NXP Semiconductors FRDM-PF1510EVM User manual

KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
Rev. 1.0 — 18 June 2018 User guide
1 FRDM-PF1510EVM

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
2 / 29
2 Important notice
NXP provides the enclosed product(s) under the following conditions:
This evaluation kit is intended for use of ENGINEERING DEVELOPMENT OR
EVALUATION PURPOSES ONLY. It is provided as a sample IC pre-soldered to a
printed circuit board to make it easier to access inputs, outputs, and supply terminals.
This evaluation board may be used with any development system or other source of
I/O signals by simply connecting it to the host MCU or computer board via off‑the‑shelf
cables. This evaluation board is not a Reference Design and is not intended to represent
a final design recommendation for any particular application. Final device in an
application will be heavily dependent on proper printed circuit board layout and heat
sinking design as well as attention to supply filtering, transient suppression, and I/O
signal quality.
The goods provided may not be complete in terms of required design, marketing, and
or manufacturing related protective considerations, including product safety measures
typically found in the end product incorporating the goods. Due to the open construction
of the product, it is the user's responsibility to take any and all appropriate precautions
with regard to electrostatic discharge. In order to minimize risks associated with the
customers applications, adequate design and operating safeguards must be provided
by the customer to minimize inherent or procedural hazards. For any safety concerns,
contact NXP sales and technical support services.
Should this evaluation kit not meet the specifications indicated in the kit, it may be
returned within 30 days from the date of delivery and will be replaced by a new kit.
NXP reserves the right to make changes without further notice to any products herein.
NXP makes no warranty, representation or guarantee regarding the suitability of its
products for any particular purpose, nor does NXP assume any liability arising out of the
application or use of any product or circuit, and specifically disclaims any and all liability,
including without limitation consequential or incidental damages. “Typical” parameters
can and do vary in different applications and actual performance may vary over time.
All operating parameters, including “Typical”, must be validated for each customer
application by customer’s technical experts.
NXP does not convey any license under its patent rights nor the rights of others. NXP
products are not designed, intended, or authorized for use as components in systems
intended for surgical implant into the body, or other applications intended to support or
sustain life, or for any other application in which the failure of the NXP product could
create a situation where personal injury or death may occur.
Should the buyer purchase or use NXP products for any such unintended or
unauthorized application, the buyer shall indemnify and hold NXP and its officers,
employees, subsidiaries, affiliates, and distributors harmless against all claims, costs,
damages, and expenses, and reasonable attorney fees arising out of, directly or
indirectly, any claim of personal injury or death associated with such unintended or
unauthorized use, even if such claim alleges NXP was negligent regarding the design or
manufacture of the part.
NXP and the NXP logo are trademarks of NXP B.V. All other product or service names
are the property of their respective owners. © NXP B.V. 2018.

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
3 / 29
3 Overview of the PF1510 PMIC development environment
NXP offers a combination of boards that support the evaluation of the PF1510 power
management integrated circuit (PMIC).
The FRDM-PF1510EVM boards serve as an evaluation platform that allows users to test
and demo designs that incorporate the PF1510 PMIC. The evaluation board contains
a preconfigured MC32PF1510A4EP device and provides numerous jumpers and test
points that allow users to tailor the evaluation to their needs.
The kit comes with a FRDM-KL25Z already mounted and loaded with compatible
microcode. The primary function of the FRDM-KL25Z is to control communication
between the evaluation board and a PC.
4 Getting started
The NXP analog product development boards provide an easy-to-use platform for
evaluating NXP products. These development boards support a range of analog,
mixed‑signal, and power solutions. These boards incorporate monolithic integrated
circuits and system-in-package devices that use proven high-volume technology. NXP
products offer longer battery life, a smaller form factor, reduced component counts, lower
cost, and improved performance in powering state-of-the-art systems.
The tool summary page for FRDM-PF1510EVM is at http://www.nxp.com/FRDM-
PF1510EVM. The overview tab on this page provides an overview of the device, a list
of device features, a description of the kit contents, links to supported devices and a
Get Started section.
The Get Started section provides information applicable to using the
FRDM‑PF1510EVM.
1. Go to http://www.nxp.com/FRDM-PF1510EVM.
2. On the Overview tab, locate the Jump To navigation feature on the left side of the
window.
3. Select the Get Started link.
4. Review each entry in the Get Started section.
5. Download an entry by clicking the linked title.
After reviewing the Overview tab, visit the other related tabs for additional information:
• Documentation: Download current documentation.
• Software & Tools: Download current hardware and software tools.
• Buy/Parametrics: Purchase the product and view the product parametrics.
After downloading files, review each file, including the user guide, which includes setup
instructions. If applicable, the bill of materials (BOM) and supporting schematics are also
available for download in the Get Started section of the Overview tab.
4.1 Kit content/packing list
The FRDM-PF1510EVM content includes:
•Assembled and tested evaluation board in an anti-static bag
•Cable, USB type A male/type mini B male 3 ft
•Quick start guide

