NuPrime IDA-6 User manual

IDA-6
Class A+D Integrated Amplifier
with DAC

01
FCC Notice - Declaration of Conformity Information
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit di erent from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
WARNING: Only peripherals complying with the FCC class B limits may be attached to this
equipment.
Changes or modi cations made to this equipment, not expressly approved by us or parties
authorized by us could void the user’s authority to operate the equipment. This device complies with
part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

02
EU Declaration of Conformity
Hereby, NuPrime Audio, Inc. declares that this device is in compliance with the essential requirements
and other relevant provisions of Directive 2004/108/EC.
The manufacturer of this product is NuPrime Audio, Inc., 1712 Pioneer Ave. Ste 1817, Cheyenne,
Wyoming 82001, USA.
The Authorized Representative for EMC and product safety is NuPrime Audio, Inc., 1712 Pioneer Ave.
Ste 1817, Cheyenne, Wyoming 82001, USA.
For any service or guarantee matters please refer to the addresses given in separate service or
guarantee documents.
For customers in Europe
Disposal of Old Electrical & Electronic Equipment (Applicable in the European Union and other
European countries with separate collection systems)
This symbol on the product or on its packaging indicates that this product shall not be treated as
household waste. Instead it shall be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this product. The recycling
of materials will help to conserve natural resources. For more detailed information about
recycling of this product, please contact your local Civic Oce, your household waste disposal
service or the shop where you purchased the product.

03
SAFETY INSTRUCTIONS
There are two categories of Safety Instructions included in this manual:
Product Warnings, (i.e., what must never be done to assure avoiding those hazards that
could cause bodily injury or property damage); and
User Directions (i.e., what must always be done to assure the safe use of your device).
The Safety Instructions contained in this manual have been categorized in accordance with the
seriousness of the potential hazards through the use of Signal Words. Those Signal Words, and their
intended meanings, are as follows:
DANGER: Indicates that a failure to observe the Safety Instructions could result in death or
catastrophic bodily injury.
WARNING: Indicates that a failure to observe the Safety Instructions could result in serious bodily
injury.
CAUTION: Indicates that a failure to observe the Safety Instructions could result in minor bodily
injury or property damage.
NOTE: Designates important information that relates to activities and/or conditions that might
result in loss of data and/or damage to your device.
Safe Use and Operation of Your Device
This equipment emits stray RF energy and will interfere with the reception of signals by airborne
electronic navigational devices or medical devices. Do not operate this equipment near any sensitive
medical devices.
WARNING: Use only grounded AC power cords.
Always immediately disconnect the power to the equipment in the event the device emits an unusual
odor or sound or generates smoke.

04
WARNING: Never attempt to disassemble, repair or make any modi cation to your device.
Disassembly, modi cation or any attempt at repair could cause bodily injury or property damage, as
well as damage to the device itself.
WARNING: Your device is not a toy. Never allow children to play with your device. Misuse, rough or
improper handling of your device by children could result in serious bodily injury for any of the
enumerated safety warnings in this manual. In addition, always keep all accessories and components
out of the reach of small children as small parts might present a choking hazard. Seek immediate
medical attention if choking occurs or if any small part has been swallowed.
CAUTION: Never raise the sound volume level too high when using your device with earphones. An
excessive sound volume level could cause damage to your hearing.
WARNING: To reduce the risk of re or electric shock, do not expose the unit to moisture or water.
Do not allow foreign objects to get into the enclosure. If the unit is exposed to moisture, or a foreign
object gets into the enclosure, immediately disconnect the power cord from the wall. Take the unit
to a quali ed service person for inspection and necessary repairs.
Read all the instructions before connecting or operating the component.
Keep this manual so you can refer to these safety instructions.
Heed all warnings and safety information in these instructions and on the product itself. Follow all
operating instructions.
Do not use this unit near water.
You must allow a minimum 10 cm or 4 inches of unobstructed clearance around the unit. Do not
place the unit on a bed, sofa, rug, or similar surface that could block the ventilation openings. If the
unit is placed in a bookcase or cabinet, there must be ventilation of the cabinet to allow proper
cooling. Keep the component away from radiators, heat registers, stoves, or any other appliance that
produces heat.

