED01 SMT IPA82 LED01 SMT ASSY 1
....4 11170658 chip resistor 1/8W,56Ω,±1%,0805 18
R5,R14,R20,R26,R32,R38,R44,R50,R56,R59,R65,R68,R71,R74,R77,R
80,R83,R86
