NuPrime MCX-800MZ User manual

USER’S MANUAL
Multi-zone multi-room system 8-channel amplifier, using adaptive
voltage gallium nitride switching power supply technology, with
explosive power and ultra-low distortion characteristics. MCX-800MZ

www.nuprimeaudio.com
Table of Contents
..................................................................... 2
....................................................................................................... 3
......................................................................................................................... 4
Introduction ................................................................................................................................... 7
...............................
..........................................................................................................................
.....................................................................................................................................
................................................................................................. 8
. 9
. 12
................................ .............................14
1
Quick Start Guide
Connection
FCC Notice - Declaration of Conformity Information
EU Declaration of Conformity
Safety Instructions
Specifications
NuPrime’s Limited Warranty and Limitation of Liabilities

www.nuprimeaudio.com
FCC Notice - Declaration of Conformity Information
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
WARNING: Only peripherals complying with the FCC class B limits may be attached to this
equipment.
Changes or modifications made to this equipment, not expressly approved by us or parties
authorized by us could void the user’s authority to operate the equipment. This device complies
with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
2

www.nuprimeaudio.com
EU Declaration of Conformity
Hereby, NuPrime Audio, Inc. declares that this device is in compliance with the essential
requirements and other relevant provisions of Directive 2004/108/EC.
The manufacturer of this product is NuPrime Audio, Inc., 1712 Pioneer Ave. Ste 1817, Cheyenne,
Wyoming 82001, USA.
The Authorized Representative for EMC and product safety is NuPrime Audio, Inc., 1712 Pioneer
Ave. Ste 1817, Cheyenne, Wyoming 82001, USA.
For any service or guarantee matters please refer to the addresses given in separate service or
guarantee documents.
For Customers in Europe
Disposal of Old Electrical & Electronic Equipment (Applicable in the European
Union and other European countries with separate collection systems)
This symbol on the product or on its packaging indicates that this product shall
not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. The
recycling of materials will help to conserve natural resources. For more detailed information
about recycling of this product, please contact your local Civic Office, your household waste
disposal service or the shop where you purchased the product.
3

www.nuprimeaudio.com
Safety Instructions
There are two categories of Safety Instructions included in this manual:
•Product Warnings, (i.e., what must never be done to assure avoiding those hazards that
•could cause bodily injury or property damage); and
•User Directions (i.e., what must always be done to assure the safe use of your device).
The Safety Instructions contained in this manual have been categorized in accordance with the
seriousness of the potential hazards through the use of Signal Words. Those Signal Words, and
their intended meanings, are as follows:
DANGER: Indicates that a failure to observe the Safety Instructions could result in death or
catastrophic bodily injury.
WARNING: Indicates that a failure to observe the Safety Instructions could result in serious
bodily injury.
CAUTION: Indicates that a failure to observe the Safety Instructions could result in minor bodily
injury or property damage.
NOTE: Designates important information that relates to activities and/or conditions that might
result in loss of data and/or damage to your device.
Safe Use and Operation of Your Device
This equipment emits stray RF energy and will interfere with the reception of signals by airborne
electronic navigational devices or medical devices. Do not operate this equipment near any
sensitive medical devices.
WARNING: Use only grounded AC power cords.
Always immediately disconnect the power to the equipment in the event the device emits an
unusual odor or sound or generates smoke.
4