05
The unit must be connected to a power supply only of the type and voltage speci ed on the rear
panel. Connect the component to the power outlet only with the supplied power supply cable or an
exact equivalent. Do not modify the supplied cable.
Do not route the power cord where it will be crushed, pinched, bent, exposed to heat, or damaged in
any way. Pay particular attention to the power cord at the plug and where the cord exits the back of
the unit.
The power cord should be unplugged from the wall outlet during a lightning storm or if the unit is to
be left unused for a long period of time.
Immediately stop using the component and have it inspected and/or serviced by a quali ed service
agency if:
The power supply cord or plug has been damaged.
Objects have fallen or liquid has been spilled into the unit.
The unit has been exposed to rain.
The unit shows signs of improper operation.
The unit has been dropped or damaged in any way

06
Background
NuPrime is not a Switching Digital Ampli er
Switching Digital Amps, commonly known as Class-D, rst appeared some decades ago. From the
start, Class-D showed enormous potential along with signi cant shortcomings: limited usable
bandwidth, and a xed saw-tooth waveform for audio- signal modulation, the latter producing jitter
that e ectively masks low-level signals.
Instead of the conventional saw-tooth con guration, NuPrime’s patented circuit design uses a
naturally occurring analog-modulating signal that adds neither noise nor jitter. Rather than reverting
to o -the-shelf solutions, NuPrime’s in-house advances have further unlocked the switching amp’s
potential without the di culties pure digital-switching ampli ers simply cannot avoid – in other
words, the best of both worlds.
Once upon a time heat and bulk were badges of status. Today, they’re the bane of obsolescent
technology. NuPrime amps switch at 500,000Hz – more than 10X the CD sampling rate. At these
frequencies, transformers and capacitors work far more e ciently, making it possible to reduce their
size. Typically, Class-A amps rarely utilize more than 30% of the power they draw; the rest is wasted
as heat. High operating temperatures also shorten the useful life of the electrolytic capacitors used in
abundance in these designs.
A comparison with traditional designs is mind-boggling. A NuPrime amp, small enough to sit on the
palm of one’s hand, is, typically, 85% e cient – in practical terms, cool-running and easy on the
utility bill.

07
Advantages of NuPrime Ampli er Technology
1. High bandwidth. Truly faithful reproduction of music demands bandwidth, and plenty of it.
Inadequate bandwidth withholds important spatial information and tonal complexities. NuPrime
amps deliver high bandwidth with a ruler- at response from 20 to 50,000Hz. Only a very few,
very expensive linear ampli ers are capable of achieving that. This bandwidth allows NuPrime to
amplify complex music with faithfulness far beyond the capability of conventional amps, with
particular regard to a vast soundstage – accurate spatial information delivered in full.
2. An extremely high damping factor. Damping factor is simply a measure of an ampli er’s ability
to drive and control a speaker. The higher the number, the better. An excellent tube ampli er
might have a damping factor between 10 and 100. A high-quality Class-A ampli er might reach
200. A NuPrime ampli er has a damping factor about 400. And unlike conventional amps,
NuPrime’s damping factor is totally una ected by changes in audio frequencies. Simply stated,
NuPrime delivers lightning-fast dynamics to any speaker.
3. No phase shift. Many amps use output lters that create phase shift. When phase shifts, spatial
information becomes inaccurate. Most amps present phase shifts of better than 45 degrees at 20
kHz, heading toward 90 degrees as frequency increases. NuPrime amps cancel these distortions
owing to a unique closed-loop design producing zero phase shift across all frequencies. Repeat,
zero.
NuPrime provides unequalled, fully regulated output without ripple voltage or noise. Absent this
electronic smog, music emerges from a pristine background, delicate details and nuances intact.
Purity has a sound, and it’s beautiful.

08
Introduction:
The NuPrime IDA-6 consists of an integrated ampli er and digital-to-analog converter that decode
PCM 384 and DoP64 with the convenience of wireless audio in a small, handsomely designed home
stereo component. NuPrime's Single End Class A+D hybrid ampli cation technologies deliver the
substance and warmth of Class A ampli cation and the e ciency and speed of Class D technology.
The IDA-6's spacious, transparent, dynamic and luxuriously textured soundstage has to be heard to
believed.

