NZXT INTERNAL USB HUB User manual

ENGLISH
INTERNAL USB HUB
4X INTERNAL USB PORT EXPANSION

VERSION 1.0
TABLE OF CONTENTS
1. COMPONENT LIST ............................ 02
3. INSTALLATION................................... 04
2. HARDWARE INTRODUCTION .......... 03
4. TROUBLESHOOTING ........................ 08
5. APPENDIX ........................................ A-1

02
INTERNAL USB HUB
1. COMPONENT LIST
A. Internal USB Hub
x1
B. SATA Power Cable
x1
C. USB Connection Cable
x1
D. Velcro Cable Tie
x1
E. 3M Dual Lock Tape
x2

03
INTERNAL USB HUB
2. HARDWARE INTRODUCTION
A. Internal USB Connectors
Plug in devices with internal USB connectors here
B. Magnets (bottom)
Allow you to mount the Internal USB Hub onto steel surfaces
C. Internal USB Connector (MB)
Plug in the included USB connector cable to the motherboard
D. LED Indication
Power on/off indicator
E. SATA Power Connector
Plug in the SATA power cable here

04
INTERNAL USB HUB
3.1 INSTALLATION
Place the Internal USB Hub onto any steel surface within your
case using the embedded magnets.
A

05
INTERNAL USB HUB
3.2 INSTALLATION
Ensure your PC is powered off and connect the Internal USB
Hub to the power supply using the SATA power cable.
B

06
INTERNAL USB HUB
3.3 INSTALLATION
Connect the USB connection cable to the motherboard
connector on the hub (first one below the LED indicator) and
connect the other end to the motherboard’s USB 2.0 header.
Make sure the USB connector is securely connected.
C

07
INTERNAL USB HUB
3.4 INSTALLATION
Connect USB devices to the other internal connectors.

08
INTERNAL USB HUB
4. TROUBLESHOOTING
1. Problem:The light indication of my Internal USB Hub is not
lighting up.
a. Make sure the USB Connector Cable is securely connected to the Internal
USB Hub and the internal USB 2.0 connector on the motherboard.
b. Make sure the SATA power cable is securely connected to the Internal USB
Hub and the power supply.
c. Please apply RMA with the retailer or distributor from whom you purchased
the Internal USB Hub if step (a) and (b) fails to fix the issue.
2. Problem: How do I know my Internal USB Hub is detected and
ready to work?
a. The internal USB Hub is a USB device which will be visible within NZXT
CAM as “Internal USB Hub Device”.
b. The Internal USB Hub is a USB device which will also be visible within
Windows Device Manager as “NZXT Internal USB Hub”. as “NZXT Internal
USB Hub”.
c. If you can’t find it within NZXT CAM or Windows Device Manager, please
reconnect the USB Connector Cable while the PC is powered off. Press
“scan for hardware changes” in Device Manager and you should be able to
see it inside the Device Manager under “Universal Serial Bus controllers”.

A-1
INTERNAL USB HUB
5. APPENDIX
5.1 NZXT Global Warranty Policy.................................... A-2
5.2 Support and Service....................................................A-8
5.3 Regulatory Notices.....................................................A-11

A-2
INTERNAL USB HUB
5.1 NZXT GLOBAL WARRANTY POLICY
This NZXT Global Warranty Policy governs the sale of products by NZXT to you.
I. WARRANTY LENGTH
Any replacement product will be covered under warranty for the remainder
of the warranty period or thirty days, whichever is longer. Proof of
purchase is required for warranty service.
II. WHO IS PROTECTED
The Warranty covers only NZXT products purchased by the
original consumer.
NEW NZXT PRODUCT WARRANTY LENGTH FOR PARTS
Computer Cases 2 Years
Temperature Meters 2 Years
Fans 2 Years
Lighting 2 Years
Accessories 2 Years
Kraken M Coolers 3 Years
Headset/Headphone 2 Years
Headset/Headphone Storage 2 Years
Mixer 2 Years
Motherboards 3 Years
Power Supply 10 Years
Kraken X/Z Coolers 6 Years
Mini ITX Case with PSU, AIO, and Riser Card 3-year warranty on case, riser card, and AIO. 10-year warranty on PSU.
REFURBISHED NZXT PRODUCT WARRANTY LENGTH FOR PARTS
All NZXT Certified Refurbished Products 1 Years

