NUTRICHEF PKSTMOVN72 User manual

Digital Convection Oven Cooker & Steamer
PKSTMOVN72
Smart Multi-Function Oven Cooker & Food Steamer
Digital Convection Oven & Air Fryer (Stainless Steel)

Contents
Product Structural Diagram ----------------------------------------------------------------------------- 2
Notices for Use ------------------------------------------------------------------------------------------------- 4
Control Panel ---------------------------------------------------------------------------------------------------- 6
DISPLAY PCB ---------------------------------------------------------------------------------------------------- 6
Operating Instructions ------------------------------------------------------------------------------------- 8
Menu -------------------------------------------------------------------------------------------------------------- 13
Other Functions ---------------------------------------------------------------------------------------------- 14
Cleaning and Maintenance ----------------------------------------------------------------------------- 16
Guideline for Troubleshooting ----------------------------------------------------------------------- 17
Specication --------------------------------------------------------------------------------------------------- 18
www.NutrichefKitchen.com
1

Product Structural Diagram
1. Control Panel 2. Fork Assembly 3. Fork Handle 4. Grill
5. Bakeware 6. Water tank 7. Handle 8. Door
9. Water tray 10. Body 11. Door switch 12. Glove
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cord, plugs in water or other
liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking o parts.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return appliance to the
nearest authorized service facility for examination, repair, or adjustment.
7. The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
8. Do not use outdoors. Household use only.
www.NutrichefKitchen.com 2

4
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution must be used when moving an appliance containing hot oil or
other hot liquids.
12. Always attach plug to appliance rst, then plug cord into the wall outlet.
To disconnect, turn any control to "OFF", then remove plug from wall outlet.
13. Do not use appliance for other than intended use.
14. Oversize foods or metal utensils must not be inserted in a toaster-oven as they
may create a re or risk of electric shock.
15. A re may occur if the toaster-oven is covered or touching ammable material,
including curtains, draperies, walls, and the like, when in operation. Do not store
any item on top of the appliance when in operation.
16. Do not clean with metal scouring pads. Pieces can break o the pad and touch
electrical parts involving a risk of electric shock.
17. Extreme caution should be exercised when using containers constructed of
other than metal or glass.
18. Do not store any materials, other than manufacturers recommended
accessories, in this oven when not in use.
19. Do not place any of the following materials in the oven: paper, cardboard,
plastic or any ammable materials.
20. Do not cover crumb tray or any part of the oven with metal foil. This will cause
overheating of the oven.
21. Use extreme caution when removing tray or disposing of hot grease.
22. When the appliance is operating, press the ON/OFF key, the appliance will
return to o.
SAVE THESE INSTRUCTIONS.
WARNING
1. Do not rinse the shell of the product in water because there are electric
components in the shell;
2. Do not allow water or other liquids to enter the product to avoid electric shock;
3. This product is not suitable to be used by children under 8 years old and anyone
who has unsound body and sensory or mental disability or lacks of related
experiences and knowledge unless they are instructed to use this product and
supervised to master the operation methods;
4. Please check whether the voltage of the product matches the voltage of local
power supply before the product is connected to the power supply;
www.NutrichefKitchen.com
3

5
5. Do not use this product if the plug, power cord or the product is damaged;
6. If the power cord is damaged, it must be replaced by the manufacturer or its
professional service technicians in order to avoid the danger;
7. Please take care of the children to make sure they do not play this product;
8. Do not use wet hands to insert the plug or operation console of this product;
9. Do not place this product on or near the tablecloths, curtains and other
ammable materials;
10. A free space of at least 15cm shall be reserved on the back and two sides and
over the product when the product is placed. Do not place any item on the
product;
11. The product in use must be watched;
12. A high temperature steam or high temperature airow will be released when
you open its door during or after the cooling operation of the product. A safe
distance shall be maintained when the door of the product is opened to avoid
scalding yourself;
13. Do not stu any foreign matter into door lock switch of the oven door;
14. The recommended temperature probe to this oven must be used;
15. Appliances will heat during the use. Please pay attention to the heating unit in
the oven.
Notices for Use
1. Please read the Instructions carefully before the use. This product is designed
specially for the home heating and cooling of food and it is not suitable for other
public and commercial purposes;
2. Do not touch at random the steam oven in use because it may have a very high
surface temperature; If it is needed to touch or move the oven, please power o
the product rstly and then use the insulated gloves;
3. The oven cannot be cleaned unless the power plug has been unplugged and the
oven is cooled down;
4. The steam oven shall be kept in a dry and at place with plenty of space around it
and a distance of at least 15cm shall be kept away from the surrounding objects
when it is used;
5. An overloaded circuit may cause the steam oven to work abnormally when the
product is used, and therefore, the steam oven shall use a single circuit;
6. Do not put the steam oven near any ammable object. It shall be kept far away
from window curtains, door curtains, wallpapers and similar items to prevent a
re. It is not allowed to put any object on the steam oven when it works;
www.NutrichefKitchen.com 4