09
IDA-6 utilized a design technique that allows it to perform PCM 384 and DoP64 decoding that
measured up to the performance of high-end DAC. A SRC (Sampling Rate Converter) FPGA IC chip
up samples the input signal to gigahertz range before it is down sampled to a xed PCM sampling
rate for ultra-low jitter and distortion rates. This classi ed xed sampling rate simpli es system
design that resulted in sound quality that is unprecedented for an integrated amp at this price point.
With all stages in one chassis, the IDA-6 avails itself of the shortest possible signal paths in order to
facilitate low levels of noise and distortion for a black-velvet background to music. Volume changes
occur in 99 precise 0.5dB increments for each input’s individually adjustable volume level. Precise
level matching is a breeze, as is the user’s ability to make comparisons of music sources.
The NuPrime amp circuit improves on traditional class-D design by using a self-oscillating circuit to
generate pulse-width modulation. The amplifier switches at a frequency of 500kHz, well beyond the
compact disc’s 44.1kHz sampling rate. Most class-D amps switch at 300kHz or lower. In addition, a
new low noise switching power supply is designed speci cally to complement the IDA-6 ampli er.
The IDA-6's frequency response to 50 kHz elevates vocals into emotional experiences; similarly,
instrumental upper registers mimic a live performance’s shimmering heights. The IDA-6's features
and speci cations have few equals. Just one audition will convince you that the IDA-6’s performance
is unmatched at this price point.

10
Features:
Single End Class A + D design achieves audiophile-quality sound with Class-D’s dynamics,
speed and e ciency
Sampling Rate Converter (SRC) IC supporting PCM 384 and DoP 64 decoding
Extension port for Bluetooth dongle and WiFi audio streaming (optional)
Full microprocessor control with memory retention for each input volume
Five digital inputs and one analog stereo input for complete system exibility
Capable of decoding DoP formats via coaxial and optical inputs
Volume adjustment in 99 precise 0.5dB increments
Advanced switched-resistor ladder network (implemented in FPGA) for controlling volume,
with a single resistor in the signal path at any volume setting
Includes remote control
Speci cations:
Inputs:
A1: 3.5mm Analog Input
E2: Extension port for optional modules (NuPrime BTR-8 (Bluetooth) or NuPrime WR-100
(WiFi receiver)
O3: Optical Digital S/PDIF (PCM up to 192K supporting DoP format DSD64)
O4: Optical Digital S/PDIF (PCM up to 192K supporting DoP format DSD64)
C5: Coaxial Digital S/PDIF (PCM up to 384K supporting DoP format DSD64)
C6: Coaxial Digital S/PDIF (PCM up to 384K supporting DoP format DSD64)
Outputs:
2 x pair of stereo speaker (binding posts) output
1 x Control panel for extended control panel and display (Optional accessory)

11
Optical Sampling Rates: 44.1KHz, 48KHz, 88.2KHz, 96, 176.4KHz, 192KHz
Coaxial Sampling Rates: 44.1KHz, 48KHz, 88.2KHz, 96, 176.4KHz, 192KHz, 352.8KHZ,
384KHz
Bit Resolution: 24-bits
Power output: 60W x 2 (8-Ohm) or 35W x 4 (4-Ohm) *
THD+N: 0.05%
SNR = > 88dB
Peak Output Power: 170W
Frequency Response: 10Hz ~50KHz
Dimensions: 200 mm W x 198 mm D x 60 mm H (including feet)
Weight: 1.4Kg
Worldwide AC voltage: 100VAC~ 240VAC
Available in black color only.
*Please note it is not recommended to use 2 pairs of 4-ohm speakers, as it will have an impact on
sound quality.

12
Quick Start Guide
Front Panel View:
Power and Input Selector:
Power:
Hold and press for 3 sec to On/O standby mode
Volume:
Turn the knob to adjust volume
Input Selection:
Brie y press to switch between input channels
Display:
PCM: 44.1, 48, 88.2, 96,176.4, 192, 352.8, 384
DoP: d2.8
VOL: 00 ~ 99
O3: Optical digital input
O4: Optical digital input
C5: Coaxial digital input
C6: Coaxial digital input
NuPrime
Inputs:
A1: 3.5mm analog input
E2: Extension port input

