Nuvico Xcel NCT-8ML2-E21AF User manual

Package
Overview
Installation
1
2
3
4
►Connecting Network Cable
Warning and Caution
Camera Quick start guide
Plastic plug ×4
Drill template
Allen Key
Tapping screw ×4
Before you start, please make sure that the wall or ceiling is
strong enough to withstand three times the weight of the camera.
① Loosen the fixed screw to disassemble the camera.
②
that, install the cover back.
Open the cover of the dome and then insert a micro SD card. After
■Please read these instructions carefully before operating the unit
and keep it for further reference.
■All the examples and pictures used here are for reference only.
■The contents of this manual are subject to change without notice.
■Visit nuvico.com for additional downloads, manuals, and resources.
* 1 It is recommended to install the security cap for outdoor installation.
* 2 If the PoE switch is used to power the camera, DC12V power supply is not
required.
Security Cap
2
13
Fixed Screw Mounting Base
Enclosure
Dome
1
2
3
4
5
6
7
8
Ethernet connector
Audio input connector
Power connector
Mounting base
Fixed screw
Microphone
Micro SD card slot
Reset
78
Insert a micro SD card
Cover
DC12V
1
2
3
4
5
6
Note: *Check whether the waterproof ring on the card slot cover is
installed properly before installing the cover back.
* Please install the cover in the same way you disassemble it, so that
the sealing performance will not be affected.
NCT-8ML2-E21AF Eyeball Camera
Quick Start Guide
■If the product does not work properly, please contact your dealer or
the nearest service center. Never attempt to disassemble the camera
yourself. (We shall not be responsible for any problems caused by
unauthorized repair or maintenance.)
■Do not allow water or liquid intrusion into the camera.
■In the use of the product, you must be in strict compliance with the
electrical safety regulations of the nation and region. When the product is
mounted on wall or ceiling, the device shall be firmly fixed.
■Do not use camera beyond specified voltage range.
■Do not drop the camera or subject it to physical shock.
■Avoid touching the camera lens.
■If cleaning is necessary, please use clean cloth to wipe it gently.
■Avoid pointing the camera towards the sun or other light sources.
■Do not place the camera in extremely hot, cold (the operating
temperature shall be -22˚F~140˚F), dusty or damp locations, and do not
expose it to high electromagnetic radiation.
■To avoid heat accumulation, good ventilation is required for operating
environment.
③Connect the cable to the hermetic connector. Then tighten the nut
and the main cover.
①
②
Loosen the nut from the main element.
Run the network cable (without the RJ45 connector) through
both elements. Then crimp the cable with the RJ45 connector.

Network Connection
5
MENU
IPC
Network Cable Network Cable
Switch
Router Computer
●Access Through Xcel IP Utility
①Make sure that the camera and the PC are connected to the local
network.
②Download and install Xcel IP Utility from nuvico.com and run
it after installation.
Device Network Search
Immediate Refresh
Nuvico Xcel
Nuvico Xcel
Nuvico Xcel
IPC
IPC
IPC
NCT-8ML2-E2
NCT-5MLC-B2
NCT-5ML-OV2
192.168.226.201
192.168.1.2
192.168.1.3
80
80
80
9008
9008
9008
255.255.
255.255.
255.255.
Modify Netw ork Parameter
Mac Address
IP Address
Modify
CE :98 :23 :75 :3 5 :22
192 . 168 . 226 . 201
255 . 255 . 255 . 0
192 . 168 . 226 . 1
i
Tip: Enter the administrator password, and
then modify the network p arameter s.
Total Device: 3 Local IP Address:192.168.1.4Subne t Mask:255.255.255.0 Gateway: 19 2.168.1.1 DNS：21 0.21.196.6
Device Name Device Type IP Address Http Port Data Port Subnet
Product Mod el
About
Subnet Mask
Gateway
Restore IPC Default Configuration
③Modify the IP address. The default IP address of this camera is
192.168.226.201. Click the information of the camera listed in the
above table to show the network information on the right hand.
Modify the IP address and gateway of the camera and make sure its
network address is in the same local network segment as the
computer’s. Please modify the IP address of your device according
to the practical situation.
Mac Address
IP Address
Modify Network Parameter
Modify
CE :98 :23 :75 :35 :22
192 . 168 . 1 . 201
255 . 255 . 255 . 0
192 . 168 . 1 . 1
Subnet Mask
Gateway
450043001628 A0
⑤Install the dome and enclosure to the mounting base and then
adjust the dome to obtain an optimum view angle.
Ø107.7
Ø5.0
Ø79.4
56.1
56.1
④
ceiling or wall with the screws provided.
Route and connect the cables. T hen secure the mounting base to the
(mm)
Fixed Screw
Tilt: 80°
Pan: 360°
For example, the IP address of your computer is 192.168.1.4. So
the IP address of the camera shall be changed to 192.168.1.X. After
modification, please enter the password of the administrator and
click “Modify” button to modify the setting.
The default password of the administrator is “123456”.
④ Double click the IP address to open up the web browser or
manually enter the modified IP address in the address bar of your browser.
Then follow directions to download and run the plugin in the computer.
the user name and password in the login interface. ⑤Enter
③
the drill template.
Drill the screw holes and the cable hole on the wall according to
⑥Finally, tighten the fixed screw and make sure the camera is
fixed firmly.
The default username is admin; the default password is 123456.
