NX NX-602A User manual

60W 2.1 CHANNEL SOUNDBAR
& WIRED SUBWOOFER
WITH BLUETOOTH CONNECTIVITY
NX-602A | USER MANUAL

3
CONTENTS
WELCOME����������������������������������������������������������������������������������������� 5
GETTING STARTED �������������������������������������������������������������������������� 5
SAFETY AND NOTICE ���������������������������������������������������������������������� 5
WARNING................................................................................................ 5
SAFETY ................................................................................................... 5
CARE FOR YOUR PRODUCT .................................................................. 7
TECHNICAL SPECIFICATIONS�������������������������������������������������������� 8
WHAT’S IN THE BOX ������������������������������������������������������������������������ 8
DESCRIPTION OF PARTS ���������������������������������������������������������������� 8
OVERVIEW OF THE MAIN UNIT............................................................... 8
OVERVIEW OF REMOTE CONTROL...................................................... 10
REPLACING BATTERY ������������������������������������������������������������������� 12
GETTING STARTED ������������������������������������������������������������������������ 12
POWER ................................................................................................. 12
AUTO STAND-BY .................................................................................. 13
INPUT MODE SELECTION..................................................................... 13
CONNECTING TO AN EXTERNAL AUDIO DEVICES�������������������� 13
OPTICAL INPUT (REQUIRES AN OPTICAL CABLE, NOT PROVIDED) ... 13
LINE INPUT (REQUIRES A 3.5MM CABLE, PROVIDED)......................... 14
AUXILIARY INPUT (REQUIRES RCA CABLE, PROVIDED)...................... 14
USB/SD CARD INPUT (REQUIRES USB/SD CARD NOT PROVIDED).... 14
PAIRING WITH BLUETOOTH ................................................................. 15
A. PAIRING WITH A CELLPHONE’S BLUETOOTH................................. 15
B. PAIRING WITH STEREO TRANSMITTER’S BLUETOOTH .................. 15
TROUBLESHOOTING ��������������������������������������������������������������������� 17
WARRANTY TERMS & CONDITIONS�������������������������������������������� 18
NOTES ��������������������������������������������������������������������������������������������� 19

4

5
1�0 WELCOME
Thank You for a purchasing the NX-602A. Please take the
time to read the following safety warnings and operating
instructions carefully.
2�0 GETTING STARTED
• Remove the sound system from the box.
• Remove any packaging from the product.
• Place the packaging inside the box and either or dispose
of safely.
3�0 SAFETY AND NOTICE
Read and understand all instructions before you use
this product. If damage is caused by failure to follow the
instructions, the warranty does not apply.
WARNING
• Never remove the casing of the unit.
• Never lubricate any part of the unit.
• Never place the unit on other electrical equipment.
• Keep the unit away from direct sunlight, naked flames
or heat.
• Never look into the laser beam inside the unit.
• Ensure that you always have easy access to the power
cord, plug or adaptor to disconnect the unit from the
power.
SAFETY
1. Read these instructions.
2. Keep these instructions.
3. Read all warnings.
4. Follow all instructions.
5. Do not use the unit near water.
6. Clean only with a dry cloth.

6
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other products (including
amplifiers) that produce heat.
9. Protect the power cord from being walked on or
pinched, particularly at plugs, electrical outlets, and the
point where they exit from the unit.
10. Only use attachments and accessories specified by the
manufacturer.
11. Unplug the unit during lightning storms or when unused
for long periods of time.
12. Refer all servicing to qualified personnel. Servicing is
required when the unit has been damaged in any way,
such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the unit, the
unit has been exposed to rain or moisture, does not
operate normally, or has been dropped.
13. The unit should not be exposed to dripping or splashing.
14. Do not place any sources of danger on the unit (e.g.
liquid filled objects, lit candles).
15. Where the mains plug or an appliance coupler is used as
the disconnect device, the disconnected device should
remain readily operable.
16. Make sure there is enough free space around the
product for ventilation.
17. Batteries (battery pack or batteries installed) should not
be exposed to excessive heat such as sunshine, fire or
the like.
18. The unit must equipped with the appropriate batteries in
order to function properly.
19. Only recommended batteries should be used.

7
20. Polarity must be respected in such a way as to avoid any
short circuits.
21. Don’t mix used and new batteries.
22. Don’t mix alkaline, standard (carbon-zinc) and
rechargeable (nickel-cadmium) batteries.
23. Don’t recharge or try to open the batteries. Don’t throw
the batteries in fire.
24. Replace all batteries at the same time with new, identical
batteries.
25. Remove the batteries when unused for a long time.
CARE FOR YOUR PRODUCT
1. Always unplug the unit when not in use and before
cleaning.
2. Do not play music at excessive volume levels as damage
to hearing and or the equipment may occur.
3. Do not use this unit in wet or damp conditions.
4. Always disconnect the unit from the main power supply
before cleaning. Clean the appliance with a soft, lint free
cloth. Do not use abrasives or harsh cleaners.