A-3
INTERNAL USB HUB
5.1 NZXT GLOBAL WARRANTY POLICY
III. WHAT IS AND IS NOT COVERED
Please note that our warranty is not an unconditional guarantee. If the
product, in NZXT’s reasonable opinion, malfunctions within the warranty
period, NZXT will provide you at its sole discretion with a repaired or
replacement product, either new or refurbished, with a similar function
that is equal or greater in value depending on supply.
Our warranty does not cover the following:
a. any product or serial number/warranty sticker modification applied
without permission from NZXT;
b. any damage that is not a manufacturing defect;
c. damage, deterioration or malfunction resulting from: accident,
abuse, misuse, neglect, fire, water, lightning, or other acts of nature,
unauthorized product modification or failure to follow instructions
included with the product;
d. improper installation, unauthorized alterations or modifications, or repair
or attempted repair by anyone not authorized by NZXT;
e. shipping or transport damage (claims must be made with the carrier);
f. normal wear and tear.
NZXT does not warrant that this product will meet your requirements. It
is your responsibility to determine the suitability of this product for your
purpose. For NZXT Store orders, we cover two way return shipping for all
exchanges and returns. For all other authorized dealers, NZXT Support
does not cover return shipping and only covers one way shipping from
NZXT back to the end user for exchanges. Two way expedited shipping
is provided for all PSUs covered under the Less Than Three program,
indiscriminate of purchase location, provided the location is an approved
NZXT reseller.
IV. EXCLUSION OF DAMAGES (DISCLAIMER)
NZXT's sole obligation and liability under this warranty is limited to
the repair or replacement of a defective product with either a new or
refurbished product with a similar function that is equal or greater in value
at our option. NZXT shall not, in any event, be liable for any incidental or
consequential damage, including but not limited to damages resulting
from interruption of service and loss of data, business, or for liability in
tort relating to this product or resulting from its use or possession.

A-4
INTERNAL USB HUB
5.1 NZXT GLOBAL WARRANTY POLICY
V. LIMITATIONS OF IMPLIED WARRANTIEST
Here are no other warranties, expressed or implied, including but not
limited to those of merchantability or fitness for a particular purpose. The
duration of implied warranties is limited to the warranty length specified
in Paragraph I.
VI. TO OBTAIN TECHNICAL SUPPORT
If you have already referenced your product owner's manual and still
need help, you may contact us by phone at [phone], by email at
[e-mail], or visit the NZXT Support site at
nzxt.com/customer-support.
VII. HOW TO OBTAIN A WARRANTY SERVICE FROM NZXT
To receive a warranty service for your product when purchased directly
from NZXT, you must submit a request via the NZXT Support site outlining
the problem. If a technician deems the product defective or requiring
testing, you will be required to provide a copy of your proof of purchase,
which will enable you to submit a Return Merchandise Authorization
"RMA" request.
Once approved, you`ll receive an RMA number, upon which you will be
asked to ship the defective item back to NZXT with the RMA number
clearly marked or labelled on the package. NZXT recommends that
appropriate measures are taken to safeguard the product from damage
during shipping.

