Numerik Jena SCM-1000 User manual

USER MANUAL
English Original Instruction
SMART COMMUNICATION MODULE FOR LENGTH GAUGE ACANTO

Smart Communication Module
2/24
INDEX
1. FEATURES AND APPLICATIONS......................................................................3
2. SAFETY INFORMATION.........................................................................................4
2.1 General Information .................................................................................................4
2.2 Notes on Legal Requirements..................................................................................5
2.3 Notes on Transport, Storage and Handling..............................................................6
2.4 Notes on Operation..................................................................................................6
2.5 Environmental Protection and Disposal ...................................................................6
2.6 Scope of Delivery of SCM-1000...............................................................................6
3. TECHNICAL INFORMATION ................................................................................7
3.1 Technicalspecication .............................................................................................7
3.2 Technical drawing.....................................................................................................7
3.3 Nameplate................................................................................................................8
4. STATUS MESSAGES IN OPERATING MODE ..............................................9
5. INITIAL SETUP OF THE SMART COMMUNICATION MODULE.........10
5.1 Factory Settings .....................................................................................................10
5.2 Mechanical connections.........................................................................................10
5.3 Compatible software ..............................................................................................11
5.4 Commissioning of the Smart Communication Module ...........................................13
5.5 Changeofcustomer-specicsettings ....................................................................15
6. OPERATION OF THE SMART COMMUNICATION MODULE ..............16
6.1 Operation of the SCM with the SCA.......................................................................17
6.2 SCM output parameter ..........................................................................................19
6.3 ACANTO length gauge output parameter..............................................................20
6.4. Encoder settings ...................................................................................................20
7. APPLICATION PROGRAMMING INTERFACE ...........................................21
8. ORDER INFORMATION ........................................................................................21
9. SCM & SCA – TROUBLESHOOTING .............................................................21

Smart Communication Module
3/24
1. FEATURES AND APPLICATIONS
The SCM (Smart Communication Module) enables the conversion and data transfer of length
gaugesACANTOusingtheOpenPlatformCommunicationsUniedArchitecture(OPC)UAIoT-
protocol to transfer information to IT systems and IoT software.
OPC UA is a service-oriented industrial communication standard for secure and reliable data
exchange.Theprotocolisplatform-independentandenablesaseamlessowofinformation
betweendevicesfromdi󰀨erentmanufacturers.OPCUAdenesthetransportofdataand
interfaces, security mechanisms and the semantic structure of the data, as well as services
for the exchange of data between clients and servers - including access to real-time data,
monitoring of alarms and events, access to historical data and other applications. This standard
is maintained and developed by the “OPC UA FOUNDATION”.
Essential features:
• Wireless data transmission up to 50 m
• Transmission of measured values, diagnostic data and evaluation numbers
• Identification and transfer of additional environmental information
(such as humidity, temperature, pressure)
• Use of the OPC UA communication structure
• Available for length gauge ACANTO (EnDat 2.2) in Europe.
Essential Benets:
• Cost-effective extension of networks, systems and applications
• Flexibility to integrate new devices into an existing network infrastructure
• Improved usability through wireless data transmission
• Data Improvement - Transparency for analysis and reporting at all IT levels
• Improved IT security through a sophisticated communication concept, protecting
against unauthorized data access
• Improved data availability and data security through a robust data architecture with
reliable communication mechanisms
• Reduction of downtimes due to predictive maintenance processes

Smart Communication Module
4/24
2. SAFETY INFORMATION
2.1 General Information
• Make sure to familiarize yourself thoroughly with the contents of the user manuals and
data sheets before installing and starting up the device!
• The devices as well as the accessory are guaranteed to function if the mounting and
operating conditions are maintained as stated in the respective user manuals and data
sheets .
• NUMERIK JENA GmbH is not liable for damages caused by unauthorized handling
of the devices and the accessory. Any unauthorized handling leads to forfeiture of all
warranty claims!
• NUMERIK JENA GmbH does not assume any liability for any damages or operating
errors caused by incorrect mounting and/or startup operations.
• Please consider user manuals, data sheets and safety instructions of devices from
other manufacturers which will be used in combination with encoders and accessories
from NUMERIK JENA to ensure a reliable operation.
• Please contact the support of NUMERIK JENA GmbH or an authorized representation
for further information. Please visit the NUMERIK JENA website to get the contact
information.
• Please pay attention to the safety instructions and warning symbols in the user manuals
and data sheets from NUMERIK JENA!
Danger to the device or to the function of the device!
Pull the plug!
Highlyinammable!