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
4 / 29
4.2 Required equipment
This kit requires the following items:
•5.0 V DC power supply or USB with enough current capability (3.0 A for maximum
performance)
•KITPF1510GUI installed on a Windows PC
•Optional voltmeters to measure regulator outputs
•Optional oscilloscope
4.3 System requirements
The kit requires the following to function properly with the software:
•USB-enabled computer running Windows XP, Vista 7, 8, or 10 (32 bit or 64 bit)
5 Getting to know the hardware
5.1 Board overview
The FRDM-PF1510EVM board is an easy-to-use circuit board, allowing the user to
exercise all the functions of the PF1510 PMIC.
The FRDM-KL25Z is mounted to the EVB as an integral component and serves as an
interface between the KITPF1510GUI and the PF1510 PMIC. The FRDM-KL25Z drives
circuitry on the FRDM-PF1510EVM and provides an analog-to-digital converter (ADC) to
monitor PF1510 regulator voltages which are displayed in the GUI.
5.2 Board features
The board features the following:
•PF1510 PMIC
•Integrated FRDM-KL25Z as a communication link between the EVB and a PC
5.3 Device features
The evaluation board features the following NXP product:
Table 1. Device features
Device Description Features
PF1510 power management integrated circuit
(PMIC) for i.MX 7ULP, i.MX 6SL, 6UL,
6ULL, and 6SX processors
•Three adjustable high efficiency buck regulators with 1.0 A per
regulator current capability
•Three adjustable general-purpose linear regulators
•Input voltage range on VIN: 4.1 V to 6.0 V
•Low dropout (LDO)/switch supply
•Double data rate (DDR) memory reference voltage
•One time programmable (OTP) memory for device configuration

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
5 / 29
5.3.1 Device description
The PF1510 device populated on board features the A4 OTP; see Table 2.
Table 2. Startup configuration
Register Pre-programmed OTP configuration –
A4 configuration
OTP_VSNVS_VOLT[2:0] 3.0 V
OTP_SW1_VOLT[5:0] 1.1 V
OTP_SW1_PWRUP_SEQ[2:0] 4
OTP_SW2_VOLT[5:0] 1.2 V
OTP_SW2_PWRUP_SEQ[2:0] 3
OTP_SW3_VOLT[5:0] 1.8 V
OTP_SW3_PWRUP_SEQ[2:0] 2
OTP_LDO1_VOLT[4:0] 3.3 V
OTP_LDO1_PWRUP_SEQ[2:0] 1
OTP_LDO2_VOLT[3:0] 3.3 V
OTP_LDO2_PWRUP_SEQ[2:0] 2
OTP_LDO3_VOLT[4:0] 1.8 V
OTP_LDO3_PWRUP_SEQ[2:0] 1
OTP_VREFDDR_PWRUP_SEQ[2:0] 3
OTP_SW1_DVS_ENB dynamic voltage scaling (DVS) mode
OTP_SW2_DVS_ENB DVS mode
OTP_LDO1_LS_EN LDO mode
OTP_LDO3_LS_EN LDO mode
OTP_SW1_RDIS_ENB enabled
OTP_SW2_RDIS_ENB enabled
OTP_SW3_RDIS_ENB enabled
OTP_SW1_DVSSPEED 12.5 mV step each 4.0 μs
OTP_SW2_DVSSPEED 12.5 mV step each 4.0 μs
OTP_SWx_EN_AND_STBY_EN SW1, SW2, SW3 enabled in RUN and STANDBY
OTP_LDOx_EN_AND_STBY_EN LDO1, LDO2, LDO3, VREFDDR enabled in RUN
and STANDBY
OTP_PWRON_CFG level sensitive
OTP_SEQ_CLK_SPEED 2 ms time slots
OTP_TGRESET[1:0] 4 s global reset timer
OTP_POR_DLY[2:0] 2 ms RESETBMCU power up delay
OTP_UVDET[1:0] rising 3.0 V; falling 2.9 V
OTP_I2C_DEGLITCH_EN I2C-bus deglitch filter disabled
OTP_VSYSMIN[1:0] VSYSMIN = 4.3 V