13
Back Panel View:
Inputs:
A1: 3.5mm stereo analog for CD/DVD/BD players, TV and any analog source device.
E2: Extension port for Bluetooth and WiFi module. (Optional modules)
O3: Optical input for CD/DVD/BD players, TV and any device with an optical source.
O4: Optical input for CD/DVD/BD players, TV and any device with an optical source.
C5: Coaxial input for CD/DVD/BD players, TV and any device with a coaxial source.
C6: Coaxial input for CD/DVD/BD players, TV and any device with a coaxial source.
Outputs:
2 x pair of stereo speaker (binding posts) output
1 x Control panel for optional extended control panel and display.
Dual Stereo Speakers
Stereo Speakers
C6 C5
Coaxial
A1
Analog
E2
Extension
O3O4
Optical

14
Remote Control:
Power: Power On/O
Ch+: Selection next channel
CH-: Selection previous channel
Vol +: Volume up
Vol –: Volume down
Mute: Mute/Unmute audio
A1: Analog input selection
E2: Extension input selection
O3: Optical input selection
O4: Optical input selection
C5: Coaxial input selection
C6: Coaxial input selection

15
Optional Control Panel:
Optional Control Panel
Power: Power On/O
Ch+: Selection next channel
CH-: Selection previous channel
Vol +: Volume up
Vol –: Volume down
*This is an optional accessory that is sold separately.

16
NuPrime’s Limited Warranty and Limitation of Liabilities
ADDITIONAL RIGHTS
FOR CONSUMERS, WHO ARE COVERED BY CONSUMER PROTECTION LAWS OR REGULATIONS IN THEIR COUNTRY OF
PURCHASE OR, IF DIFFERENT, THEIR COUNTRY OF RESIDENCE, THE BENEFITS CONFERRED BY THIS WARRANTY ARE IN
ADDITION TO ALL RIGHTS AND REMEDIES CONVEYED BY SUCH CONSUMER PROTECTION LAWS AND REGULATIONS.
THIS WARRANTY DOES NOT EXCLUDE, LIMIT OR SUSPEND ANY RIGHTS OF CONSUMERS ARISING OUT OF
NONCONFORMITY WITH A SALES CONTRACT. SOME COUNTRIES, STATES AND PROVINCES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES OR ALLOW LIMITATIONS ON HOW LONG
AN IMPLIED WARRANTY OR CONDITION MAY LAST, SO THE LIMITATIONS OR EXCLUSIONS DESCRIBED BELOW MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
THAT VARY BY COUNTRY, STATE OR PROVINCE. THIS LIMITED WARRANTY IS GOVERNED BY AND CONSTRUED UNDER
THE LAWS OF THE COUNTRY IN WHICH THE PRODUCT PURCHASE TOOK PLACE.
LIMITED WARRANTY
For a period of ONE (1) YEAR from the date of retail purchase by the original end-user purchaser (“Warranty Period”),
NuPrime warrants (in) this product against defects in materials and workmanship, and (ii) that each Product, unmodi ed and
under normal use and conditions, will substantially comply with NuPrime’ applicable written technical documentation for the
Product. NuPrime reserves the right to make substitutions and modi cations from time to time in the speci cations of
Products sold by NuPrime, provided that such substitutions or modi cations do not materially a ect overall Product
performance.
If a hardware defect exists and a valid claim is received within the Warranty Period, at its option and to the extent permitted by
law, NuPrime will (1) repair the hardware defect at no charge, using new or refurbished replacement parts, (2) exchange the
product with a product that is new or which has been manufactured from new or serviceable used parts and is at least
functionally equivalent to the original product, or (3) refund the purchase price of the product. NuPrime may request that you
replace defective parts with user-installable new or refurbished parts that NuPrime provides in ful llment of its warranty