Smart Communication Module
5/24
Europe
2.2 Notes on Legal Requirements
Approval for radio transmission: For operation in radio mode.
NUMERIK JENA GmbH hereby declares that the SCM transmitter/receiver unit is in compliance
with the essential requirements and other relevant provisions of Directive 2014/53/EU.
The EC Declaration of Conformity can be requested from
NUMERIK JENA GmbH
Im Semmicht 4
07751 Jena
Germany
or www.numerikjena.de
Other countries on request.
USA FCC ID 2AC7Z-ESPWROOM32 -
THE DEVICE COMPLIES WITH PART 15 OF THE FCC RULES
This equipment radiates radio frequency energy and if not used properly - that is, in
strict accordance with the instructions in this manual - may cause interference to radio
communications and television reception.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Changesormodicationsnotexpresslyapprovedbythepartyresponsibleforcompliancecould
void the user‘s authority to operate the equipment.
This device has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
theequipmento󰀨andon,theuserisencouragedtotrytocorrecttheinterferencebyoneor
more of the following measures:
(3) Reorient or relocate the receiving antenna.
(4) Increase the separation between the equipment and receiver.
(5) Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
(6) Consult the dealer or an experienced radio/TV technician for help.

Smart Communication Module
6/24
2.3 Notes on Transport, Storage and Handling
The products from NUMERIK JENA GmbH must be transported and stored in the original
packaging only!
2.4 Notes on Operation
• The devices and accessories from NUMERIK JENA GmbH must be operated with the
supply voltage stated in the respective user manual or data sheet only.
• Comply with applicable PIN assignment if auxiliary electronic units are connected!
Do not connect or disconnect plugs if the power is on!
2.5 Environmental Protection and Disposal
Environmental damage due to incorrect disposal of the product, accessories or peripherals!
• Do not dispose in domestic waste.
• Dispose only by authorized collection points. Electrical waste and electronic components
are subject to special-waste regulations.
• Observe the applicable country-specific regulations.
More detailed information on legal regulations can be obtained from competent authorities.
2.6 Scope of Delivery of SCM-1000
The SCM-1000 comes with the following items:
• Smart Communication Module SCM-1000
• USB adapter cable, cable length 1.80 m
• Installation instructions
The current version of the data sheet is available in the download area at www.numerikjena.de.

Smart Communication Module
7/24
D24 59,65
48
3. TECHNICAL INFORMATION
3.1 Technical specication
TheSCM-1000complieswiththefollowingtechnicalspecication:
Table 1: Technical data of the SCM-1000
3.2 Technical drawing
Illustration 1: Technical drawing (all dimensions in mm)
Parameter SCM Unit
Interfaces USB 2.0
WiFi 802.11 b/g/n
Supply voltage 5.0 ± 10% V
Current consumption (max.) 165 mA
Samplerate Position (max.) 100 Hz
Weight 50 g
IP-rating (EN 60 529) IP50
Dimensions 59.65 x 24 mm
Operating temperature 0 to +55 (+32 to +131) °C (°F)
Storage temperature -20 to +70 (-4 to +158) °C (°F)
Shock [per 11 ms] ≤500(EN60068-2-27) m/s2
Vibration [within 55-2000 Hz] ≤100(EN60068-2-6) m/s2
Range (typical) 50 m

Smart Communication Module
8/24
3.3 Nameplate
Illustration 2: Figure of the SCM-1000 nameplate
Product Name
FCC-Declaration
Identity Number
Serial Number
Data Matrix Code

Smart Communication Module
9/24
LED status Length gauge connected Denition
Blue (steady) Yes Length gauge detected, SCM
operable
Red (steady) Yes SCM-1000 Error
Red(ashing) Yes Length gauge Error
please check the length gauge
Blue (steady) No Search for connected length
gauges
Red(ashing)/(steady) No Setup mode active; SCM-1000
initiated access point
M12 connector
(to connect the length gauge)
USB connector type Micro-B
(USB-power supply)
Status LED
4. STATUS MESSAGES IN OPERATING MODE
ThecurrentstatusoftheSCM-1000isindicatedbytheintegratedLED(checkgure3).
Illustration3:SchematicgureoftheSCM
Depending on the Smart Communication Modules status, the LED can assume one of
the following LED states (see table 2). Please note that the current state of assembly or
disassembly of the length gauge ACANTO is relevant for the correct interpretation of the status
message.
Table 2: LED states - overview