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
6 / 29
Register Pre-programmed OTP configuration –
A4 configuration
OTP_VIN_ILIM[4:0] VIN ILIM = 1500 mA
OTP_USBPHYLDO USBPHY LDO enabled
OTP_USBPHY USBPHY = 3.3 V
OTP_ACTDISPHY USBPHY active discharge enabled
5.4 Board description
Figure 1 describes the main elements on the FRDM-PF1510EVM.
Figure 1. Board description
Table 3. Board description
Number Name Description
1 1A ELOAD electronic load 1.0 A
2 ELOAD CSA current sense amplifier for the electronic load
3 PF1510 PF1510 PMIC
4 analog MUX analog multiplexers
5 VSYS CSA current sense amplifier for VSYS
6 VIN CSA current sense amplifier for VIN
7 VIN USB input USB 5.0 V power supply for the VIN
8 ONKEY and PWRON
buttons
buttons connected to the ONKEY and PWRON signals

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
7 / 29
5.4.1 LED description
The following LED is provided as visual output device for the board:
Figure 2. LED location
Table 4. LED description
LED ID Description
D1 red LED, VSYS on state indicator

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
8 / 29
5.4.2 Jumper and switch definitions
Figure 3 shows the location of jumpers and switches on the evaluation board.
Figure 3. Jumper and switch locations
Table 5 describes the function and settings for each jumper and switch.
Table 5. Jumper and switch definitions
Jumper/switch Description Setting Connection/result
S1 ONKEY open connects ONKEY pin to GND when
pressed; if configured properly, it causes
wake-up event
S2 PWRON open connects PWRON pin to GND when
pressed; resets the PMIC device
J3 5.0 V USB - power supply for the board (J12 shall be
opened)
[1-2] pullup to VSNVSJ4 pullup configuration
[2-3] pullup to VDDIO which is supplied by
P3V3 coming from the FRDM-KL25Z
board
open 5.0 V from the J3 (USB) is usedJ12 5 V power supply
[1-2] 5.0 V is used from the FRDM-KL25Z
board (current is limited)
open pull STANDBY pin highJ13 STANDBY pin
configuration connected pull STANDBY pin low to GND

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
9 / 29
5.4.3 Test point definitions
The following test points provide access to various signals to and from the board.
Figure 4. Test point locations
Table 6. Test point definitions
Test point name Signal name Description
TP1 VIN_PORT 5.0 V power supply (from USB connector J3)
TP2 SW1OUT SW1 output
TP3 GND ground (next to SW1OUT)
TP4 SW3OUT SW3 output
TP5 SW2OUT SW2 output
TP6 GND ground (next to SW3OUT)
TP7 GND ground (next to SW2OUT)
TP19 VSNVS VSNVS regulator output
TP20 SW1IN SW1 input
TP24 VLDO1 VLDO1 regulator output
TP25 SW3IN SW3 input
TP29 VLDO2 VLDO2 regulator output
TP30 SW2IN SW2 input
TP33 VLDO3 VLDO3 regulator output
TP34 VLDO1IN VLDO1 regulator input
TP35 STANDBY STANDBY input
TP36 VREFDDR VREFDDR regulator output
TP37 VLDO2IN VLDO2 regulator input
TP38 PWRON PWRON input
TP39 USBPHY USBPHY regulator output

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
10 / 29
Test point name Signal name Description
TP40 VLDO3IN VLDO3 regulator input
TP41 WDI watchdog input from microcontroller unit (MCU)
TP42 LICELL coin cell input
TP44 GND ground
TP45 ONKEY ONKEY push-button input
TP46 SDA1 data signal of the I2C-bus
TP47 VINREFDDR VREFDDR regulator input
TP49 INTB interrupt to the MCU
TP50 SCL1 clock signal of the I2C-bus
TP51 GND ground
TP52 VSYS_SH VSYS of PMIC
TP53 RESETBMCU MCU reset signal
TP54 VDDIO I/O supply voltage of the PMIC
TP59 ELOAD electronic load input (connect the tested power
supply)
TP63 GND ground (next to the electronic load)
TP66 USBPHY USBPHY regulator output
6 FRDM-KL25Z Freedom development platform
The NXP Freedom development platform is a set of software and hardware tools for
evaluation and development. It is ideal for rapid prototyping of microcontroller-based
applications. The NXP Freedom KL25Z hardware, FRDM-KL25Z, is a simple, yet
sophisticated design featuring a Kinetis L series microcontroller, the first microcontroller
of the industry built on the Arm Cortex-M0+ core.
6.1 Connecting the FRDM-KL25Z to the board
The FRDM-KL25Z evaluation board was chosen specifically to work with the
FRDM‑PF1510EVM kit because of its low cost and features. The FRDM-KL25Z board
uses the USB, built-in LEDs, and I/O ports available with NXPs Kinetis KL2x family of
microcontrollers.
The FRDM-PF1510EVM connects to the FRDM-KL25Z using the four dual row Arduino
R3 connectors on the bottom of the board.