A-5
INTERNAL USB HUB
5.1 NZXT GLOBAL WARRANTY POLICY
VIII. APPLICABLE LAW AND ADDITIONAL LEGAL RIGHTS FOR CONSUMERS
This warranty gives you specific legal rights. These conditions are
governed and construed in accordance with the laws of California (with
exception of its conflict of law provisions), and the application of the
United Nations Convention of Contracts for the International Sale of
Goods is expressly excluded. The non-exclusive jurisdiction of the courts
of California is agreed, which means that you may bring a claim to enforce
your consumer protection rights in connection with this Global Warranty
in the country which you have your habitual residence where you may have
additional rights. These rights may vary.
For original consumers who are covered by consumer protection laws or
regulations in their country, state, or province of purchase or, if different,
their country, state, or province of residence, the benefits conferred by
this warranty are in addition to all rights and remedies conveyed by such
consumer protection laws and regulations. To the extent that liability
under such consumer laws can be limited, NZXT’s liability is limited, and
its sole option, to repair or replacement, either new or refurbished, with a
similar function that is equal or greater in value depending on supply.
In the United Kingdom:
a. For NZXT products sold to customers in the UK, during the expected
lifespan of your product your legal rights entitle you to the following:
> Up to 30 days: if your goods are faulty, then you can get an immediate refund.
> Up to six months: if your goods can't be repaired or replaced, then you're entitled
to a full refund, in most cases.
> Up to six years: if your goods do not last a reasonable length of time you may be
entitled to some money back.
b. If the person seeking to rely on the guarantee is not the original
consumer, the NZXT Warranty will cover the product in relation to that
person provided that they are able to provide proof of the transfer of the
benefit of the guarantee from the original consumer.
c. The implied warranties under the Consumer Rights Act 2015 says that
your goods must be as described, fit for all purposes for which such
goods are usually supplied, and of satisfactory quality.
In the EU:
d. If you are a consumer and have your habitual residence in the EU, you
additionally enjoy the protection afforded to you by provisions that cannot
be derogated from by agreement by virtue of the law where you have your
habitual residence.

A-6
INTERNAL USB HUB
5.1 NZXT GLOBAL WARRANTY POLICY
IX. WARRANTY SERVICE FROM RESELLERS
In the event that a warranty service is sought, you must provide proof of
purchase (store receipt or invoice) in order to receive the service and if
deemed necessary, repair or replacement product.
In North America:
Within the first 60 days after purchase, please return your product (or
for power supplies installed within our enclosures, just the failed power
supply) to your dealer or reseller for a replacement. If the product is
still within warranty and you can no longer return it to your dealer,
please contact NZXT Customer Support (see above) for assistance and
instructions. NZXT will not accept returns without prior approval and an
RMA number.
In Europe:
Within the first year after purchase, please return your product (or for
power supplies installed within our enclosures, just the failed power
supply) to your dealer or reseller for a replacement. If the product is
still within warranty and you can no longer return it to your dealer,
please contact NZXT Customer Support (see above) for assistance and
instructions. NZXT will not accept returns without prior approval.
In Australasia:
Within the first two years after purchase, please return your product
(or for power supplies installed within our enclosures, just the failed
power supply) to your dealer or reseller for a replacement. If the product
is still within warranty and you can no longer return it to your dealer,
please contact NZXT Customer Support (see above) for assistance and
instructions. NZXT will not accept returns without prior approval.
The cost of shipping will be borne at the first instance by you; however, if
the purchased item is defective, NZXT will reimburse reasonable postage
or transportation of costs.
Outside North America, Europe, and Australasia:
If your product needs to be returned within the warranty period, please
contact the retailer or distributor from whom you purchased the product.

A-7
INTERNAL USB HUB
5.1 NZXT GLOBAL WARRANTY POLICY
X. NZXT.COM STORE RETURNS/EXCHANGE POLICY
Eligible products under this NZXT Warranty qualify for a full refund or
exchange only with an authorized RMA number and if the item is returned
to the NZXT.com store inventory within 30 days of purchase. Returns are
not allowed beyond 30 days of the purchase date. The NZXT.com Store
reserves the right to deny any return or exchange. Refunds will be credited
to the original method of payment. To initiate a return, simply submit a
request via NZXT support site.
> Visit nzxt.com/warranty and support.nzxt.com for information on warranty
coverage and service.
>Visite el sitio Web nzxt.com/warranty y support.nzxt.com para obtener
información sobre la cobertura y el servicio de la garantía.
>Visitez nzxt.com/warranty et support.nzxt.com pour les informations de la
couverture de la garantie et du service.
>Informationen zu Geltungsbereich und Service der Garantie finden Sie unter
support.nzxt.com und nzxt.com/warranty.
>Visitare il sito nzxt.com/warranty e support.nzxt.com per informazioni sulla
copertura e sul servizio della garanzia.
>Visite nzxt.com/warranty e support.nzxt.com para obter informações sobre a
cobertura da garantia e assistência.
> Подробную информацию об условиях гарантийного обслуживания см. на
веб-сайте nzxt.com/warranty иsupport.nzxt.com.
>제품 보증 범위와 서비스 정보를 확인하시려면 nzxt.com/warranty 또는 support.nzxt.
com 을방문해 주시기 바랍니다.
>保証範囲およびサービスに関する情報については、support.nzxt.com とnzxt.com/
warranty にアクセスしてください。
>请造访 nzxt.com/warranty 和support.nzxt.com 了解保修范围和服务的信息。
>請訪問 nzxt.com/warranty 和support.nzxt.com 了解產品保固範圍和更多服務訊息。
NZXT, Inc./ 15736 E Valley Blvd, City of Industry, CA 91744, USA
NZXT Europe GmbH/ Industriering Ost 66 | 47906 Kempen | Germany
[phone] / [e-mail] / NZXT.com