WARNING: Never attempt to disassemble, repair or make any modification to your device.
Disassembly, modification or any attempt at repair could cause bodily injury or property damage,
as well as damage to the device itself.
WARNING: Your device is not a toy. Never allow children to play with your device. Misuse, rough
or improper handling of your device by children could result in serious bodily injury for any of the
enumerated safety warnings in this manual. In addition, always keep all accessories and
components out of the reach of small children as small parts might present a choking hazard.
Seek immediate medical attention if choking occurs or if any small part has been swallowed.
CAUTION: Never raise the sound volume level too high when using your device with earphones.
An excessive sound volume level could cause damage to your hearing.
WARNING: To reduce the risk of re or electric shock, do not expose the unit to moisture or water.
Do not allow foreign objects to get into the enclosure. If the unit is exposed to moisture, or a
foreign object gets into the enclosure, immediately disconnect the power cord from the wall.
Take the unit to a qualified service person for inspection and necessary repairs.
Read all the instructions before connecting or operating the component.
Keep this manual so you can refer to these safety instructions.
Heed all warnings and safety information in these instructions and on the product itself. Follow
all operating instructions.
Do not use this unit near water.
You must allow a minimum 10 cm or 4 inches of unobstructed clearance around the unit.
Do not place the unit on a bed, sofa, rug, or similar surface that could block the ventilation
openings. If the unit is placed in a bookcase or cabinet, there must be ventilation of the cabinet to
allow proper cooling.
www.nuprimeaudio.com
5

any other appliance that
on the rear
Keep the component away from radiators, heat registers, stoves, or
produces heat.
The unit must be connected to a power supply only of the type and voltage speci ed
panel. Connect the component to the power outlet only with the supplied power supply cable or
an exact equivalent. Do not modify the supplied cable.
Do not route the power cord where it will be crushed, pinched, bent, exposed to heat, or
damaged in any way. Pay particular attention to the power cord at the plug and where the cord
exits the back of the unit.
The power cord should be unplugged from the wall outlet during a lightning storm or if the unit is
to be left unused for a long period of time.
Immediately stop using the component and have it inspected and/or serviced by a quali ed
service agency if:
•The power supply cord or plug has been damaged.
•Objects have fallen or liquid has been spilled into the unit.
•The unit has been exposed to rain.
•The unit shows signs of improper operation.
•The unit has been dropped or damaged in any way
www.nuprimeaudio.com
6

www.nuprimeaudio.com
7
Introduction
The NuPrime MCX-800MZ is a multizone eight channels amplifier that has four stereo modules, each with
its own Adaptive Voltage Switching Power Supply technology and integrated amplifier incorporating high-
speed gate driver error correction. This technology enables each module to deliver explosive power and
ultra-low distortion, with a neutral and detailed sound characteristic. The MCX-800MZ has advanced
protection circuitry that safeguards it from fault conditions such as short circuits, overload, overtemperature,
and under-voltage.
The Adaptive Voltage Switching Power Supply is the most innovative SMPS design introduced by NuPrime.
The amplifier's output signal feeds back into the power supply's servo power stage, causing a change in the
output voltages supplying the power stage of the amplifier. This design resulted in more details at a low
music level and explosive power at a high volume.
AC IN
Servo power
Anti-jamming and
eliminating noise
Gain
Controller
Power
Amplifier
Balanced
Matched
Voltage
Amplification
Primary voltage
regulation
Analog
Voltage
Secondary
voltage regulation
VD VC
VE
VC VD
VE
VB USB
+
-VA
+
-VA
+
-VA
+
-VA
FB II
FB II
550-600 kHz
High Frequency
Class D Power Stage
Isolated
switching
power
supply
Isolated
switching
power
supply
FB I
FB I
FB III
FB III
FB III
Modern floating voltage technology causes the voltage to change in accordance with the strength of the incoming music signal.
Block Diagram

