1
BFS-6/0355
Wireless Body Analysis Scale
with Smartphone Compatibility
INSTRUCTION MANUAL
PLEASE READ ALL INSTRUCTIONS CAREFULLY
AND RETAIN FOR FUTURE USE
2
Table of Contents
Introduction
Getting Started 3
Package Contents 3
Features 3
How to Ensure Readings 3
Operating Instructions
Quick Start Guide 4-8
Understanding Your Information 9
Weight 9
Body Fat % 10
Muscle Mass % 11
Hydration % 11
Body Mass Index (BMI) 11
Visceral Fat (%) 11
Bone Mass (lb) 11
Calories 11
Maintenance and Care 12
Technical Specication 12
FCC Instructions 13
Warranty
14
Warranty Duration 14
Warranty Coverage 14
Warranty Disclaimers 14
Warranty Performace 14
Service & Repair 14
3
Introduction
GETTING STARTED
• Remove Wireless Body Analysis Scale and other accessories from the box.
• Remove any packaging from the product.
• Please read all instructions and retain all packaging until you have checked and counted all of the parts.
PACKAGE CONTENTS
• Wireless Body Analysis Scale
• Instruction manual
Features
• Accurately measures weight, body fat, muscle mass, body mass index (BMI), calories, hydration and visceral fat
• Large LCD screen with easy-to-read blue backlit display
• Attractive tempered 6mm black glass rated for use up to 400 lbs
• Quickly takes measurements the second you step on the scale
• Convenient app with cloud storage works with all NuvoMed devices
• Results sent wirelessly to your iOS™ or Android™ smartphone or tablet
• Google Fit™ and iOS™ Health integration
• Single user memory that tracks and detects changes in your weight with date & time
• Share history data via email
• Digital LCD display with blue backlight
• Auto turn off
• Operates on 2x1.5V (AAA) batteries (not included)
How to Ensure Accurate Readings
• Always measure barefoot. Do not step on unit with wet feet, wearing socks or shoes to prevent slipping,
damage and inaccurate readings
• Recommended to be placed on hard at surface only.
• Always weigh yourself on the same scale, same place and same surface if possible.
• Recommended measurement time is after waking up but before breakfast (optimal), 2 hours after recent
meal but before the next meal, or before bed but 2 hours after dinner.
• Erroneous measurements can occur if feet are dirty, dry or extremely callous.
• Body fat percentage estimates will vary with the amount of water in the body, and can be affected by
dehydration or over-hydration due to such factors as alcohol consumption, menstruation, illness, intense
exercise.
• Stand upright and not to the edge of the scale to ensure good contact with the lm or electrodes (the lm
and electrodes both are conductive media depending scale models).
• Horizontal line should be running below arch of each foot.
• Full feature of scale only available with corresponding app.
How does the Wireless Body Analysis Scale work?
This Wireless Body Analysis Scale uses BIA (Bio-electrical Impedance Analysis) technology to estimate body
fat mass, muscle mass, total body water and bone mass. The general principle behind: two or more conduc-
tors (electrode or ITO lm) on the scale contact person’s body and a small electric current is sent through
the body. The resistance between the conductors will provide a measure of body fat. The electrical current is
small and may not be felt.
4
Operating Instructions
NOTE: This device is a personal monitor and should be used in a consistent manner for the most accurate
reading. While readings of this analyzer might be different with that of others (hydro-densitometry or hand
held calipers), your changes in body fat percentage shown by this device will be reected accurately.
While this analyzer will work accurately as a scale for anyone and give accurate body fat readings for a ma-
jority of people, it is not intended for being used by pregnant women or children under the age of 18.
OPERATING INSTRUCTIONS
Quick Start Guide
1. Remove the battery cover at the back of Wireless Body Analysis Scale, and insert 2x1.5V AAA batteries
(not included) into the unit. Make sure the polarity is correct when done. Then, put back the battery cover. Do
not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium)
batteries.
2. Place the unit on a hard at surface (avoiding carpets or soft surface).
3. To set “units” in lbs, press the button located on the back of the unit, right behind the display. The set
display unit is kg, lbs, st:lb.
4. This product does not have an ON/OFF button. It will turn on when you press the middle button located on
the back of the unit.
Compatibility
This Wireless Body Analysis Scale is compatible with the App – “NuvoMed”
This Wireless Body Analysis Scale and App is compatible with the below devices using iOS 7.0 and above, and with
Bluetooth 4.0 and above -
· iPhone 5 and above,
· iPod Touch 5th GEN and above,
· iPad 4 and above, etc.
is Wireless Body Analysis Scale and App are compatible with the below devices using Android 5.0 and above, and
with Bluetooth 4.0 and above -
· Samsung Galaxy S5 and above,
· Samsung Note 4 and above, etc.
5
Operating Instructions
Operating Instructions
1. Ensure Bluetooth is turned “ON” on your phone.
2. Search for and download “NuvoMed” app on your phone.
3. Open the App and the following screens would appear -
4. Create your new account for the rst time use –
6
Operating Instructions
5. Input your prole information –
7
Operating Instructions
6. Click “Info & Support” to set the corresponding weight unit: kg/lb/st:lb, and then return
back.