8
4�0 TECHNICAL SPECIFICATIONS
5�0 WHAT’S IN THE BOX
Check and identify the contents of your package:
6�0 DESCRIPTION OF PARTS
OVERVIEW OF THE MAIN UNIT
• Power Supply: 230V - 50Hz • S/N (A): 75dB
• Total Consumption: 75W • THD (1kzHz, 1W): 0.5%
• Input Sensitivity: AUX IN
1000MV, LINE IN 775MV
• Frequency Response:
20Hz- 20KHz
• Speakers Impedance: 4ohm • Total Music Output: 60W
• Sound Bar and Subwoofer • Line-in cable
• Remote Control • Audio cable for subwoofer
• User Manual • AC adaptor
• RCA cable
9.
10.
11 .

9
1. SD Card Socket:
Insert SD card to play files stored on an SD Card
(SD card not provided).
Note: Supports maximum 32GB SD Card.
2. USB Socket:
Insert USB to play files stored on a USB drive
(USB not provided).
Note: Supports maximum 32GB USB drive.
3. Audio in:
To connect external audio device.
4. LED Indicator:
Shows the power and selected input.
5. Power:
Red color LED shows unit in Stand-by mode.
6. Mode:
Press Mode button to select Bluetooth /USB /
Audio In mode
7�
Skip to the previous track.
8� VOL-
Press and hold to decrease volume.
9.
Start or pause play.
10.
Skip to the next track.
11. VOL+
Press and hold to increase volume.

10
12. Optical in
Insert Optical Digital input.
13. AUX in
Connect an external audio device with RCA cable.
14. Subwoofer out:
To connect to Subwoofer
15. DC Power In
16. Wall Mount Bracket
OVERVIEW OF REMOTE CONTROL
8.
4.
VOL-
USB
VOL
1.
2.
3.
6.
7.
9.
10.
11.
12.
AUX
LINE
+
IN
BT OPT
SD
5.
13.
RL L
AUX SU B OU T
18V...2.5 A
OPT IN
12 13 14 15 16

11
1. POWER
Press to turn Unit in/out of Standby mode.
2. BT
Press to select Bluetooth input.
3. USB
Press to select USB input.
4. SD
Press to select SD Card input.
5. VOLUME+
Press to increase the volume.
6.
Press to skip to previous track.
7. VOLUME-
Press to Decrease volume.
8. OPT
Press to select Optical input.
9. MUTE
Press to Mute/Unmute
10. AUX
Press to select AUX Input
11. LINE IN
Press to select Line Input.
12.
Press to Pause/Play.
13.
Press to skip to next track.

12
7�0 REPLACING BATTERY
The remote control works with lithium button cell CR2025
3V batteries. When the remote no longer works you need to
replace the batteries as follows:
• Press the tab on the side of the battery cover to release
it and allow the battery support to come out.
• Replace the battery paying attention to the correct
orientation of the poles.
• Replace the battery support pushing it inside until you
hear a “click”.
ATTENTION: Danger of explosion if batteries are not inserted
correct.
8�0 GETTING STARTED
POWER
CAUTION:
• Risk of product damage! Make sure that the power
voltage corresponds to the voltage printed on the
back label.
• Risk of electric shock! When you unplug the AC
power cord always pull the plug from the socket.
Never pull the cord.
• Before connecting the AC power cord, ensure
you have completed all other connections.

13
Place the unit in the desired position and unravel the mains
cable. Insert the cable into the supply socket and switch on if
applicable.
AUTO STAND-BY
To save power, the Soundbar automatically switches to
stand-by if:
• No Audio is available from the connected input for more
than 10 minutes
• When the unit is power ON.
INPUT MODE SELECTION
The LED will turn red in Standby mode, press the remote
power button or the power button on the Soundbar to turn
OFF Stand-by mode. Th red LED will turn OFF indicating the
unit is no longer in Stand-by mode.
9�0 CONNECTING TO EXTERNAL AUDIO DEVICES
OPTICAL INPUT (REQUIRES AN OPTICAL
CABLE, NOT PROVIDED)
1. Connect an Optical cable to the optical input on the
back panel of the Soundbar. Connect the other end of
the Optical cable to the digital audio device.
2. Press the button to turn the unit on.
3. Press the MODE button repeatedly until the LED above
LIN/OPT turns green.

