MODEL CAT
01
TV OVER CAT5 DISTRIBUTION AMPLIFIER
The CAT01 is a high output distribution amplifier specially designed to distribute TV signal over CAT5/6 cable.
The amplifier has four separate RJ45 outputs each with an individual gain control. The amplifier also has an
overall gain and tilt control.
INSTALLATION
Connect the RF signal to the RF input of the amplifier.
Note: If the input signal is to low it may be necessary to install a pre- amplifier
(MDA20H and KPS06 power supply).
Connect the DC power supply to the DC input socket.
Make an overall loss calculation for each of the CAT5 cables to be connected, the loss per 10 metres is
approximately 6 dB (CAT6 @ 700 MHz). Adjust the respective output gain controls to compensate for losses
in the cable.
Connect CAT5/6 patch cables to the outputs of the CAT01.
Note: Ensure to leave the terminators in place on any ports that are not to be used.
Adjust the overall gain and tilt controls to the required output.
Connect your television to the RJ45 wall socket which has been fed RF signal via the CAT01 using a KLE02
Balun transformer cable. Repeat for all televisions you wish to connect to the CAT01.
Once all televisions are connected fine adjust the output gain controls if required for optimum performance.
INSTALLATION MANUAL
Specialists in TV signal amplification
46984-1 CAT01 Manual
Includes FOLD LINES - DO NOT PRINT
Total 120 mm wide by 200 mm high double sided
Folds at 40 mm intervals
80 gsm - One colour - Black 100%
RECOMMENDED SIGNAL LEVELS dBuV
Number of channels 42 10 2 Measurement location
Min input level dBuV 63 63 63 Input RF signal
Min output level dBuV 87 87 87 KLE02 connected to output
Max output level 96 102 111 KLE02 connected to output
ACCESSORIES
19” mounting panel with blanking plate KB02
KLE02 Balun transformer cable Terminator PL041
46984-1_CAT01_manual.indd 1 24/05/13 5:14 PM
STANDARD COMMUNICATIONS CONTRACT WARRANTY AGAINST DEFECTS
This warranty against defects is given by Standard Communications
Pty Ltd ACN 000 346 814 (We, us, our or GME). Our contact details
are set out in clause 2.7. This warranty statement only applies to
products purchased in Australia. Please contact your local GME
distributor for products sold outside of Australia. Local distributor
details at www.gme.net.au/export.
1. Consumer guarantees
1.1 Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are
also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not
amount to a major failure.
1.2 To the extent we are able, we exclude all other conditions,
warranties and obligations which would otherwise be implied.
2. Warranty against defects
2.1 This warranty is in addition to and does not limit, exclude or
restrict your rights under the Competition and Consumer Act
2010 (Australia) or any other mandatory protection laws that
may apply.
2.2 We warrant our goods to be free from defects in materials
and workmanship for the warranty period (see warranty table)
from the date of original sale (or another period we agree to
in writing). Subject to our obligations under clause 1.2, we
will at our option, either repair or replace goods which we
are satisfied are defective.We warrant any replacement parts
for the remainder of the period of warranty for the goods into
which they are incorporated.
2.3 To the extent permitted by law, our sole liability for breach
of a condition, warranty or other obligation implied by law is
limited:
(a) in the case of goods we supply, to any one of the following
as we decide -
(i) the replacement of the goods or the supply of equivalent
goods;
(ii) the repair of the goods;
(iii) the cost of repairing the goods or of acquiring equivalent
goods;
(b) in the case of services we supply, to any one of the
following as we decide –
(i) the supplying of the services again;
(ii) the cost of having the services supplied again.
2.4 For repairs outside the warranty period, we warrant our repairs
to be free from defects in materials and workmanship for three
months from the date of the original repair. We agree to re-
repair or replace (at our option) any materials or workmanship
which we are satisfied are defective.
2.5 We warrant that we will perform services with reasonable care
and skill and agree to investigate any complaint regarding
our services made in good faith. If we are satisfied that the
complaint is justified, and as our sole liability to you under this
warranty (to the extent permitted at law), we agree to supply
those services again at no extra charge to you.
2.6 To make a warranty claim you must before the end of the
applicable warranty period (see warranty table), at your own
cost, return the goods you allege are defective, provide written
details of the defect, and give us an original or copy of the
sales invoice or some other evidence showing details of the
transaction.
2.7 Send your claim to:
Standard Communications Pty Ltd.
17 Gibbon Rd, Winston Hills, NSW 2153, Australia.
Tel: (02) 8867 6000, Fax: (02) 8867 6199
Email: servadmin@gme.net.au
2.8 If we determine that your goods are defective, we will pay for
the cost of returning the repaired or replaced goods to you,
and reimburse you for your reasonable expenses of sending
your warranty claim to us.
3. What this warranty does not cover
3.1 This warranty will not apply in relation to:
(a) goods modified or altered in any way;
(b) defects and damage caused by use with non Standard
Communications products;
(c) repairs performed other than by our authorised
representative;
(d) defects or damage resulting from misuse, accident, impact
or neglect;
(e) goods improperly installed or used in a manner contrary to
the relevant instruction manual; or
(f) goods where the serial number has been removed or made
illegal.
4. Warranty period
4.1 We provide the following warranty on GME and Kingray
products. No repair or replacement during the warranty period
will renew or extend the warranty period past the period from
original date of purchase.
Product Type Warranty
Period
Kingray amplifiers, modulators, diplexers and
filters, Kingray plug pack power supplies,
Kingray Professional rack mount products.
3 years
Drawing No: 46984-1 Part No: 310612
46984-1_CAT01_manual.indd 2 24/05/13 5:14 PM
