NuWave PIC Gold User manual

Owner’s Manual
Model No: 30211
Questions or Concerns?
Toll Free: 1-877-689-2838 • [e-mail]
(Mon-Fri 7:30am-4:30pm CST)
PIC®
Precision Induction Cooktop
Gold

4| nuwavenow.com
WARNING: When using the PIC, always
follow basic safety precautions:
1. There may be residual heat on the
cooking surface. Do not touch.
2. To protect against electrical shock, do
not immerse cord, plugs, or the PIC in
water or other liquids.
3. Do not operate the PIC with a damaged
cord, plug, after the appliance
malfunctions, or has been damaged in
any manner. Return appliance to the
nearest authorized service facility for
examination, repair, or adjustment.
4. Close supervision is necessary when
the PIC is used near children. This
appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or who lack experience
or knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
5. The use of accessories not
intended for use with the PIC is not
recommended. Doing so may damage
the PIC and can cause accidents.
6. FOR HOUSEHOLD USE ONLY. NOT
INTENDED FOR OUTDOOR USE.
7. Do not use the PIC for any purpose
other than its intended use.
8. Do not let cord hang from tables or
countertops, touch hot surfaces, or
come into contact with sharp edges.
9. Do not place the PIC on or near a hot
gas, electric burner, in a heated oven,
or on a stovetop.
10. Never use the cooktop in the proximity
of open res or other heat sources, on
ammable surfaces (e.g., tablecloth,
carpet, etc.), close to any ammable
materials, heating units, or in wet
areas.
11. Do not move the PIC while in
operation, especially with any pots or
pans containing hot oil or other hot
liquids. Remove these from the PIC
and allow it to cool before moving.
12. To disconnect, turn the PIC off and
then remove the plug from the outlet.
13. When removing the plug, do so by
the head, not the cord.
14. Never put the PIC against the wall or
other appliances. There should be at
least 3 inches of free space for the
back, sides, and the top of the PIC.
15. Unplug the PIC from outlet when not in
use and before cleaning. Allow the PIC
to cool before cleaning, putting on or
taking off parts.
16. It is normal for some smoke to escape
the PIC when heating for the rst time.
17. If a lot of smoke is escaping from the
air vent during operation, unplug the
PIC immediately and contact Customer
Service at 1-877-689-2838 or via email
at
[e-mail].
18. Place the cooktop on a stable, level,
non-metallic surface.
19. The cooktop’s surface is designed
with temperature-resistant glass. In
the event that damage to the PIC is
observed, even a small crack on the
glass surface, immediately disconnect
the PIC from the power supply.
20. Never use a towel or other material
or object to block the air vents. Do
not block the ventilation slots of the
induction cooktop. This may cause the
PIC to overheat.
21. Make sure the cord is not compressed
beneath the PIC.
22. Do not place devices or objects that
are sensitive to magnetic elds on
top of or next to the PIC, e.g., credit
cards, cellphones, radios, TVs, etc.
SAFEGUARDS & INFORMATION
ALWAYS KEEP THIS MANUAL HANDY FOR FUTURE REFERENCE.