Smart Communication Module
10/24
Setting Value
WLAN - SSID scm1000
WLAN - Password 12345678
Hostname scm1000
Network IPv4 module 192.168.4.1/24
Gateway 192.168.4.1
DHCP Server active
URL opc.tcp://192.168.4.1:4840
5. INITIAL SETUP OF THE SMART COMMUNICATION MODULE
5.1 Factory Settings
The module is delivered with the following factory settings (please check table 3). For the initial
setup or a change of previous settings (for example changing the custom network name or
password), these factory defaults will be loaded and a hotspot will be generated automatically
by the SCM, in case no length gauge ACANTO is connected.
Table 3: Overview of the factory settings
5.2 Mechanical connections
The SCM-1000 has the following physical connection points:
• USB connector (Type Micro-B connector)
• 8-pin M12 coupling
Illustration4:SchematicgureoftheSCM-1000withconnectedlengthgauge
The power supply (see section 3) of the SCM-1000 and the connected length gauge is realized
via USB. Please note that SCM and connected device are using the same power supply
(Source: USB).
Illustration 5: USB connector type Micro-B
Lokales Netzwerk/WLAN
(wireless) local area network
D24
59.65
48

Smart Communication Module
11/24
The 8-pin M12 connector realizes the data transmission as well as the power supply of the
length gauge ACANTO.
Illustration 6: Pin assignment 8 pol. Coupling M12 (UP= power supply)
5.3 Compatible soware
The SCM-1000 can be used in WLAN or USB mode. For this purpose NUMERIK JENA provides
the “Smart Communication App” (SCA) as free of charge software for Windows and Android.
The SCA includes the following functions:
• “SCM MANAGER” – management assistant for the integrated SCMs via WiFi or USB
• “ADD SCM” – Setup wizard for setting up SCMs over WiFi
• “MONITORING” – evaluation assistant with various graphic display options
• “SCA SETTINGS” – Wizard for internal software settings
Illustration 7: SCA - Start screen (Figure: Smart Communication App)
Power supply Serial data transmission
82513476
UP- 0V - DATA+ DATA- CLOCK+ CLOCK-

Smart Communication Module
12/24
Operating system App-Name Download
Windows 7 / 8 / 10 Smart Communication App Download available at www.numerikjena.de
or at the Google Play Store
Operating system App-Name Download
Android 6 (and higher) Smart Communication App Google Play Store
Windows 7 / 8 / 10 Smart Communication App Download available at www.numerikjena.de
or at the Google Play Store
Illustration 8: Figure SCA-Menu
5.3.1 SCM in WiFi mode (OPC UA compatible)
If the SCM-1000 is used in WiFi mode, a device with an installed OPC UA client is required.
For the following operating systems NUMERIK JENA GmbH provides an OPC UA compatible
software free of charge:
Table 5: Overview of the software recommendations for WiFi mode
5.3.2 SCM in USB mode
In case the SCM-1000 is used in USB mode, a device with the USB device driver installed is
required. For the following operating systems, NUMERIK JENA GmbH provides software free of
charge:
Table 6: Software recommendations for USB-Mode

Smart Communication Module
13/24
5.4 Commissioning of the Smart Communication Module
Connect the Smart Communication Module to a power supply (length gauge
disconnected). The WiFi-hotspot is established automatically by the module, set up with
the factory settings (Please check section 5.1). During the commissioning the LED of the
SCM lights red.
Illustration 9: SCM with WLAN (LED lights up red)
Connect the SCM-1000 to your setup device directly via the USB interface or via WiFi.
For the WiFi connection, an access point is automatically established by the SCM-1000
with the factory settings (see Table 7).
Illustration 10: Schematic diagram for setting up the SCM (LED lights up red) via USB/WLAN
Table 7: Settings attributes (network connection and access data)
Lokales Netzwerk/WLAN
(wireless) local area network
D24
59.65
48
1
2
Lokales Netzwerk/WLAN
(wireless) local area network
D24
59.65
48
Setting Value
WLAN - SSID scm1000
WLAN - Password 12345678
Hostname scm1000
Netzwerk IPv4 module 192.168.4.1/24