www.NutrichefKitchen.com
5
7. Please clean the door glass of the oven with a soft and wet cloth rather than any
sharp cleaning tools to prevent the damage to the door glass;
8. The appliance cannot be operated under the circumstances that it connects the
external timer or the independent remote control system;
9. Please do not share an outlet with other high-power electrical devices to avoid
the re caused by the overload of the circuit;
10. Please check whether all cooking utensils are suitable for this product before it
is used. It is recommended to hold the food with high-temperature glass or
ceramic containers; the capacity of holding the liquid food may not exceed
two-thirds of the container;
11. It is required to unplug the power plug from the outlet when the oven will not
be used for a long time to avoid any electric leakage or re caused by aging of
insulated rubber lines;
12. The power plug shall be unplugged when changing the lights or cleaning the
cavity to avoid possible electric shock;
13. The water tank shall not be overlled with water. Please use it correctly since
there is a marked maximum water level scale;
14. The food is not allowed to rely on the horizontal plane of door glass to prevent
the product from scalding yourself due to its inclination after the end of
cooking operation;
15. Please take out the water tank and allow the residual water of the product to
ow out automatically from the product and drain or pour away the water from
the bottom water holder after each use of the oven for cooking operation;
16. It is forbidden to heat the food in a sealed container because the sealed
container is possible to explode, such as, sealed bottles, boxed milk, etc. It is
necessary to tear the package and drop the food into other vessels for heating.
A free space of at least 15cm shall be reserved on the back and two sides and over
the product when the product is placed. Do not place any item on the product;
DIY
F
F
15CM 15CM
15CM
15CM

5
Control Panel
DISPLAY PCB
www.NutrichefKitchen.com 6
① ② ③ ④ ⑤
7
6
D I Y
F
F
07
01
02
03
04
05
06
Icon Function Description
Oven lamp/child lock key:
1. Touch it once, oven lamp is ON; touch it again, oven lamp goes out;
2. Oven lamp will be ON for three minutes after the work is over;
3. Oven lamp will be ON for three minutes when the oven door is opened;
4. The key turns to child lock by holding it down for three seconds; in
the standby mode, hold it down once, it is locked; press it again to
unlock.
Setting key: preset and time-delay
1. In any programs standby mode, press this key to enter the preset mode
and preset icon is ON;
2. After any programs working end, Press this key to enter the time-delay
and the time-delay icon is ON;function status
BACK key: press this key to return to the previous setting mode before start
working, and press it again to return again.
Selection key( : Reverse function)
1. Select 9 DIY regular function modes and 10 specific working modes;
2. Adjust the time;
3. Adjust the temperature.
ON/OFF key: press this key to activate all icons to light up; In the
activation or working status of the machine press this key to exit the
running mode, and the machine will return to the standby status.
Selection key( :Forward function)
1. Select 9 DIY regular function modes and 10 specific working modes
in a forwarding sequence;
2. Adjust the time;
3. Adjust the temperature.
ENTER key:
1. Start;
2. Pause;
3. Enter.
D I Y
F
F

www.NutrichefKitchen.com
7
01
02
03
04
05
06
07
08
9
10
11
12
13
14
16
17
18
19
20
21
Function Description
DIY
Time
Temperature
Preset function
prompt
prompt
Water level icon
Prompt for
cleaning of
water
Children lock
Prompt for
descaling
Top heater pipe
Prompt for a
high temperature
Ferment
Preheat
Making Yogurt
Dry fruit
and bake nuts
steam menu
Roast meat
Bake
DIY mode
Descaling
The first two LEDs are hours (0-24)and the
second two LEDs are minutes (0-59)
Adjustable range: 85 450°F - °F
Icon is always ON for water; aflashing light
means alack of water.
This menu contains 9 programs and recipes for
This menu contains 9 programs and recipes
This menu contains 9 programs and recipes
This menu contains 9 programs and recipes
Baking method and time shall be set by
customers themselves
Remind to clean the scale in the evaporating
heater (steam heater)
Working time
-delay
Bottom heater
pipe
different fruits and bake different nuts
for fish and different meat
for different food
for different bread cake
15 This menu contains 9 programs and recipes
Air Fryer
F
F
tray