nuwavenow.com | 5
SAFEGUARDS & INFORMATION
23. Prior to connecting the PIC, conrm
that the voltage needs indicated
in this manual correspond to the
voltage supply in your home. A wrong
connection may lead to the PIC’s
damage and possible injury to persons.
24. If any trouble arises during operation,
any service MUST be done by NuWave
LLC or authorized by the manufacturer
for repairs.
25. The appliance is not intended to be
operated by means of an external timer
or separate remote-control system.
26. Do not disassemble the PIC or replace
any parts without prior written consent
from the manufacturer.
27. Make sure the PIC is always clean prior
to cooking.
28. Use extreme caution when operating
the PIC or any other appliance.
Electrical Information
A short power-supply cord is provided to
reduce the risk resulting from becoming
entangled in or tripping over a longer cord.
Longer detachable power-supply cords or
extension cords are available and may be
used if care is exercised in their use. If a
longer detachable power-supply cord or
extension cord is used:
1. The marked electrical rating of the
extension cord should be at least as
great as the electrical rating of the
appliance.
2. The longer cord should be arranged
so that it will not drape over the
countertop or tabletop where it
could be pulled on or tripped over
unintentionally. The PIC should be
operated on a separate electrical
outlet from other operating
appliances due to wattage limitations.
The appliance has a polarized plug
(one blade is wider than the other).
To reduce the risk of electric shock,
this plug is intended to fit into a
polarized outlet only one way. If the
plug does not fit fully into the outlet,
reverse the plug. If it still does not
fit, contact a qualified electrician. Do
not attempt to modify the plug in any
way.
ALWAYS KEEP THIS MANUAL HANDY FOR FUTURE REFERENCE.
SEE CARE & MAINTENANCE
BEFORE USE
SAVE THESE INSTRUCTIONS
Read and understand the entire manual
before using the PIC.
THE FAILURE TO FOLLOW THESE
SAFEGUARDS AND INSTRUCTIONS IS A
MISUSE OF YOUR PIC THAT CAN VOID
YOUR WARRANTY AND CREATE THE
RISK OF SERIOUS INJURY.
NOTICE
This appliance is intended for normal
household use. It is not intended to
be used in environments such as staff
kitchens/cafeterias of shops, ofces,
farms, or other work environments, nor is
it intended to be used by clients in hotels,
motels, bed and breakfasts, and non-
residential environments.
WARNING
In case of malfunction, immediately
unplug the PIC and contact NuWave’s
Customer Service Department at
1-877-689-2838 (Mon - Fri, 7:30am to
4:30pm, CST) or [e-mail]

6| nuwavenow.com
SAFEGUARDS & INFORMATION
IMPORTANT - FCC Information:
Warning: Changes or modications to this
unit not expressly approved by the party
responsible for compliance could void the
user’s authority to operate the equipment.
Note: This equipment has been tested
and found to comply with the limits for a
consumer ISM equipment, pursuant to
Part 18 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference in
a residential installation. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed and
used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that the interference will not
occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can
be determined by turning the equipment
off and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced
radio TV technician for help.
The device complies with part 18 of the
FCC rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and (2)
This device must accept any interference
received, including interference that may
cause undesired operation.
Questions About
Your PIC Gold?
Just contact our friendly and know edg-
able Customer Service Team Monday‒Fri-
day, from 7:30am‒4:30pm,CST
at 877-689-2838 or anytime by email at
[e-mail]
WARNING
Electric shock hazard. Use with adequate
electrical system. Do not use if cord or
plug is damaged.
WARNING: All items on the cooktop can
get very hot during cooking. Please be
careful when removing these items from
the unit. Always wear oven mitts or use
pot holders. Cooktop may retain residual
heat after cookware has been removed.
Allow everything to cool completely
before cleaning.
Correct Disposal
of this Product
This marking
indicates that this
product should not
be disposed of with
other household
wastes throughout
the EU. To prevent possible harm to
the environment or human health from
uncontrolled waste disposal, recycle it
responsibly to promote the sustainable
reuse of material resources. To return
your used device, please use return and
collection systems or contact the retailer
where the product was purchased.
They can handle environmentally safe
recycling.
NOTICE