14
LINE INPUT (REQUIRES A 3�5MM CABLE,
PROVIDED)
1. Connect a 3.5mm cable to the line input on the control
panel of the Soundbar. Connect the other end of the
3.5mm cable to an MP3 player or other compatible
audio device.
2. Press the button to turn the unit on.
3. Press the MODE button repeatedly until the LED above
LIN/OPT turns yellow.
4. Use the controls on the connected device to begin
playing audio via the sound system.
AUXILIARY INPUT (REQUIRES RCA CABLE,
PROVIDED)
1. Connect an RCA cable to the AUX Input on the
back panel of the Soundbar. Connect the other end
of the RCA cable to the audio output on your DVD
player, gaming system, television or other compatible
equipment.
2. Press the power button to turn the unit on.
3. Press the MODE button repeatedly until the LED above
AUX turns green.
4. Use the controls on the connected device to begin
playing audio via the sound system.
USB/SD CARD INPUT (REQUIRES USB/SD CARD
NOT PROVIDED)
1. Plug your USB flash drive or SD card into the USB
socket or SD slot on the control panel of the Soundbar.
2. Press Mode button until the LED above USB/SD turns
green or yellow. Green shows USB input is selected and
yellow shows SD card input is selected.
Files should start playing automatically after input
selection. If not, press .
3. Press the / to select track.

15
4. Press the VOL+/VOL–to adjust the volume.
NOTE: Maximum 32GB USB or SD card storage is supported.
PAIRING WITH BLUETOOTH
A� PAIRING WITH A SMART PHONE’S
BLUETOOTH
Please ensure your smart phone’s Bluetooth is turned on.
Specific pairing steps may vary with different cell phones.
Please refer to the user manual of your cell phone for further
information. The general pairing steps are as follows:
1. Keep the sound bar and Bluetooth cell phone within 1
metre of each other when pairing.
2. Press button, and press the MODE button multiple
times until the sound system enters Bluetooth mode.
The LED above Bluetooth will turn Blue signaling the unit
is ready to be connected via bluetooth.
3. Switch ON your smart phone’s Bluetooth function
and search for Bluetooth devices. After the search is
completed, select “NX-602A” from the Bluetooth
device list.
4. Depending on the prompt received on your smart
phone, enter password or PIN: “0000” and press “Yes”
or “confirm”.
5. After successful pairing, select “NX-602A” from the
Bluetooth device list and press “connect”.
B� PAIRING WITH STEREO TRANSMITTER’S
BLUETOOTH
Different Bluetooth transmitters have different pairing
methods. Please refer to the user manual of your Bluetooth
transmitter for further information. The general pairing steps
are as follows:
1. Keep Soundbar and Bluetooth transmitter within 1 metre
of each other when pairing.

16
2. Press button, and press the MODE button multiple
times until the sound system enters Bluetooth mode.
The LED above Bluetooth will turn Blue signaling the unit
is ready to be connected via bluetooth.
3. Switch on your Bluetooth transmitter and let it enter
pairing mode.
4. Switch ON your transmitter’s Bluetooth function and
search for Bluetooth devices. After the search is
completed, select “NX-602A” from the Bluetooth device
list.
5. Depending on the prompt received on your transmitter,
enter password or PIN: “0000” and press “Yes” or
“confirm”.
6. After successful pairing, select “NX-602A” from the
Bluetooth device list and press “connect”.
NOTE: The sound bar will return to pairing mode
automatically after disconnecting from a Bluetooth device.

17
10�0 TROUBLESHOOTING
• In order to save energy when the unit has no input, the
unit will be switched to stand-by mode automatically. It
can be switched on by pressing the POWER button on
Soundbar or remote.
• If there is an incoming call while Soundbar is connected
to your cell phone for music playback, music will be
paused when the call is answered and resume after the
call is completed. (Depending on cell phones, music may
remain paused even after the call has ended).
Please do not discard electrical and electronic appliances in a
regular waste disposal.
• Take them to a collection point.
• Some components in the NX-602A may be hazardous to
health and the environment.

18
11�0 WARRANTY TERMS & CONDITIONS
Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
This warranty is provided in addition to your rights under the
Australian Consumer Law.
Directed Electronics Australia Pty Ltd (Directed Electronics)
warrants that this product is free from defects in material
and workmanship for a period of 12 months from the date
of purchase or for the period stated on the packaging. This
warranty is only valid where you have used the product
in accordance with any recommendations or instructions
provided by Directed Electronics.
This warranty excludes defects resulting from alterations of
the product, accident, misuse, abuse or neglect.
In order to claim the warranty, you must return the product
to the retailer from which it was purchased or if that retailer
is part of a National network, a store within that chain, along
with satisfactory proof of purchase. The retailer will then
return the goods to Directed Electronics. Directed Electronics
will repair, replace or refurbish the product at its discretion.
The retailer will contact you when the product is ready
for collection. All costs involved in claiming this warranty,
including the cost of the retailer sending the product to
Directed Electronics, will be borne by you.
Email: [email protected]

19
12�0 NOTES

20