Smart Communication Module
14/24
Feature Path Value
Netzwerk-Name SCM-1000/Software/Network Settings/WIFI SSID max. 64 characters
Netzwerk-Password SCM-1000/Software/Network Settings/WIFI PASS max. 64 characters
OPC UA Username
(optional) SCM-1000/Software/Login Settings/Username <OPC-UA-Username>
OPC UA Password
(optional) SCM-1000/Software/Login Settings/Password <OPC-UA-Password>
Operating mode SCM-1000/Software/Network Settings/
NetworkMode
RJ45 Ethernet = 0
WLAN Client = 1
WLAN Access
Point = 2
Open the Smart Communication App (SCA) from NUMERIK JENA GmbH to set up the
network settings. If you are using an alternative software for setup, please refer to Table
8 below for the relevant setting notes.
Illustration 11: Schematic representation of SCM network setup using SCA / alternative software
Table 8: SCM network setup data
The SCA has an integrated assistant („ADD SCM“) for setting up the SCM-1000 network
settings. Open the assistant and follow the instructions.
Illustration 12: Schematic representation of the SCM network setup using the SCA start-up wizard
Lokales Netzwerk/WLAN
(wireless) local area network
D24
59.65
48
3
4
Lokales Netzwerk/WLAN
(wireless) local area network
D24
59.65
48

Smart Communication Module
15/24
When the setup is completed, the network settings made are permanently stored in the
SCM (even if the power supply is disconnected) and are loaded if an ACANTO length
gauge is connected. To change the network settings again, repeat steps 1 to 4.
Illustration 13: Software display of the setup wizard “ADD SCM”
5.5 Change of customer-specic settings
Tochangethecustomer-specicsettingsthelengthgaugemustbedisconnectedfromtheSCM
and restarted by interrupting the power supply.
Illustration 14: Schematic diagram SCM (LED lights red, WLAN access point is set up) with power
supply without gauge
Subsequently, the factory settings of the SCM will be loaded and a separate hotspot will be
established. A commissioning (see section 5.4) can be repeated.
Please note that by restarting the SCM without a connected length gauge an
access point is created automatically. The previously entered user-specic
network data is stored in the SCM.
Lokales Netzwerk/WLAN
(wireless) local area network
D24
59.65
48

Smart Communication Module
16/24
6. OPERATION OF THE SMART COMMUNICATION MODULE
Connect the Smart Communication Module (SCM) with an ACANTO length gauge to a power
supply. During operation, the SCM’s LED is permanently lit in blue. The SCM-1000 can then be
used directly via USB interface or via WiFi.
For a WiFi connection, the entered network settings (see Chapter 4) will be loaded
automatically.
• SCMs that are connected via a WLAN connection can be used by all output devices
(PC/tablet) in the network.
• SCMs that are integrated via the USB interface can only be used on the connected
terminal device.
The output values of the SCMs (SCM-data/ length gauge) can be read out via the SCA from
NUMERIK JENA GmbH or via alternative software.
Illustration 15: Schematic network illustration with several SCMs/end devices
Lokales Netzwerk/WLAN
(wireless) local area network
D24
59.65
48

Smart Communication Module
17/24
Submenu „SCM DETAILS“
(temperature, humidity...)
ADD SCM (change to start-up wizard)
absolute measured value /
reset measured value
Lokales Netzwerk/WLAN
(wireless) local area network
D24
59.65
48
Description of the measured value
Submenu „SCM SETTINGS“
Current measured value
Name of the currently selected SCM
6.1 Operation of the SCM with the SCA
The Smart Communication App (SCA) from NUMERIK JENA has an integrated assistant („SCM
MANAGER“) to manage all SCMs in the network as well as the locally connected USB devices.
In this menu measured values and information (e.g. temperature & humidity) of the SCM/
ACANTO length gauge are provided. In addition, changes to the SCMs can be made in the
submenu options (including naming, network settings, etc.).
If you are using an alternative software to manage your embedded devices, please refer to
chapter 6.2/6.3 for the available information.
Illustration 16: Schematic illustration of SCM management using the SCA’s “SCM MANAGER”
Illustration 17: “SCM MANAGER” software interface
Illustration18:Submenu“SCMMANAGER-Details”withspecicinformation
go back to „SCM MANAGER“