nuwavenow.com | 7
PARTS & ACCESSORIES
PIC Gold
Part #: 30211
Optional PIC Carrying Case
order at www.nuwavenow.com
Induction-Ready Cookware
Induction technology is based on a magnetic
eld distributing heat through ferrous (iron-
based, magnetic) metal. Some cookware
is made of naturally magnetic metals (such
as pure iron), while others are rendered
magnetic by “sandwiching” a thin layer of a
ferrous metal within the base. Examples of
compatible cookware include:
• All NuWave Cookware, NuWave
Duralon®Healthy Ceramic Non-Stick
Cookware
• Cast iron
• Enameled iron and steel
• Stainless-steel with a magnetic base
Incompatible cookware includes:
• Copper
• Glass
• Aluminum
• Pottery-type vessels
Checking Induction Compatibility
There are three simple ways to check if your
existing pots and pans, or future cookware
purchases, are compatible with the PIC
Gold:
1. A magnet is typically a great indicator.
If it sticks to the bottom of a piece of
cookware, this typically means the pot
or pan is induction-ready. However,
sometimes a cooking vessel’s magnetic
properties are not strong enough to work
efficiently with the PIC Gold.
2. Place a small amount of water in a pot or
pan and place it on the PIC Gold while
operating. If it is induction compatible,
water will begin to boil.
3. An induction-ready symbol may be
printed on the bottom of the cookware.

8| nuwavenow.com
GETTING STARTED
Primary Controls
Easy Start
The PIC Gold is preset to cook on Med/High (375°F) for 1 hour. Turn it on, and you
will see “0” on the display, showing that the unit is on but the program is clear (See the
Pause/Clear Function section for more). Then, place an induction-ready pot on the cooking
surface and press Start.
This default setting is adjustable before or during the cooking cycle. Press one of the
preset temperature buttons (Low, Med/Low, Med, High, or Max/Sear) or press -or +to
decrease or increase the cooking temperature.
Preset Temperatures
Press Button Temperature Panel Display Examples
Low 100°F 100F Warm
Med/Low 175°F 175F Simmer
Med 275°F 275F Steam
Med/High 375°F 375F Stir/Deep-Fry
High 425°F 425F Boil/Saute
Max/Sear 575°F SEAR Sear
The minimum is 100F while the maximum temperature reaches 500F.
Decrease
cooking
temperature or
time.
Adjustable set
temperatures: 100°F,
175°F, and 275°F.
Adjustable set
temperatures: 375°F,
425°F, 575°F (Sear).
Increase
cooking
temperature or
time.
Prog:
Set your
own cooking
stages.
Time:
Adjusts the
cooking time. Pause/Clear:
Pauses and
clears the cooking
process.
Start:
Begins the cooking
process.
Watts
Controls the
power consuption.

nuwavenow.com | 9
GETTING STARTED
Primary Controls
CAUTION
While the PIC Gold is in operation, do not touch the cooking surface as it may
become very hot, leading to the risk of burns. The cooktop may retain residual heat
after cookware has been removed.
Control Function
Start Press Start to begin cooking. If you have paused cooking,
pressing Start will begin the cooking process again.
Pause/
Clear
Press Pause/Clear to pause cooking. To clear out a set
cooking sequence, press Pause/Clear a second time.
Prog Set up to 10 cooking stages.
Watts
Controls the power consumption of your PIC. The default
wattage is 1500W. The lower wattage will consume less
energy, ideal if your home does not take 1500 watts. Press
WATTS to adjust from 1500W to 600W to 900W.
Time Allows you to adjust the cooking time before and during the
cooking process.
Low
Left side set temperature buttons: Low (100°F), Med Low
(175°F), and Med (275°F). Use the - or + keys to further adjust
the cooking temperature in 10°F increments.
Med Low
Med
Med High
Right side set temperature buttons: Med High (375°F), High
(425°F), and Max/Sear (575°F). Use the - or + keys to further
adjust the cooking temperature in 10°F increments.
High
Max/Sear
(-) Allows you to decrease the cooking temperature and time
before and during the cooking process.
(+) Allows you to increase the cooking temperature and time
before and during the cooking process.

