Nuvo Simplese System User manual

Simplese®
Four-Source, Four-Zone Audio Distribution System
www.nuvotechnologies.com
2395 Arbor Tech Drive, Hebron, KY 41048
Phone: [phone] Toll Free: 866-796-4904
Zones 1-4 Power Amplifier Outputs
Continuous Average Output Power 30W (15W x 2)
Two channels driven 30-20kHz @1% THD
Rated Distortion (1/2 power) 0.40%
Rated Impedance 6 Ohms
Damping Factor 50+
Frequency Response 20-20kHz
Preamplifier
Variable output 0-600mV
Fixed output 600mV
Impedance 600 Ohms
Source Inputs 1-4
Input Impedance 10K
Input Sensitivity for rated power 300mV RMS
Input Overload 3V RMS
Emitter Outputs
Source Outputs 4
Output Drive Current 50mA
Output Drive Voltage 5V
Source 1 and 2 38kHz/56kHz Selectable
Source 3 and 4 38kHz Fixed
System Specifications
System On 5V @ 50mA
External Mute 3-12V DC
Power Requirements
Power Supply 90-260VAC 50/60Hz
Power Consumption all channels 140W
driven to full-rated power
Power Consumption average 30W
operating conditions
Power Consumption no signal Less than 10W
Physical Specifications
Unit Size Millimeters 44H x 432W x 270D
Unit Size Inches 1.75H x 17W x 10.625D
Unit Weight Kilograms 2.95
Unit Weight Pounds 6.5
Keypad Size Millimeters 50H x 50W x 33.5D
NuVo reserves the right to change specifications without notice.
Simplese system package ships complete with the following:
• Simplese four-source, four-zone system
• 4 keypads (with trim plates)
• 36 pre-printed source buttons
• 1 LRC1 remote with batteries
• Allport® and Allport cable
• 4 IR emitters
• REM1U Rack Ear Mounts
SMP-159-0721C
Sim pl es e
3033118
CUS
R
T
E
E
T
K
N
I
CM
D
R
T
E
E
T
K
N
I
100~2 40V 50~60 Hz 85W
SENSITIVITY
-12
+6
0
LEFT
+6 -12
RIGHT
0
VOLTAGE
TRIGGER
3-30VOLTS
ACORDC
8OHM:70W X 2
4OHM:100W X 2
ON/OFFSWITCH
AUDIOAC/DC
POWER
MODE
Source 2
Tuner 2
Audio
Out
SOUR CE IN PUT
L
R
L
R
1234
L
R
ZONE 4
FIXED VA R
LINE O UT IR OUT
13
24
SYST EM
LINK
RS232
STATUS
ON=+1 2V
MUTE
=0V
SPEA KER AN D DATA SIGN ALS
ALL PO RT CONN ECTIO N
CONFORM S TO
ULS TD.65 00
CERTIFI ED TO
CAN/CSA S TD.E 6006 5
NuVo Techn ologi es Cinc innat i Ohio US A
FOUR-SOURCE FOUR-ZONE
USE FOR S AT
OR CABL E
NORMA L
USE
56KH z38KH z
1
2
Source 1
Tuner 1
Audio
Out
Source 4
DVD
Audio
Out
Source 3
CD
Audio
Out
Simplese D UK Wiring
Diagram
System shown using the optional NuVo
P2100 audio amplifier for zone 4.
Zone 1 Zone 2 Zone 3 Zone 4
VOLUME
MUTE
MP3
SAT HD
CD
VOLUME
MUTE
MP3
SAT HD
CD
VOLUME
MUTE
MP3
SAT HD
CD
VOLUME
MUTE
MP3
SAT HD
CD
NuVo uses D Amplifier™
by Philips Semiconductors

The Sound of LiVing.
Simple. Affordable. Stylish.
Get Pure Sound with
Generation D Technology
Simplese now incorporates the Generation D
technology previously only available on NuVo’s
higher end Essentia and Concerto systems.
Generation D design protocol by NuVo makes
pure digital audio a reality for your family,
delivering energy conservation, lower heat
generation, and clear, precise sound through-
out the home.
Customize Sound for Each Room
in Your House
Whether you thrill to a pulse-pounding bass
or soul-souring highs, easily adjust equaliza-
tion settings at the keypad to fit the natural
acoustics for each room. Find creating the
ideal listening experience, even in open living
spaces (such as the living, dining and kitchen
area) is as easy as the touch of a button using
NuVo’s unique grouping feature. Instantly
apply group mode to share the same listening
selection throughout multiple zones of your
choice.
Simple, Seamless Installation
The revolutionary Allport® wiring system
neatly conceals individual connections for
each zone while seamlessly integrating the
entire system.
Flexibility
As your needs change, Simplese is designed
to grow with you, so even if you don’t need a
complex system now, you will always have the
option to add more in the future. Easily expand
the Simplese to eight zones of sound or up-
grade to NuVo's Essentia or Concerto systems.
Control the Excitement
Simplese is taken to a whole new level of
control with the new Learning Remote Control.
Manage your whole home audio system and
access control for up to six additional devices
for an All-In-One control solution. The
combinations and possibilities are endless
and aren’t limited to one zone or even one
remote. Add additional learning remotes to
zones where added control is desired.
Now RS-232 Compatible
Simplese, in addition to all NuVo whole home
audio systems, is RS-232 compatible, allow-
ing easy, seamless integration of your audio
system into complete whole home automation
systems.
Change Rooms. Change Moods.
Simplese gives you the flexibility to send audio
from your choice of four sources to any of four
different listening zones of your home. That
means you can listen to a CD in the kitchen while
your spouse listens to the radio in the family
room, your daughter tunes into a favorite FM
station in her room, and your son watches a
DVD in your home theater — all at the same
time.
Generation D Simplese is our most afford-
able and simple home sound system yet, with
the easiest installation, RS-232 compatibility
AND the control of the learning remote — all
at a price comparable to many single-source
systems. NuVo’s award winning Simplese is the
most feature rich, quality system in its class.
NuVo home audio systems bring the advanced
Generation D technology of superior home sound
together with a sleek, slim new look, and the simplicity of
user-friendly design—all at a price that’s easy to live with.
Simplese features:
• Four audio source inputs for multi-source capability, and up to four zones of music
(expandable to eight zones)
• 30 watts of power per zone for high-quality sound
• 56 Khz and 38 Khz modulation outputs for better compatibility with more source equipment
• Generation D digital amplifier for cooler operation and higher power output
• Trim-line, 6 1/2 pound chassis takes up less vertical space in rack
• RS-232 serial port for easy integration with home automation systems
• NEW Learning Remote for control of up to six additional devices
• Unique Allport® wiring system means fewer wires to clutter installation
Home never sounded so good.
CAUTION: NuVo may cause spontaneous dancing.
NuVo’s user-friendly keypad comes in one color
of your choice (white or black) to fit a wide
range of interior designs and is compatible
with UK standard trim plates.
Simplese comes complete with all
necessary components for installation,
with the exception of speakers, wire,
and audio source equipment.