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
11 / 29
Figure 5. Connecting the FRDM-KL25Z to the FRDM-PF1510EVM
Table 7. FRDM-PF1510EVM to FRDM-KL25Z connections
FRDM-PF1510EVM FRDM-KL25Z Pin hardware name
Header Pin Header Pin FRDM-PF1510EVM FRDM-KL25Z
Description
J1 1 J1 1 n.c. PTC7 not connected
J1 2 J1 2 INTB PTA1 interrupt to the MCU
J1 3 J1 3 n.c. PTC0 not connected
J1 4 J1 4 WDI PTA2 watchdog input from MCU
J1 5 J1 5 n.c. PTC3 not connected
J1 6 J1 6 nLDAC PTD4 DAC configuration signal
J1 7 J1 7 n.c. PTC4 not connected
J1 8 J1 8 RDY/BSY PTA12 DAC control signal
J1 9 J1 9 n.c. PTC5 not connected
J1 10 J1 10 MUX_RESETB PTA4 multiplexer reset
J1 11 J1 11 n.c. PTC6 not connected
J1 12 J1 12 VDDIO PTA5 VDDIO power supply
J1 13 J1 13 n.c. PTC10 not connected
J1 14 J1 14 SCL2 PTC8 clock signal of the I2C-bus (for
additional ICs)
J1 15 J1 15 n.c. PTC11 not connected
J1 16 J1 16 SDA2 PTC9 data signal of the I2C-bus (for
additional ICs)
J2 1 J2 1 n.c. PTC12 not connected
J2 2 J2 2 PWRON PTA13 PWRON input

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
12 / 29
FRDM-PF1510EVM FRDM-KL25Z Pin hardware name
Header Pin Header Pin FRDM-PF1510EVM FRDM-KL25Z
Description
J2 3 J2 3 n.c. PTC13 not connected
J2 4 J2 4 STANDBY PTD5 STANDBY input
J2 5 J2 5 n.c. PTC16 not connected
J2 6 J2 6 RESETBMCU PTD0 MCU reset signal
J2 7 J2 7 n.c. PTC17 not connected
J2 8 J2 8 VSYS_CSA_ALERT PTD2 alert signal from the VSYS
current shunt
J2 9 J2 9 ELOAD_CSA_ALERT PTA16 alert signal from the ELOAD
current shunt
J2 10 J2 10 n.c. PTD3 not connected
J2 11 J2 11 n.c. PTA17 not connected
J2 12 J2 12 VBUS_CSA_ALERT PTD1 alert signal from the VBUS
current shunt
J2 13 J2 13 n.c. PTE31 not connected
J2 14 J2 14 GND GND ground
J2 15 J2 15 n.c. n.c. not connected
J2 16 J2 16 n.c. VREFH not connected
J2 17 J2 17 n.c. PTD6 not connected
J2 18 J2 18 SDA1 PTE0 data signal of the I2C-bus
(PF1510)
J2 19 J2 19 n.c. PTD7 open
J2 20 J2 20 SCL1 PTE1 clock signal of the I2C-bus
(PF1510)
J10 1 J10 1 n.c. PTE20 not connected
J10 2 J10 2 n.c. PTB0 not connected
J10 3 J10 3 n.c. PTE21 not connected
J10 4 J10 4 n.c. PTB1 not connected
J10 5 J10 5 n.c. PTE22 not connected
J10 6 J10 6 2V5_ADC PTB2 voltage reference for ADC
J10 7 J10 7 n.c. PTE23 not connected
J10 8 J10 8 ADC_1 PTB3 analog signal to ADC1
J10 9 J10 9 n.c. PTE29 not connected
J10 10 J10 10 ADC_0 PTC2 analog signal to ADC0
J10 11 J10 11 n.c. PTE30 not connected
J10 12 J10 12 n.c. PTC1 not connected
J9 1 J9 1 n.c. PTB8 not connected
J9 2 J9 2 P3V3 SDA_PTD5 3.3 V coming from the
Freedom board