10 | nuwavenow.com
GETTING STARTED
Ventilation Air Vents
Ventilation Air Vents
Surface:
Heat-resistant
glass
Heat Source:
Electromagnetic
Coils Under the
Heat-Resistant
Glass
Control Panel
with LED
Display
3
2
1
4
1
1
2
3
4
Ventilation: Air vents allow any heat generated by the unit to escape, preventing
heat transfer to the cooking surface and ensuring efcient performance.
Surface: The NuWave PIC Gold’s heat-resistant glass surface stays cool to the touch
and cleans easily with the simple wipe of a damp cloth.
Control Panel with LED Display: Clearly lit, easy-to-read control panel.
Heat Source: Electromagnetic coils located below the glass surface generate heat
within the induction-ready cookware.
INDUCTION COOKING
The heating surface is located inside the thicker silver ring. The minimum diameter of
acceptable cookware is 3 inches. Always place cookware in the center of the heating
circle. You may use pans measuring up to the 10-inch width of the PIC Gold, but heat
will transfer more slowly to the outer edges. Not recommended for pans larger than 10
inches.
NOTICE
The heating surface is located inside the thicker silver ring. The minimum diameter of
acceptable cookware is 3 inches. Always place cookware in the center of the heating
circle. You may use pans measuring up to the 10-inch width of the PIC Gold, but heat
will transfer more slowly to the outer edges. The PIC Gold is not recommended for pans
larger than 10 inches.

nuwavenow.com | 11
COOKING FUNCTIONS
To Start Cooking
There are several ways to begin
cooking with your PIC Gold.
1. Press Start. The defaults are 375°F for
1 hour.
2. Set the cooking temperature and press
Start. The default cooking time is 1
hour.
3. Set the cooking time and press Start.
The default cooking temperature is
375°F.
4. Set temperature and time, then press
“Start”.
• The PIC Gold will automatically stop
cooking once time has expired and the
PIC will beep.
• The display will always show current
temperature during the cooking cycle.
• To display time lapse, press “Time” and
a countdown will appear, marking the
duration before the cycle or stage is
complete.
Setting the Cooking Temperature
This appliance is preset to cook on
Med/High (375°F).
1. To reset, press the desired
temperature on the control panel then
press “Start”. The temperature range
will appear on the display.
2. To raise or lower the temperature in
10-degree increments, press “+” or
“-” until the desired temperature is
displayed.
Refer to the Preset Temperatures Chart on
page 8 for preset temperature information.
NOTE: Displayed temperature represents
the center temperature of 1.5L of oil in the
NuWave 3.5-quart Stainless Steel Pot.
Thermometer location was tested at the
origin (middle) of the NuWave 3.5-quart
Stainless Steel Pot at an equidistant length
between the pot base and the top of the oil.
Temperature Format: ºF to ºC
The PIC Gold defaults to displaying the
cooking temperature in degrees Fahrenheit
(F), but this can be changed to Celsius.
1. Press Prog.
2. Press -twice.
The display will change and temperature
will be displayed in Celsius. To return to
Fahrenheit, simply press -once more.
To close out of the F/C conversion option,
press Pause/Clear until a “0” appears on
the display.
Setting the Cooking Time
1. Press Time. “0” will flash in the far right
corner of the display.
2. Press +until the desired amount of
time is reached.
Example 1: To program 5 minutes, press
Time once, then press +until “00:05” is
displayed. Press Start.
Example 2: For 20 minutes, press
Time twice, then press +until “00:20” is
displayed. Press Start.
Example 3: For 2 hours and 30 minutes,
press Time twice, then press +until you
reach “00:30”, then press Time again.
Press +until “02:30” is displayed, then
press Start.
• The blinking “0” indicates the digit you
can adjust. The maximum time is 99
hours and 60 minutes.
• The display shows hours and minutes,
but not seconds.