7. Press the button located on the back of the Wireless Body Analysis Scale to turn it on. Place
the unit on a hard at surface (avoiding carpets or soft surface).
8
Operating Instructions
9. Press “Save” to store the measured data inside the App with the Wireless Body Analysis Scale.
8. Click “Weight” & “Start Measurement”, wait the App screen showing green display, and then stand on
the scale for Bluetooth-Pairing to measure and obtain the weight data.
9
Operating Instructions
11. Reading the Data from Wireless Body Analysis Scale. After nishing the pairing process. You are ready
to explore the journey to measure weight and body composition.
The Wireless Body Analysis Scale uses BIM technology. Bioelectrical Impedance Analysis (BIM) is a method
of measuring body fat percentage by sending a low-level, safe, electrical current through the body. There-
fore, you need to remove your shoes and socks, and then stand on the scale barefoot, covering the chrome
discs located on the face of the scale.
The scale will fail to measure body composition if your feet are too dry to make a connection. For these
circumstances, try to moisten your feet with a damp tissue or cloth to take readings.
Never attempt to take reading when you are wet after a shower/bath or sauna/steam room or after vigorous
exercise.
A summary of your data is then displayed on the App screen, and the scale display only shows your weight.
You can monitor weight, BMI, Body Fat (%), Visceral Fat (%), Muscle Mass (%), Bone Mass (lb), Hydration
(%) and Calories for you.
12. Take routine readings and explore the App functions
Understanding your information
The information displayed: Weight (kg, lb or st:lb), Body Fat (%), Bone Mass (lb), Muscle Mass (%), Hydra-
tion (%), Calories and BMI.
Weight
Your weight displays and gets stored in the App. It will show your weight in relation to your target weight in
a line graph, and you can view this over a week, month, year or all of your data.
10. You can see your past measured temperature data through “My History” and/or “Health report” to
review and print report.
10
Operating Instructions
Body Fat %
This value can serve as a guide to whether you need to adjust your diet, tness program or uid
intake to help you to achieve a healthy balance. Our bodies comprise of bone, fat and muscle. Fat
is vital for a healthy, functioning body – it protects vital organs, cushions joints, helps regulate body
temperature, stores vitamins and helps the body sustain itself when food is in short supply. But too
much or too little body fat can be damaging to our health. This is why it is important to measure and
monitor our body fat percentage using the Wireless Body Analysis Scale.
Body fat percentage gives us a good measure of wellness when used in conjunction with weight – if
we are aiming to lose weight, our weight loss could be because we are losing muscle mass, rather
than fat - we can still have a high percentage of fat even when a scale indicates ‘normal weight’.
MALE Age 20-29 30-39 40-49 50-59 60+
Low <13 <14 <16 <17 <18
Optimal 14-20 15-21 17-23 18-24 19-25
Moderate 21-23 22-24 24-26 25-27 26-28
High >23 >24 >26 >27 >28
For guidance, the Body Fat ranges for men and women are:
Female Age 20-29 30-39 40-49 50-59 60+
Low <19 <20 <21 <22 <23
Optimal 20-28 21-29 22-30 23-31 24-32
Moderate 29-31 30-32 31-33 32-33 33-35
High >31 >32 >33 >34 >35
11
Operating Instructions
Muscle Mass %
Knowing our muscle mass percentage is useful if we are undergoing any changes in our exercise regime or
undertaking a program of weight loss. Lean muscle mass may decrease by nearly 50% between the ages
of 20 and 90. We can replace this loss with fat if we don't maintain our exercise levels. We can also lose
muscle rather than fat if we undergo starvation-type diets, which are not recommended. At rest, the body
burns approximately 50 additional calories for each pound of muscle gained. So if we come off a starva-
tion-type diet, we actually put on more weight as fat. Ideally we want to maintain our muscle mass % while
reducing fat %.
Hydration %
Water is a vital element in the majority of the body’s functions and can be found in every cell, tissue, and
organ. A healthy hydration % needs to be maintained to operate at maximum efciency. Hydration levels
uctuate throughout the day, so use this measurement as a guide and not your absolute. Also note that
eating large meals, consuming alcohol, menstruation, illness, exercising and bathing may cause variations
in your hydration level. Optimal hydration % for Women is 45-60% and for Men is 50-65%.
Body Mass Index (BMI)
Body Mass Index (BMI) is an index of weight-for-height that is routinely used to classify underweight, over-
weight and obesity in adults.
Visceral Fat (%)
Visceral Fat is located in our abdominal cavity (stomach area) and surrounds our vital organs. The more
visceral fat you have the greater the chance of developing insulin resistance (leading to type 2 diabetes),
heart disease and high blood pressure.
The Wireless Body Analysis Scale gives a visceral fat percentage for reference. Visceral Fat percentage
between 1% and 9%: Indicates that you have a healthy level of visceral fat.
Visceral Fat percentage more than 9%: Indicates that you could have excess visceral fat and you may wish
to consider modifying your diet or increasing your exercise levels.