17
obligation. A replacement product/part assumes the remaining warranty of the original product or ninety (90) days from the
date of replacement or repair, whichever provides longer coverage for you. When a product or part is exchanged, any
replacement item becomes your property and the replaced item becomes NuPrime's property. When a refund is given, your
product becomes NuPrime's property.
OBTAINING WARRANTY SERVICE
If you purchased the product in the U.S., deliver the product, at your expense, to any NuPrime Service Center located in the
U.S. If you purchased the product outside of the U.S., deliver the product to any NuPrime Authorized Importer in the country
where you purchased the product. Be aware, however, that not all countries have NuPrime Authorized Service Providers
(‘NASP’) and not all Authorized Service Providers outside the country of purchase have all parts or replacement units for the
product. If the product cannot be repaired or replaced in the country it is in, it may need to be sent to a di erent country or
returned to the country of purchase at your expense for repair or replacement. If you seek service in a country that is not the
country of original purchase, you will comply with all applicable import and export laws and regulations and be responsible for
all custom duties, V.A.T. and other associated taxes and charges. Where international service is available, NuPrime may repair
or exchange defective products and parts with comparable products and parts that comply with local standards.
You can always deliver the product to NuPrime’s U.S. main service center for obtaining warranty service, however, you may
have to pay for return shipping cost.
NuPrime may send you user-installable new or refurbished replacement product or parts to enable you to service or exchange
your own product (“DIY Service”). Upon receipt of the replacement product or part, the original product or part becomes the
property of NuPrime and you agree to follow instructions, including, if required, arranging the return of original product or
part to NuPrime in a timely manner.
When providing DIY Service requiring the return of the original product or part, NuPrime may require a credit card
authorization as security for the retail price of the replacement product or part and applicable shipping costs. If you follow
instructions, NuPrime will cancel the credit card authorization, so you will not be charged for the product or part and shipping
costs. If you fail to return the replaced product or part as instructed or the replaced product or part is not eligible for warranty
service, NuPrime will charge the credit card for the authorized amount.

18
EXCLUSIONS AND LIMITATIONS
This Limited Warranty applies only to hardware products manufactured by or for NuPrime that can be identi ed by the
"NuPrime" trademark, trade name, or logo a xed to them. The Limited Warranty does not apply to any non-NuPrime
hardware products or any accessories, even if packaged or sold with NuPrime hardware. Non-NuPrime manufacturers,
suppliers, may provide their own warranties. Other accessories distributed by NuPrime under the NuPrime brand name are
not covered under this Limited Warranty. This warranty does not apply: (a) to damage caused by accident, abuse, misuse,
misapplication, liquid contact, re, earthquake, non-NuPrime products, or other external causes; (b) to damage caused by
service performed by anyone who is not a NASP; (c) to a product or a part that has been modi ed without the written
permission of NuPrime; (d) to consumable parts, such as batteries, or protective coatings designed to diminish over time
unless failure has occurred due to a defect in materials or workmanship; (e) to cosmetic damage, including but not limited to
scratches, dents, and broken plastic on ports; (f) to defects caused by normal wear and tear or otherwise due to the normal
aging of the product; or (g) if any NuPrime serial number has been removed or defaced.
Important: Do not open the hardware product. Opening the hardware product may cause damage that is not covered by this
warranty. Only NuPrime or a NASP should perform service on this hardware product.
THIS WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES,
REMEDIES AND CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. NUPRIME SPECIFICALLY DISCLAIMS
ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. IF NUPRIME CANNOT LAWFULLY DISCLAIM IMPLIED WARRANTIES UNDER THIS
LIMITED WARRANTY, ALL SUCH WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. No NuPrime reseller, agent,
or employee is authorized to make any modi cation, extension, or addition to this warranty.

19
NUPRIME IS NOT RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
ANY BREACH OF WARRANTY OR CONDITION, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT LIMITED
TO LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPLACEMENT OF EQUIPMENT AND PROPERTY, ANY
COSTS OF RECOVERING, REPROGRAMMING, OR REPRODUCING ANY PROGRAM OR DATA STORED IN OR USED WITH
NUPRIME PRODUCTS, AND ANY FAILURE TO MAINTAIN THE CONFIDENTIALITY OF DATA STORED ON THE PRODUCT.
NUPRIME SPECIFICALLY DOES NOT REPRESENT THAT IT WILL BE ABLE TO REPAIR ANY PRODUCT UNDER THIS
WARRANTY OR MAKE A PRODUCT EXCHANGE WITHOUT RISK TO OR LOSS OF PROGRAMS OR DATA.
Some states and provinces do not allow the exclusion or limitation of incidental or consequential damages or exclusions or
limitations on the duration of implied warranties or conditions, so the above limitations or exclusions may not apply to you.
This warranty gives you speci c legal rights, and you may also have other rights that vary by state or province.
Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the unit is within the Warranty period
must be presented to obtain warranty service.
REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER.
NUPRIME SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN
DURATION TO THE DURATION OF THIS WARRANTY.
© 2016 NuPrime Audio, Inc. All rights reserved. 1712 Pioneer Ave. Ste 1850 Cheyenne Wyoming 82001 USA