12 | nuwavenow.com
COOKING FUNCTIONS
The Pause/Clear Function
To interrupt cooking time, press
Pause/Clear once. This will pause
the NuWave PIC Gold regardless of cooking
stage.
The temperature will remain listed in the
display panel, but the “F” will be blinking.
To resume cooking, press Start.
To clear the cooking mode or display
while the PIC Gold is in operation, press
Pause/Clear twice. The display will be fully
cleared and “0” will appear.
The Programming Function
(Stage Cooking)
1. Press Prog. “Pro” will appear on the
display.
2. Set the cooking temperature using the
preset temperature keys, from Low to
Max/Sear. To increase or decrease the
temperature, press -or +.
3. Press Time. “00:00” will be displayed,
then press -or +until the desired time
is reached. See Setting Cooking Time
for entering minutes and hours.
• To add additional stages, repeat steps
1 and 2 then press Start to begin the
program. You may program up to 10
stages (delay is considered a stage).
• To change any part of the program,
press Pause/Clear twice to start over.
Example: Boil for 5 minutes before
reducing to a simmer for 20 minutes:
Press Prog. Press Max/Sear. Press Time
once, and then press +until “00:05” is
reached. Press Med/Low. Press Time
twice, and then press +until “00:20” is
reached. Finally, press Start.
NOTE: The maximum programmable cook
time is 99 hours and 60 minutes.
The Delay Function
This function allows for set programs to start at
a later time.
1. To delay a program, press Prog.
2. Press Time. A “0” will ash in the
display.
3. Press +until the desired amount of time
to delay the program start is reached.
See “Setting Cooking Time” for more.
4. Press Prog again to set the cooking
program. The amount of time selected
for delay is included in the programmed
stages.
• To continue to the next stage,
enter the cooking temperature and
then continue with Step 2 from the
“Programming Function” instructions.
5. Once ready for the countdown to begin,
press Start. When the delay countdown
reaches “0”, the PIC Gold will beep
twice and the cooking time will start with
the cooking temperature displayed.
The Wattage Function
The default wattage of the PIC Gold is 1500
watts, which is adjustable to 900 watts and
600 watts.
1. Press Watts once. The red light will
illuminate above “600”, indicating that
the PIC Gold is now set to 600 watts.
2. Press Watts again. The red light above
“900” will illuminate, indicating the PIC
Gold is now set to 900 watts.
3. Press Watts once more and the red
light above “1500” will illuminate,
indicating that the PIC Gold is now set
to the default 1500 watts.

nuwavenow.com | 13
COOKING FUNCTIONS
Cooking Tips
The recipe book contains valuable information designed to assist in the incorporation of the
PIC Gold into daily life. We’ve provided easy-to-prepare recipes along with helpful tips at
the beginning of each section for perfect results every time.
Here we’d like to offer a few general suggestions to help you start cooking:
• Place a small bowl next to your cutting board for discarding food scraps.
• Flexible cutting boards are very convenient. Just chop and lift–no mess, no spills.
• Glass measuring cups are preferred for liquids while plastic measuring cups work well
for dried ingredients.
• After you have juiced lemons, put them in the garbage disposal to freshen the
surrounding air.
• Pay close attention to butter as it’s melting. Butter melts when its internal temperature
reaches a range of 82.4°F~96.8°F. This means it melts fast, so be prepared to remove
it from the PIC quickly.
Measuring Up
Here are some measurements that every chef and home cook should know:
• 1 square of baker’s chocolate = 1 ounce
• 4 pecks = 1 bushel
• 8 tablespoons = ½ cup
• 1 pound of chopped nuts = 2 cups
• ½ cup of butter = 1 stick
• 2 cups granulated sugar = 1 pound
• 2 cups butter = 1 pound
• 16 uid ounces = 1 pint
• 1 cup = ½ pint
Questions About
Your PIC Gold?
Just contact our friendly and know edg-
able Customer Service Team Monday‒Fri-
day, from 7:30am‒4:30pm,CST
at 877-689-2838 or anytime by email at
[e-mail]

