Number 8 N8CH120 User manual

CERAMIC TOWER HEATER
OPERATING INSTRUCTIONS
For Model: N8CH120

This page is intentionally left blank

CAUTION: In order to avoid a hazard due to inadvertent resetting of the
thermal cut-out, this appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
•This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, unless they are supervised or have been given instruction
concerning the use of the appliance by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the
appliance.
•If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
WARNING: You must not cover this heater. Covering this heater presents
fire risk and will activate the safety fuse; permanently disabling the unit.
WARNING: Do not use this heater in small rooms when they are occupied
by persons not capable of leaving the room on their own, unless constant
supervision is provided.
WARNING: To reduce the risk of fire, keep textiles, curtains, or any
flammable material a minimum distance of 1 metre from the air outlet.
General Care and Safety Guide
•Use only the voltage specified on the rating label of the appliance.
•The heater must not be located immediately below a socket outlet.
•Keep all objects at least 1 metre from the front, sides and rear of the appliance.
•This appliance is intended for household use only and not for commercial or industrial use.
•Indoor use only.
•Use this appliance only as described in this manual. Any other use is not recommended by
the manufacturer and may cause fire, electric shock or injury.
•Do not use the heater if it has been dropped or damaged.
•The common cause of overheating is deposits of dust or fluff in the appliance. Ensure these
deposits are removed regularly by unplugging the appliance and vacuum cleaning the air
vents and grills.
•Always unplug appliance when not in use.
•When the appliance has been unpacked, check it for transport damage and ensure all parts
have been delivered. If parts are missing or the appliance has been damaged, contact the
Customer Services Team.
•Do not use if there are visible signs of damage to the heater.
YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF THE
INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL.

•Never use the appliance to dry clothes.
•Do not connect the appliance to mains supply until completely assembled and adjusted.
•Ensure hands are dry before handling the plug or main unit.
•Ensure heater is on a flat, stable, heat-resistant surface.
•Do not operate with cord set coiled up as a heat build up is likely, which could be sufficient to
become a hazard.
•Carry out regular checks of the supply cord to ensure no damage is evident
•Do not operate this appliance with a damaged cord, plug or after the appliance malfunctions
or has been dropped or damaged in any manner. Return to a qualified electrical person for
examination, electrical service or repair.
•Do not twist, kink or wrap the cord around the appliance, as this may cause the insulation to
weaken and split. Always ensure that all cord has been removed from any cord storage area
and is unrolled before use.
•It is recommended that this heater is plugged directly into the wall socket. Power boards are
not rated to supply power to high wattage appliances.
•A correctly specified, undamaged extension cord may be used with this heater provided it is
used in a safe manner.
•Do not remove plug from power socket until the appliance has been switched off.
•Do not remove plug from power socket by pulling cord; always grip plug.
•Do not place cord under carpet or cover with rugs or furniture. Arrange the cord so it cannot
be tripped over.
•Don’t place appliance on bedding or on thick & long carpet where the openings may get
blocked.
•Switch off and use handle provided when moving
•Do not place appliance close to radiant heat source.
•Do not insert or allow foreign objects to enter any ventilation or exhaust opening, as this may
cause an electric shock, fire or damage to the appliance.
•Do not sit on the appliance.
•Do not use abrasive cleaning products on this appliance. Clean with a damp cloth (not wet)
rinsed in hot soapy water only. Always remove plug from the mains supply before cleaning.
•Do not operate in areas where petrol, paint or other flammable liquids are used or stored.
•Do not use this appliance in the immediate surrounds of a bath, a shower, or a swimming
pool or other liquids.
•The appliance must not be immersed in any liquids.
•There are no user serviceable parts installed in the unit.
•Do not place the unit in wardrobes or other enclosed spaces as this may cause fire hazards.
•This unit is not supposed to be used in or around locations where foodstuffs, works of art or
delicate articles of science, etc are stored.
•If your appliance does not work, or is not working properly, contact the place of purchase or
the Customer Services Team.
General Care and Safety Guide

WARNING!
DANGER IF SWALLOWED
Keep batteries out of reach of
children. Swallowing may lead to
serious injury or death in as little
as 2 hours due to internal burns.
If swallowed, go straight to a
hospital emergency room.
Dispose of used batteries
immediately.
General Care and Safety Guide
The remote control supplied with this heater uses a CR2025 coin type battery
(Included).
DANGER IF SWALLOWED
Keep batteries out of reach of children. Swallowing may lead to serious injury or
death in as little as 2 hours due to internal burns.
If swallowed, go straight to a hospital emergency room.
Dispose of used batteries immediately.