www.nuprimeaudio.com
8
Specifications:
Inputs
• Inputs: Switch L position: RCA analog input x 8
Switch B position: XLR analog input x 2
Switch A position: RCA analog input x 2
•Trigger in (DC 0V~15V). Floating or (DC 3V~15V) as running; less than 0.7V as standby.
Outputs
• Stereo Speaker Out x 8
• Line Out : XLR analog Out x 2 , RCA analog Out x 2
• Trigger Out (12V,＜0.1A)
• DC 5V Output via Type-A USB Connector (Maximum output 1.6A) x 2
**When only using one USB power, the maximum output current can reach 2A.
Amplifier
• Power: 120W@8 Ohms/channel
• Power: 210W@4 Ohms/channel
• Peak Output Power: 170W@8 Ohms/channel
• Peak Output Power: 300W@4 Ohms/channel
• Input Impedance: 47k Ohms
• Gain Adjustable: Magnification x 17~x 32 is adjusted through variable resistor
• Signal to Noise Ratio: > 95dB at 1W, 10W, 100W
• THD+N: <0.005%
• Frequency Response: 10Hz to 50kHz
• Worldwide AC voltage: US Version 100 ~ 120Vac, Europe version 220 ~ 240Vac,AC voltage not switchable
• AC Fuse: Slow-blow, 15A/250V(US Version) , 10A/250V(Europe version)
• Dimension: 430 mm W x 330 mm D x 105 mm H (including feet)
• Weight: 10.5 kg
• Color: Black

Quick Start Guide
Front Panel View:
Light indication
LED 1 : Power-on and standby status lights: Orange light: MUTE /// Blue light: Power on Power supply
thermal protection: no light
LED 2 : Fault code indicator: Yellow light: power amplifier fault indication /// Red light: overload protection
1
2
Power
www.nuprimeaudio.com
9

Back Panel View:
Inputs switch :
L: Each channel has an independent input ( LINE IN )
B: All inputs are transmitted through XLR cable ( BUS B )
A: All inputs are transmitted through RCA cable ( BUS A )
Inputs :
Switch L position : RCA analog input x 8
Switch B position : XLR analog input x 2
Switch A position : RCA analog input x 2
Outputs :
Stereo Speaker Out x 8
XLR analog BUS Out x 2
RCA analog BUS Out x 2
DC 5V Output x2
www.nuprimeaudio.com
10
1
2
3
4
5
6
7
8
LINE
IN
LINE
IN
LINE
IN
LINE
IN
BUS MUTE
MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX
L
B
A
BUS
L
B
A
BUS
L
B
A
BUS
L
B
A
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
BUS INPUT
A
A
B
B
BUS OUTPUT
TRIGGER
DC OUT

Control:
GAIN Control VR x 8
MUTE Control x 2 (Please see the description on page 12)
Trigger in x 1
Trigger out x 1
BUS Function :
BUS L : When the switch is in the L position (LINE IN), each channel has an independent input to drive
each corresponding speaker output.
BUS B : When the switch is in the B position(BUS B), all inputs are transmitted through BUS B XLR
cable , the left channel drives speaker outputs 1, 3, 5, and 7,the right channel drives speaker
outputs 2, 4, 6, and 8 and Bus Output can feed Bus input of another MCX-800MZ.
BUS A : When the switch is in the A position(BUS A), all inputs are transmitted through BUS A RCA
cable , the left channel drives speaker outputs 1, 3, 5, and 7,the right channel drives speaker
outputs 2, 4, 6, and 8 and Bus Output can feed Bus input of another MCX-800MZ.
www.nuprimeaudio.com
11

1
2
3
4
5
6
7
8
LINE
IN
LINE
IN
LINE
IN
LINE
IN
BUS MUTE
MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX MIN MAX
L
B
A
BUS
L
B
A
BUS
L
B
A
BUS
L
B
A
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8
BUS INPUT
A
A
B
B
BUS OUTPUT
TRIGGER
DC OUT
Connection:
L
B
AMIN MAX
www.nuprimeaudio.com
12
Analog RCA
Preamplier
or CD/DVD/BD player
MUTE
GAIN Control VR
1 2 3
1 and 2 short CH5 and CH6 channels muted.
3 and 2 short CH7 and CH8 channels muted.
1 and 2 short CH1 and CH2 channels muted.
3 and 2 short CH3 and CH4 channels muted.
BUS Switch
MUTE
1 2 3
Mono
Speakers