Smart Communication Module
18/24
Limit values for tolerances
/ Total displays
Setting Measured value display
Adjustment single / multiple display
Setting in mm / µm
Activation / deactivation of the
congurationmode
Adjustment single / multiple display
Lokales Netzwerk/WLAN
(wireless) local area network
D24
59.65
48
Figure18:Submenu“SCMMANAGER-Settings”withSCM-specicparameters
Setting up SCM as an access point
during operation (Restart necessary
by disconnecting the power supply)
Reset device error
Active SCM settings
Error code (Acanto internal)
Figure 19: Schematic illustration of the graphical representation of information using the SCA’s “MONITORING”-assistant
The app also provides a monitoring assistant („MONITORING“), which allows a graphical
monitoring and recording of the information/measured values of the integrated devices in the
network with various options.
Figure 20: Software surface “MONITORING”

Smart Communication Module
19/24
Parameter Bedingung/
Bezugsgröße Min Typ Max Einheit
Acceleration
Sensitivity ±2g average temperature = 25
°C 4096 LSB/g
Resolution 0.244 mg/LSB
Path
SCM-1000\Hardware\Accel X
SCM-1000\Hardware\Accel Y
SCM-1000\Hardware\Accel Z
Pressure
Operating temperature
range operational -40 25 85 °C
Operating pressure range full accuracy 300 1100 hPa
Absolute accuracy pressure 300...1100 hPa, 0...65 °C ±1.0 hPa
Path SCM-1000\Hardware\Pressure
Parameter Condition Min Typ Max Unit
Temperature
Operating Range operational -40 25 85 °C
Absolute temperature
accuracy 0...65 ±1.0 °C
Resolution API output resolution 0.01 °C
Path SCM-1000\Hardware\Temperature
Humidity
Operating Range for temperatures
< 0 °C and > 60 °C
-40 25 85 °C
0 100 %RH
Absolute accuracy tolerance 20...80 %RH, 25 °C ±3 %RH
Resolution 0.008 %RH
Path SCM-1000\Hardware\Humidity
6.2 SCM output parameter
The SCM-1000 provides the following information independently of the connected probe (Note:
All parameters are measured within the module):
Table8:Overviewofmodule-specicoutputvalues

Smart Communication Module
20/24
Parameter Min Typ Max Unit
Length
SCM-1000\Axes\Axis 1\Encoder 1\Position mm
Valuation Number
SCM-1000\Axes\Axis 1\Encoder 1\Diagnostic\Incremental
Track 0 255 –
SCM-1000\Axes\Axis 1\Encoder 1\Diagnostic\Absolute Track 0 255 –
Functionality Path Value
Set zero position (manually) SCM-1000\Axes\Axis1\Encoder1\Cong\DatumShift <User-dened>
zero position (Automatic -
current position)
SCM-1000\Axes\Axis1\Encoder1\Cong\Useactual
pos. for Datum Shift 1 = set value
Set counter unit SCM-1000\Axes\Axis1\Encoder1\Cong\Measuring
Unit
0 = mm/deg
1 = counts
Set power save mode SCM-1000\Axes\Axis 1\Encoder 1\isActive
0=switcho󰀨
1 = switch on
Get error status SCM-1000\Axes\Axis 1\Encoder 1\Error
0 = no error
1 = error
Read device name plate
Identnummer: SCM-1000\Axes\Axis 1\Encoder 1\Nameplate\Ident Number
Seriennummer: SCM-1000\Axes\Axis 1\Encoder 1\Nameplate\Serial Number
Read SCM name plate
Identnummer: SCM-1000\Nameplate\Ident Number
Seriennummer: SCM-1000\Nameplate\Serial Number
6.3 ACANTO length gauge output parameter
The output values can be read with a suitable software under the following paths:
Table 9: Overview of gauge settings
6.4. Encoder settings
The following settings can be adapted with a suitable software for SCM / length gauge:
Table 10: Overview of encoder settings