Bone Mass (lb)
Similar to MUSCLE MASS percentage, understanding changes in our BONE MASS (lb) can be useful,
especially during weight reduction programs.
Male Weight Less than 132 lb 132-165 lb More than 165 lb
Calculated Bone 5.5 lb 6.4 lb 7 lb
Female Weight Less than 99 lb 99-132 lb More than 132 lb
Calculated
Bone
4 lb 4.8 lb 5.5 lb
Calories
It is a measure of the number of calories required to keep your body functioning at rest.
12
Maintenance and Care
• When the scale is overloaded, it will display “OL”.
• When the battery needs to be replaced, it will display “Lo”.
• Ensure the scale is used on a at, even and rm surface. Avoid carpet or soft surface.
• Always weigh yourself with the same scale placed on the same surface. Uneven oor may affect the
reading.
• The surface of the scale will be slippery if wet. Keep it dry!
• To ensure a consistent result, weigh yourself without clothing and footwear, before meals and at the
same time of day.
• Do not expose scale to direct sunlight.
• Keep the scale in a dry place to protect the electronic components.
• Clean after use with a lightly damp cloth, do not use solvents or immerse the product in water.
• Avoid overloading the scales other than to replace the battery.
• Do not disassemble the scales other than to replace the battery.
• Do not store the scale in an upright position when not in use. Only store at and on an even surface to
maintain correct calibration for every use.
• Avoid excessive impact or vibration to the unit, such as dropping the scale onto the oor, or leaving
objects on the scale.
• A user who has any metal material inserted into his/her body may get differences in measurement of
body fat reading.
TECHINCAL SPECIFICATION
Display: All data displayed when power on
Capacity: (6.6 lbs-396 lbs) 3kg-180kg
Division: 1D=100g/0.2 lb
Unit: kg/lbs/st:lb
Voltage: 3V
Battery: 2x1.5V AAA batteries
Low battery indication: 2.4V±0.2V, display “Lo” and power off
Current: ≤25mA
Standby current: ≤10μA
Overload indication: overload more than 5.5 lbs (2.5kgs), total 401.5 lbs (182.5kgs) display “OL”
Best working temperature: 41~95°F (5~35°C)
Storage temperature: 14~140°F (-10~60°C)
Moisture environment: ≤90%RH
Dimension: 11”(L) x 11”(W) x 1”(H)
Weight: 3 lbs
Maintenance and Care
13
NOTE: This product has been tested and found to comply with the limits for a Class B digital device, pursu-
ant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This product generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation.
If the product does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures :
- Reorient or relocate the receiving antenna.
- Increase the separation between the product and receiver.
- Connect the product into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Instructions
FCC Instructions
Changes or modications not expressly approved by the party responsible for compliance could void the
14
This manufacturer's product warranty extends to the original consumer purchaser of the product. Neither the retailer
nor any other company involved in the sale or promotion of this product is a co-warrantor of this manufacturer warran-
ty.
WARRANTY DURATION: All materials and workmanship are warranted to the original consumer purchaser for a period
of ninety (90) days from the original purchase date.
WARRANTY COVERAGE: This product is warranted against defective materials or workmanship. This warranty is void
if the product has been damaged by accident, in shipment, unreasonable use, misuse, neglect, improper service, com-
mercial use, repairs by unauthorized personnel or other causes not arising out of defects in materials or workmanship.
This warranty doesn’t cover the following which may be supplied with this product, including but not limited to; LCD
Screens, glass parts, lenses, bulbs etc. This warranty is effective only if the product is purchased and operated in USA
and Canada, and does not extend to any units which have been used in violation of written instructions furnished by
manufacturer or to units which have been altered or modied or, to damaged products or parts thereof which have had
the serial number removed, altered, defaced or rendered illegible.
WARRANTY DISCLAIMERS: This warranty is in lieu of all warranties expressed or implied and no representative or
person is authorized to assume for manufacturer any other liability in connection with the sale of our products. There
shall be no claims for defects or failure under any theory of tort, contractor commercial law including but not limited to,
negligence, gross negligence, strict liability, breach of warranty and breach of contract. Under no circumstances will
Manufacturer’s / Distributor’s maximum liability exceed the retail value of the product.
WARRANTY PERFORMANCE: During the above 90 day warranty period, a product with a defect will be either
repaired or replaced with a reconditioned comparable model (at manufacturer's option). The repaired or replacement
product will be in warranty for the balance of the 90 day warranty period and an additional one-month period. No
charge will be applicable for such repair or replacement.
SERVICE AND REPAIR: If service is required for this product, you should rst contact Nuvomed Inc Customer
NOTE: Manufacturer cannot assume responsibility for loss or damage during incoming shipment. As a precautionary
measure, carefully package the product for shipment, and insure it with the carrier. Be sure to enclose the following
details with the product: your full name, return address and daytime phone number, a note describing the problem you
experienced, a copy of your sales receipt or other proof of purchase to determine warranty status. C.O.D. shipments
cannot be accepted.
Limited Warranty
Warranty
Table of contents