A-8
INTERNAL USB HUB
5.2 SUPPORT AND SERVICE
SUPPORT AND SERVICE
If you have any questions or problems with the NZXT product you
purchased, please don’t hesitate to contact us using our support system.
support.nzxt.com
Please include a detailed explanation of your problem and your proof of
purchase. For comments and suggestions, you can e-mail our design team,
[e-mail]. Lastly we would like to thank you for your support by
purchasing this product.
For more information about NZXT, please visit us online. NZXT Website:
NZXT.com
SOPORTE Y SERVICIO
Si tiene preguntas o problemas con el producto NZXT que usted compró,
no dure en ponerse en contacto con [e-mail] y suministrar una
explicación detallada de su problema así como su prueba de compra.
Puede hacer consultas sobre piezas de repuesto en support.nzxt.com.
Para comentarios y sugerencias, escriba un mensaje de correo electrónico
a nuestro equipo de diseño: [e-mail]. Gracias por comprar un
producto NZXT. Para más información acerca de NZXT, visítenos en línea.
Página web de NZXT: NZXT.com
SUPPORT ET SERVICE
Si vous avez des questions ou des problèmes avec le produit NZXT
que vous avez acheté, n’hésitez pas à contacter [email protected]
avec une description détaillée de votre problème et votre preuve
d’achat. Vous pouvez aussi commander des pièces de remplacement
auprès support.nzxt.com. Pour les commentaires et les suggestions,
envoyez un email à notre équipe de design, [e-mail].
Merci d'avoir acheté ce produit de NZXT. Pour plus d'informations sur
NZXT, visitez notre site Web. Site Web de NZXT : NZXT.com
KUNDENDIENST UND SERVICE
Falls Fragen oder Probleme bezüglich Ihres NZXT-Produktes
auftreten, wenden Sie sich bitte mit einer detaillierten
Problembeschreibung und Ihrem Kaufbeleg an [email protected].
Ersatzteile können Sie unter support.nzxt.com anfragen.
Kommentare und Anregungen senden Sie bitte per designer@nzxt.
com an unser Designteam. Vielen Dank, dass Sie ein NZXT-Produkt
erworben haben. Weitere Informationen über NZXT erhalten Sie im
Internet. NZXT-Webseite: NZXT.com

