NuWave PIC Gold 30211 User manual

Model: 30211
Quick Start
Press Start and the display will
show a default cooking time and tem-
perature of 1 hour at 375°F.
Pause/Clear
• Press Pause/Clear once to pause
cooking. The display will clear after
45 minutes.
• Press Start to resume cooking.
• Press Pause/Clear twice to clear out
the cooking settings.
Temperature Format: °F to °C
• Press Prog once.
• Press –once to display Fahrenheit.
• Press –again to display Celsius.
• Press Pause/Clear to nish.
Adjusting Cooking Temperature
Increase or decrease the temperature
manually by selecting 1 of the 6 Preset
Temperature buttons, or by pressing –
or +to adjust the temperature down or
up in 10-degree increments.
Preset Temperature Buttons
Button Temperature Examples
Low 100°F Warm
Med/Low 175°F Simmer
Med 275°F Steam
Med/High 375°F Stir/Deep Fry
High 425°F Boil/Saute
Max/Sear 575°F Sear
Adjusting Cooking Time
To cook for a specic time, or longer than
1 hour, set each column as follows. Ex: 3
hours and 45 minutes.
1. Press Time to set column one, then
press + 5 times to set 5 minutes.
2. Press Time again to set column
two, then press+ 4 times to set 40
minutes.
3. Press Time again to set column
three, then press + 3 times to set 3
hours.
The ashing digit is the number being
altered.
Changing Wattage Setting
The PIC Gold defaults to 1500 watts. If
used somewhere with limited wattage,
you can adjust the PIC Gold's wattage
by pressing Watts until you reach the
desired power.
When cooking at lower wattages,
your cooking time may increase slightly.
Wattage and Amps
Power Setting Wattage Setting
Max/Sear 600W
5A
900W
7.5A
1500W
12.5A
Stage/Programming Cooking
Program the PIC to cook at different
temperatures for different amounts of
time. Ex: High for 5 Min., Low for 3 Min.
1. Press Prog to set the stages.
2. Press High then Time and then
press +5 times for 5 min. at High.
3. Press Low then Time and then
press +3 times for 3 min. at Low.
4. Press Start to begin cooking.
You can add more stages by repeating
steps 2 or 3 before pressing Start.
Delay Cooking
How to program the PIC to delay cook-
ing. Ex: Delay cooking for 6 minutes,
then cook on High for 3 minutes.
1. Press Prog to set the delay.
2. Press Time then press +6 times to
delay for 6 minutes.
3. Press Prog then press High.
4. Press Time and then press + 3 times
to cook for 3 minutes.
5. Press Start to begin cooking.
PIC®
Precision Induction Cooktop
Gold
Quick Start Guide

Power and
Temperature
Setting
Wattage Setting (based on 120V)
600W
5.0 Amps
900W
7.5 Amps
1500W
12.5 Amps
Sear 600W 900W 1500W
High
425°F~490°F 600W 900W 1200W
Med/High
375°F~420°F 600W 900W 1000W
Med
275°F~370°F 600W 800W 800W
Med/Low
175°F~270°F 600W 600W 600W
Low
100°F~170°F 600W 600W 600W
PIC Gold Specifications
Cooking Area
The heating surface is located inside the thicker gold ring. The minimum diameter of acceptable cookware is 3 inches.
Always place cookware in the center of the heating circle. You may use pans measuring up to the total width of the PIC Gold, which is
12 inches. However, in these situations heat will transfer more slowly to the outer edges. The PIC Gold is not recommended for pans
larger than 12 inches. There are no open ames or hot coils, the surface remains cool to the touch where not magnetically activated
and can accommodate weights up to 50 pounds.
PIC On The Go
For those cooking on the road or open water, the NuWave PIC
Gold requires up to 12.5 amps when used on an RV or boat
and uses up to 1500W of energy depending on the tempera-
ture and wattage setting. The appliance may be plugged into
any standard electrical outlet, but cannot operate on batteries.
Heating Surface
(within gold ring)
12 Inches