www.nuprimeaudio.com
13
DAC-9X
WR-2
Stream-mini-DAC
.........
Can connect multiple MCX-800MZ
Analog RCA
XLR output

www.nuprimeaudio.com
14
NuPrime’s Limited Warranty and Limitation of Liabilities
ADDITIONAL RIGHTS
For consumers, who are covered by consumer protection laws or regulations in their country of
purchase or, if different, their country of residence, the benefits conferred by this warranty are in
addition to all rights and remedies conveyed by such consumer protection laws and regulations.
This warranty does not exclude, limit or suspend any rights of consumers arising out of
nonconformity with a sales contract. Some countries, states and provinces do not allow the
exclusion or limitation of incidental or consequential damages or allow limitations on how long an
implied warranty or condition may last, so the limitations or exclusions described below may not
apply to you. This warranty gives you specific legal rights, and you may also have other rights that
vary by country, state or province. This limited warranty is governed by and construed under the
laws of the country in which the product purchase took place.
LIMITED WARRANTY
For a period of ONE (1) YEAR from the date of retail purchase by the original end-user purchaser
(“Warranty Period”), NuPrime warrants (in) this product against defects in materials and
workmanship, and (ii) that each Product, unmodified and under normal use and conditions, will
substantially comply with NuPrime’ applicable written technical documentation for the Product.
NuPrime reserves the right to make substitutions and modifications from time to time in the
specifications of Products sold by NuPrime, provided that such substitutions or modifications do
not materially affect overall Product performance.
If a hardware defect exists and a valid claim is received within the Warranty Period, at its option
and to the extent permitted by law, NuPrime will (1) repair the hardware defect at no charge,
using new or refurbished replacement parts, (2) exchange the product with a product that is new
or which has been manufactured from new or serviceable used parts and is at least functionally
equivalent to the original product, or (3) refund the purchase price of the product. NuPrime may
request that you replace defective parts with user-installable new or refurbished parts that
NuPrime provides in fulfillment of its warranty obligation. A replacement product/part assumes

www.nuprimeaudio.com
15
the remaining warranty of the original product or ninety (90) days from the date of replacement
or repair, whichever provides longer coverage for you. When a product or part is exchanged, any
replacement item becomes your property and the replaced item becomes NuPrime's property.
When a refund is given, your product becomes NuPrime's property.
OBTAINING WARRANTY SERVICE
If you purchased the product in the U.S., deliver the product, at your expense, to any NuPrime
Service Center located in the U.S. If you purchased the product outside of the U.S., deliver the
product to any NuPrime Authorized Importer in the country where you purchased the product.
Be aware, however, that not all countries have NuPrime Authorized Service Providers (‘NASP’)
and not all Authorized Service Providers outside the country of purchase have all parts or
replacement units for the product. If the product cannot be repaired or replaced in the country it
is in, it may need to be sent to a different country or returned to the country of purchase at your
expense for repair or replacement. If you seek service in a country that is not the country of
original purchase, you will comply with all applicable import and export laws and regulations and
be responsible for all custom duties, V.A.T. and other associated taxes and charges. Where
international service is available, NuPrime may repair or exchange defective products and parts
with comparable products and parts that comply with local standards.
You can always deliver the product to NuPrime’s U.S.A or Taiwan service center for obtaining
warranty service, however, you may have to pay for shipping cost.
NuPrime may send you user-installable new or refurbished replacement product or parts to
enable you to service or exchange your own product (“DIY Service”). Upon receipt of the
replacement product or part, the original product or part becomes the property of NuPrime and
you agree to follow instructions, including, if required, arranging the return of original product or
part to NuPrime in a timely manner.
When providing DIY Service requiring the return of the original product or part, NuPrime may
require a credit card authorization as security for the retail price of the replacement product or
part and applicable shipping costs. If you follow instructions, NuPrime will cancel the credit card

www.nuprimeaudio.com
16

www.nuprimeaudio.com
17

Scan to e-Manual