14 | nuwavenow.com
CARE AND MAINTENANCE
Cleaning the PIC Gold
Before rst use, wipe the cooking surface with a cloth damp with
warm, soapy water. Dry throughly before plugging the PIC Gold
into any electrical outlet.
General Cleaning Instructions
1. Unplug the PIC before cleaning.
2. Clean after each use.
3. Make sure the PIC has cooled completely prior to cleaning.
4. The outer surface may be cleaned by wiping carefully with a damp dishcloth or
sponge.
5. Remove the power plug prior to cleaning the NuWave PIC. Do not use caustic
cleaning agents and water should not penetrate the interior of the induction cooktop.
6. Never immerse the PIC cables or plug in water or other liquids.
7. Wipe the glass surface with a damp cloth or use a mild, non-abrasive soap solution.
8. Wipe casing and operating panel with a damp soft cloth and mild detergent.
9. Do not use oil-based cleansing products as their use may damage plastic parts or the
casing/operating panel.
10. Do not use flammable, acidic or alkaline materials or substances near the PIC, as
this may reduce the service life of the induction cooktop or pose a fire risk when the
induction cooktop is in use.
11. Ensure that the bottom of any cookware does not scrape the PIC’s glass surface,
although a scratched surface will not impair the use of the induction cooktop.
12. Properly clean the PIC before storing it in a cool, dry place.
NOTICE
Check Your Electrical Outlets
Check your electrical outlets to ensure proper operation. Do not use in an outlet where
other major appliances are engaged. Check the wattage settings if the PIC is cooking
too slowly.
The electrical plug must be properly plugged into the outlet.
WARNING
Electric Shock Hazard
Do not immerse the PIC Gold in water or attempt to cycle it through dishwasher. The
outer surface may be cleaned by wiping carefully with a damp dishcloth or sponge.
Make sure PIC has cooled completely prior to cleaning.

nuwavenow.com | 15
Error Messages
TROUBLESHOOTING
Error Message: Solution(s):
E1
An E1 reading typically means the PIC Gold does not detect
cookware on its surface. This can occur for one of two reasons:
1. The induction coils contained within the PIC Gold will only work
when they are in direct contact with a piece of cookware. To
maintain your appliance’s effectiveness, always ensure that it
rests on a flat surface and that contact is consistent with your
cookware.
2. An E1 message may also occur if the chosen cookware is not
induction-ready.
E2 The PIC is malfunctioning. Contact Customer Service.
E3 The PIC’s voltage is too low. Minimum = 85 volts
E4 The PIC’s voltage is too high. Maximum = 144 volts
E5 The PIC is malfunctioning. Contact Customer Service.
E6 The PIC is malfunctioning. Contact Customer Service.
E7
Overheating, or air ventilation is obstructed. If internal temperature
exceeds 230F (110C), operation will cease, and the PIC will beep.
Press Pause/Clear twice. Wait for the PIC to cool.
E8 Overheating, if PIC exceeds a temperature 20F (-7C) higher than
sear, the appliance will turn off. Contact Customer Service.
E9 The PIC is malfunctioning. Contact Customer Service.
FULL In programming mode, when the total entered time reaches the
appliance’s limit of 99:60, no additional stages can be inputted.
After Removing
Cookware:
Beep
Sound: Display: Reference:
Initial < 10
seconds
“F” or “C”
or Sear or :
flashing. Return cookware to PIC Gold. Cooking will
automatically resume.
< 10 seconds None
“F” or “C”
or Sear or :
flashing.
11- 70 seconds Yes E1
If an error is displayed, return cookware to
PIC Gold and press Start to automatically
resume cooking.
After 70 seconds None 0 Cooking stops. Choose desired
temperature setting and press “Start.”
• When any error messages are displayed, the PIC will beep at least once.
• The fan will run up to a maximum of 60 seconds after pressing Pause/Clear or when
cooking has stopped. Press Start within 45 minutes to resume cooking. After that, it
will turn off if no buttons are pressed, displaying “0” when the program clears.