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
13 / 29
FRDM-PF1510EVM FRDM-KL25Z Pin hardware name
Header Pin Header Pin FRDM-PF1510EVM FRDM-KL25Z
Description
J9 3 J9 3 n.c. PTB9 not connected
J9 4 J9 4 P3V3 3V3 3.3 V coming from the
Freedom board
J9 5 J9 5 n.c. PTB10 not connected
J9 6 J9 6 P3V3 RESET/PTA20 3.3 V coming from the
Freedom board
J9 7 J9 7 n.c. PTB11 not connected
J9 8 J9 8 P3V3 3V3 3.3 V coming from the
Freedom board
J9 9 J9 9 n.c. PTE2 not connected
J9 10 J9 10 P5V_USB 5V 5 V coming from the Freedom
board
J9 11 J9 11 n.c. PTE3 not connected
J9 12 J9 12 GND GND ground
J9 13 J9 13 n.c. PTE4 not connected
J9 14 J9 14 GND GND ground
J9 15 J9 15 n.c. PTE5 not connected
J9 16 J9 16 n.c. P5-9V_VIN not connected
7 Installing the software and setting up the hardware
7.1 Set up PF1510GUI on your computer
1. Download PF1510GUI.zip from http://www.nxp.com/FRDM-PF1550EVM. Choose the
32-bit or 64-bit version regarding the system installed on your PC.
2. Extract all the files to any desired folder on your PC.
3. Plug the evaluation board.
4. Launch the GUI (no installation is necessary, GUI can be directly launched by clicking
the file PF1510_x_Bx.jar).

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
14 / 29
7.2 Configuring the hardware and using the GUI for control and
monitoring
Figure 6. Hardware configuration
1. Apply input voltage to the board.
•First solution is to use power directly from the FRDM-KL25Z by connecting J12
jumper. Advantage of this configuration is that only one USB port (USB for GUI
communication) is needed. This solution may have limited performance because of
the current capability of the USB port.
•Second possibility is to use 5.0 V either from USB input (J3) or from DC power
supply. In these cases, keep J12 open. The DC power supply connection is
recommended for higher currents.
2. Connect the mini-USB cable from a PC to the KL25Z USB port on the FRDM-KL25Z
board.
3. Windows automatically installs the necessary drivers. Wait for this operation to
complete.
4. Launch the PF1510 GUI.
5. In the PF1510 GUI window, click the Scan For Devices button in the top-left corner.
A confirmation message that a valid device is available is logged.

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
15 / 29
6. Enable the communication by clicking the Target Enabled: checkbox. The window
turns from gray to color.
7. The GUI installation and hardware setup now are complete.

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
16 / 29
7.3 Understanding and using the GUI
7.3.1 GUI structure for PF1510
Figure 7 shows the different components of the GUI.
Figure 7. GUI components
7.3.2 GUI panels
When the GUI is launched, it looks for a PF1510 target board connected via the USB
cable. If connected, the USB connection panel displays the vendor ID: 0x15A2, and part
ID: 0x00D0.
The main log window displays messages, example, when the board is connected
(PF1510 attached) and when the board was removed (PF1510 removed).

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
17 / 29
Figure 8. GUI startup
Pressing the Scan For Devices button attempts to read from each of the eight
permissible I2C-bus device addresses. The results are displayed in the main log window.
If multiple PMIC devices are detected, the GUI can be configured to communicate with a
particular device by selecting the corresponding device address.
Note: The GUI can communicate with only one PMIC device at a time.
Figure 9. GUI connected to the target board

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
18 / 29
7.3.3 Switching supplies panel
The switching supplies panel allows users to adjust the functional parameters of each
supply.
Figure 10. Switching supplies panel
To change supply parameters, click and adjust the desired control. An Update button
appears whenever a change is made, and pressing the Update button writes the change
to the PMIC.
Note: Multiple changes can be made at a time, and all changes are written when the
Update button is pressed.

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
19 / 29
7.3.4 Linear supplies panel
The linear supplies panel allows users to adjust the functional parameters of each linear
regulator. To change supply parameters, click and adjust the desired control.
Figure 11. Linear supplies panel
An Update button appears whenever a change is made, and pressing the Update button
writes the change to the PMIC.
Note: Multiple changes can be made at a time, and all changes are written when the
Update button is pressed.

NXP Semiconductors KTFRDMPF1510EVMUG
FRDM-PF1510EVM evaluation board
KTFRDMPF1510EVMUG All information provided in this document is subject to legal disclaimers. © NXP B.V. 2018. All rights reserved.
User guide Rev. 1.0 — 18 June 2018
20 / 29
7.3.5 OTP configuration panel
The OTP configuration panel allows access and editing of the PF1510 startup
parameters.
Figure 12. OTP configuration panel
Initially, the panel display is the OTP configuration read from PMIC PF1510.
The Load CFG File button opens the configuration file open dialog, and populates the
panel with the parameters contained in this file.
The Load From PMIC button loads the OTP configuration data from the PMIC PF1510 of
the evaluation board.