A-9
INTERNAL USB HUB
5.2 SUPPORT AND SERVICE
ASSISTENZA E SERVIZIO
In caso di dubbi o problemi con il prodotto NZXT acquistato, non esitate a
contattarci utilizzando il nostro sistema di assistenza. support.nzxt.com
Includere una spiegazione dettagliata del problema e la prova di acquisto.
Per commenti e suggerimenti, siete pregati di inviare un messaggio
al nostro team di progettisti, all'indirizzo: [email protected]. Infine,
vogliamo ringraziarvi del vostro supporto con l'acquisto di questo prodotto.
Per altre informazioni su NZXT, visitate il nostro sito. Sito NZXT: NZXT.com
ASSISTÊNCIA E MANUTENÇÃO
Caso tenha questões ou problemas com o produto NZXT adquirido,
não hesite em contactar-nos através do endereço [e-mail]
fornecendo a explicação detalhada do seu problema e a prova de compra.
Poderá solicitar peças de substituição através do endereço support.nzxt.
com. Para comentários e sugestões, contacte a nossa equipa de design
através do endereço de e-mail, [e-mail]. Obrigado por ter
adquirido um produto NZXT. Para mais informações acerca da NZXT, visite-
nos online. Web site da NZXT: NZXT.com
СЛУЖБА ПОДДЕРЖКИ И ОБСЛУЖИВАНИЯ
Вслучае возникновения вопросов или неисправностей вприобретенных
вами продуктах NZXT обращайтесь по адресу: [e-mail]
сподробным описанием проблемы иподтверждением покупки. О
наличии запчастей можно узнать, обратившись по адресу: support.
nzxt.com. Замечания ипредложения отправляйте вадрес нашей группы
разработчиков: [email protected]. Благодарим вас за покупку продукта
NZXT. Более подробная информация окомпании NZXT представлена на
наших веб-сайтах. Веб-сайт NZXT: NZXT.com

A-10
INTERNAL USB HUB
5.2 SUPPORT AND SERVICE
지원 및서비스
구입한 NZXT 제품과 관련하여 질문 또는 문제가 있을 경우, 당사의 지원 시스템
(support.nzxt.com)을사용하여 문의하십시오.
문제를 자세히 기술하고 구매 증빙을 제출하십시오. 의견 또는 제안 사항이 잇을
경우 당사 설계 팀에 [e-mail]으로 이메일을 보내십시오. 마지막으로
이제품을 구입하여 당사를 응원해 주셔서 감사합니다. NZXT에대해 자세히 알려면
온라인으로 방문하십시오. NZXT 웹사이트: NZXT.com
サポートおよびサービス
購入されましたNZXTの製品に関するご質問または問題は、問題の詳細および購入の証
明を添えて、ご遠慮なく
[e-mail]までご連絡ください。交換部品はsupport.
nzxt.comまでお尋ねください。ご意見およびご提案は弊社設計チーム、designer@
nzxt.com までメールを送信してください。NZXT製品をご購入いただきましてありが
とうございます。
NZXTに関する詳細は、インターネット上のウェブサイトをご覧くださ
い。
NZXT ウェブ サ イト: NZXT.com
支持和服务
如果有任何疑问或者在使用 NZXT 产品的过程中遇到任何问题,欢迎联络
[e-mail],联络时请提供关于问题的详细说明及购买凭证。您可以向
support.nzxt.com 查询更换部件。如有任何意见或建议,欢迎致信我们的设计团
队,电子邮件地址是 [e-mail]。感谢您购买 NZXT 产品。有关 NZXT
的更多信息,请造访我们的在线网站。NZXT 网站：NZXT.com
支援和服務
如果在使用NZXT 產品的過程中有遇到任何問題或疑問，歡迎聯繫 service@
nzxt.com，並請提供問題的詳細敘述及購買證明。您可以透過 support.
nzxt.com 查詢更換部件。如有任何意見或建議，歡迎來信與設計團隊聯繫
[e-mail]。最後，感謝您購買 NZXT 產品。有關 NZXT 的更多信息，
請訪問我們的網站。NZXT 網站：NZXT.com

A-11
INTERNAL USB HUB
5.3 REGULATORY NOTICES
Federal Communications Commission (FCC) Notice
This device complies with Part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the
limits for a class A digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment uses, generates, and can radiate radio
frequency energy and if not installed in accordance with the operator’s
manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause
interference in which case the user will be required to correct the
interference at his own expense.
WARNING: Changes or modifications made to this device which are not
expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003
du Canada.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation. CAN ICES-3 (B) / NMB-3 (B)
이기기는 가정용 (B급) 전자파적합기기로서 주로가정에서 서용하는 것을
목적으로 하며, 모듣지역에서 사용할 수있습니다.
この裝置は、クラスB情報技術裝置です。この裝置は、家庭環境で使用することを目的と
していますが、この裝置がラジオやテレビジョン受信機に近接して使用されると、受信
障害を引き起こすことがあリます。
取扱説明書に従って正しぃ取リ扱いをして下さい。 VCCI-B