Note: Temperatures and times may need minor adjustments to best suit your desired results.
Prepackaged Foods: Follow the directions on the package and reduce temps and times by 15%. Check periodically.
Beef Temp Fresh–Minutes Frozen–Minutes Internal Temperature (Thermometer)
Patties, 1-inch thick 370°F 00:10 00:18–00:20 Well 160°F
Steaks, 1-inch thick* 400°F
00:02–00:03
00:03–00:04
00:04–00:05
00:05–00:06
00:06–00:07
00:08–00:10
00:10–00:12
00:12–00:14
00:14–00:16
00:16–00:18
Rare
Medium Rare
Medium
Medium Well
Well
125°F–134°F
135°F–144°F
145°F–149°F
150°F–159°F
160°F
Beef Stew 325°F 03:00–04:00 Hours 04:00–05:00 Hours Well 160°F and
higher
*Let rest for 10 minutes before serving.
Poultry Temp Fresh–Minutes Frozen–Minutes Internal Temperature (Thermometer)
Chicken Breasts, Legs, Thighs, Bone-In 380°F 00:30–00:40 00:45–00:55 165°F
2 Boneless/Skinless Chicken Breasts,
6oz.–8oz. each 380°F 00:09–00:11 00:14–00:16 165°F
Turkey Breast (cutlet) 360°F 00:05–00:08 00:10–00:15 165°F
Duck Breast, 6oz.–10oz. 360°F 00:10–00:14 00:15–00:18 165°F
Chicken Sausage 360°F 00:10–00:15 00:15–00:20 165°F
Pork Temp Fresh–Minutes Frozen–Minutes Internal Temperature (Thermometer)
Bacon 400°F 00:08–00:10 Extra crispy* --
*For extra crispy, cook for an additional 2–3 minutes.
Sausage, 1oz. links 375°F 00:12–00:16 00:14–00:16 160°F
Sausage, 2oz. patties 175°F 00:12–00:14 00:15–00:16 160°F
Italian Sausage, Bratwurst, etc. 375°F 00:09–00:13 00:17–00:21 160°F
2–3 Pork Chops, 6oz. each 375°F 00:10–00:12 00:18–00:21 145°F
Tenderloins, 1½lbs.–2lbs. 350°F 00:18–00:20 00:28–00:30 145°F
Hot Dogs (boiled in water) 350°F 00:05 00:05 140°F
Seafood Temp Fresh–Minutes Frozen–Minutes Internal Temperature (Thermometer)
Fish: Fillets, ½ inch thick 400°F 00:05–00:07 00:10–00:12 145°F
Fish: Steaks and Fillets, 1 inch thick 400°F 00:10–00:12 00:14–00:18 145°F
6–12 Shrimp, large, boiled 400°F 00:03–00:05 00:14–00:17 Cooking time may vary with size.
6–12 Sea Scallops, large 400°F 00:04–00:05 00:10–00:14
Scallops and/or lobster turns opque
when
cooking is complete.
6–12 Bay Scallops, large 400°F 00:06–00:08 00:08–00:10 --
Vegetables Temp Fresh–Minutes Frozen–Minutes
2–4 Corn on the Cob, boiled in water 350°F 00:05–00:06 Alternative, season to taste.
Potatoes: Pancakes
Cut in ½ lengthwise
French Fries
350°F
00:05–00:06
00:05–00:08
00:03–00:06
8oz. each
Broccoli, 6oz.–12oz., boiled in water 350°F 00:02–00:03 Varies with thickness.
Squash, sliced, ¼-inch thick 350°F 00:02–00:03 Cut in half, remove seeds and membrane, place in a shallow dish
and brush with oil.
Eggplant, sliced, ½-inch thick 350°F 00:02–00:03 --
Cooking Guide
PIC®
Precision Induction Cooktop
Gold

Induction-Ready Cookware
There are three simple ways to check if your existing pots and
pans or future cookware purchases are compatible with the
NuWave PIC Gold:
1. A magnet is typically a great indicator. If it sticks to the bot-
tom of a piece of cookware, that typically means the pot or
pan is induction-ready. However, there are instances when
a cooking vessel’s magnetic properties may not be strong
enough for the pot to work efciently with the PIC Gold.
2. Place a small amount of water in a pot or pan. If the vessel
is induction compatible, the water will begin to boil.
3. Look for the induction-ready symbol, which may be printed
on the bottom of the cookware.
The Magnet Method of determining
induction compatibility.
The Induction Ready symbol printed on most
induction-compatible cookware.
Troubleshooting Guide
E1 Error
An E1 reading typically means that your PIC Gold does not
detect
cookware on its surface. This can occur for one of two reasons:
1. The induction coils contained within the PIC Gold will only
work when they are in direct contact with a piece of cook-
ware. To maintain your appliance’s effectiveness, always
ensure that it rests on a at surface and set the cookware
on the PIC Gold before pressing Start.
2. An E1 message may also occur if your chosen cookware
is not induction-ready.
When an E1 error occurs the PIC will beep every 2 seconds
until it detects a pot. If the PIC has not detected a pot after 1
minute, it will shut off automatically.
In order to resume cooking, place induction-ready cookware on
the PIC’s surface then press Start.
E7 Error & Cooking Fan
An E7 error is displayed when the PIC becomes overheated.
This is typically caused by obstruction of the PIC’s underside
Cooling Fan. Always ensure that the PIC Gold is placed on a
at, level surface with the cooling fan unobstructed. Typical
interferences include tablecloths, wooden cutting boards,
placemats, etc.
PIC & Pacemakers
Scientic tests are inconclusive as to whether the electrical
eld created by the PIC Gold will disrupt the function of a pace-
maker. Please consult your doctor or medical professional for
guidance before use.
General Cleaning Instructions
1. Unplug the PIC before cleaning.
2. Clean after each use.
3. Make sure the PIC has cooled completely prior to
cleaning.
4. The outer surface may be cleaned by wiping carefully with
a damp dishcloth or sponge.
5. Remove the power plug prior to cleaning the NuWave PIC.
Do not use caustic cleaning agents and water should not
penetrate the interior of the induction cooktop.
6. Never immerse the PIC, cables, or plug in water or other
liquids.
7. Wipe the glass surface with a damp cloth or use a mild,
non-abrasive soap solution.
8. Wipe casing and operating panel with a damp soft cloth
and mild detergent.
9. Do not use oil-based cleansing products as their use may
damage plastic parts or the casing/operating panel.
10. Do not use flammable, acidic or alkaline materials or
substances near the PIC, as this may reduce the service
life of the induction cooktop or pose a fire risk when the
induction cooktop is in use.
11. Ensure that the bottom of any cookware does not scrape
the PIC’s glass surface, although a scratched surface will
not impair the use of the induction cooktop.
12. Properly clean the PIC before storing it in a cool, dry
place.
©2022 NuWave LLC • All Rights Reserved. • Customer Service: 1-877-689-2838 • [e-mail]
Item No: BQ30211 • Rev.13-CB • 08-31-22