Operating Instructions
1. First Energization
The machine enters the full-screen standby interface after a “beep” sound when
it is energized rstly by touching power ON . During the setting process, if
there is no operation for continuous in three minutes all current settings will be
cancelled and the machine will return to the standby interface for a standby
status.
2. Menu Selection
In the standby status, press the selection key “ ”“ ” to enter the menu
selection mode. Default menu “ ”steam function, press selection keys “ ”“ ”
to move left or right to select the menu mode
1. Ferment (steam function, default temperature 105°F, adjustable among 85
-120°F; time adjustable among 0-7 hours)
2. Preheat (temperature is not adjustable). It is set as 360°F. When the temperature
reaches 360°F, the work is over, the display shows “END” and the buzzer will beep
for 10 times to prompt that the preheating work is completed and you can
continue the baking operation;
3. Making Yogurt (default temperature 115°F that is not adjustable, and default
time of 8 hours that is not adjustable)
4. When this menu “Air Fryer” is selected, icon is ON. The temperature display
column will show“P-1”, and meanwhile, the time display column will show the
required working time. Press the selection key “ ”, the temperature display
column will show“P-1”, “P-2”, “P-3”… “P-9”.. “P-1”, and repeat this circle, and the
corresponding time column will show the required time. Press the ENTER key “ ”,
the machine begins to work and the time begins to count down.
5. Dry fruits or bake nuts. When this menu is selected, icon is ON, and the
temperature display column will show “L-1”, and meanwhile, the time display
column will show the required working time. Press the selection key, the
temperature display column will show “L-2”,“L-3”, “L-4”, … “L-9”...“L-1”, and repeat
this circle, and the corresponding time column will show the required time. Press
the ENTER key , the machine begins to work and the time begins to count down.
6. When this menu “Steam” is selected, icon is ON. The temperature display
column will show“E-1”, and meanwhile, the time display column will show the
required working time. Press the selection key “ ” , the temperature display
column will show“E-1”, “E-2”, “E-3” … “E-9”.. “E-1”, and repeat this circle, and the
corresponding time column will show the required time. Press the ENTER key “ ”,
the machine begins to work and the time begins to count down.
5
www.NutrichefKitchen.com 8
DIY
F
F

www.NutrichefKitchen.com
9
7. When the menu “Roast” is selected, icon is ON. The temperature display
column will show“F-1”, and meanwhile, the time display column will show the
required working time. Press the selection key “ ”, the temperature display
column will show“F-1”, “F-2”, “F-3” … “F-9”.. “F-1”, and repeat this circle, and the
corresponding time column will show the required time. Press the ENTER key, the
machine begins to work and the time begins to count down.
8. When the menu “Bake” is selected, icon is ON. The temperature display
column will show“H-1”, and meanwhile, the time display column will show the
required working time. Press the selection key “ ”, the temperature display
column will show“H-1”, “H-2”, “H-3” … “H-9”.. “H-1”, and repeat this circle, and the
corresponding time column will show the required time. Press the ENTER key, the
machine begins to work and the time begins to count down.
9. When the menu DIY is selected, the “steam”function icon in upper left corner is
ON. Press the selection key “ ”to enter the function selection mode. The display
column at the left side of the screen will show the corresponding function icon,
as shown in the following gure. There are 9 DIY regular function modes. Each
gear of the key corresponds to a function. The key moves a gear, the function icon
will automatically jump down to ash, and the frame will not ash. After the
desired function is selected, it can be conrmed by press the ENTER key
10. When the menu “Descaling” is selected, the icon is ON to remove the scale.
(Working time of 50 minutes is not adjustable. The work process cannot be paused)
3. Setting of working hours and temperature
After the desired function is selected, it shall be conrmed by pressing the ENTER
key to enter the setting of working hours. The hour bit will ash. Press the
selection key to set the hour bit. After it is conrmed by pressing the ENTER key,
the minute bit will ash, and then press the selection key to set the minute bit.
After it is conrmed by pressing the ENTER key, the temperature bit will ash,
and then press the selection key to set the working temperature for “Top heater
pipe” and “Bottom heater pipe”. After the setting of working temperature is
nished, press the ENTER key to start working.
For example, the setting of “Top heater pipe” working mode:
1. Select function
F
°F
F