Operating Your Heater
Always choose a safe location for the heater, keeping in mind the safety precautions
outlined. Ensure all packaging has been removed from the unit before use. Please follow
the below instructions.
WARNING: In order to avoid overheating or fire, do not cover the heater.
WARNING: Keep all objects at least 1 metre from the front, sides and rear
of the appliance.
WARNING: Do not use this heater with a programmer, separate timer,
remote-control system or any other device that switches the heater on
automatically, since a fire risk exists if the heater is covered or positioned
incorrectly.
WARNING: Never leave this heater unattended when in use.
Ensure heater is on a flat, stable, heat-resistant surface.
Once the heater is in a safe operating position and all switches are in the off
position, insert the power plug into the mains outlet.
CAUTION: Ensure the power cord is not tight because if pulled it may
partially pull the plug from the socket. A partially inserted plug will overheat
the plug and socket and could result in fire.
CONTROL PANEL

Check that the heat control switch is set to Off
position on the back of the heater before plugging
the heater into the mains supply.
Turn the heat control switch On.
HEAT CONTROL SWITCH
The control switch positions are:
On/Off
Mode Button
ILow Heat
II High Heat
Turn the On/Off button on. Press the Mode button
to select either ‘I’ for Low Heat setting or II for High
Heat setting.
For greater economy, use the High Heat setting
initially and then switch to the Low Heat setting.
OSCILLATION
Press the Oscillation button to allow the heater to
swing from side to side. Press again to turn off.
TIMER
Press the Timer button to set the Timer from
anywhere between 1 and 10 hours by pressing the
button until the desired amount of hours is reached.
The appliance will remain on for that length of time
until the Timer counts down and the set time elapses
at which time the appliance will turn off.
Operating Your Heater

Operating your Appliance
REMOTE CONTROL
The Remote Control will operate the same functions on the control panel of the heater:
1. On/Off
2. Mode –Heat Settings
3. Oscillation
4. Timer
For best results, aim the remote directly at the display screen on the front of the heater. The
remote has a 3 metre range of operation.
The remote control requires one CR2025 type battery. Remove the plastic tab from the
battery and battery terminal prior to first use of the Remote Control.
12
3
4

SUPPORT AND TECHNICAL ADVICE
North Shore City, Auckland, New Zealand
Monday –Friday 8am-5pm
Phone: [phone]
TECHNICAL SPECIFICATION
Model No: N8CH120
Supply: 220-240VAC 50-60Hz
Wattage: 2000W
Operating Your Heater
SAFETY DEVICES
This appliance has three protection devices:
•Tilt Switch - this will automatically turn the appliance off if the appliance is not in the
correct operating position.
•Resettable Thermal Link - this will automatically disconnect the power to the
appliance at a pre-set overheat temperature. After cooling down it will reset and
power on again. If this occurs, investigate what is causing the appliance to overheat.
•Thermal Fuse - this disconnects the appliance permanently in case of overheating. (It
is non resettable).
CAUTION: The heater generates heat during use. Proper precautions must
be taken to prevent the risk of burns, scalds, fires or other damage to persons.
CARE AND CLEANING
•The heater requires regular cleaning to ensure trouble free operation:
•Unplug the heater from the mains supply before cleaning.
•Ensure that the heater has been allowed to cool down completely before cleaning.
•The common cause of overheating is deposits of dust or fluff in the appliance. Ensure
these deposits are removed regularly by unplugging the appliance and vacuum
cleaning the air vents and grills.
•Use a damp cloth (not wet) to wipe the exterior of the heater to remove dust and
dirt.
•Never use solutions such as petrol, thinners or polishing agents.
•Ensure the heater is dry before plugging back into the mains supply.
PROOF OF PURCHASE
To receive warranty retain receipt as proof of purchase.

Thank you for purchasing this Number 8 product. Your product is warranted against factory faults when used in
a normal domestic setting for a period of one year from the date of purchase. Valid proof of purchase will be
required. As the product is intended for home use only, commercial usage of this product for professional or
industrial purposes will VOID this warranty.
Should your product be faulty, it may be replaced, repaired or refunded during the warranty period, as deemed
appropriate by the retailer.
This warranty excludes damage caused by misuse, neglect, shipping accident, incorrect installation, or work
carried out by anyone other than a qualified electrical service technician.
PLEASE KEEP YOUR RECEIPT AS THIS WILL HELP VERIFY YOUR WARRANTY.
This warranty is additional to the conditions and guarantees of the Consumers Guarantee Act (1993).
ONE YEAR WARRANTY
Number 8 One Year Warranty (IMPORTANT: Please complete and retain this warranty card)
Name
Address
Place Of Purchase
Date of Purchase
Name Of Product
Model Number
Attach a copy of the purchase receipt to this warranty card
Due to continual design improvements, the product illustrated in this User Manual may differ slightly from the
actual product.
Number 8 –New Zealand
67 Corinthian Drive
Albany
Auckland 0632
New Zealand
Phone [phone]
